  • Letter
  • Open Access

Ubiquitous mechanism of creep-quake cycles in porous media

Leonardo A. Crespo Parraga, Itai Einav, and François Guillard*

  • *Contact author: francois.guillard@sydney.edu.au
PDF

Phys. Rev. Research 7, L032034 – Published 13 August, 2025

DOI: https://doi.org/10.1103/cpk4-1d5y

Abstract

The degradation of porous media can trigger devastating events, from sinkhole formation to ice-shelve breakouts. In a recent study, regularly recurring creep-quake collapse cycles were identified in cereals, whose progression was related to partial saturation. This Letter reveals such patterns in other materials, including sand and ice, but crucially, we demonstrate that they do not necessitate partial saturation. Conversely, we experimentally and theoretically show how the mechanism underpinning the creep-quake collapse cycles can develop in any porous medium, as long as it is simultaneously subjected to compression and a nonuniform degradation field, let that be a hydraulic, thermal, or chemical field. Our results highlight the ubiquity of creep-quake collapse cycles and the importance of the underlying degradation processes that activate this mechanism in any porous medium. Given the vast interest in porous media, this understanding is anticipated to have significant implications in the agricultural, pharmaceutical, and environmental sciences.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (35)

  1. T. Waltham, A. C. Waltham, F. G. Bell, and M. G. Culshaw, Sinkholes and Subsidence Karst and Cavernous Rocks in Engineering and Construction (Springer-Verlag, Berlin, Heidelberg, 2005).
  2. E. Shalev, V. Lyakhovsky, and Y. Yechieli, Salt dissolution and sinkhole formation along the Dead Sea shore, J. Geophys. Res. 111, B03102 (2006).
  3. C. Polashenski, D. Perovich, and Z. Courville, The mechanisms of sea ice melt pond formation and evolution, J. Geophys. Res. 117, C01001 (2012).
  4. D. R. MacAyeal, A. F. Banwell, E. A. Okal, J. Lin, I. C. Willis, B. Goodsell, and G. J. MacDonald, Diurnal seismicity cycle linked to subsurface melting on an ice shelf, Ann. Glaciol. 60, 137 (2019).
  5. V. A. Gray and T. W. Rosanske, Dissolution (Elsevier, Amsterdam, 2020), pp. 481–503.
  6. S. Xie, L. Qi, and D. Zhou, Investigation of the effects of acid rain on the deterioration of cement concrete using accelerated tests established in laboratory, Atmos. Environ. 38, 4457 (2004).
  7. P. P. Lewicki, E. Jakubczyk, A. Marzec, M. C. Cabral, and P. M. Pereira, Effect of water activity on mechanical properties of dry cereal products, Acta Agrophys. 4, 381 (2004).
  8. J. K. Pringle, P. Styles, C. P. Howell, M. W. Branston, R. Furner, and S. M. Toon, Long-term time-lapse microgravity and geotechnical monitoring of relict salt mines, Marston, Cheshire, UK, Geophysics 77, B287 (2012).
  9. I. Einav and F. Guillard, Tracking time with ricequakes in partially soaked brittle porous media, Sci. Adv. 4, eaat6961 (2018).
  10. W. A. Olsson, Theoretical and experimental investigation of compaction bands in porous rock, J. Geophys. Res. 104, 7219 (1999).
  11. A. El Bied, J. Sulem, and F. Martineau, Microstructure of shear zones in Fontainebleau sandstone, Int. J Rock Mech. Min. Sci. 39, 917 (2002).
  12. H. Fossen, R. A. Schultz, Z. K. Shipton, and K. Mair, Deformation bands in sandstone: A review, J. Geol. Soc. 164, 755 (2007).
  13. I. Stefanou and J. Sulem, Chemically induced compaction bands: Triggering conditions and band thickness, J. Geophys. Res. 119, 880 (2014).
  14. U. Kelka, M. Veveakis, D. Koehn, and N. Beaudoin, Zebra rocks: Compaction waves create ore deposits, Sci. Rep. 7, 14260 (2017).
  15. W. A. Olsson and D. J. Holcomb, Compaction localization in porous rock, Geophys. Res. Lett. 27, 3537 (2000).
