Self-propelled particles undergoing cyclic transitions

Ye Zhang and Duanduan Wan*

  • Key Laboratory of Artificial Micro- and Nano-structures of Ministry of Education and School of Physics and Technology, Wuhan University, Wuhan 430072, China

  • *Contact author: ddwan@whu.edu.cn
PDF

Phys. Rev. Research 7, L032040 – Published 21 August, 2025

DOI: https://doi.org/10.1103/bxmn-hzwh

Abstract

Cyclic transitions between active and passive states are central to many natural and synthetic systems, ranging from light-driven active particles to animal migrations. Here, we investigate a minimal model of self-propelled Brownian particles undergoing cyclic transitions across three spatial zones: gain, loss, and neutral regions. Particles become active in the gain region, passive in the loss region, and retain their state in the neutral region. By analyzing the steady-state behavior as a function of particle number and the size of the loss region, we identify a threshold particle number, below and above which distinct structural changes are observed. Interestingly, below this threshold, increasing the particle number reduces the state-switching time (the time required for a particle to transition from active to passive and back to active). In contrast, above the threshold, further increases in particle number result in longer switching times. In the subthreshold regime, our analytical model predicts structural characteristics and switching dynamics that align well with simulations. Above the threshold, we observe an emergent clustering, with particles transitioning from passive to active states in close proximity. These findings provide insights into the collective dynamics of cyclic processes between active and passive states across distinct spatial zones in active matter systems.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (46)

