Spectroscopy and coherence of an excited-state transition in Tm3+:YAlO3 at telecommunication wavelength

Luozhen Li1,2,*, Akshay Babu Karyath1,2,*, Julien Bertrand1,2, Mohsen Falamarzi Askarani3,†, Maria Gieysztor3,4, Hridya Meppully Sasidharan3, Joshua A. Slater3,‡, Aaron D. Marsh5,§, Philip J. T. Woodburn5,∥ et al.

Charles W. Thiel5, Rufus L. Cone5, Sara Marzban3,¶, Nir Alfasi3,**, Patrick Remy6, and Wolfgang Tittel1,2,††

  • *These authors contributed equally to this work.
  • †Present address: Xanadu Quantum Technologies Inc., Toronto, Ontario M5G 2C8, Canada.
  • ‡Present address: Q*Bird BV, 2628 XJ Delft, Netherlands.
  • §Present address: Intel Corporation, Hillsboro, Oregon, USA.
  • ∥Present address: S2 Corporation, Bozeman, Montana, USA.
  • Present address: PiCard Systems BV, 6525 EC Nijmegen, Netherlands.
  • **Present address: Quantum Machines, Tel Aviv, Israel.
  • ††Contact author: wolfgang.tittel@unige.ch
PDF

Phys. Rev. Research 8, 033284 – Published 8 September, 2026

DOI: https://doi.org/10.1103/73jf-lvyk

Abstract

We characterize spectroscopic and coherence properties of the 1451.37 nm excited-state zero-phonon line (ZPL) between the F43 and the H43 manifolds of a thulium-doped yttrium aluminum perovskite (Tm3+:YAlO3) crystal at temperatures around 1.5 K. We measure the absorption spectrum between H63−F43 and F43−H43 manifolds, the inhomogeneous broadening of the F43−H43 (excited-state) ZPL, and the lifetimes of the higher-lying and lower-lying excited states. We also investigate level shifts caused by the quadratic Zeeman interaction as well as spectral hole-burning spectra with varying magnetic fields, providing insights into hyperfine interactions. Using spectral holes again but also optical free induction decays, we assess optical coherence times, finding a maximum of 4.75±0.07 μs at B = 2 T and low ion concentration in the F43 level. Our results—the first to demonstrate coherence of an excited-state transition in a rare-earth crystal—suggest the possibility of exploiting such transitions for quantum technology.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (68)

  1. B. Kraus, W. Tittel, N. Gisin, M. Nilsson, S. Kröll, and J. I. Cirac, Quantum memory for nonstationary light fields based on controlled reversible inhomogeneous broadening, Phys. Rev. A 73, 020302(R) (2006).
  2. A. L. Alexander, J. J. Longdell, M. J. Sellars, and N. B. Manson, Photon echoes produced by switching electric fields, Phys. Rev. Lett. 96, 043602 (2006).
  3. M. Nilsson and S. Kröll, Solid state quantum memory using complete absorption and re-emission of photons by tailored and externally controlled inhomogeneous absorption profiles, Opt. Commun. 247, 393 (2005).
  4. W. Tittel, M. Afzelius, A. Kinos, L. Rippe, and A. Walther, Quantum networks using rare-earth ions, Quantum Sci. Technol. 10, 033002 (2025).
  5. N. Sangouard, C. Simon, H. De Riedmatten, and N. Gisin, Quantum repeaters based on atomic ensembles and linear optics, Rev. Mod. Phys. 83, 33 (2011).
  6. N. Sinclair, E. Saglamyurek, H. Mallahzadeh, J. A. Slater, M. George, R. Ricken, M. P. Hedges, D. Oblak, C. Simon, W. Sohler, and W. Tittel, Spectral multiplexing for scalable quantum photonics using an atomic frequency comb quantum memory and feed-forward control, Phys. Rev. Lett. 113, 053603 (2014).
