Construction of quantum bisource based on dressed-state-assisted photon blockade effect

Hui Yang*, Xinlong Zhou, Yuxuan Wang, and Zhihai Yao

  • *Contact author: yangh@cust.edu.cn
PDF

Phys. Rev. Research 7, 043003 – Published 1 October, 2025

DOI: https://doi.org/10.1103/crn2-v8fl

Abstract

A simple scheme that could contribute to the construction of quantum double sources effectively is proposed and numerically verified. The scheme could be constructed by a four-wave-mixing system under a weak driving, in which the same-frequency single-photon and two-photon blockade effects could be realized simultaneously based on a blockade mechanism referred to as dressed-state-assisted photon blockade. The advantages of this mechanism over conventional and unconventional photon blockades are revealed, which could contribute to improve the purity and brightness of quantum bisources effectively. All of these make the construction of quantum bisource possible and would open a route to design simple and efficient quantum sources.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (55)

  1. C. Couteau, S. Barz, T. Durt, T. Gerrits, J. Huwer, R. Prevedel, J. Rarity, A. Shields, and G. Weihs, Applications of single photons to quantum communication and computing, Nat. Rev. Phys. 5, 326 (2023).
  2. B. Lounis and M. Orrit, Single-photon sources, Rep. Prog. Phys. 68, 1129 (2005).
  3. D. E. Chang, V. Vuletić, and M. D. Lukin, Quantum nonlinear optics – photon by photon, Nat. Photon. 8, 685 (2014).
  4. E. Knill, R. Laflamme, and G. J. Milburn, A scheme for efficient quantum computation with linear optics, Nature (London) 409, 46 (2001).
  5. W. Denk, J. H. Strickler, and W. W. Webb, Two-photon laser scanning fluorescence microscopy, Science 248, 73 (1990).
  6. A. Imamoglu, H. Schmidt, G. Woods, and M. Deutsch, Strongly interacting photons in a nonlinear cavity, Phys. Rev. Lett. 79, 1467 (1997).
  7. Z.-G. Lu, Y. Wu, and X.-Y. Lü, Chiral interaction induced near-perfect photon blockade, Phys. Rev. Lett. 134, 013602 (2025).
  8. H. J. Carmichael, Breakdown of photon blockade: A dissipative quantum phase transition in zero dimensions, Phys. Rev. X 5, 031028 (2015).
  9. J. M. Fink, A. Dombi, A. Vukics, A. Wallraff, and P. Domokos, Observation of the photon-blockade breakdown phase transition, Phys. Rev. X 7, 011012 (2017).
  10. R. Trivedi, M. Radulaski, K. A. Fischer, S. Fan, and J. Vučković, Photon blockade in weakly driven cavity quantum electrodynamics systems with many emitters, Phys. Rev. Lett. 122, 243602 (2019).
  11. H. Zheng, D. J. Gauthier, and H. U. Baranger, Cavity-free photon blockade induced by many-body bound states, Phys. Rev. Lett. 107, 223601 (2011).
  12. A. Majumdar and D. Gerace, Single-photon blockade in doubly resonant nanocavities with second-order nonlinearity, Phys. Rev. B 87, 235319 (2013).
  13. P. Rabl, Photon blockade effect in optomechanical systems, Phys. Rev. Lett. 107, 063601 (2011).
  14. M. Li, Y.-L. Zhang, S.-H. Wu, C.-H. Dong, X.-B. Zou, G.-C. Guo, and C.-L. Zou, Single-mode photon blockade enhanced by Bi-tone drive, Phys. Rev. Lett. 129, 043601 (2022).
  15. A. Cidrim, T. S. do Espirito Santo, J. Schachenmayer, R. Kaiser, and R. Bachelard, Photon blockade with ground-state neutral atoms, Phys. Rev. Lett. 125, 073601 (2020).
  16. K. Wang, Q. Wu, Y.-F. Yu, and Z.-M. Zhang, Nonreciprocal photon blockade in a two-mode cavity with a second-order nonlinearity, Phys. Rev. A 100, 053832 (2019).
