Directional transport and nonlinear localization of light in a one-dimensional driven-dissipative photonic lattice

Tony Mathew Blessan1, Bastián Real2, Camille Druelle1,3, Clarisse Fournier1, Alberto Muñoz de las Heras4, Alejandro González-Tudela4, Isabelle Sagnes5, Abdelmounaim Harouri5, Luc Le Gratiet5 et al.

Aristide Lemaître5, Sylvain Ravets5, Jacqueline Bloch5, Clément Hainaut1, and Alberto Amo1,*

  • *Contact author: alberto.amo-garcia@univ-lille.fr
PDF

Phys. Rev. Research 7, 033283 – Published 25 September, 2025

DOI: https://doi.org/10.1103/b3wk-r8r3

Abstract

Photonic lattices facilitate band structure engineering, supporting both localized and extended modes through their geometric design. However, greater control over these modes can be achieved by taking advantage of the interference effect between external drives with precisely tuned phases and photonic modes within the lattice. In this work, we build on this principle to demonstrate optical switching, directed light propagation, and site-specific localization in a one-dimensional photonic lattice of coupled microresonators by resonantly driving the system with a coherent field of controlled phase. Importantly, our experimental results provide direct evidence that increased driving power acts as a tuning parameter enabling nonlinear localization at frequencies previously inaccessible in the linear regime. These findings open different avenues for controlling light propagation and localization in lattices with more elaborate band structures.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (47)

