Improved diffusive approximation of Markov jump processes close to equilibrium

David Roberts, Trevor McCourt*, Geremia Massarelli, Jeremy Rothschild, and Nahuel Freitas

  • Extropic Corporation, Cambridge, Massachusetts, USA

  • *Contact author: trevor@extropic.ai
PDF

Phys. Rev. Research 8, 013161 – Published 11 February, 2026

DOI: https://doi.org/10.1103/dw4d-yj8c

Abstract

Diffusive approximations of Markov jump processes often fail to accurately capture large fluctuations. This is confounding, as the rare events triggered by these large fluctuations, such as the failure of electronic memories, are often the object of interest. In this paper, we present an improved diffusive approximation, extending a method previously limited to equilibrium systems. Using recently developed tools from stochastic thermodynamics, we prove its validity to linear order in departures from equilibrium and demonstrate its superior accuracy over the Kramers-Moyal expansion in predicting both steady state and transient properties, including the error rate of a nonequilibrium electronic memory.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (52)

  1. A. Arkin, J. Ross, and H. H. McAdams, Stochastic kinetic analysis of developmental pathway bifurcation in phage λ-infected Escherichia coli cells, Genetics 149, 1633 (1998).
  2. P. C. Bressloff, Stochastic switching in biology: From genotype to phenotype, J. Phys. A: Math. Theor. 50, 133001 (2017).
  3. H. Spohn, Long range correlations for stochastic lattice gases in a non-equilibrium steady state, J. Phys. A: Math. Gen. 16, 4275 (1983).
  4. J. L. Lebowitz and H. Spohn, A Gallavotti–Cohen-type symmetry in the large deviation functional for stochastic dynamics, J. Stat. Phys. 95, 333 (1999).
  5. C. Wasshuber, Computational Single-Electronics (Springer, Vienna, Wien, Austria, 2001).
  6. S. V. Moreira, P. Samuelsson, and P. P. Potts, Stochastic thermodynamics of a quantum dot coupled to a finite-size reservoir, Phys. Rev. Lett. 131, 220405 (2023).
  7. C. Y. Gao and D. T. Limmer, Principles of low dissipation computing from a stochastic circuit model, Phys. Rev. Res. 3, 033169 (2021).
  8. N. Freitas, J.-C. Delvenne, and M. Esposito, Stochastic thermodynamics of nonlinear electronic circuits: A realistic framework for computing around kT, Phys. Rev. X 11, 031064 (2021).
  9. N. Freitas, G. Massarelli, J. Rothschild, D. Keane, E. Dawe, S. Hwang, A. Garlapati, and T. McCourt, Taming non-equilibrium thermal fluctuations in subthreshold CMOS circuits (unpublished).
  10. D. T. Gillespie, A general method for numerically simulating the stochastic time evolution of coupled chemical reactions, J. Comput. Phys. 22, 403 (1976).
  11. D. T. Gillespie, Exact stochastic simulation of coupled chemical reactions, J. Phys. Chem. 81, 2340 (1977).
  12. D. T. Gillespie, The chemical Langevin equation, J. Chem. Phys. 113, 297 (2000).
  13. J. M. Horowitz, Diffusion approximations to the chemical master equation only have a consistent stochastic thermodynamics at chemical equilibrium, J. Chem. Phys. 143, 044111 (2015).
  14. A. J. McKane and T. J. Newman, Predator-prey cycles from resonant amplification of demographic stochasticity, Phys. Rev. Lett. 94, 218102 (2005).
  15. C. K. Fisher and P. Mehta, The transition between the niche and neutral regimes in ecology, Proc. Natl. Acad. Sci. USA 111, 13111 (2014).
  16. M. Vellela and H. Qian, Stochastic dynamics and non-equilibrium thermodynamics of a bistable chemical system: The Schlögl model revisited, J. R. Soc. Interface 6, 925 (2009).
  17. C. Gardiner, Stochastic Methods (Springer, Berlin, 2009).
  18. M. I. Dykman, E. Mori, J. Ross, and P. M. Hunt, Large fluctuations and optimal paths in chemical kinetics, J. Chem. Phys. 100, 5735 (1994).
  19. L. E. Reichl, A Modern Course in Statistical Physics, 2nd ed. (John Wiley & Sons, New York, NY, 1998).
  20. N. G. van Kampen, Stochastic Processes in Physics and Chemistry, 3rd ed. (Elsevier, Amsterdam, 2007).
  21. P. Hanggi, Nonlinear fluctuations: The problem of deterministic limit and reconstruction of stochastic dynamics, Phys. Rev. A 25, 1130 (1982).
  22. P. Hanggi, H. Grabert, P. Talkner, and H. Thomas, Bistable systems: Master equation versus Fokker-Planck modeling, Phys. Rev. A 29, 371 (1984).
  23. P. Hanggi and P. Jung, Bistability in active circuits: Application of a novel Fokker-Planck approach, IBM J. Res. Dev. 32, 119 (1988).
  24. T. Reichenbach, M. Mobilia, and E. Frey, Coexistence versus extinction in the stochastic cyclic Lotka-Volterra model, Phys. Rev. E 74, 051907 (2006).
  25. O. Ovaskainen and B. Meerson, Stochastic models of population extinction, Trends Ecol. Evol. 25, 643 (2010).