  17. S. Chakram, K. He, A. V. Dixit, A. E. Oriani, R. K. Naik, N. Leung, H. Kwon, W.-L. Ma, L. Jiang, and D. I. Schuster, Multimode photon blockade, Nat. Phys. 18, 879 (2022).
  18. A. J. Hoffman, S. J. Srinivasan, S. Schmidt, L. Spietz, J. Aumentado, H. E. Türeci, and A. A. Houck, Dispersive photon blockade in a superconducting circuit, Phys. Rev. Lett. 107, 053602 (2011).
  19. C. Lang, D. Bozyigit, C. Eichler, L. Steffen, J. M. Fink, A. A. Abdumalikov, M. Baur, S. Filipp, M. P. da Silva, A. Blais, and A. Wallraff, Observation of resonant photon blockade at microwave frequencies using correlation function measurements, Phys. Rev. Lett. 106, 243601 (2011).
  20. T. C. H. Liew and V. Savona, Single photons from coupled quantum modes, Phys. Rev. Lett. 104, 183601 (2010).
  21. H.-J. Li, L.-B. Fan, S. Ma, J.-Q. Liao, and C.-C. Shu, Exploring photon blockade in a two-photon Jaynes-Cummings model with atom and cavity drivings, Phys. Rev. A 110, 043707 (2024).
  22. H. Z. Shen, Y. H. Zhou, and X. X. Yi, Tunable photon blockade in coupled semiconductor cavities, Phys. Rev. A 91, 063808 (2015).
  23. E. Zubizarreta Casalengua, J. C. López Carreño, F. P. Laussy, and E. Valle, Conventional and unconventional photon statistics, Laser Photon. Rev. 14, 1900279 (2020).
  24. K. Müller, A. Rundquist, K. A. Fischer, T. Sarmiento, K. G. Lagoudakis, Y. A. Kelaita, C. Sánchez Muñoz, E. del Valle, F. P. Laussy, and J. Vučković, Coherent generation of nonclassical light on chip via detuned photon blockade, Phys. Rev. Lett. 114, 233601 (2015).
  25. C. Hamsen, K. N. Tolazzi, T. Wilk, and G. Rempe, Two-photon blockade in an atom-driven cavity QED system, Phys. Rev. Lett. 118, 133604 (2017).
  26. Y. H. Zhou, X. Y. Zhang, Q. C. Wu, B. L. Ye, Z.-Q. Zhang, D. D. Zou, H. Z. Shen, and C.-P. Yang, Conventional photon blockade with a three-wave mixing, Phys. Rev. A 102, 033713 (2020).
  27. R. Huang, A. Miranowicz, J.-Q. Liao, F. Nori, and H. Jing, Nonreciprocal photon blockade, Phys. Rev. Lett. 121, 153601 (2018).
  28. K. M. Birnbaum, A. Boca, R. Miller, A. D. Boozer, T. E. Northup, and H. J. Kimble, Photon blockade in an optical cavity with one trapped atom, Nature (London) 436, 87 (2005).
  29. H. Wang, X. Gu, Y.-X. Liu, A. Miranowicz, and F. Nori, Tunable photon blockade in a hybrid system consisting of an optomechanical device coupled to a two-level system, Phys. Rev. A 92, 033806 (2015).
  30. A. Miranowicz, M. Paprzycka, Y.-X. Liu, J. Bajer, and F. Nori, Two-photon and three-photon blockades in driven nonlinear systems, Phys. Rev. A 87, 023809 (2013).
  31. A. Ridolfo, M. Leib, S. Savasta, and M. J. Hartmann, Photon blockade in the ultrastrong coupling regime, Phys. Rev. Lett. 109, 193602 (2012).
  32. O. Kyriienko, D. N. Krizhanovskii, and I. A. Shelykh, Nonlinear quantum optics with trion polaritons in 2D monolayers: Conventional and unconventional photon blockade, Phys. Rev. Lett. 125, 197402 (2020).
  33. Y. H. Zhou, H. Z. Shen, and X. X. Yi, Unconventional photon blockade with second-order nonlinearity, Phys. Rev. A 92, 023838 (2015).
  34. Y. Wang, W. Verstraelen, B. Zhang, T. C. H. Liew, and Y. D. Chong, Giant enhancement of unconventional photon blockade in a dimer chain, Phys. Rev. Lett. 127, 240402 (2021).
  35. B. Li, R. Huang, X. Xu, A. Miranowicz, and H. Jing, Nonreciprocal unconventional photon blockade in a spinning optomechanical system, Photon. Res. 7, 630 (2019).
  36. M.-A. Lemonde, N. Didier, and A. A. Clerk, Antibunching and unconventional photon blockade with Gaussian squeezed states, Phys. Rev. A 90, 063824 (2014).