  16. P. Baud, E. Klein, and T.-F. Wong, Compaction localization in porous sandstones: Spatial evolution of damage and acoustic emission activity, J. Struct. Geol. 26, 603 (2004).
  17. J. Fortin, S. Stanchits, G. Dresen, and Y. Guéguen, Acoustic emission and velocities associated with the formation of compaction bands in sandstone, J. Geophys. Res. 111 (2006).
  18. J. Weiss and F. Louchet, Seismology of plastic deformation, Scr. Mater. 54, 747 (2006).
  19. J. Fortin, S. Stanchits, G. Dresen, and Y. Gueguen, Acoustic emissions monitoring during inelastic deformation of porous sandstone: Comparison of three modes of deformation, Pure Appl. Geophys. 166, 823 (2009).
  20. See Supplemental Material at http://link.aps.org/supplemental/10.1103/cpk4-1d5y for experimental and numerical simulation details, comparison with ice assembly behavior under uniform degradation, and videos of the experiments.
  21. W. F. Brace and J. D. Byerlee, Stick-slip as a mechanism for earthquakes, Science 153, 990 (1966).
  22. J. R. Rice and A. L. Ruina, Stability of steady frictional slipping, J. Appl. Mech. 50, 343 (1983).
  23. N. H. Sleep and M. L. Blanpied, Creep, compaction and the weak rheology of major faults, Nature (London) 359, 687 (1992).
  24. J. Chen, A. R. Niemeijer, and C. J. Spiers, Microphysical modeling of carbonate fault friction at slip rates spanning the full seismic cycle, J. Geophys. Res. 126, e2020JB021024 (2021).
  25. F. Masi and I. Einav, Hydrodynamics of fault gouges from constitutive modelling to the physics of friction, J. Geophys. Res. 130, e2024JB030822 (2025).
  26. W. M. Haynes, CRC Handbook of Chemistry and Physics (CRC Press, Boca Raton, 2016).
  27. S. Dorbolo, F. Ludewig, N. Vandewalle, and C. Laroche, How does an ice block assembly melt? Phys. Rev. E 85, 051310 (2012).
  28. L. Crespo-Parraga, F. Guillard, and I. Einav, Identification of creep-quake cycles in calcareous sands, in Multiscale Processes of Instability, Deformation and Fracturing in Geomaterials, International Workshop on Bifurcation and Degradation in Geomaterials (Springer, Berlin, 2022), pp. 51–58.
  29. E. C. Krug and C. R. Frink, Acid rain on acid soil: A new perspective, Science 221, 520 (1983).
  30. E. E. Alonso and A. Gens, Aznalcóllar dam failure. Part 1: Field observations and material properties, Géotechnique 56, 165 (2006).
  31. B. G. Lottermoser and P. M. Ashley, Tailings dam seepage at the rehabilitated Mary Kathleen uranium mine, Australia, J. Geochem. Explor. 85, 119 (2005).
  32. D. N. Espinoza, S. H. Kim, and J. C. Santamarina, CO2 geological storage–geotechnical implications, KSCE J. Civil Eng. 15, 707 (2011).
  33. A. Frumkin, M. Ezersky, A. Al-Zoubi, E. Akkawi, and A.-R. Abueladas, The Dead Sea sinkhole hazard: Geophysical assessment of salt dissolution and collapse, Geomorphology 134, 102 (2011).
  34. F. Walter, N. Deichmann, and M. Funk, Basal icequakes during changing subglacial water pressures beneath Gornergletscher, Switzerland, J. Glaciol. 54, 511 (2008).
  35. Z. Peng, J. I. Walter, R. C. Aster, A. Nyblade, D. A. Wiens, and S. Anandakrishnan, Antarctic icequakes triggered by the 2010 Maule earthquake in Chile, Nat. Geosci. 7, 677 (2014).

Outline

Information

Phys. Rev. Research 7, L032034– Published 13 August, 2025
  • Received 24 September 2023
  • Accepted 17 July 2025
Crossmark - Check for updates button
Creative Commons Logo

Published by the American Physical Society under the terms of the Creative Commons Attribution 4.0 International license. Further distribution of this work must maintain attribution to the author(s) and the published article's title, journal citation, and DOI.