  1. L. H. Cisneros, R. Cortez, C. Dombrowski, R. E. Goldstein, and J. O. Kessler, Fluid dynamics of self-propelled microorganisms, from individuals to concentrated populations, Exp. Fluids 43, 737 (2007).
  2. M. Guix, S. M. Weiz, O. G. Schmidt, and M. Medina-Sánchez, Self-propelled micro/nanoparticle motors, Part. Part. Syst. Charact. 35, 1700382 (2018).
  3. C. Chen, S. Liu, X.-Q. Shi, H. Chaté, and Y. Wu, Weak synchronization and large-scale collective oscillation in dense bacterial suspensions, Nature (London) 542, 210 (2017).
  4. S. Liu, S. Shankar, M. C. Marchetti, and Y. Wu, Viscoelastic control of spatiotemporal order in bacterial active matter, Nature (London) 590, 80 (2021).
  5. H. P. Zhang, A. Be’er, E.-L. Florin, and H. L. Swinney, Collective motion and density fluctuations in bacterial colonies, Proc. Natl. Acad. Sci. USA 107, 13626 (2010).
  6. T. Vicsek, A. Czirók, E. Ben-Jacob, I. Cohen, and O. Shochet, Novel type of phase transition in a system of self-driven particles, Phys. Rev. Lett. 75, 1226 (1995).
  7. G. Grégoire and H. Chaté, Onset of collective and cohesive motion, Phys. Rev. Lett. 92, 025702 (2004).
  8. M. C. Marchetti, J. F. Joanny, S. Ramaswamy, T. B. Liverpool, J. Prost, M. Rao, and R. A. Simha, Hydrodynamics of soft active matter, Rev. Mod. Phys. 85, 1143 (2013).
  9. G. Gompper et al., The 2024 motile active matter roadmap, J. Phys.: Condens. Matter 37, 143501 (2025).
  10. B. Liebchen and D. Levis, Collective behavior of chiral active matter: Pattern formation and enhanced flocking, Phys. Rev. Lett. 119, 058002 (2017).
  11. J.-B. Caussin, A. Solon, A. Peshkov, H. Chaté, T. Dauxois, J. Tailleur, V. Vitelli, and D. Bartolo, Emergent spatial structures in flocking models: A dynamical system insight, Phys. Rev. Lett. 112, 148102 (2014).
  12. I. Buttinoni, J. Bialké, F. Kümmel, H. Löwen, C. Bechinger, and T. Speck, Dynamical clustering and phase separation in suspensions of self-propelled colloidal particles, Phys. Rev. Lett. 110, 238301 (2013).
  13. G. S. Redner, M. F. Hagan, and A. Baskaran, Structure and dynamics of a phase-separating active colloidal fluid, Phys. Rev. Lett. 110, 055701 (2013).
  14. J. Elgeti, R. G. Winkler, and G. Gompper, Physics of microswimmers—single particle motion and collective behavior: A review, Rep. Prog. Phys. 78, 056601 (2015).
  15. C. Bechinger, R. Di Leonardo, H. Löwen, C. Reichhardt, G. Volpe, and G. Volpe, Active particles in complex and crowded environments, Rev. Mod. Phys. 88, 045006 (2016).
  16. M. E. Cates and J. Tailleur, Motility-induced phase separation, Annu. Rev. Condens. Matter Phys. 6, 219 (2015).
  17. P. Digregorio, D. Levis, A. Suma, L. F. Cugliandolo, G. Gonnella, and I. Pagonabarraga, Full phase diagram of active Brownian disks: From melting to motility-induced phase separation, Phys. Rev. Lett. 121, 098003 (2018).
  18. A. K. Omar, K. Klymko, T. GrandPre, and P. L. Geissler, Phase diagram of active Brownian spheres: Crystallization and the metastability of motility-induced phase separation, Phys. Rev. Lett. 126, 188002 (2021).
  19. L. Berthier and J. Kurchan, Non-equilibrium glass transitions in driven and active matter, Nat. Phys. 9, 310 (2013).
  20. G. Szamel, E. Flenner, and L. Berthier, Glassy dynamics of athermal self-propelled particles: Computer simulations and a nonequilibrium microscopic theory, Phys. Rev. E 91, 062304 (2015).
  21. R. Wiese, K. Kroy, and D. Levis, Fluid-glass-jamming rheology of soft active Brownian particles, Phys. Rev. Lett. 131, 178302 (2023).
  22. J. Elgeti and G. Gompper, Wall accumulation of self-propelled spheres, Europhys. Lett. 101, 48003 (2013).
  23. Y. Fily, A. Baskaran, and M. F. Hagan, Dynamics of self-propelled particles under strong confinement, Soft Matter 10, 5609 (2014).
  24. S. Williams, R. Jeanneret, I. Tuval, and M. Polin, Confinement-induced accumulation and de-mixing of microscopic active-passive mixtures, Nat. Commun. 13, 4776 (2022).
  25. C. Liu, C. Zhou, W. Wang, and H. P. Zhang, Bimetallic microswimmers speed up in confining channels, Phys. Rev. Lett. 117, 198001 (2016).
  26. J. Stenhammar, R. Wittkowski, D. Marenduzzo, and M. E. Cates, Activity-induced phase separation and self-assembly in mixtures of active and passive particles, Phys. Rev. Lett. 114, 018301 (2015).
  27. J. Palacci, S. Sacanna, A. P. Steinberg, D. J. Pine, and P. M. Chaikin, Living crystals of light-activated colloidal surfers, Science 339, 936 (2013).
  28. G. Frangipane, D. Dell’Arciprete, S. Petracchini, C. Maggi, F. Saglimbeni, S. Bianchi, G. Vizsnyiczai, M. L. Bernardini, and R. Di Leonardo, Dynamic density shaping of photokinetic E. coli, eLife 7, e36608 (2018).
  29. F. D. C. Farrell, M. C. Marchetti, D. Marenduzzo, and J. Tailleur, Pattern formation in self-propelled particles with density-dependent motility, Phys. Rev. Lett. 108, 248101 (2012).
  30. P. K. Mishra, A. Krishna, and S. Mishra, Active Brownian particles can mimic the pattern of the substrate, Soft Mater. 21, 377 (2023).
  31. M. Rey, G. Volpe, and G. Volpe, Light, matter, action: Shining light on active matter, ACS Photon. 10, 1188 (2023).
  32. M. Dacke, B. el Jundi, Y. Gagnon, A. Yilmaz, M. Byrne, and E. Baird, A dung beetle that path integrates without the use of landmarks, Anim. Cogn. 23, 1161 (2020).
  33. F. C. Lincoln and S. R. Peterson, Migration of Birds (US Fish and Wildlife Service, Washington, 1979).
  34. P. Varuni, S. N. Menon, and G. I. Menon, Phototaxis as a collective phenomenon in cyanobacterial colonies, Sci. Rep. 7, 17799 (2017).
  35. P. K. Ghosh, Y. Li, F. Marchesoni, and F. Nori, Pseudochemotactic drifts of artificial microswimmers, Phys. Rev. E 92, 012114 (2015).
  36. R. H. Luchsinger, Transport in nonequilibrium systems with position-dependent mobility, Phys. Rev. E 62, 272 (2000).
  37. J. A. Anderson, J. Glaser, and S. C. Glotzer, Hoomd-blue: A Python package for high-performance molecular dynamics and hard particle Monte Carlo simulations, Comput. Mater. Sci. 173, 109363 (2020).
  38. X. Yang, M. L. Manning, and M. C. Marchetti, Aggregation and segregation of confined active particles, Soft Matter 10, 6477 (2014).
  39. See Supplemental Material at http://link.aps.org/supplemental/10.1103/bxmn-hzwh for details.
  40. M. Bruna and S. J. Chapman, Excluded-volume effects in the diffusion of hard spheres, Phys. Rev. E 85, 011103 (2012).
  41. M. Bruna and S. J. Chapman, Diffusion of multiple species with excluded-volume effects, J. Chem. Phys. 137, 204116 (2012).
  42. J. Stenhammar, A. Tiribocchi, R. J. Allen, D. Marenduzzo, and M. E. Cates, Continuum theory of phase separation kinetics for active Brownian particles, Phys. Rev. Lett. 111, 145702 (2013).
  43. W. Hess and R. Klein, Generalized hydrodynamics of systems of Brownian particles, Adv. Phys. 32, 173 (1983).
  44. J. M. Lahtinen, T. Hjelt, T. Ala-Nissila, and Z. Chvoj, Diffusion of hard disks and rodlike molecules on surfaces, Phys. Rev. E 64, 021204 (2001).
  45. D. Henderson, A simple equation of state for hard discs, Mol. Phys. 30, 971 (1975).
  46. https://github.com/zhangyemayapro/gainloss-ABP.