  1. I. L. Garanovich, S. Longhi, A. A. Sukhorukov, and Y. S. Kivshar, Light propagation and localization in modulated photonic lattices and waveguides, Phys. Rep. 518, 1 (2012).
  2. E. Yablonovitch, Photonic band-gap structures, J. Opt. Soc. Am. B 10, 283 (1993).
  3. J. D. Joannopoulos, S. G. Johnson, J. N. Winn, and R. D. Meade, Photonic Crystals: Molding the Flow of Light (Princeton University Press, Princeton, 2008).
  4. B. A. Bell, K. Wang, A. S. Solntsev, D. N. Neshev, A. A. Sukhorukov, and B. J. Eggleton, Spectral photonic lattices with complex long-range coupling, Optica 4, 1433 (2017).
  5. A. Amo and J. Bloch, Exciton-polaritons in lattices: A non-linear photonic simulator, C. R. Phys. 17, 934 (2016).
  6. T. Ozawa, H. M. Price, A. Amo, N. Goldman, M. Hafezi, L. Lu, M. C. Rechtsman, D. Schuster, J. Simon, O. Zilberberg et al., Topological photonics, Rev. Mod. Phys. 91, 015006 (2019).
  7. M. Kremer, L. J. Maczewsky, M. Heinrich, and A. Szameit, Topological effects in integrated photonic waveguide structures, Opt. Mater. Express 11, 1014 (2021).
  8. O. Painter, J. Vučković, and A. Scherer, Defect modes of a two-dimensional photonic crystal in an optically thin dielectric slab, J. Opt. Soc. Am. B 16, 275 (1999).
  9. T. Schwartz, G. Bartal, S. Fishman, and M. Segev, Transport and anderson localization in disordered two-dimensional photonic lattices, Nature (London) 446, 52 (2007).
  10. I. D. Vatnik, A. Tikan, G. Onishchukov, D. V. Churkin, and A. A. Sukhorukov, Anderson localization in synthetic photonic lattices, Sci. Rep. 7, 4301 (2017).
  11. R. A. Vicencio, C. Cantillano, L. Morales-Inostroza, B. Real, C. Mejía-Cortés, S. Weimann, A. Szameit, and M. I. Molina, Observation of localized states in Lieb photonic lattices, Phys. Rev. Lett. 114, 245503 (2015).
  12. S. Mukherjee, A. Spracklen, D. Choudhury, N. Goldman, P. Öhberg, E. Andersson, and R. R. Thomson, Observation of a localized flat-band state in a photonic Lieb lattice, Phys. Rev. Lett. 114, 245504 (2015).
  13. D. Leykam and S. Flach, Perspective: photonic flatbands, APL Photonics 3, 070901 (2018).
  14. D. N. Christodoulides, F. Lederer, and Y. Silberberg, Discretizing light behaviour in linear and nonlinear waveguide lattices, Nature (London) 424, 817 (2003).
  15. O. Jamadi, B. Real, K. Sawicki, C. Hainaut, A. González-Tudela, N. Pernet, I. Sagnes, M. Morassi, A. Lemaitre, L. Le Gratiet et al., Reconfigurable photon localization by coherent drive and dissipation in photonic lattices, Optica 9, 706 (2022).
  16. A. González-Tudela, Connecting steady-states of driven-dissipative photonic lattices with spontaneous collective emission phenomena, New J. Phys. 24, 043001 (2022).
  17. A. Muñoz de las Heras, A. Amo, and A. González-Tudela, Nonlinearity-enabled localization in driven-dissipative photonic lattices, Phys. Rev. A 109, 063523 (2024).
  18. G. Usaj, Localization engineering by resonant driving in dissipative polariton arrays, SciPost Phys. Core 7, 052 (2024).
  19. B. Real, P. Solano, and C. Hermann-Avigliano, Controlling directional propagation in driven two-dimensional photonic lattices, Opt. Express 32, 47458 (2024).
  20. I. Salinas, J. C. Cornejo, A. Szameit, P. Solano, and R. A. Vicencio, Harnessing collective radiative phenomena on a photonic Kagome lattice, APL Photonics 9, 020801 (2024).
  21. N. Pernet, P. St-Jean, D. D. Solnyshkov, G. Malpuech, N. Carlon Zambon, Q. Fontaine, B. Real, O. Jamadi, A. Lemaître, M. Morassi et al., Gap solitons in a one-dimensional driven-dissipative topological lattice, Nat. Phys. 18, 678 (2022).
  22. N. Englebert, N. Goldman, M. Erkintalo, N. Mostaan, S.-P. Gorza, F. Leo, and J. Fatome, Bloch oscillations of coherently driven dissipative solitons in a synthetic dimension, Nat. Phys. 19, 1014 (2023).
  23. C.-E. Bardyn, T. Karzig, G. Refael, and T. C. H. Liew, Chiral Bogoliubov excitations in nonlinear bosonic systems, Phys. Rev. B 93, 020502 (2016).
  24. S. Ravets, N. Pernet, N. Mostaan, N. Goldman, and J. Bloch, Thouless pumping in a driven-dissipative Kerr resonator array, Phys. Rev. Lett. 134, 093801 (2025).
  25. H. Pichler, T. Ramos, A. J. Daley, and P. Zoller, Quantum optics of chiral spin networks, Phys. Rev. A 91, 042116 (2015).
  26. T. Ramos, B. Vermersch, P. Hauke, H. Pichler, and P. Zoller, Non-Markovian dynamics in chiral quantum networks with spins and photons, Phys. Rev. A 93, 062104 (2016).
