Green’s function theory of magnetism in Bi2CuO4: Anisotropic Heisenberg XYZ model

R. O. Kuzian1,2,* and E. E. Krasovskii1,3,4

  • *Contact author: r.kuzian@ipms.kyiv.ua
PDF

Phys. Rev. Research 8, 033136 – Published 4 August, 2026

DOI: https://doi.org/10.1103/bn1b-mt34

Abstract

The Green’s function theory of Lymar’ and Rudoi [Theor. Math. Phys. 21, 990 (1974)] is generalized to the case of multiple intra- and intersublattice magnetic interactions in a collinear spin-half antiferromagnet and applied to magnetic excitations in Bi2CuO4. The spin Hamiltonian includes both the out-of-plane and in-plane symmetric anisotropy terms and the Zeeman term, which describes the interaction with an external magnetic field B applied along the Néel vector. Within the spin-wave approximation, we calculate spin excitation dispersion, antiferromagnetic resonance frequencies, and the critical field Bc of the spin-flop metamagnetic transition. A weak in-plane anisotropy is shown to result in a gap in the acousticlike branch of the excitations. The gap nonlinearly depends on the external field and closes at B=Bc. An expression for the Néel temperature in the Tyablikov random phase approximation at zero field is derived. For the parameters derived from the recent inelastic neutron scattering study by Yuan et al. [Phys. Rev. B 103, 134436 (2021)], it gives TN≈52K.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (55)

