Heat-dissipation decomposition and free-energy generation in a nonequilibrium dot with multiple electron states

Chloe Salhani, Kensaku Chida, Takase Shimizu, and Toshiaki Hayashi

Katsuhiko Nishiguchi*

  • *Contact author: nishiguchi-katsuhiko-kr@ynu.ac.jp
PDF

Phys. Rev. Research 8, 023209 – Published 26 May, 2026

DOI: https://doi.org/10.1103/947j-vvk2

Abstract

We experimentally demonstrate the decomposition of heat dissipation during free-energy generation in a nanometer-scale dot transitioning to a nonequilibrium steady state via single-electron counting statistics. An alternating-current signal driving a reservoir that injects multiple electrons into the dot makes it nonequilibrium, leading to free-energy generation, heat dissipation, and Shannon-entropy production. By analyzing the time-domain probability distributions of multielectron states of the dot, we quantitatively decompose the heat dissipation into housekeeping and excess heats, thereby revealing their direct correlation with free-energy generation. This correlation suggests that the ratio of the generated free energy to the work applied to the dot can potentially reach 0.5 under far-from-equilibrium conditions induced by a large signal, while an efficiency of 0.25 was experimentally achieved. These results establish a quantitative link between decomposed heat dissipation and free-energy generation in a multielectron stochastic system, providing a thermodynamic framework for nonequilibrium electronic devices.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (39)

