First principles study of the Fermi surface topology of CeCu2Si2

Roxanne M. Tutchton*

Jean-Pierre Julien

Qimiao Si

Jian-Xin Zhu

  • Department of Physics and Astronomy, Rice University, Houston, Texas 77005, USA

  • *Contact author: rtutchton@lanl.gov
PDF

Phys. Rev. Research 7, 043341 – Published 29 December, 2025

DOI: https://doi.org/10.1103/fh8z-r7rx

Abstract

Since the discovery of heavy-fermion superconductivity in CeCu2Si2, the material has attracted great interest, particularly with regard to the nature of the superconducting pairing and its mechanism. Consequently, it is essential to better understand the electronic Fermi surface topology and its role in strong antiferromagnetic fluctuations. The standard density functional theory method is insufficient to model the interplay of strong on-site Coulomb repulsion in localized 4f electrons and their hybridization with itinerant ligand-orbital electrons. We have performed electronic ground-state calculations on CeCu2Si2 using the Gutzwiller wave function approximation. The Gutzwiller approximation captures the quasiparticle band renormalization from the strong on-site Coulomb repulsion. We have performed an analysis of this effect on the electronic structure and the Fermi surface topology by varying the interaction strength and taking into account the crystal-field splitting. Using the de Haas-van Alphen effect, the extremal Fermi surface cross-sectional areas were calculated to quantify the effects of quasiparticle mass renormalization on the Fermi surface. Our results confirm the presence of two Fermi surface sheets corresponding to the heavy (488me) and light (4.35me) quasiparticles when the crystal-field splitting is accounted for on equal footing with the electronic correlations. This method gives the best agreement with experimental measurements as well as the renormalized band method.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (46)