  27. A. González-Tudela and J. I. Cirac, Quantum emitters in two-dimensional structured reservoirs in the nonperturbative regime, Phys. Rev. Lett. 119, 143602 (2017).
  28. A. González-Tudela and F. Galve, Anisotropic quantum emitter interactions in two-dimensional photonic-crystal baths, ACS Photonics 6, 221 (2019).
  29. A. González-Tudela, C. S. Muñoz, and J. Cirac, Engineering and harnessing giant atoms in high-dimensional baths: A proposal for implementation with cold atoms, Phys. Rev. Lett. 122, 203603 (2019).
  30. B. Kannan, A. Almanakly, Y. Sung, A. Di Paolo, D. A. Rower, J. Braumüller, A. Melville, B. M. Niedzielski, A. Karamlou, K. Serniak, A. Vepsäläinen, M. E. Schwartz, J. L. Yoder, R. Winik, J. I.-J. Wang, T. P. Orlando, S. Gustavsson, J. A. Grover, and W. D. Oliver, On-demand directional microwave photon emission using waveguide quantum electrodynamics, Nat. Phys. 19, 394 (2023).
  31. M. Bello, G. Platero, J. I. Cirac, and A. González-Tudela, Unconventional quantum optics in topological waveguide QED, Sci. Adv. 5, eaaw0297 (2019).
  32. L. Leonforte, A. Carollo, and F. Ciccarello, Vacancy-like dressed states in topological waveguide QED, Phys. Rev. Lett. 126, 063601 (2021).
  33. E. Kim, X. Zhang, V. S. Ferreira, J. Banker, J. K. Iverson, A. Sipahigil, M. Bello, A. González-Tudela, M. Mirhosseini, and O. Painter, Quantum electrodynamics in a topological waveguide, Phys. Rev. X 11, 011015 (2021).
  34. C. Joshi, F. Yang, and M. Mirhosseini, Resonance fluorescence of a chiral artificial atom, Phys. Rev. X 13, 021039 (2023).
  35. T. Jacqmin, I. Carusotto, I. Sagnes, M. Abbarchi, D. Solnyshkov, G. Malpuech, E. Galopin, A. Lemaître, J. Bloch, and A. Amo, Direct observation of dirac cones and a flatband in a honeycomb lattice for polaritons, Phys. Rev. Lett. 112, 116402 (2014).
  36. F. Baboux, L. Ge, T. Jacqmin, M. Biondi, E. Galopin, A. Lemaître, L. Le Gratiet, I. Sagnes, S. Schmidt, H. E. Türeci et al., Bosonic condensation and disorder-induced localization in a flat band, Phys. Rev. Lett. 116, 066402 (2016).
  37. C. Whittaker, E. Cancellieri, P. Walker, D. Gulevich, H. Schomerus, D. Vaitiekus, B. Royall, D. Whittaker, E. Clarke, I. Iorsh et al., Exciton polaritons in a two-dimensional Lieb lattice with spin-orbit coupling, Phys. Rev. Lett. 120, 097401 (2018).
  38. S. Rodriguez, A. Amo, I. Sagnes, L. Le Gratiet, E. Galopin, A. Lemaître, and J. Bloch, Interaction-induced hopping phase in driven-dissipative coupled photonic microcavities, Nat. Commun. 7, 11887 (2016).
  39. F. Mangussi, M. Milićević, I. Sagnes, L. Le Gratiet, A. Harouri, A. Lemaître, J. Bloch, A. Amo, and G. Usaj, Multi-orbital tight binding model for cavity-polariton lattices, J. Phys.: Condens. Matter 32, 315402 (2020).
  40. See Supplemental Material at http://link.aps.org/supplemental/10.1103/b3wk-r8r3 for further data on the directional transport, an analytical derivation of the intensity profiles, and a numerical study on the effects of disorder.
  41. I. Carusotto and C. Ciuti, Probing microcavity polariton superfluidity through resonant Rayleigh scattering, Phys. Rev. Lett. 93, 166401 (2004).
  42. I. Frérot, A. Vashisht, M. Morassi, A. Lemaître, S. Ravets, J. Bloch, A. Minguzzi, and M. Richard, Bogoliubov excitations driven by thermal lattice phonons in a quantum fluid of light, Phys. Rev. X 13, 041058 (2023).
  43. M. Richard, I. Frérot, S. Ravets, J. Bloch, C. Anton-Solanas, F. Claude, Y. Zhou, M. Morassi, A. Lemaître, I. Carusotto, and A. A. Minguzzi, Excitonic oscillator-strength saturation dominates polariton-polariton interactions, arXiv:2501.07899.
  44. P. Lodahl, A. Floris van Driel, I. S. Nikolaev, A. Irman, K. Overgaag, D. Vanmaekelbergh, and W. L. Vos, Controlling the dynamics of spontaneous emission from quantum dots by photonic crystals, Nature (London) 430, 654 (2004).
  45. Y. Lahini, A. Avidan, F. Pozzi, M. Sorel, R. Morandotti, D. N. Christodoulides, and Y. Silberberg, Anderson localization and nonlinearity in one-dimensional disordered photonic lattices, Phys. Rev. Lett. 100, 013906 (2008).
  46. Y. Lahini, R. Pugatch, F. Pozzi, M. Sorel, R. Morandotti, N. Davidson, and Y. Silberberg, Observation of a localization transition in quasiperiodic photonic lattices, Phys. Rev. Lett. 103, 013901 (2009).
  47. The datasets correspoding to the figures of this article are available at DOI: 10.57745/jhi4l8.
