Focusing characteristics of cylindrically bent Laue crystals

Yu-Hang Wang1,*, Ming Li2,3, and Quan-Jie Jia2,†

  • *Contact author: wangyuhang@mail.iasf.ac.cn
  • †Contact author: jiaqj@ihep.ac.cn
PDF

Phys. Rev. Research 8, L032001 – Published 6 July, 2026

DOI: https://doi.org/10.1103/f1jk-13c4

Abstract

Based on paraxial optics and the Takagi-Taupin theory, we establish an analytical framework for cylindrically bent Laue crystals that treats them as bulk diffraction devices and decomposes their behavior into geometric, kinematical, and higher-order scattering contributions. In this framework, we derive three fundamental results: a conservation relation accounting for aperture effects, a monochromatic focusing condition, and a polychromatic focusing condition. We further clarify the origin and limitations of common focusing conditions derived from geometric-optics arguments. These results deepen the fundamental understanding of bent Laue crystals and reshape their design logic, paving the way for practical applications.