  7. X. Liu, J. Hu, Z.-F. Li, X. Li, P.-Y. Li, P.-J. Liang, Z.-Q. Zhou, C.-F. Li, and G.-C. Guo, Heralded entanglement distribution between two absorptive quantum memories, Nature (London) 594, 41 (2021).
  8. D. Lago-Rivera, S. Grandi, J. Rakonjac, A. Seri, and H. de Riedmatten, Telecom-heralded entanglement between multimode solid-state quantum memories, Nature (London) 594, 37 (2021).
  9. A. Ortu, A. Holzäpfel, J. Etesse, and M. Afzelius, Storage of photonic time-bin qubits for up to 20 ms in a rare-earth doped crystal, npj Quantum Inf. 8, 29 (2022).
  10. T.-X. Zhu, C. Zhang, Z.-W. Ou, X. Liu, P.-J. Liang, X.-M. Hu, Y.-F. Huang, Z.-Q. Zhou, C.-F. Li, and G.-C. Guo, A metropolitan-scale multiplexed quantum repeater with Bell non-locality, Nat. Photonics 20, 812 (2026).
  11. A. M. Dibos, M. Raha, C. M. Phenicie, and J. D. Thompson, Atomic source of single photons in the telecom band, Phys. Rev. Lett. 120, 243601 (2018).
  12. T. Zhong, J. M. Kindem, J. G. Bartholomew, J. Rochman, I. Craiciu, V. Verma, S. W. Nam, F. Marsili, M. D. Shaw, A. D. Beyer, and A. Faraon, Optically addressing single rare-earth ions in a nanophotonic cavity, Phys. Rev. Lett. 121, 183603 (2018).
  13. M. Raha, S. Chen, C. M. Phenicie, S. Ourari, A. M. Dibos, and J. D. Thompson, Optical quantum nondemolition measurement of a single rare earth ion qubit, Nat. Commun. 11, 1605 (2020).
  14. J. M. Kindem, A. Ruskuc, J. G. Bartholomew, J. Rochman, Y. Q. Huan, and A. Faraon, Coherent control and single-shot readout of a rare-earth ion embedded in a nanophotonic cavity, Nature (London) 580, 201 (2020).
  15. A. Gritsch, A. Ulanowski, J. Pforr, and A. Reiserer, Optical single-shot readout of spin qubits in silicon, Nat. Commun. 16, 64 (2025).
  16. R. W. Equall, Y. Sun, R. L. Cone, and R. M. MacFarlane, Ultraslow optical dephasing in Eu3+:Y2SiO5, Phys. Rev. Lett. 72, 2179 (1994).
  17. T. Böttger, C. W. Thiel, R. L. Cone, and Y. Sun, Effects of magnetic field orientation on optical decoherence in Er3+:Y2SiO5, Phys. Rev. B 79, 115104 (2009).
  18. S. Welinski, A. Tiranov, M. Businger, A. Ferrier, M. Afzelius, and P. Goldner, Coherence time extension by large-scale optical spin polarization in a rare-earth doped crystal, Phys. Rev. X 10, 031060 (2020).
  19. M. F. Askarani, A. Das, J. H. Davidson, G. C. Amaral, N. Sinclair, J. A. Slater, S. Marzban, C. W. Thiel, R. L. Cone, D. Oblak, et al., Long-lived solid-state optical memory for high-rate quantum repeaters, Phys. Rev. Lett. 127, 220502 (2021).
  20. M. Zhong, M. P. Hedges, R. L. Ahlefeldt, J. G. Bartholomew, S. E. Beavan, S. M. Wittig, J. J. Longdell, and M. J. Sellars, Optically addressable nuclear spins in a solid with a six-hour coherence time, Nature (London) 517, 177 (2015).
  21. See Supplemental Material at http://link.aps.org/supplemental/10.1103/73jf-lvyk for additional experimental details, data analysis, and theoretical derivations, which includes Refs. [50, 51, 52, 53, 54, 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67, 68].