  1. F. Steglich, J. Aarts, C. D. Bredl, W. Lieke, D. Meschede, W. Franz, and H. Schäfer, Superconductivity in the presence of strong Pauli paramagnetism: CeCu2Si2, Phys. Rev. Lett. 43, 1892 (1979).
  2. S. Horn, E. Holland-Moritz, M. Loewenhaupt, F. Steglich, H. Scheuer, A. Benoit, and J. Flouquet, Magnetic neutron scattering and crystal-field states in CeCu2Si2, Phys. Rev. B 23, 3171 (1981).
  3. F. Steglich, U. Ahlheim, J. J. M. Franse, N. Grewe, D. Rainer, and U. Rauchschwalbe, CeCu2Si2 and UPt3: Two different cases of heavy fermion superconductivity, J. Magn. Magn. Mater. 52, 54 (1985).
  4. P. Fulde and M. Loewenhaupt, Magnetic excitations in crystal-field split 4f systems, Adv. Phys. 34, 589 (2006).
  5. M. Hunt, P. Meeson, P. A. Probst, P. Reinders, M. Springford, W. Assmus, and W. Sun, Magnetic oscillations in the heavy-fermion superconductor CeCu2Si2, J. Phys.: Condens. Matter 2, 6859 (1990).
  6. H. Harima and A. Yanase, Fermi surface of CeCu2Si2 within the local density approximation, J. Phys. Soc. Jpn. 60, 21 (1991).
  7. H. Harima and A. Yanase, Fermi surfaces of CeCu6 and CeCu2Si2, J. Magn. Magn. Mater. 108, 145 (1992).
  8. G. Zwicknagl and U. Pulst, CeCu2Si2: Renormalized band structure, quasiparticles and co-operative phenomena, Phys. B: Condens. Matter 186-188, 895 (1993).
  9. E. A. Goremychkin and R. Osborn, Crystal-field excitations in CeCu2Ci2, Phys. Rev. B 47, 14280 (1993).
  10. B. Batlogg, J. P. Remeika, A. S. Cooper, and Z. Fisk, Magnetism and superconductivity in CeCu2Si2 single crystals, J. Appl. Phys. 55, 2001 (1984).
  11. H. Q. Yuan, F. M. Grosche, M. Deppe, C. Geibel, G. Sparn, and F. Steglich, Observation of two distinct superconducting phases in CeCu2Si2, Science 302, 2104 (2003).
  12. L. Ning and G. P. Brivio, Density functional theory calculation of crystal-field energy levels for Yb3+ in the Cs2NaYbF6 crystal, Phys. Rev. B 75, 235126 (2007).
  13. M. Matsumoto, M. J. Han, J. Otsuki, and S. Y. Savrasov, First-principles simulations of heavy fermion cerium compounds based on the Kondo lattice, Phys. Rev. Lett. 103, 096403 (2009).
  14. J. Arndt, O. Stockert, E. Faulhaber, P. Fouquet, H. S. Jeevan, C. Geibel, M. Loewenhaupt, and F. Steglich, Characteristics of the magnetic order in CeCu2Si2 revealed by neutron spin-echo measurements, J. Phys.: Conf. Ser. 200, 012009 (2010).
  15. O. Stockert, J. Arndt, E. Faulhaber, C. Geibel, H. S. Jeevan, S. Kirchner, M. Loewenhaupt, K. Schmalzl, W. Schmidt, Q. Si, and F. Steglich, Magnetically driven superconductivity in CeCu2Si2, Nat. Phys. 7, 119 (2010).
  16. F. Steglich, Heavy-fermion superconductivity in the Kondo-lattice system CeCu2Si2, J. Phys.: Conf. Ser. 400, 022111 (2012).
  17. H. A. Vieyra, N. Oeschler, S. Seiro, H. S. Jeevan, C. Geibel, D. Parker, and F. Steglich, Determination of gap symmetry from angle-dependent Hc2 measurements on CeCu2Si2, Phys. Rev. Lett. 106, 207001 (2011).
  18. O. Stockert, E. Faulhaber, G. Zwicknagl, N. Stusser, H. S. Jeevan, M. Deppe, R. Borth, R. Kuchler, M. Loewenhaupt, C. Geibel, and F. Steglich, Nature of the A phase in CeCu2Si2, Phys. Rev. Lett. 92, 136401 (2004).
  19. I. Eremin, G. Zwicknagl, P. Thalmeier, and P. Fulde, Feedback spin resonance in superconducting CeCu2Si2 and CeCoIn5, Phys. Rev. Lett. 101, 187001 (2008).
  20. R.-S. Li, X. Lu, J.-T. Wang, D.-Q. Xin, and X.-G. Yao, Localization for 4f electrons in a heavy fermion compound CeCu2Si2: Insights from dynamical mean-field theory, Chin. J. Phys. 66, 684 (2020).
  21. L. V. Pourovskii, P. Hansmann, M. Ferrero, and A. Georges, Theoretical prediction and spectroscopic fingerprints of an orbital transition in CeCu2Si2, Phys. Rev. Lett. 112, 106407 (2014).
  22. G. Zwicknagl, The utility of band theory in strongly correlated electron systems, Rep. Prog. Phys. 79, 124501 (2016).
  23. H. Ikeda, M. T. Suzuki, and R. Arita, Emergent loop-nodal S±-wave superconductivity in CeCu2Si2: Similarities to the iron-based superconductors, Phys. Rev. Lett. 114, 147003 (2015).
  24. Y. Song, W. Wang, C. Cao, Z. Yamani, Y. Xu, Y. Sheng, W. Loser, Y. Qiu, Y. F. Yang, R. J. Birgeneau, and P. Dai, High-energy magnetic excitations from heavy quasiparticles in CeCu2Si2, npj Quantum Inf. 6, 60 (2021).
