Trapping potentials and quantum gates for microwave-dressed Rydberg atoms on an atom chip

Iason Tsiamis1,2,*, Georgios Doultsinos2,3, Andreas F. Tzortzakakis4, Manuel Kaiser5, Dominik Jakab5, Andreas Günther5, József Fortágh5, and David Petrosyan2,5

  • *Contact author: iason.tsiamis@fu-berlin.de
PDF

Phys. Rev. Research 8, 013088 – Published 27 January, 2026Erratum Phys. Rev. Research 8, 039003 (2026)

DOI: https://doi.org/10.1103/d8w4-wbrj

Abstract

Rydberg atoms in dc electric fields acquire static dipole moments. When the atoms are close to a surface producing an inhomogeneous electric field, such as by the adsorbates on an atom chip, depending on the sign of the dipole moment of the Rydberg-Stark eigenstate, the atoms may experience a force toward or away from the surface. We show that by applying a bias electric field and coupling a desired Rydberg state by a microwave field of proper frequency to another Rydberg state with opposite sign of the dipole moment, we can create a trapping potential for the atom at a prescribed distance from the surface. Perfectly overlapping trapping potentials for several Rydberg states can also be created by multicomponent microwave fields. A pair of such trapped Rydberg states of an atom can represent a qubit. Finally, we discuss an optimal realization of the SWAP gate between pairs of such atomic Rydberg qubits separated by a large distance but interacting with a common mode of a planar microwave resonator at finite temperature.

View figure in article

Physics Subject Headings (PhySH)

Erratum

Erratum: Trapping potentials and quantum gates for microwave-dressed Rydberg atoms on an atom chip [Phys. Rev. Research 8, 013088 (2026)]

Iason Tsiamis, Georgios Doultsinos, Andreas F. Tzortzakakis, Manuel Kaiser, Dominik Jakab, Andreas Günther, József Fortágh, and David Petrosyan
Phys. Rev. Research 8, 039003 (2026)

Article Text

References (27)

