Intertwined orbital distribution of charge density waves in NbSe2

Jyun-Yu Wu1, Yung-Ting Lee2,3, Guan-Hao Chen1,4, Zheng-Hong Li1, Chang-Tsan Lee1, Jie-Yu Hsu1, Chia-Nung Kuo5, Juhn-Jong Lin1, Wen-Hao Chang1,4 et al.

Chin Shan Lue5,6, Noriaki Takagi7, Po-Tuan Chen2, Cheng-Tien Chiang8,9, Chien-Cheng Kuo10, Chien-Te Wu1,11, Chi-Cheng Lee9,*, Ming-Chiang Chung12,†, Hung-Chung Hsueh9,‡, and Chun-Liang Lin1,§

  • *Contact author: cclee.physics@gmail.com
  • †Contact author: mingchiangha@phys.nchu.edu.tw
  • ‡Contact author: hchsueh521@gmail.com
  • §Contact author: clin@nycu.edu.tw
PDF

Phys. Rev. Research 7, 043206 – Published 21 November, 2025

DOI: https://doi.org/10.1103/dn1j-gkjs

Abstract

Charge density wave (CDW) resulting from a periodic distortion in the lattice creates orders beyond the original lattice. In 2H−NbSe2, one of the layered transition metal dichalcogenides, the 3×3 charge order appears in two-dimensional (2D) layers. Although CDW can be observed by different techniques, the spatial distribution within a 2D layer has never been systematically visualized. Here, by using scanning tunneling microscopy and density functional theory, we monitored the evolution of CDW along the c axis and found a strong relation with the orbital charges. The results show that the appearance of the CDW varies while tuning the tunneling current and undergoes a transition from Se orbital charges to Nb orbital charges. The calculation of orbital charge distributions shows that both CDW intensity modulation and the transition are strongly intertwined with the distribution of Se 4p orbitals and Nb 4d orbitals.
