Enhanced plasma production by ambipolar electric fields in convergent magnetic fields

Kazunori Takahashi1,*, Christine Charles2, Rod W. Boswell2, and Antonella Caldarelli3

  • 1Department of Electrical Engineering, Tohoku University, Sendai 980-8579, Japan
  • 2Space Plasma, Power and Propulsion Laboratory, Research School of Physics, The Australian National University, Canberra ACT 2601, Australia
  • 3Institut de Combustion, Aérothermique, Réactivité et Environnement, CNRS, 45071 Orléans, France

  • *Contact author: kazunori.takahashi.e8@tohoku.ac.jp
PDF

Phys. Rev. Research 8, 023322 – Published 22 June, 2026

DOI: https://doi.org/10.1103/86rf-6dvz

Abstract

Controlled unidirectional remote plasma production in a radio-frequency (rf) plasma source is demonstrated by placing magnetic nozzle throat several tens of centimeters away from the rf antenna, where a local density peak forms near the throat. The experiment indicates that the dominant electron energization mechanism responsible for the density peak in the magnetic nozzle throat is electrostatic electron acceleration driven by a spontaneously formed ambipolar electric field, yielding an energy gain of approximately 5 eV and enhanced remote ionization. These results establish plasma sources driven by spontaneous electrostatic electron acceleration.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (18)

  1. A. Artemyev, O. Agapitov, D. Mourenas, V. Kranoselskikh, V. Shastun, and F. Mozer, Oblique whistler-mode waves in the Earth's inner magnetosphere: Energy distribution, origins, and role in radiation belt dynamics, Space Sci. Rev. 200, 261 (2016).
  2. S. Kurita, Y. Miyoshi, S. Saito, S. Kasahara, Y. Katoh, S. Matsuda, S. Yokota, Y. Kasahara, A. Matsuoka, T. Hori, K. Keika, M. Teramoto, and I. Shinohara, Detection of ultrafast electron energization by whistler-mode chorus waves in the magnetosphere of Earth, Sci. Rep. 15, 992 (2025).
  3. R. Boström, Observation of weak double layers on auroral field lines, IEEE Trans. Plasma Sci. 20, 756 (1992).
  4. R. E. Ergun, Y.-J. Su, L. Andersson, C. W. Carlson, J. P. McFadden, F. S. Mozer, D. L. Newman, M. V. Goldman, and R. J. Strangeway, Direct observation of localized parallel electric fields in a space plasma, Phys. Rev. Lett. 87, 045003 (2001).
  5. D. B. Graves, Plasma processing, IEEE Trans. Plasma Sci. 22, 31 (1994).
  6. H. Conrads and M. Schmidt, Plasma generation and plasma sources, Plasma Sources Sci. Technol. 9, 441 (2000).
  7. A. R. Ellingboe and R. W. Boswell, Capacitive, inductive and helicon-wave modes of operation of a helicon plasma source, Phys. Plasmas 3, 2797 (1996).
  8. A. Bennet, C. Charles, and R. W. Boswell, Non-local plasma generation in a magnetic nozzle, Phys. Plasmas 26, 072107 (2019).
  9. F. Filleul, A. Caldarelli, C. Charles, R. W. Boswell, N. Rattenbury, and J. Cater, Characterization of a new variable magnetic field linear plasma device, Phys. Plasmas 28, 123514 (2021).
  10. K. Takahashi and Y. Teranishi, Characterization of a radiofrequency linear plasma device in uniform and convergent magnetic fields, Plasma Sources Sci. Technol. 32, 125004 (2023).
  11. F. Filleul, A. Caldarelli, K. Takahashi, R. W. Boswell, C. Charles, J. E. Cater, and N. Rattenbury, Helicon waves in a converging-diverging magnetoplasma, Plasma Sources Sci. Technol. 32, 115015 (2023).
  12. A. Caldarelli, R. Andriulli, R. W. Boswell, C. Charles, K. Takahashi, and F. Ponti, Observation of hybrid coupling modes and non-local ionization in an rf plasma source with non-uniform magnetic fields, Phys. Plasmas 33, 053505 (2026).
  13. F. Filleul, A. Caldarelli, R. Boswell, C. Charles, N. Rattenbury, and J. Cater, The role of ion magnetization on plasma generation in a magnetic nozzle rf device, J. Electr. Propul. 1, 20 (2022).
  14. I. D. Sudit and F. F. Chen, rf compensated probes for high-density discharges, Plasma Sources Sci. Technol. 3, 162 (1994).
  15. K. F. Schoenberg, Pulsed electrostatic probes as a diagnostic for transient plasmas, Rev. Sci. Instrum. 49, 1377 (1978).
  16. E. G. Devin, J. Bak, G. U. Rincon, S. Yatom, and Y. Raitses, Measurements of the electron energy distribution function in partially magnetized low temperature plasmas, Phys. Plasmas 33, 033507 (2026).
  17. K. Takahashi, C. Charles, R. W. Boswell, and A. Ando, Thermodynamic analogy for electrons interacting with a magnetic nozzle, Phys. Rev. Lett. 125, 165001 (2020).
  18. M. A. Lieberman and A. J. Lichtenberg, Principles of Plasma Discharges and Material Processing, 2nd ed. (Wiley-Interscience, Hoboken, NJ, 2005).
