Remote-sensing of tectonic-induced stress across faults using high energy muon beams

L. Serafini, A. Bacci, F. Broggi, M. Rossetti Conti*, A. R. Rossi, and S. Samsam

G. Muttoni, A. M. Marotta, M. Voltolini, and M. Zucali

L. Giuliano

V. Petrillo

E. Puppin

  • Department of Earth Sciences DISTAD, University of Milan, Via Mangiagalli 34, 20133 Milan, Italy

  • *Contact author: marcello.rossetti@mi.infn.it
PDF

Phys. Rev. Research 7, 043336 – Published 26 December, 2025

DOI: https://doi.org/10.1103/6wxr-jgnd

Abstract

We illustrate a theoretical study of a technique using high-energy muon beams (TeV class) propagating through thick (kilometer-long) crystalline rock layers subject to tectonic-induced stress, potentially capable of actively monitoring the temporal evolution of the pressure rise in seismic fault zones associated with earthquake triggering when the induced tectonic pressure reaches and overcomes the rock elastoplastic deformation limit. This technique could contribute to improving earthquake forecasting statistics in seismically active regions, offering support for seismic hazard assessment and prevention strategies. Active monitoring of the induced tectonic stress and its time evolution is achieved by remote sensing of the electric field generated in quartz crystals embedded in crystalline rocks by piezoelectric effects. In this context, tectonic pressure refers to the time-dependent stress field acting on the rock body due to tectonic forces, which adds to the time-independent lithostatic pressure resulting from the weight of overlying materials. High-energy muon beams transmitted through a rock layer subject to tectonic pressure will be affected in their transverse phase-space distributions by the piezoelectric fields, therefore transferring to a detector the information on the applied tectonic stress. Finally, we illustrate the design of a proof-of-principle experiment to be conducted in a standard accelerator laboratory, using moderate-energy muons (GeV class) propagating through granite slabs subject to a press-induced stress reaching the rupture limit. A zero-generation proof-of-principle test can also be performed using 20–150 MeV electron beams transmitted through single quartz crystals subject to variable pressure.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (40)