  22. J. Geusic, H. Marcos, and L. Van Uitert, Laser oscillations in Nd-doped yttrium aluminum, yttrium gallium and gadolinium garnets, Appl. Phys. Lett. 4, 182 (1964).
  23. Y. Yu, D. Oser, G. Da Prato, E. Urbinati, J. C. Ávila, Y. Zhang, P. Remy, S. Marzban, S. Gröblacher, and W. Tittel, Frequency tunable, cavity-enhanced single erbium quantum emitter in the telecom band, Phys. Rev. Lett. 131, 170801 (2023).
  24. E. Saglamyurek, N. Sinclair, J. Jin, J. A. Slater, D. Oblak, F. Bussieres, M. George, R. Ricken, W. Sohler, and W. Tittel, Broadband waveguide quantum memory for entangled photons, Nature (London) 469, 512 (2011).
  25. E. Miyazono, T. Zhong, I. Craiciu, J. M. Kindem, and A. Faraon, Coupling of erbium dopants to yttrium orthosilicate photonic crystal cavities for on-chip optical quantum memories, Appl. Phys. Lett. 108, 011111 (2016).
  26. J. D. Franson, Bell inequality for position and time, Phys. Rev. Lett. 62, 2205 (1989).
  27. A. H. Myerson, D. J. Szwer, S. C. Webster, D. T. C. Allcock, M. J. Curtis, G. Imreh, J. A. Sherman, D. N. Stacey, A. M. Steane, and D. M. Lucas, High-fidelity readout of trapped-ion qubits, Phys. Rev. Lett. 100, 200502 (2008).
  28. V. Antonov, P. Arsenev, K. Bienert, and A. Potemkin, Spectral properties of rare-earth ions in YAlO3 crystals, Phys. Stat. Sol. (a) 19, 289 (1973).
  29. J. M. O’Hare and V. Donlan, Crystal-field determination for trivalent thulium in yttrium orthoaluminate, Phys. Rev. B 14, 3732 (1976).
  30. J. Körner, T. Lühder, J. Reiter, I. Uschmann, H. Marschner, V. Jambunathan, A. Lucianetti, T. Mocek, J. Hein, and M. C. Kaluza, Spectroscopic investigations of thulium doped YAG and YAP crystals between 77 K and 300 K for short-wavelength infrared lasers, J. Lumin. 202, 427 (2018).
  31. L. Guillemot, P. Loiko, J.-L. Doualan, A. Braud, and P. Camy, Excited-state absorption in thulium-doped materials in the near-infrared, Opt. Express 30, 31669 (2022).
  32. C. W. Thiel, T. Böttger, and R. Cone, Rare-earth-doped materials for applications in quantum information storage and signal processing, J. Lumin. 131, 353 (2011).
  33. L. Guillemot, P. Loiko, A. Braud, J.-L. Doualan, A. Hideur, M. Koselja, R. Moncorge, and P. Camy, Continuous-wave Tm:YAlO3 laser at ∼2.3 μm, Opt. Lett. 44, 5077 (2019).
  34. J. H. Davidson, P. J. T. Woodburn, A. D. Marsh, K. J. Olson, A. Olivera, A. Das, M. Falamarzi Askarani, W. Tittel, R. L. Cone, and C. W. Thiel, Measurement of the thulium ion spin Hamiltonian in an yttrium gallium garnet host crystal, Phys. Rev. B 104, 134103 (2021).
  35. N. Sinclair, D. Oblak, E. Saglamyurek, R. L. Cone, C. W. Thiel, and W. Tittel, Optical coherence and energy-level properties of a Tm3+-doped LiNbO3 waveguide at subkelvin temperatures, Phys. Rev. B 103, 134105 (2021).
