Perpendicular growth of a tip-growing polymer precipitate on parallel line-patterned surfaces
Phys. Rev. Research 8, L012005 – Published 7 January, 2026
DOI: https://doi.org/10.1103/c93s-mpwj
Abstract
Growth on surfaces with parallel line patterns typically results in longitudinal alignment, whether in living cells or nonliving crystals. However, unlike many other cells, tip-growing fungal germ tubes grow perpendicular to these line patterns. Here, we show that a recently reported artificial system that mimics the tip growth of germ tubes also exhibits similar perpendicular growth on grooved or ridged surfaces. Our experiments using tip-growing polymer precipitates reveal that the soft growing tip can be partially trapped by substrate patterns, and that the tip can change its growing direction when encountering the surface pattern obliquely. We theoretically rationalize this change in growth direction induced by physical interaction between the soft growing system and the substrate topography. Our physical explanation of the unique growth behavior based on material characteristics without external control suggests a way to achieve embedded physical intelligence in soft mechanical systems interacting with the surrounding objects.
Physics Subject Headings (PhySH)
Article Text
Supplemental Material
References (24)
- A. D. Doyle, F. W. Wang, K. Matsumoto, and K. M. Yamada, One-dimensional topography underlies three-dimensional fibrillar cell migration, J. Cell Biol. 184, 481 (2009).
- P. Clark, P. Connolly, A. S. G. Curtis, J. A. T. Dow, and C. D. W. Wilkinson, Topographical control of cell behaviour: II. Multiple grooved substrata, Development 108, 635 (1990).
- S. Ankam, M. Suryana, L. Y. Chan, A. A. K. Moe, B. K. K. Teo, J. B. K. Law, M. P. Sheetz, H. Y. Low, and E. K. F. Yim, Substrate topography and size determine the fate of human embryonic stem cells to neuronal or glial lineage, Acta Biomater. 9, 4535 (2013).
- S. A. Biela, Y. Su, J. P. Spatz, and R. Kemkemer, Different sensitivity of human endothelial cells, smooth muscle cells and fibroblasts to topography in the nano-micro range, Acta Biomater. 5, 2460 (2009).
- A.-S. Andersson, P. Olsson, U. Lidberg, and D. Sutherland, The effects of continuous and discontinuous groove edges on cell shape and alignment, Exp. Cell Res. 288, 177 (2003).
- K. Mukaddam, M. Astasov-Frauenhoffer, E. Fasler-Kan, L. Marot, M. Kisiel, E. Meyer, J. Köser, M. Waser, M. M. Bornstein, and S. Kühl, Effect of a nanostructured titanium surface on gingival cell adhesion, viability and properties against P. gingivalis, Materials 14, 7686 (2021).
- P.-Y. Wang, H.-T. Yu, and W.-B. Tsai, Modulation of alignment and differentiation of skeletal myoblasts by submicron ridges/grooves surface structure, Biotechnol. Bioeng. 106, 285 (2010).
- J. F. Walsh, M. E. Manwaring, and P. A. Tresco, Directional neurite outgrowth is enhanced by engineered meningeal cell-coated substrates, Tissue Eng. 11, 1085 (2005).
- D. Hoffman-Kim, J. A. Mitchel, and R. V. Bellamkonda, Topography, cell response, and nerve regeneration, Annu. Rev. Biomed. Eng. 12, 203 (2010).
- Y.-X. Ma and X.-D. Wang, Directional self-assembly of organic vertically superposed nanowires, Nat. Commun. 15, 7706 (2024).
- A. Kaneko, Surface micro-/nanostructuring using self-assembly of fine particles, in Micro and Nano Fabrication Technology, edited by J. Yan (Springer, Singapore, 2018), pp. 1–28.
- R. Maheshwari and A. C. Hildebrandt, Directional growth of the urediospore germ tubes and stomatal penetration, Nature (London) 214, 1145 (1967).
- H. C. Hoch, R. C. Staples, B. Whitehead, J. Comeau, and E. D. Wolf, Signaling for growth orientation and cell differentiation by surface topography in Uromyces, Science 235, 1659 (1987).
- T. J. Collins and N. D. Read, Appressorium induction by topographical signals in six cereal rusts, Physiol. Mol. Plant Pathol. 51, 169 (1997).
- N. D. Read, L. J. Kellock, T. J. Collins, and A. M. Gundlach, Role of topography sensing for infection structure differentiation in cereal rust fungi, Planta 202, 163 (1997).
- E. A. Allen, et al., Appressorium formation in response to topographical signals by 27 rust species, Phytopathology 81, 323 (1991).
- C. J. Park, J. Ha, H.-R. Lee, K. Park, J.-Y. Sun, and H.-Y. Kim, Plant cell-like tip-growing polymer precipitate with structurally embedded multistimuli sensing ability, Proc. Natl. Acad. Sci. USA 120, e2211416120 (2023).
- See Supplemental Material at http://link.aps.org/supplemental/10.1103/c93s-mpwj for additional experimental characterizations and detailed derivations of the models.
- N. D. Read, L. J. Kellock, H. Knight, and A. J. Trewavas, Contact sensing during infection by fungal pathogens, in Perspectives in Plant Cell Recognition, edited by J. A. Callow and J. R. Green (Cambridge University Press, Cambridge, UK, 1992), pp. 137–172.
- A. Goriely and M. Tabor, Self-similar tip growth in filamentary organisms, Phys. Rev. Lett. 90, 108101 (2003).
- S. Bartnicki-García, C. E. Bracker, G. Gierz, R. López-Franco, and H. Lu, Mapping the growth of fungal hyphae: Orthogonal cell wall expansion during tip growth and the role of turgor, Biophys. J. 79, 2382 (2000).
- O. Campàs and L. Mahadevan, Shape and dynamics of tip-growing cells, Curr. Biol. 19, 2102 (2009).
- J. Dumais, S. L. Shaw, C. R. Steele, S. R. Long, and P. M. Ray, An anisotropic-viscoplastic model of plant cell morphogenesis by tip growth, Int. J. Dev. Biol. 50, 209 (2006).
- M. Riquelme, J. Aguirre, S. Bartnicki-García, G. H. Braus, M. Feldbrügge, U. Fleig, W. Hansberg, A. Herrera-Estrella, J. Kämper, U. Kück, R. R. Mouriño-Pérez, N. Takeshita, and R. Fischer, Fungal morphogenesis, from the polarized growth of hyphae to complex reproduction and infection structures, Microbiol. Mol. Biol. Rev. 82, e00068-17 (2018).