  1. N. Plakida, High-Temperature Cuprate Superconductors: Experiment, Theory, and Applications (Springer, Berlin, 2010).
  2. S.-D. Chen, M. Hashimoto, Y. He, D. Song, K.-J. Xu, J.-F. He, T. P. Devereaux, H. Eisaki, D.-H. Lu, J. Zaanen, and Z.-X. Shen, Incoherent strange metal sharply bounded by a critical doping in Bi2212, Science 366, 1099 (2019).
  3. T. Li, A short review of the recent progresses in the study of the cuprate superconductivity, Chin. Phys. B 30, 100508 (2021).
  4. V. V. Val’kov, D. M. Dzebisashvili, M. M. Korovushkin, and A. F. Barabanov, Spin-polaron concept in the theory of normal and superconducting states of cuprates, Phys. Usp. 64, 641 (2021).
  5. J. A. Sobota, Y. He, and Z.-X. Shen, Angle-resolved photoemission studies of quantum materials, Rev. Mod. Phys. 93, 025006 (2021).
  6. B. Bacq-Labreuil, B. Lacasse, A.-M. S. Tremblay, D. Sénéchal, and K. Haule, Toward an ab initio theory of high-temperature superconductors: A study of multilayer cuprates, Phys. Rev. X 15, 021071 (2025).
  7. J. Schlappa, K. Wohlfeld, K. J. Zhou, M. Mourigal, M. W. Haverkort, V. N. Strocov, L. Hozoi, C. Monney, S. Nishimoto, S. Singh, A. Revcolevschi, J.-S. Caux, L. Patthey, H. M. Rønnow, J. van den Brink, and T. Schmitt, Spin–orbital separation in the quasi-one-dimensional Mott insulator Sr2CuO3, Nature (London) 485, 82 (2012).
  8. J. Schlappa, U. Kumar, K. J. Zhou, S. Singh, M. Mourigal, V. N. Strocov, A. Revcolevschi, L. Patthey, H. M. Rønnow, S. Johnston, and T. Schmitt, Probing multi-spinon excitations outside of the two-spinon continuum in the antiferromagnetic spin chain cuprate Sr2CuO3, Nat. Commun. 9, 5394 (2018).
  9. Z. Chen, Y. Wang, S. N. Rebec, T. Jia, M. Hashimoto, D. Lu, B. Moritz, R. G. Moore, T. P. Devereaux, and Z.-X. Shen, Anomalously strong near-neighbor attraction in doped 1D cuprate chains, Science 373, 1235 (2021).
  10. S.-L. Drechsler, J. Richter, R. Kuzian, J. Málek, N. Tristan, B. Büchner, A. Moskvin, A. Gippius, A. Vasiliev, O. Volkova, A. Prokofiev, H. Rakoto, J.-M. Broto, W. Schnelle, M. Schmitt, A. Ormeci, C. Loison, and H. Rosner, Helimagnetism and weak ferromagnetism in edge-shared chain cuprates, J. Magn. Magn. Mater. 316, 306 (2007).
  11. S. Nishimoto, S.-L. Drechsler, R. Kuzian, J. Richter, and J. van den Brink, Interplay of interchain interactions and exchange anisotropy: Stability and fragility of multipolar states in spin-12 quasi-one-dimensional frustrated helimagnets, Phys. Rev. B 92, 214415 (2015).
  12. S. Johnston, C. Monney, V. Bisogni, K.-J. Zhou, R. Kraus, G. Behr, V. N. Strocov, J. Málek, S.-L. Drechsler, J. Geck, T. Schmitt, and J. van den Brink, Electron-lattice interactions strongly renormalize the charge-transfer energy in the spin-chain cuprate Li2CuO2, Nat. Commun. 7, 10563 (2016).
  13. C. E. Agrapidis, S.-L. Drechsler, and S. Nishimoto, Self-organized magnon condensation in quasi-one-dimensional edge-shared cuprates without external magnetic field, Phys. Rev. Res. 7, 043051 (2025).
  14. B. Yuan, N. P. Butch, G. Xu, B. Winn, J. P. Clancy, and Y.-J. Kim, Neutron scattering study of magnetic anisotropy in the tetragonal antiferromagnet Bi2CuO4, Phys. Rev. B 103, 134436 (2021).
  15. J.-C. Boivin, D. Thomas, and J. Tréhoux, étude structurale de CuBi2O4, Bull. Minéral. 99, 193 (1976).
  16. J. L. Garcia-Munoz, J. Rodriguez-Carvajal, F. Sapina, M. J. Sanchis, R. Ibanez, and D. Beltran-Porter, Crystal and magnetic structures of Bi2CuO4, J. Phys.: Condens. Matter 2, 2205 (1990).
  17. K. Sreedhar, P. Ganguly, and S. Ramasesha, Investigations on Bi2CuO4: A quasi-one-dimensional oxide system, J. Phys. C 21, 1129 (1988).
  18. J. P. Attfield, Exchange striction and exchange constants in Bi2CuO4, J. Phys.: Condens. Matter 1, 7045 (1989).
  19. R. Troc, J. Janicki, I. Filatow, P. Fischer, and A. Murasik, Three-dimensional magnetic properties of Bi2CuO4, J. Phys.: Condens. Matter 2, 6989 (1990).
  20. E. W. Ong, G. H. Kwei, R. A. Robinson, B. L. Ramakrishna, and R. B. Von Dreele, Long-range antiferromagnetic ordering in Bi2CuO4, Phys. Rev. B 42, 4255 (1990).
  21. K. Yamada, K.-i. Takada, S. Hosoya, Y. Watanabe, Y. Endoh, N. Tomonaga, T. Suzuki, T. Ishigaki, T. Kamiyama, H. Asano, and F. Izumi, Three-dimensional antiferromagnetic order and anisotropic magnetic properties in Bi2CuO4, J. Phys. Soc. Jpn. 60, 2406 (1991).
  22. J. Konstantinovic, G. Stanisic, M. Ain, and G. Parette, On the magnetic structure of Bi2CuO4, J. Phys.: Condens. Matter 3, 381 (1991).
  23. M. Aïn, G. Dhalenne, O. Guiselin, B. Hennion, and A. Revcolevschi, Magnon dispersion curve of antiferromagnetic Bi2CuO4, Phys. Rev. B 47, 8167 (1993).
