Creation of highly charged gold ion beam through collisional ionizations in a dense gold plasma driven by a femtosecond petawatt laser

Masayasu Hata1,*, Chang Liu1, James Kevin Koga1, Natsumi Iwata2, Yasuhiko Sentoku2, and Mamiko Nishiuchi1,†

  • *Contact author: hata.masayasu@qst.go.jp
  • †Contact author: nishiuchi.mamiko@qst.go.jp
PDF

Phys. Rev. Research 7, 033200 – Published 29 August, 2025

DOI: https://doi.org/10.1103/8k98-6q48

Abstract

Numerical investigations of the ionization mechanisms in the high-temperature high-density gold plasma formed by a high-contrast high-intensity laser pulse interacting with gold foil are performed to investigate high-efficiency gold ion acceleration with few petawatt (PW)-level laser systems, aiming at producing ≳10 MeV/u gold beams required to serve as an alternative to the front end of a conventional heavy-ion accelerator complex such as an ion source, linac, and drift tube linac. Short-pulse high-intensity laser pulses with a peak intensity of a few times 1022Wcm−2, which is not strong enough to expel Au L-shell electrons by laser field ionization, are shown to sufficiently resistively heat up the target bulk temperature so that collisional ionization by electrons in the plasma can expel L-shell electrons. The resultant highly charged Au ions (∼+72±4) are exposed to the sheath field and accelerated to higher energies of ∼20 MeV/u.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (25)

