Partial persistence of memory in bubble breakup: Incomplete universality acquired by broken symmetry

Ikumi Yoshino and Ko Okumura*

  • Physics Department and Soft Matter Center, Ochanomizu University, 2-1-1 Ohtsuka, Bunkyo-ku, Tokyo 112-8610, Japan

  • *Contact author: okumura@phys.ocha.ac.jp
PDF

Phys. Rev. Research 7, 043346 – Published 30 December, 2025

DOI: https://doi.org/10.1103/bv7m-my1m

Abstract

When a water drop falls from a faucet, the drop is created with the formation of an axisymmetric constriction region, which thins down to breakup. Such formation of a fluid drop has been extensively studied as a representative of the singular dynamics widely observed in nature. The singular dynamics is often self-similar, i.e., shapes at different times collapsing onto a master curve after rescaling, and the self-similar dynamics has been categorized as either “universal” or “nonuniversal”: The master curve is independent of or dependent on the length scales that set the initial boundary conditions, as if memory is erased or retained. Here, we focus on the post-breakup dynamics and confine the system to break the axisymmetry, introducing three length scales, which leads to a third category: “incomplete universality” where memory is partially retained: The master curve could be dependent on the smallest scale but independent of the other two scales. The fact that only the smallest length scale can affect the shape of the master curve suggests that scale separation is deeply related to the emergence of universality. The present study suggests a promising direction for the study on the singular dynamics by exploring the symmetry.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (28)

  1. M. W. Choptuik, Universality and scaling in gravitational collapse of a massless scalar field, Phys. Rev. Lett. 70, 9 (1993).
  2. X. D. Shi, M. P. Brenner, and S. R. Nagel, A cascade of structure in a drop falling from a faucet, Science 265, 219 (1994).
  3. T. Koike, T. Hara, and S. Adachi, Critical behavior in gravitational collapse of radiation fluid: A renormalization group (linear perturbation) analysis, Phys. Rev. Lett. 74, 5170 (1995).
  4. G. I. Barenblatt, Scaling, Self-Similarity, and Intermediate Asymptotics (Consultants Bureau, New York, 1979).
  5. G. I. Barenblatt, Scaling (Cambridge University Press, 2003), Vol. 34.
  6. J. Eggers and M. A. Fontelos, Singularities: Formation, Structure, and Propagation (Cambridge University Press, 2015), Vol. 53.
  7. B. W. Zeff, B. Kleber, J. Fineberg, and D. P. Lathrop, Singularity dynamics in curvature collapse and jet eruption on a fluid surface, Nature (London) 403, 401 (2000).
  8. I. Cohen and S. R. Nagel, Scaling at the selective withdrawal transition through a tube suspended above the fluid surface, Phys. Rev. Lett. 88, 074501 (2002).
  9. M. Yokota and Ko Okumura, Dimensional crossover in the coalescence dynamics of viscous drops confined in between two plates, Proc. Natl. Acad. Sci. USA 108, 6395 (2011).
  10. J. F. Hernández-Sánchez, L. A. Lubbers, A. Eddi, and J. H. Snoeijer, Symmetric and asymmetric coalescence of drops on a substrate, Phys. Rev. Lett. 109, 184502 (2012).
  11. P. R. Kaneelil, A. A. Pahlavan, N. Xue, and H. A. Stone, Three-dimensional self-similarity of coalescing viscous drops in the thin-film regime, Phys. Rev. Lett. 129, 144501 (2022).
  12. J. Eggers, Universal pinching of 3D axisymmetric free-surface flow, Phys. Rev. Lett. 71, 3458 (1993).
  13. P. Doshi, I. Cohen, W. W. Zhang, M. Siegel, P. Howell, O. A. Basaran, and S. R. Nagel, Persistence of memory in drop breakup: The breakdown of universality, Science 302, 1185 (2003).
  14. A. A. Pahlavan, H. A. Stone, G. H. McKinley, and R. Juanes, Restoring universality to the pinch-off of a bubble, Proc. Natl. Acad. Sci. USA 116, 13780 (2019).
  15. H. Nakazato, Y. Yamagishi, and Ko Okumura, Self-similar dynamics of air film entrained by a solid disk in confined space: A simple prototype of topological transitions, Phys. Rev. Fluids 3, 054004 (2018).
  16. Ko Okumura, A renormalization group analysis of bubble breakup, Sci. Rep. 15, 34507 (2025).
  17. H. Nakazato and Ko Okumura, Air entrained into viscous liquid by a disk: Confinement induced suppression of breakup, Phys. Rev. Res. 4, 013150 (2022).
  18. S. Ii and K. Okumura, Breakup to non-breakup transition of air entrained into viscous liquid by a disk: analogy of the self-similar dynamics with critical phenomena, arXiv:2405.03006.
  19. J. Cardy, Scaling and Renormalization in Statistical Physics (Cambridge University Press Cambridge, 1996).
  20. N. Goldenfeld, Lectures on Phase Transitions and the Renormalization Group (Addison-Wesley Publishing Company, 1992).
  21. P. G. De Gennes and P. G. Gennes, Scaling Concepts in Polymer Physics (Cornell University Press, 1979).
  22. R. Livi and P. Politi, Nonequilibrium Statistical Physics: A Modern Perspective (Cambridge University Press, 2017).
  23. A. Altland and B. D. Simons, Condensed Matter Field Theory (Cambridge University Press, 2023).
  24. J. Tailleur, G. Gompper, M. C. Marchetti, J. M. Yeomans, and C. Salomon, Active Matter and Nonequilibrium Statistical Physics: Lecture Notes of the Les Houches Summer School, 2018 (Oxford University Press, 2022), Vol. 112.
  25. A. Parmigiani, S. Faroughi, C. Huber, O. Bachmann, and Y. Su, Bubble accumulation and its role in the evolution of magma reservoirs in the upper crust, Nature (London) 532, 492 (2016).
  26. H. A. Stone, A. D. Stroock, and A. Ajdari, Engineering flows in small devices, Annu. Rev. Fluid Mech. 36, 381 (2004).
  27. S. Shad, M. Salarieh, B. Maini, and I. D. Gates, The velocity and shape of convected elongated liquid drops in narrow gaps, J. Pet. Sci. Eng. 72, 67 (2010).
  28. S. L. Anna, Droplets and bubbles in microfluidic devices, Annu. Rev. Fluid Mech. 48, 285 (2016).

Outline

Information

Phys. Rev. Research 7, 043346– Published 30 December, 2025
  • Received 10 September 2024
  • Accepted 24 November 2025
Crossmark - Check for updates button
Creative Commons Logo

Published by the American Physical Society under the terms of the Creative Commons Attribution 4.0 International license. Further distribution of this work must maintain attribution to the author(s) and the published article's title, journal citation, and DOI.