  24. B. Roessli, P. Fischer, A. Furrer, G. Petrakovskii, K. Sablina, V. Valkov, and B. Fedoseev, Magnetic neutron scattering in single crystal Bi2CuO4, J. Appl. Phys. 73, 6448 (1993).
  25. B. Roessli, B. Fåk, M.-T. Fernández-Díaz, K. Sablina, and G. Petrakovskii, Polarization analysis of spin waves in Bi2CuO4, Physica B 234–236, 726 (1997).
  26. O. Janson, R. O. Kuzian, S.-L. Drechsler, and H. Rosner, Electronic structure and magnetic properties of the spin-1/2 Heisenberg magnet Bi2CuO4, Phys. Rev. B 76, 115119 (2007).
  27. M. J. Konstantinovic, Z. V. Popovic, S. D. Devic, A. Revcolevschi, and G. Dhalenne, Light scattering by magnons in Bi2CuO4 single crystals, J. Phys.: Condens. Matter 4, 7913 (1992).
  28. M. J. Konstantinovic and Z. V. Popovic, Effects of magnetic ordering on Raman scattering spectra of Bi2CuO4, J. Phys.: Condens. Matter 6, 10357 (1994).
  29. M. J. Konstantinović, Z. Konstantinović, and Z. V. Popović, Two-magnon light scattering in Bi2CuO4, Phys. Rev. B 54, 68 (1996).
  30. H. Ohta, K. Yoshida, T. Matsuya, T. Nanba, M. Motokawa, K. Yamada, Y. Endoh, and S. Hosoya, EPR and AFMR of Bi2CuO4 in submillimeter wave region, J. Phys. Soc. Jpn. 61, 2921 (1992).
  31. A. Pankrats, G. Petrakovskii, and K. Sablina, Microwave resonance absorption in antiferromagnet Bi2CuO4, Solid State Commun. 91, 121 (1994).
  32. A. Pankrats, D. Sobyanin, A. Vorotinov, and G. Petrakovskii, Antiferromagnetic resonance in Bi2CuO4 single crystals, Solid State Commun. 109, 263 (1998).
  33. H. Ohta, Y. Ikeuchi, S. Kimura, S. Okubo, H. Nojiri, M. Motokawa, S. Hosoya, K. Yamada, and Y. Endoh, High field AFMR measurement of Bi2CuO4, Physica B 246–247, 557 (1998).
  34. M. Herak, M. Miljak, G. Dhalenne, and A. Revcolevschi, Easy plane anisotropy in Bi2CuO4, J. Phys.: Condens. Matter 22, 026006 (2010).
  35. L. Zhao, H. Guo, W. Schmidt, K. Nemkovski, M. Mostovoy, and A. C. Komarek, Magnetically induced ferroelectricity in Bi2CuO4, Phys. Rev. B 96, 054424 (2017).
  36. K. Kimura, Y. Otake, and T. Kimura, Visualizing rotation and reversal of the Néel vector through antiferromagnetic trichroism, Nat. Commun. 13, 697 (2022).
  37. T. Miyamoto, M. Tsujii, T. Kubo, N. Takamura, J. Zhang, R. Ikeda, Y. Otake, K. Kimura, T. Kimura, and H. Okamoto, Control of nonreciprocal directional dichroism in Bi2CuO4 using electric and magnetic fields of an intense terahertz pulse, Phys. Rev. Lett. 135, 216903 (2025).
  38. D. N. Zubarev, Double-time Green functions in statistical physics, Sov. Phys. Usp. 3, 320 (1960).
  39. S. V. Tyablikov, Methods in the Quantum Theory of Magnetism (Springer, New York, 1967).
  40. D. Zubarev, V. Morozov, and G. Röpke, Statistical Mechanics of Nonequilibrium Processes (Akademie, Berlin, 1996), p. 375.
  41. Y. G. Rudoy, The Bogoliubov-Tyablikov Green’s function method in the quantum theory of magnetism, Theor. Math. Phys. 168, 1318 (2011).
  42. V. I. Lymar’ and Y. G. Rudoi, Spectrum and correlation functions of an anisotropic Heisenberg antiferromagnet, Theor. Math. Phys. 21, 990 (1974).
  43. J. Feder and E. Pytte, Low-temperature behavior of the anisotropic Heisenberg antiferromagnet in the neighborhood of the magnetic phase boundaries, Phys. Rev. 168, 640 (1968).
  44. S. V. Tyablikov, Lagging and anticipating Green functions in the theory of ferromagnetism., Ukr. Math. J. 11, 287 (1959).
  45. F. Bloch, Zur theorie des ferromagnetismus, Z. Phys. 61, 206 (1930).
  46. J. C. Slater, Cohesion in monovalent metals, Phys. Rev. 35, 509 (1930).
  47. T. Holstein and H. Primakoff, Field dependence of the intrinsic domain magnetization of a ferromagnet, Phys. Rev. 58, 1098 (1940).
  48. N. Bogoliubov, Lectures on Quantum Statistics (Gordon and Breach Science Publishers, New York, London, Paris, 1967), Vol. 1.
  49. T. Oguchi, Theory of spin-wave interactions in ferro- and antiferromagnetism, Phys. Rev. 117, 117 (1960).
  50. T. Oguchi, Critical behavior of the spin system with anisotropic exchange interactions. I., J. Phys. Soc. Jpn. 30, 988 (1971).
  51. S. Toth and B. Lake, Linear spin wave theory for single-Q incommensurate magnetic structures, J. Phys.: Condens. Matter 27, 166002 (2015).
  52. N. Bogolubov, On the theory of superfluidity, J. Phys. (USSR) 11, 23 (1947), also reprinted in D. Pines, The Many-Body Problem (W.A. Benjamin, Inc., New York, 1961), p. 292.
  53. J. Colpa, Diagonalization of the quadratic boson Hamiltonian, Physica A 93, 327 (1978).
  54. E. Manousakis, The spin-½ Heisenberg antiferromagnet on a square lattice and its application to the cuprous oxides, Rev. Mod. Phys. 63, 1 (1991).
  55. P. Rosenberg and E. Manousakis, Quantum Weyl-Heisenberg antiferromagnet, Phys. Rev. B 108, 214431 (2023).