  36. T. Böttger, C. W. Thiel, Y. Sun, and R. L. Cone, Optical decoherence and spectral diffusion at 1.5 µm in Er3+:Y2SiO5 versus magnetic field, temperature, and Er3+ concentration, Phys. Rev. B 73, 075101 (2006).
  37. C. Thiel, R. M. Macfarlane, Y. Sun, T. Böttger, N. Sinclair, W. Tittel, and R. Cone, Measuring and analyzing excitation-induced decoherence in rare-earth-doped optical materials, Laser Phys. 24, 106002 (2014).
  38. H. de Vries and D. A. Wiersma, Photophysical and photochemical molecular hole burning theory, J. Chem. Phys. 72, 1851 (1980).
  39. Z. Bai, Z. Zhao, Y. Qi, J. Ding, S. Li, X. Yan, Y. Wang, and Z. Lu, Narrow-linewidth laser linewidth measurement technology, Front. Phys. 9, 768165 (2021).
  40. R. G. Brewer and R. Shoemaker, Optical free induction decay, Phys. Rev. A 6, 2001 (1972).
  41. Y. S. Bai and R. Kachru, Spin-fluctuation-induced optical spectral diffusion in Pr3+:YAlO3, Phys. Rev. A 44, R6990(R) (1991).
  42. R. Yano, M. Mitsunaga, and N. Uesugi, Stimulated-photon-echo spectroscopy. I. Spectral diffusion in Eu3+:YAlO3, Phys. Rev. B 45, 12752 (1992).
  43. J. H. Van Vleck, The Theory of Electric and Magnetic Susceptibilities (Clarendon Press, Oxford, 1932).
  44. Y. Takikawa, S. Ebisu, and S. Nagata, Van Vleck paramagnetism of the trivalent Eu ions, J. Phys. Chem. Solids 71, 1592 (2010).
  45. A. Ortu, A. Tiranov, S. Welinski, F. Fröwis, N. Gisin, A. Ferrier, P. Goldner, and M. Afzelius, Simultaneous coherence enhancement of optical and microwave transitions in solid-state electronic spins, Nat. Mater. 17, 671 (2018).
  46. G. Huang, H. Liu, H. Dong, and Z. He, Investigation of the clock transition and its pressure-dependent behavior of the trigonal Yb3+171 centers in lithium niobate crystal, J. Appl. Phys. 133, 205103 (2023).
  47. R. Valivarthi, P. Umesh, C. John, K. A. Owen, V. B. Verma, S. W. Nam, D. Oblak, Q. Zhou, and W. Tittel, Measurement-device-independent quantum key distribution coexisting with classical communication, Quantum Sci. Technol. 4, 045002 (2019).
  48. L. Li, A. B. Karyath, J. Bertrand, M. Falamarzi Askarani, M. Gieysztor, H. Meppully Sasidharan, J. A. Slater, A. D. Marsh, P. J. T. Woodburn, C. W. Thiel, R. L. Cone, S. Marzban, N. Alfasi, P. Remy, and W. Tittel, Experimental data for paper “Spectroscopy and coherence of an excited-state transition in Tm3+:YAlO3 at telecommunication wavelength”, Zenodo, 2026, https://doi.org/10.5281/zenodo.20024931.
  49. G. Asatryan and J. Rosa, EPR of Er3+, Nd3+, and Ce3+ ions in YAlO3 single crystals, Phys. Solid State 44, 864 (2002).
  50. F. Wang, M. Ren, W. Sun, M. Guo, M. J. Sellars, R. L. Ahlefeldt, J. G. Bartholomew, J. Yao, S. Liu, and M. Zhong, Nuclear spins in a solid exceeding 10-hour coherence times for ultra-long-term quantum storage, PRX Quantum 6, 010302 (2025).
  51. G. Heinze, C. Hubrich, and T. Halfmann, Coherence time extension in Pr3+:Y2SiO5 by self-optimized magnetic fields and dynamical decoupling, Phys. Rev. A 89, 053825 (2014).