  1. R. Landauer, Irreversibility and heat generation in the computing process, IBM J. Res. Dev. 5, 183 (1961).
  2. A. Bérut, A. Arakelyan, A. Petrosyan, S. Ciliberto, R. Dillenschneider, and E. Lutz, Experimental verification of Landauer's principle linking information and thermodynamics, Nature (London) 483, 187 (2012).
  3. Y. Jun, M. Gavrilov, and J. Bechhoefer, High-precision test of Landauer's principle in a feedback trap, Phys. Rev. Lett. 113, 190601 (2014).
  4. J. V. Koski, V. F. Maisi, J. P. Pekola, and D. V. Averin, Experimental realization of a Szilard engine with a single electron, Proc. Natl. Acad. Sci. USA 111, 13786 (2014).
  5. A. Bérut, A. Petrosyan, and S. Ciliberto, Information and thermodynamics: Experimental verification of Landauer's erasure principle, J. Stat. Mech. (2015) P06015.
  6. L. Martini, M. Pancaldi, M. Madami, P. Vavassori, G. Gubbiotti, S. Tacchi, F. Hartmann, M. Emmerling, S. Höfling, L. Worschech, and G. Carlotti, Experimental and theoretical analysis of Landauer erasure in nano-magnetic switches of different sizes, Nano Energy 19, 108 (2016).
  7. J. Hong, B. Lambson, S. Dhuey, and J. Bokor, Experimental test of Landauer's principle in single-bit operations on nanomagnetic memory bits, Sci. Adv. 2, e1501492 (2016).
  8. D. Barker, M. Scandi, S. Lehmann, C. Thelander, K. A. Dick, M. Perarnau-Llobet, and V. F. Maisi, Experimental verification of the work fluctuation-dissipation relation, Phys. Rev. Lett. 128, 040602 (2022).
  9. N. Shiraishi, K. Saito, and H. Tasaki, Universal trade-off relation between power and efficiency for heat engines, Phys. Rev. Lett. 117, 190601 (2016).
  10. D. H. Wolpert, The stochastic thermodynamics of computation, J. Phys. A: Math. Theor. 52, 193001 (2019).
  11. K. Proesmans, J. Ehrich, and J. Bechhoefer, Finite-time Landauer principle, Phys. Rev. Lett. 125, 100602 (2020).
  12. J. S. Lee, S. Y. Lee, H. Kwon, and H. Park, Speed limit for a highly irreversible process and tight finite-time Landauer's bound, Phys. Rev. Lett. 129, 120603 (2022).
  13. M. Esposito and C. Van den Broeck, Second law and Landauer principle far from equilibrium, Europhys. Lett. 95, 40004 (2011).
  14. Y. Oono and M. Paniconi, Steady state thermodynamics, Prog. Theor. Phys. Suppl. 130, 29 (1998).
  15. T. Hatano and S.-i. Sasa, Steady-state thermodynamics of Langevin systems, Phys. Rev. Lett. 86, 3463 (2001).
  16. M. Esposito, U. Harbola, and S. Mukamel, Entropy fluctuation theorems in driven open systems: Application to electron counting statistics, Phys. Rev. E 76, 031132 (2007).
  17. K. Yoshimura, A. Kolchinsky, A. Dechant, and S. Ito, Housekeeping and excess entropy production for general nonlinear dynamics, Phys. Rev. Res. 5, 013017 (2023).
  18. U. Seifert, Entropy production along a stochastic trajectory and an integral fluctuation theorem, Phys. Rev. Lett. 95, 040602 (2005).
  19. P. Gaspard, Fluctuation theorem for nonequilibrium reactions, J. Chem. Phys. 120, 8898 (2004).
  20. T. Speck and U. Seifert, Integral fluctuation theorem for the housekeeping heat, J. Phys. A: Math. Gen. 38, L581 (2005).
  21. C. Van den Broeck and M. Esposito, Three faces of the second law. II. Fokker-Planck formulation, Phys. Rev. E 82, 011144 (2010).
  22. M. Esposito and C. Van den Broeck, Three faces of the second law. I. Master equation formulation, Phys. Rev. E 82, 011143 (2010).
  23. D. V. Averin and J. P. Pekola, Statistics of the dissipated energy in driven single-electron transitions, Europhys. Lett. 96, 67004 (2011).
  24. B. Küng, C. Rössler, M. Beck, M. Marthaler, D. S. Golubev, Y. Utsumi, T. Ihn, and K. Ensslin, Irreversibility on the level of single-electron tunneling, Phys. Rev. X 2, 011001 (2012).
  25. O. P. Saira, Y. Yoon, T. Tanttu, M. Möttönen, D. V. Averin, and J. P. Pekola, Test of the Jarzynski and Crooks fluctuation relations in an electronic system, Phys. Rev. Lett. 109, 180601 (2012).
  26. J. P. Pekola and O. P. Saira, Work, free energy and dissipation in voltage driven single-electron transitions, J. Low. Temp. Phys. 169, 70 (2012).
  27. A. Hofmann, V. F. Maisi, C. Rössler, J. Basset, T. Krähenmann, P. Märki, T. Ihn, K. Ensslin, C. Reichl, and W. Wegscheider, Equilibrium free energy measurement of a confined electron driven out of equilibrium, Phys. Rev. B 93, 035425 (2016).
  28. A. Hofmann, V. F. Maisi, J. Basset, C. Reichl, W. Wegscheider, T. Ihn, K. Ensslin, and C. Jarzynski, Heat dissipation and fluctuations in a driven quantum dot, Phys. Status Solidi B 254, 1600546 (2017).
  29. E. H. Trepagnier, C. Jarzynski, F. Ritort, G. E. Crooks, C. J. Bustamante, and J. Liphardt, Experimental test of Hatano and Sasa's nonequilibrium steady-state equality, Proc. Natl. Acad. Sci. USA 101, 15038 (2004).
  30. A. Mounier and A. Naert, The Hatano-Sasa equality: Transitions between steady states in a granular gas, Europhys. Lett. 100, 30002 (2012).
  31. T. Ando and T. Otsu-Hyodo, Nonequilibrium heat dissipation as a probe for detecting wavefront distortion in microscopy, Phys. Rev. Res. 6, 043263 (2024).
  32. K. Nishiguchi, Y. Ono, and A. Fujiwara, Single-electron thermal noise, Nanotechnology 25, 275201 (2014).
  33. P.-A. Carles, K. Nishiguchi, and A. Fujiwara, Deviation from the law of energy equipartition in a small dynamic-random-access memory, Jpn. J. Appl. Phys. 54, 06FG03 (2015).
  34. K. Nishiguchi, C. Koechlin, Y. Ono, A. Fujiwara, H. Inokawa, and H. Yamaguchi, Single-electron-resolution electrometer based on field-effect transistor, Jpn. J. Appl. Phys. 47, 8305 (2008).
  35. K. Nishiguchi, Y. Ono, and A. Fujiwara, Single-electron counting statistics of shot noise in nanowire Si metal-oxide-semiconductor field-effect transistors, Appl. Phys. Lett. 98, 193502 (2011).
  36. C. Salhani, K. Chida, T. Shimizu, T. Hayashi, and K. Nishiguchi, Alternating-current signal sensing beyond cutoff frequency using a single-electron dynamic random access memory, Phys. Rev. Appl. 23, L021001 (2025).
  37. H. A. Kramers, Brownian motion in a field of force and the diffusion model of chemical reactions, Physica 7, 284 (1940).
  38. O. Raz, Y. Subaşı, and C. Jarzynski, Mimicking nonequilibrium steady states with time-periodic driving, Phys. Rev. X 6, 021022 (2016).
  39. A. Datta, P. Pietzonka, and A. C. Barato, Second law for active heat engines, Phys. Rev. X 12, 031034 (2022).