  1. S. Busold, D. Schumacher, C. Brabetz, D. Jahn, F. Kroll, O. Deppert, U. Schramm, T. E. Cowan, A. Blažević, V. Bagnoud, and M. Roth, Towards highest peak intensities for ultra-short MeV-range ion bunches, Sci. Rep. 5, 12459 (2015).
  2. P. N. Ostroumov and K. W. Shepard, Multiple-charge beam dynamics in an ion linac, Phys. Rev. Spec. Top. Accel. Beams 3, 030101 (2000).
  3. D. Habs, P. G. Thirolf, M. Gross, K. Allinger, J. Bin, A. Henig, D. Kiefer, W. Ma, and J. Schreiber, Introducing the fission–fusion reaction process: using a laser-accelerated Th beam to produce neutron-rich nuclei towards the N = 126 waiting point of the r-process, Appl. Phys. B 103, 471 (2011).
  4. S. Kawata, T. Karino, and A. I. Ogoyski, Review of heavy-ion inertial fusion physics, Matter Radiat. Extremes 1, 89 (2016).
  5. W. Bang, B. J. Albright, P. A. Bradley, D. C. Gautier, S. Palaniyappan, E. L. Vold, M. A. S. Cordoba, C. E. Hamilton, and J. C. Fernández, Visualization of expanding warm dense gold and diamond heated rapidly by laser-generated ion beams, Sci. Rep. 5, 14318 (2015).
  6. J. W. Yoon, Y. G. Kim, I. W. Choi, J. H. Sung, H. W. Lee, S. K. Lee, and C. H. Nam, Realization of laser intensity over 1023W/cm2, Optica 8, 630 (2021).
  7. P. Wang, Z. Gong, S. G. Lee, Y. Shou, Y. Geng, C. Jeon, I. J. Kim, H. W. Lee, J. W. Yoon, J. H. Sung, S. K. Lee, D. Kong, J. Liu, Z. Mei, Z. Cao, Z. Pan, I. W. Choi, X. Yan, C. H. Nam, and W. Ma, Super-heavy ions acceleration driven by ultrashort laser pulses at ultrahigh intensity, Phys. Rev. X 11, 021049 (2021).
  8. F. H. Lindner, E. McCary, X. Jiao, T. M. Ostermayr, R. Roycroft, G. Tiwari, B. M. Hegelich, J. Schreiber, and P. G. Thirolf, En-route to the fission–fusion reaction mechanism: a status update on laser-driven heavy ion acceleration, Plasma Phys. Controlled Fusion 61, 055002 (2019).
  9. M. Nishiuchi, N. P. Dover, M. Hata, H. Sakaki, K. Kondo, H. F. Lowe, T. Miyahara, H. Kiriyama, J. K. Koga, N. Iwata et al., Dynamics of laser-driven heavy-ion acceleration clarified by ion charge states, Phys. Rev. Res. 2, 033081 (2020).
  10. M. Afshari, S. Morris, L. D. Geulig, Z. M. Chitgar, P. Gibbon, P. G. Thirolf, and J. Schreiber, The role of collisional ionization in heavy ion acceleration by high intensity laser pulses, Sci. Rep. 12, 18260 (2022).
  11. S. Augst, D. D. Meyerhofer, D. Strickland, and S. L. Chin, Laser ionization of noble gases by Coulomb-barrier suppression, J. Opt. Soc. Am. B 8, 858 (1991).
  12. S. C. Wilks, W. L. Kruer, M. Tabak, and A. B. Langdon, Absorption of ultra-intense laser pulses, Phys. Rev. Lett. 69, 1383 (1992).
  13. R. Mishra, P. Leblanc, Y. Sentoku, M. S. Wei, and F. N. Beg, Collisional particle-in-cell modeling for energy transport accompanied by atomic processes in dense plasmas, Phys. Plasmas 20, 072704 (2013).
  14. Y. Sentoku and A. J. Kemp, Numerical methods for particle simulations at extreme densities and temperatures: Weighted particles, relativistic collisions and reduced currents, J. Comput. Phys. 227, 6846 (2008).
  15. R. R. Pandit and Y. Sentoku, Higher order terms of radiative damping in extreme intense laser-matter interaction, Phys. Plasmas 19, 073304 (2012).
  16. Y. Sentoku, I. Paraschiv, R. Royle, R. C. Mancini, and T. Johzaki, Kinetic effects and nonlinear heating in intense x-ray-laser-produced carbon plasmas, Phys. Rev. E 90, 051102(R) (2014).
  17. S. Kato, Y. Kishimoto, and J. Koga, Convective amplification of wake field due to self-modulation of a laser pulse induced by field ionization, Phys. Plasmas 5, 292 (1998).
  18. W. Lotz, Electron-impact ionization cross-sections for atoms up to Z = 108, Z. Phys. 232, 101 (1970).
  19. A. Kramida, Yu. Ralchenko, J. Reader, and NIST ASD Team, NIST Atomic Spectra Database (ver. 5.12) (National Institute of Standards and Technology, Gaithersburg, MD, 2024), available online at https://physics.nist.gov/asd (10 July 2025).
  20. G. Ecker and W. Kröll, Lowering of the ionization energy for a plasma in thermodynamic equilibrium, Phys. Fluids 6, 62 (1963).
  21. H.-K. Chung, M. H. Chen, W. L. Morgan, Y. Ralchenko, and R. W. Lee, FLYCHK: Generalized population kinetics and spectral model for rapid spectroscopic analysis for all elements, High Energy Density Phys. 1, 3 (2005).
  22. M. F. Gu, The flexible atomic code, Can. J. Phys. 86, 675 (2008).
  23. A. Bar-Shalom, M. Klapisch, and J. Oreg, HULLAC, an integrated computer package for atomic processes in plasmas, J. Quant. Spectrosc. Radiat. Transfer 71, 169 (2001), Radiative Properties of Hot Dense Matter.
  24. R. R. Pandit, E. Ackad, E. d'Humieres, and Y. Sentoku, Ponderomotive scaling in the radiative damping regime, Phys. Plasmas 24, 103302 (2017).
  25. A. Kon, M. Nishiuchi, Y. Fukuda, K. Kondo, K. Ogura, A. Sagisaka, Y. Miyasaka, N. P. Dover, M. Kando, A. S. Pirozhkov et al., Characterization of the plasma mirror system at the J-KAREN-P facility, High Power Laser Sci. Eng. 10, e25 (2022).