  26. S. Panahi, U. Feudel, K. C. Abbott, A. Hastings, and Y.-C. Lai, Generalized paradox of enrichment: Noise-driven rare rarity in degraded ecological systems, J. R. Soc. Interface 22, 20250087 (2025).
  27. E. Rezaei, M. Donato, W. R. Patterson, A. Zaslavsky, and R. I. Bahar, Fundamental thermal limits on data retention in low-voltage CMOS latches and SRAM, IEEE Trans. Device Mater. Relib. 20, 488 (2020).
  28. N. Freitas, K. Proesmans, and M. Esposito, Reliability and entropy production in nonequilibrium electronic memories, Phys. Rev. E 105, 034107 (2022).
  29. A. Jelinčič, O. Lockwood, A. Garlapati, P. Schillinger, I. Chuang, G. Verdon, and T. McCourt, An efficient probabilistic hardware architecture for diffusion-like models, arXiv:2510.23972.
  30. T. Schmiedl and U. Seifert, Stochastic thermodynamics of chemical reaction networks, J. Chem. Phys. 126, 044101 (2007).
  31. A. Lazarescu, T. Cossetto, G. Falasco, and M. Esposito, Large deviations and dynamical phase transitions in stochastic chemical networks, J. Chem. Phys. 151, 064117 (2019).
  32. N. J. López-Alamilla, M. W. Jack, and K. J. Challis, Enhanced diffusion and the eigenvalue band structure of Brownian motion in tilted periodic potentials, Phys. Rev. E 102, 042405 (2020).
  33. K. J. Challis, Numerical study of the tight-binding approach to overdamped Brownian motion on a tilted periodic potential, Phys. Rev. E 94, 062123 (2016).
  34. R. Hayashi, K. Sasaki, S. Nakamura, S. Kudo, Y. Inoue, H. Noji, and K. Hayashi, Giant acceleration of diffusion observed in a single-molecule experiment on F1−ATPase, Phys. Rev. Lett. 114, 248101 (2015).
  35. I. Santamaría-Holek and A. Pérez-Madrid, Eyring equation and fluctuation–dissipation far away from equilibrium, J. Chem. Phys. 153, 244116 (2020).
  36. It is useful to point out that, provided that the jump vectors {Δρ}ρ are linearly independent, near a deterministic fixed point x≈x*, the logarithmic mean appearing in Eq. (6) reduces to the arithmetic mean, so the above diffusion tensor and Eq. (5) asymptotically coincide near a deterministic fixed point.
  37. N. Freitas, G. Falasco, and M. Esposito, Linear response in large deviations theory: A method to compute non-equilibrium distributions, New J. Phys. 23, 093003 (2021).
  38. J. N. Freitas and M. Esposito, Emergent second law for non-equilibrium steady states, Nat. Commun. 13, 5084 (2022).
  39. G. Falasco and M. Esposito, Macroscopic stochastic thermodynamics, Rev. Mod. Phys. 97, 015002 (2025).
  40. D. Santolin, N. Freitas, M. Esposito, and G. Falasco, Bridging Freidlin-Wentzell large deviations theory and stochastic thermodynamics, Phys. Rev. E 111, 024106 (2025).
  41. T. Van Vu and K. Saito, Thermodynamic unification of optimal transport: Thermodynamic uncertainty relation, minimum dissipation, and thermodynamic speed limits, Phys. Rev. X 13, 011013 (2023).
  42. T. Van Vu, V. T. Vo, and K. Saito, Dissipation, quantum coherence, and asymmetry of finite-time cross-correlations, Phys. Rev. Res. 6, 013273 (2024).
  43. To see this, note that, defining xρ≡Δρ/Ω, we can write ∂tP=∑ρ(−∂nxρn(λρP)+∂n∂mxρmxρn∑k=2∞(−∂nxρn)k−2k!(λρP)).We then note that the above is in the form Eq. (8), with μn(x)=∑ρxρnλρ(x) and D̃(x,t) given by Eq. (10).
  44. H. Risken, The Fokker-Planck Equation: Methods of Solution and Applications, 2nd ed., edited by H. Haken, Springer Series in Synergetics Vol. 18 (Springer-Verlag, Berlin, 1989).
  45. R. Kubo, K. Matsuo, and K. Kitahara, Fluctuation and relaxation of macrovariables, J. Stat. Phys. 9, 51 (1973).
  46. See Supplemental Material at http://link.aps.org/supplemental/10.1103/dw4d-yj8c for more details, which includes Refs. [16, 37, 44, 52].
  47. M. Mendler and B. Drossel, Predicting properties of the stationary probability currents for two-species reaction systems without solving the Fokker-Planck equation, Phys. Rev. E 102, 022208 (2020).
  48. A. Ceccato and D. Frezzato, Remarks on the chemical Fokker-Planck and Langevin equations: Nonphysical currents at equilibrium, J. Chem. Phys. 148, 064114 (2018).
  49. A. Gopal, M. Esposito, and N. Freitas, Large deviations theory for noisy nonlinear electronics: CMOS inverter as a case study, Phys. Rev. B 106, 155303 (2022).
  50. F. Bouchet and J. Reygner, Generalisation of the Eyring–Kramers transition rate formula to irreversible diffusion processes, Ann. Henri Poincaré 17, 3499 (2016).
  51. D. Roberts, T. McCourt, G. Massarelli, J. Rothschild, and N. Freitas, Replication package: Improved diffusive approximation of Markov jump processes, Zenodo (2026), doi:10.5281/zenodo.18204136.
  52. J. Chang and G. Cooper, A practical difference scheme for Fokker-Planck equations, J. Comput. Phys. 6, 1 (1970).