  37. C. Vaneph, A. Morvan, G. Aiello, M. Féchant, M. Aprili, J. Gabelli, and J. Estève, Observation of the unconventional photon blockade in the microwave domain, Phys. Rev. Lett. 121, 043602 (2018).
  38. H. Flayac and V. Savona, Unconventional photon blockade, Phys. Rev. A 96, 053810 (2017).
  39. H. J. Snijders, J. A. Frey, J. Norman, H. Flayac, V. Savona, A. C. Gossard, J. E. Bowers, M. P. van Exter, D. Bouwmeester, and W. Löffler, Observation of the unconventional photon blockade, Phys. Rev. Lett. 121, 043601 (2018).
  40. F. Zou, X.-Y. Zhang, X.-W. Xu, J.-F. Huang, and J.-Q. Liao, Multiphoton blockade in the two-photon Jaynes-Cummings model, Phys. Rev. A 102, 053710 (2020).
  41. Y. H. Zhou, F. Minganti, W. Qin, Q.-C. Wu, J.-L. Zhao, Y.-L. Fang, F. Nori, and C.-P. Yang, n-photon blockade with an n-photon parametric drive, Phys. Rev. A 104, 053718 (2021).
  42. Y. Li, Z. Yao, and H. Yang, One-photon and two-photon blockades in a four-wave-mixing system embedded with an atom, Phys. Rev. A 109, 043702 (2024).
  43. S. Azzini, D. Grassani, M. Galli, D. Gerace, M. Patrini, M. Liscidini, P. Velha, and D. Bajoni, Stimulated and spontaneous four-wave mixing in silicon-on-insulator coupled photonic wire nano-cavities, Appl. Phys. Lett. 103, 031117 (2013).
  44. C. Diederichs, J. Tignon, G. Dasbach, C. Ciuti, A. Lemaitre, J. Bloch, P. Roussignol, and C. Delalande, Parametric oscillation in vertical triple microcavities, Nature (London) 440, 904 (2006).
  45. G. Christmann, A. Askitopoulos, G. Deligeorgis, Z. Hatzopoulos, S. I. Tsintzos, P. G. Savvidis, and J. J. Baumberg, Oriented polaritons in strongly-coupled asymmetric double quantum well microcavities, Appl. Phys. Lett. 98, 081111 (2011).
  46. J. Teja and N. C. Wong, Twin-beam generation in a triply resonant dual-cavity optical parametric oscillator, Opt. Express 2, 65 (1998).
  47. X. Qiao, Z. Yao, and H. Yang, Strongly enhanced photon-pair blockade with three-wave mixing by quantum interference, Phys. Rev. A 110, 053702 (2024).
  48. Y. Ren, S. Duan, W. Xie, Y. Shao, and Z. Duan, Antibunched photon-pair source based on photon blockade in a nondegenerate optical parametric oscillator, Phys. Rev. A 103, 053710 (2021).
  49. C. S. Muñoz, E. Del Valle, A. G. Tudela, K. Müller, S. Lichtmannecker, M. Kaniber, C. Tejedor, J. Finley, and F. Laussy, Emitters of N-photon bundles, Nat. Photon. 8, 550 (2014).
  50. Q. Bin, H. Jing, Y. Wu, F. Nori, and X.-Y. Lü, Nonreciprocal bundle emissions of quantum entangled pairs, Phys. Rev. Lett. 133, 043601 (2024).
  51. F. Boitier, A. Godard, E. Rosencher, and C. Fabre, Measuring photon bunching at ultrashort timescale by two-photon absorption in semiconductors, Nat. Phys. 5, 267 (2009).
  52. P. M. Visser and G. Nienhuis, Solution of quantum master equations in terms of a non-Hermitian Hamiltonian, Phys. Rev. A 52, 4727 (1995).
  53. J. Tang, Y. Deng, and C. Lee, Strong photon blockade mediated by optical Stark shift in a single-atom–cavity system, Phys. Rev. Appl. 12, 044065 (2019).
  54. See Supplemental Material at https://link.aps.org/supplemental/10.1103/crn2-v8fl for construction of quantum bisource based on dressed-state-assisted photon blockade effect.
  55. Z.-X. Wang, H. Yang, X.-Q. Wang, H.-Y. Lin, and Z.-H. Yao, Conventional photon blockade in a four-wave mixing system with Kerr nonlinearity, Phys. Scr. 98, 035108 (2023).

Outline

Information

Phys. Rev. Research 7, 043003– Published 1 October, 2025
  • Received 29 April 2025
  • Revised 28 July 2025
  • Accepted 12 September 2025