  1. Z.-L. Xiang, S. Ashhab, J. Q. You, and F. Nori, Hybrid quantum circuits: Superconducting circuits interacting with other quantum systems, Rev. Mod. Phys. 85, 623 (2013).
  2. G. Kurizki, P. Bertet, Y. Kubo, K. Mølmer, D. Petrosyan, P. Rabl, and J. Schmiedmayer, Quantum technologies with hybrid systems, Proc. Natl. Acad. Sci. USA 112, 3866 (2015).
  3. N. Lauk, N. Sinclair, S. Barzanjeh, J. P. Covey, M. S. Saffman, M. Spiropulu, and C. Simon, Perspectives on quantum transduction, Quantum Sci. Technol. 5, 020501 (2020).
  4. A. S. Sørensen, C. H. van der Wal, L. I. Childress, and M. D. Lukin, Capacitive coupling of atomic systems to mesoscopic conductors, Phys. Rev. Lett. 92, 063601 (2004).
  5. D. Petrosyan, G. Bensky, G. Kurizki, I. Mazets, J. Majer, and J. Schmiedmayer, Reversible state transfer between superconducting qubits and atomic ensembles, Phys. Rev. A 79, 040304(R) (2009).
  6. S. D. Hogan, J. A. Agner, F. Merkt, T. Thiele, S. Filipp, and A. Wallraff, Driving Rydberg-Rydberg transitions from a coplanar microwave waveguide, Phys. Rev. Lett. 108, 063004 (2012).
  7. M. Kaiser, C. Glaser, L. Y. Ley, J. Grimmel, H. Hattermann, D. Bothner, D. Koelle, R. Kleiner, D. Petrosyan, A. Günther, and J. Fortágh, Cavity-driven Rabi oscillations between Rydberg states of atoms trapped on a superconducting atom chip, Phys. Rev. Res. 4, 013207 (2022).
  8. A. Tauschinsky, R. M. T. Thijssen, S. Whitlock, H. B. van Linden van den Heuvell, and R. J. C. Spreeuw, Spatially resolved excitation of Rydberg atoms and surface effects on an atom chip, Phys. Rev. A 81, 063411 (2010).
  9. H. Hattermann, M. Mack, F. Karlewski, F. Jessen, D. Cano, and J. Fortágh, Detrimental adsorbate fields in experiments with cold Rydberg gases near surfaces, Phys. Rev. A 86, 022511 (2012).
  10. J. A. Sedlacek, E. Kim, S. T. Rittenhouse, P. F. Weck, H. R. Sadeghpour, and J. P. Shaffer, Electric field cancellation on quartz by Rb adsorbate-induced negative electron affinity, Phys. Rev. Lett. 116, 133201 (2016).
  11. C. Hermann-Avigliano, R. C. Teixeira, T. L. Nguyen, T. Cantat-Moltrecht, G. Nogues, I. Dotsenko, S. Gleyzes, J. M. Raimond, S. Haroche, and M. Brune, Long coherence times for Rydberg qubits on a superconducting atom chip, Phys. Rev. A 90, 040502(R) (2014).
  12. L. A. Jones, J. D. Carter, and J. D. D. Martin, Rydberg atoms with a reduced sensitivity to dc and low-frequency electric fields, Phys. Rev. A 87, 023423 (2013).
  13. H. Perrin and B. M. Garraway, Trapping atoms with radio frequency adiabatic potentials, Adv. At. Mol. Opt. Phys. 66, 181 (2017).
  14. D. Petrosyan and M. Fleischhauer, Quantum information processing with single photons and atomic ensembles in microwave coplanar waveguide resonators, Phys. Rev. Lett. 100, 170501 (2008).
  15. L. Sárkány, J. Fortágh, and D. Petrosyan, Long-range quantum gate via Rydberg states of atoms in a thermal microwave cavity, Phys. Rev. A 92, 030303(R) (2015).
  16. L. Sárkány, J. Fortágh, and D. Petrosyan, Faithful state transfer between two-level systems via an actively cooled finite-temperature cavity, Phys. Rev. A 97, 032341 (2018).
  17. D. Bothner, D. Wiedmaier, B. Ferdinand, R. Kleiner, and D. Koelle, Improving superconducting resonators in magnetic fields by reduced field focussing and engineered flux screening, Phys. Rev. Appl. 8, 034025 (2017).
  18. H. Hattermann, D. Bothner, L. Y. Ley, B. Ferdinand, D. Wiedmaier, L. Sárkány, R. Kleiner, D. Koelle, and J. Fortágh, Coupling ultracold atoms to a superconducting coplanar waveguide resonator, Nat. Commun. 8, 2254 (2017).
  19. V. Bochko and Z. K. Silagadze, On the electrostatic potential and electric field of a uniformly charged disk, Eur. J. Phys. 41, 045201 (2020).
  20. The bare levels |r〉,|a〉 also cross (in the rotating frame) for F(z)<0 at z0=−ζln−ℏda−drΔF0+FbF0.
  21. Due to small polarizability of the atoms in the ground electronic state, they are largely immune to mechanical forces in static, spatially inhomogeneous electric fields F of moderate strengths and can be trapped by dipole forces induced by focused laser beams that form optical tweezers. In contrast, for strongly polarizable Rydberg states of the atoms, the mechanical forces ∇(dr|F|) are so large that typical optical dipole potentials cannot trap the Rydberg atoms in such inhomogeneous electric fields F.
  22. J. Verdú, H. Zoubi, C. Koller, J. Majer, H. Ritsch, and J. Schmiedmayer, Strong magnetic coupling of an ultracold gas to a superconducting waveguide cavity, Phys. Rev. Lett. 103, 043603 (2009).
  23. P. Lambropoulos and D. Petrosyan, Fundamentals of Quantum Optics and Quantum Information (Springer, Berlin, 2007).
  24. K. Mølmer, Y. Castin, and J. Dalibard, Monte Carlo wave-function method in quantum optics, J. Opt. Soc. Am. B 10, 524 (1993).
  25. M. B. Plenio and P. L. Knight, The quantum-jump approach to dissipative dynamics in quantum optics, Rev. Mod. Phys. 70, 101 (1998).
  26. I. Tsiamis, G. Doultsinos, A. F. Tzortzakakis, M. Kaiser, D. Jakab, A. Günther, J. Fortágh, and D. Petrosyan, Trapping potentials and quantum gates for microwave-dressed Rydberg atoms on an atom chip: Data [Data set], Zenodo (2025), doi: 10.5281/zenodo.15296530.
  27. I. I. Beterov, I. I. Ryabtsev, D. B. Tretyakov, and V. M. Entin, Quasiclassical calculations of blackbody-radiation-induced depopulation rates and effective lifetimes of Rydberg nS, nP, and nD alkali-metal atoms with n≤80, Phys. Rev. A 79, 052504 (2009).