  25. E. M. Nica and Q. Si, Multiorbital singlet pairing and d+d superconductivity, npj Quantum Mater. 6, 3 (2021).
  26. A. Amorese, A. Marino, M. Sundermann, K. Chen, Z. Hu, T. Willers, F. Choueikani, P. Ohresser, J. Herrero-Martin, S. Agrestini, C.-T. Chen, H.-J. Lin, M. W. Haverkort, S. Seiro, C. Geibel, F. Steglich, L. H. Tjeng, G. Zwicknagl, and A. Severing, Possible multiorbital ground state in CeCu2Si2, Phys. Rev. B 102, 245146 (2020).
  27. Y. Li, M. Liu, Z. Fu, X. Chen, F. Yang, and Y. F. Yang, Gap symmetry of the heavy fermion superconductor CeCu2Si2 at ambient pressure, Phys. Rev. Lett. 120, 217001 (2018).
  28. X. Luo, Y. Zhang, Q. Chen, Q. Liu, L. Luo, S. Tan, X. Zhu, and X. Lai, Electronic structure evolution accompanying heavy fermion formation in CeCu2Si2, Sci. China Phys. Mech. Astron. 63, 287413 (2020).
  29. S. Zhao, B. Liu, Y.-F. Yang, and S. Feng, Revealing sign-reversal S+−-wave pairing by quasiparticle interference in the heavy-fermion superconductor CeCu2Si2, Phys. Rev. B 105, 014501 (2022).
  30. S. Zhao, W. Liu, Y.-F. Yang, S. Feng, and B. Liu, Anomalous impurity effect in the heavy-fermion superconductor CeCu2Si2, Phys. Rev. B 110, 054512 (2024).
  31. Z. Wu, Y. Fang, H. Su, W. Xie, P. Li, Y. Wu, Y. Huang, D. Shen, B. Thiagarajan, J. Adell, C. Cao, H. Yuan, F. Steglich, and Y. Liu, Revealing the heavy quasiparticles in the heavy-fermion superconductor CeCu2Si2, Phys. Rev. Lett. 127, 067002 (2021).
  32. M. C. Gutzwiller, Correlation of electrons in a narrows band, Phys. Rev. 137, A1726 (1965).
  33. T. Willers, F. Strigari, N. Hiraoka, Y. Q. Cai, M. W. Haverkort, K. D. Tsuei, Y. F. Liao, S. Seiro, C. Geibel, F. Steglich, L. H. Tjeng, and A. Severing, Determining the in-plane orientation of the ground-state orbital of CeCu2Si2, Phys. Rev. Lett. 109, 046401 (2012).
  34. J. P. Rueff, J. M. Ablett, F. Strigari, M. Deppe, M. W. Haverkort, L. H. Tjeng, and A. Severing, Absence of orbital rotation in superconducting CeCu2Ge2, Phys. Rev. B 91, 201108(R) (2015).
  35. N. Lanatà, Y. Yao, C.-Z. Wang, K.-M. Ho, and G. Kotliar, Phase diagram and electronic structure of praseodymium and plutonium, Phys. Rev. X 5, 011008 (2015).
  36. R. M. Tutchton, W.-T. Chiu, R. C. Albers, G. Kotliar, and J.-X. Zhu, Electronic correlation induced expansion of Fermi pockets in δ-plutonium, Phys. Rev. B 101, 245156 (2020).
  37. W.-T. Chiu, R. M. Tutchton, G. Resta, T.-H. Lee, E. D. Bauer, F. Ronning, R. T. Scalettar, and J.-X. Zhu, Hybridization effect on the x-ray absorption spectra for actinide materials: Application to PuB4, Phys. Rev. B 102, 085150 (2020).
  38. See Supplemental Material at https://link.aps.org/supplemental/10.1103/fh8z-r7rx for the extended methods, tables, figures, and discussion of the U parameter analysis.
  39. E. U. Condon and G. H. Shortley, The Theory of Atomic Spectra, 3rd ed. (Cambridge University Press, Cambridge, 1963).
  40. N. Lanata, Y. Yao, X. Deng, V. Dobrosavljevic, and G. Kotliar, Slave boson theory of orbital differentiation with crystal field effects: Application to UO2, Phys. Rev. Lett. 118, 126401 (2017).
  41. R. Lässer, J. Fuggle, M. Beyss, M. Campagna, F. Steglich, and F. Hulliger, X-ray photoemission from Ce core levels of CePd3, CeSe, CeAl2 and CeCu2Si2, Physica B+C 102, 360 (1980).
  42. M. Edwards, S. Horn, and R. Parks, Effects of crystal fields on the scaling behavior of the magnetic susceptibility in Ce(NixCu1−x)2Si2, Solid State Commun. 61, 65 (1987).
  43. P. Rourke and S. Julian, Numerical extraction of de Haas–van Alphen frequencies from calculated band energies, Comput. Phys. Commun. 183, 324 (2012).
  44. P. Blaha, K. Schwarz, G. K. H. Madsen, D. Kvasnicka, and J. Luitz, WIEN2K: An Augmented Plane Wave Plus Local Orbitals Program for Calculating Crystal Properties (Karlheinz Schwarz, Technische Universität Wien, Austria, 2001).
  45. J. P. Perdew, K. Burke, and M. Ernzerhof, Generalized gradient approximation made simple, Phys. Rev. Lett. 77, 3865 (1996).
  46. L. Jiao, Y. Chen, Y. Kohama, D. Graf, E. D. Bauer, J. Singleton, J.-X. Zhu, Z. Weng, G. Pang, T. Shang, J. Zhang, H.-O. Lee, T. Park, M. Jaime, J. D. Thompson, F. Steglich, Q. Si, and H. Q. Yuan, Fermi surface reconstruction and multiple quantum phase transitions in the antiferromagnet CeRhIn5, Proc. Natl. Acad. Sci. USA 112, 673 (2015).