  1. A. Rovida, M. Locati, R. Camassi, B. Lolli, P. Gasperini, and A. Antonucci, Catalogo parametrico dei terremoti italiani (cpti15), versione 4.0 (2022), doi: 10.13127/cpti/cpti15.4.
  2. S. Navas et al., Review of particle physics, Phys. Rev. D 110, 030001 (2024).
  3. IMCC & MuCol Annual Meeting 2025, DESY, 12–16 May 2025, https://indico.desy.de/event/45968/.
  4. C. Ahdida et al., New capabilities of the FLUKA multi-purpose code, Front. Phys. 9, 788253 (2022).
  5. J. R. Bishop, Piezoelectric effects in quartz-rich rocks, Tectonophysics 77, 297 (1981).
  6. J. D. Byerlee, Theory of friction based on brittle fracture, J. Appl. Phys. 38, 2928 (1967).
  7. J. D. Byerlee, Brittle-ductile transition in rocks, J. Geophys. Res. 73, 4741 (1968).
  8. S. ichiro Karato, Deformation of Earth Materials: An Introduction to the Rheology of Solid Earth (Cambridge University Press, Cambridge, UK, 2008).
  9. J. G. Ramsay, Folding and Fracturing of Rocks (McGraw-Hill, New York, 1967).
  10. G. Ranalli, Rheology of the Earth : Deformation and Flow Processes in Geophysics and Geodynamics (Allen & Unwin, Boston, MA, 1987).
  11. Z. Liu, H. Wang, Y. Li, X. Wang, and A. P. S. Selvadurai, Triaxial compressive strength, failure, and rockburst potential of granite under high-stress and ground-temperature coupled conditions, Rock Mech. Rock Eng. 56, 911 (2023).
  12. H. T. Yang, J. Xu, L. Wang, M. Nie, and H. N. Ren, Experimental study on temperature effect of the mechanical properties of granite, Chin. J. Underground Space Eng. 9, 96 (2013).
  13. M. S. Paterson and T.-F. Wong, Experimental Rock Deformation—The Brittle Field (Springer, Berlin, 2005).
  14. P. H. Barrett, L. M. Bollinger, G. Cocconi, Y. Eisenberg, and K. Greisen, Interpretation of cosmic-ray measurements far underground, Rev. Mod. Phys. 24, 133 (1952).
  15. G. Molière, Theorie der Streuung schneller geladener Teilchen I. Einzelstreuung am abgeschirmten Coulomb-Feld, Z. Naturforsch. 2, 133 (1947).
  16. K. Borozdin, G. Hogan, C. Morris et al., Radiographic imaging with cosmic-ray muons, Nature (London) 422, 277 (2003).
  17. D. E. Groom, N. V. Mokhov, and S. I. Striganov, Muon stopping power and range tables: 10 MeV–100 TeV, At. Data Nucl. Data Tables 78, 183 (2001).
  18. C. R. Harris et al., Array programming with numpy, Nature (London) 585, 357 (2020).
  19. G. Abbiendi, C. M. Carloni Calame, U. Marconi, C. Matteuzzi, G. Montagna, O. Nicrosini, M. Passera, F. Piccinini, R. Tenchini, L. Trentadue, and G. Venanzoni, Measuring the leading hadronic contribution to the muon g–2 via μe scattering, Eur. Phys. J. C 77, 139 (2017).
  20. L. Calvin, E. Gerstmayr, C. Arran, L. Tudor, T. Foster, B. Bergmann, D. Doria, B. Kettle, H. Maguire, V. Malka et al., Experimental evidence of muon production from a laser-wakefield accelerator, arXiv:2503.20904.
  21. E. Rockafellow, J. E. Shrock, B. Miao, A. Sloss, M. S. Le, S. W. Hancock, S. Zahedpour, R. C. Hollinger, S. Wang, J. King et al., High charge laser acceleration of electrons to 10 GeV, Nucl. Instrum. Methods Phys. Res. Sect. A 1077, 170586 (2025).
  22. A. Picksley, J. Stackhouse, C. Benedetti, K. Nakamura, H. Tsai, R. Li, B. Miao, J. Shrock, E. Rockafellow, H. Milchberg et al., Matched guiding and controlled injection in dark-current-free, 10-GeV-class, channel-guided laser-plasma accelerators, Phys. Rev. Lett. 133, 255001 (2024).
  23. A. Titov, B. Kämpfer, and H. Takabe, Dimuon production by laser-wakefield accelerated electrons, Phys. Rev. Spec. Top. Accel. Beams 12, 111301 (2009).
  24. B. S. Rao, J. H. Jeon, H. T. Kim, and C. H. Nam, Bright muon source driven by gev electron beams from a compact laser wakefield accelerator, Plasma Phys. Controlled Fusion 60, 095002 (2018).
  25. E. Esarey, C. B. Schroeder, and W. P. Leemans, Physics of laser-driven plasma-based electron accelerators, Rev. Mod. Phys. 81, 1229 (2009).
  26. S. Steinke, J. Van Tilborg, C. Benedetti, C. Geddes, C. Schroeder, J. Daniels, K. Swanson, A. Gonsalves, K. Nakamura, N. Matlis et al., Multistage coupling of independent laser-plasma accelerators, Nature (London) 530, 190 (2016).
  27. J. van Tilborg, S. Steinke, C. Geddes, N. Matlis, B. Shaw, A. Gonsalves, J. Huijts, K. Nakamura, J. Daniels, C. Schroeder et al., Active plasma lensing for relativistic laser-plasma-accelerated electron beams, Phys. Rev. Lett. 115, 184802 (2015).
  28. R. Pompili, M. Anania, M. Bellaveglia, A. Biagioni, S. Bini, F. Bisesto, E. Brentegani, F. Cardelli, G. Castorina, E. Chiadroni et al., Focusing of high-brightness electron beams with active-plasma lenses, Phys. Rev. Lett. 121, 174801 (2018).
  29. C. Lindstrøm, E. Adli, H. Anderson, P. Drobniak, D. Kalvik, F. Peña, and K. Sjobak, The SPARTA project: Toward a demonstrator facility for multistage plasma acceleration, arXiv:2505.14493.
  30. P. Drobniak, E. Adli, H. B. Anderson, A. Dyson, S. Mewes, K. Sjobak, M. Thévenet, and C. Lindstrøm, Development of a nonlinear plasma lens for achromatic beam transport, Nucl. Instrum. Methods Phys. Res. Sect. A 1072, 170223 (2025).
  31. A. R. Rossi, V. Petrillo, A. Bacci, E. Chiadroni, A. Cianchi, M. Ferrario, A. Giribono, M. R. Conti, L. Serafini, and C. Vaccarezza, Angstrom wavelength fel driven by 5 GeV lwfa beam with external injection, J. Phys.: Conf. Ser. 1596, 012004 (2020).
  32. R. Pompili, M. Anania, A. Biagioni, M. Carillo, E. Chiadroni, A. Cianchi, G. Costa, A. Curcio, L. Crincoli, A. Del Dotto et al., Guiding of charged particle beams in curved plasma-discharge capillaries, Phys. Rev. Lett. 132, 215001 (2024).
  33. A. Frazzitta, R. Pompili, and A. Rossi, Theory of particle beams transport over curved plasma-discharge capillaries, Phys. Rev. Accel. Beams 27, 091301 (2024).
  34. D. Banerjee, J. Bernhard, M. Brugger, N. Charitonidis, G. D’Alessandro, L. Gatignon, A. Gerbershagen, E. Montbarbon, C. Mussolini, E. Parozzi, B. Rae, and B. Veit, M2 experimental beamline optics studies for next generation muon beam experiments at CERN, in Proceedings of IPAC’21, International Particle Accelerator Conference No. 12 (JACoW Publishing, Geneva, Switzerland, 2021), pp. 4041–4044.
  35. K. Floettmann, Astra: A space charge tracking algorithm (1997), https://www.desy.de/∼mpyflo/Astra_manual/Astra-Manual_V3.2.pdf.
  36. L. Giuliano, D. Alesini, F. Cardelli, M. Carillo, E. Chiadroni, M. Coppola, G. Cuttone, A. Curcio, A. De Gregorio, R. Di Raddo et al., A compact c-band flash electron linear accelerator prototype for the vhee safest project, Front. Oncol. 15, 1516576 (2025).
  37. P. Valente, B. Buonomo, and G. Mazzitelli, Diagnostics and upgrade of the DAFNE Beam Test Facility (BTF), Nucl. Phys. B Proc. Suppl. 150, 362 (2006).
  38. K. B. Korotchenko, E. I. Rozhkova, and S. B. Dabagov, Cherenkov-channeling radiation by relativistic muons in crystals, Eur. Phys. J. C 80, 927 (2020).
  39. F. Hrouda, Magnetic anisotropy of rocks and its application in geology and geophysics, Geophys. Surv. 5, 37 (1982).
  40. Y.-I. Otofuji, K. Uno, T. Higashi, T. Ichikawa, T. Ueno, T. Mishima, and T. Matsuda, Secondary remanent magnetization carried by magnetite inclusions in silicates: A comparative study of unremagnetized and remagnetized granites, Earth Planet. Sci. Lett. 180, 271 (2000).