  52. M. Rančić, M. P. Hedges, R. L. Ahlefeldt, and M. J. Sellars, Coherence time of over a second in a telecom-compatible quantum memory storage material, Nat. Phys. 14, 50 (2018).
  53. J. M. Kindem, J. G. Bartholomew, P. J. T. Woodburn, T. Zhong, I. Craiciu, R. L. Cone, C. W. Thiel, and A. Faraon, Characterization of Yb3+171:YVO4 for photonic quantum technologies, Phys. Rev. B 98, 024404 (2018).
  54. J. V. Rakonjac, Y.-H. Chen, S. P. Horvath, and J. J. Longdell, Long spin coherence times in the ground state and in an optically excited state of Er3+167:Y2SiO5 at zero magnetic field, Phys. Rev. B 101, 184430 (2020).
  55. S. Welinski, P. J. T. Woodburn, N. Lauk, R. L. Cone, C. Simon, P. Goldner, and C. W. Thiel, Electron spin coherence in optically excited states of rare-earth ions for microwave to optical quantum transducers, Phys. Rev. Lett. 122, 247401 (2019).
  56. C. W. Thiel, N. Sinclair, W. Tittel, and R. L. Cone, Optical decoherence studies of Tm3+:Y3Ga5O12, Phys. Rev. B 90, 214301 (2014).
  57. R. W. Equall, R. L. Cone, and R. M. Macfarlane, Homogeneous broadening and hyperfine structure of optical transitions in Pr3+:Y2SiO5, Phys. Rev. B 52, 3963 (1995).
  58. S. Wang, L. Yang, M. Shen, W. Fu, Y. Xu, R. L. Cone, C. W. Thiel, and H. X. Tang, Er3+:LiNbO3 with high optical coherence enabling optical thickness control, Phys. Rev. Appl. 18, 014069 (2022).
  59. A. Zangwill, Modern Electrodynamics (Cambridge University Press, Cambridge, UK, 2013).
  60. P. W. Milonni and J. H. Eberly, Laser Physics (John Wiley & Sons, Hoboken, New Jersey, 2010).
  61. R. W. Boyd, Nonlinear Optics (Academic Press, Cambridge, Massachusets, 2020).
  62. T. Böttger, C. W. Thiel, R. L. Cone, Y. Sun, and A. Faraon, Optical spectroscopy and decoherence studies of Yb3+:YAG at 968 nm, Phys. Rev. B 94, 045134 (2016).
  63. S. K. Seth, J. Nagura, V. Somjit, A. Bapat, X. Li, G. D. Grant, I. Masiulionis, X. Han, F. J. Heremans, G. Galli, et al., Spin decoherence dynamics of Er3+ in CeO2 films, Phys. Rev. Lett. 135, 266901 (2025).
  64. M. Afzelius, C. Simon, H. de Riedmatten, and N. Gisin, Multimode quantum memory based on atomic frequency combs, Phys. Rev. A 79, 052329 (2009).
  65. M. Afzelius and C. Simon, Impedance-matched cavity quantum memory, Phys. Rev. A 82, 022310 (2010).
  66. J. H. Davidson, P. Lefebvre, J. Zhang, D. Oblak, and W. Tittel, Improved light-matter interaction for storage of quantum states of light in a thulium-doped crystal cavity, Phys. Rev. A 101, 042333 (2020).
  67. R.-R. Meng, P.-X. Liu, X. Liu, T.-X. Zhu, P.-J. Liang, C. Zhang, Z.-Y. Tang, H.-Z. Zhang, J.-M. Cui, M. Jin, et al., Efficient integrated quantum memory for light, Nat. Photonics 20, 437 (2026).
  68. P. Seidler, K. Lister, U. Drechsler, J. Hofrichter, and T. Stöferle, Slotted photonic crystal nanobeam cavity with an ultrahigh quality factor-to-mode volume ratio, Opt. Express 21, 32468 (2013).
