When surface dynamics fakes symmetry: Oxygen on Rh(100) revisited

Lutz Hammer1,*, Tilman Kißlinger1, Margareta Wagner2,†, Reinhard B. Neder3, Michael Schmid2, Ulrike Diebold2, and M. Alexander Schneider1

  • *Contact author: lutz.hammer@fau.de
  • †Contact author: wagner@iap.tuwien.ac.at
PDF

Phys. Rev. Research 8, 023296 – Published 15 June, 2026

DOI: https://doi.org/10.1103/5wmb-kmjb

Abstract

Heating a long-range ordered adsorbate phase beyond its stability temperature does not necessarily result in a disordered phase; it can also break up into heavily fluctuating ordered domains. Temporal and/or spatial averaging over these fluctuations may give the impression of both a wrong periodicity and false symmetry elements such as nonexisting glide planes or rotational axes of incorrect order. This can happen in real space and reciprocal space, and also below liquid-nitrogen temperature, so that the true nature of the phase might remain undetected. We demonstrate this scenario at the catalytically active Rh(100) surface covered by 12 monolayer of oxygen, using quantitative low-energy electron diffraction, variable-temperature scanning tunneling microscopy, and density functional theory. Using the example of CO adsorption, we show that local symmetry can have a decisive influence on the binding energy and thus the chemical reactivity.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (33)

  1. G. A. Somorjai and M. A. Van Hove, Restructuring of metal surfaces and adsorbed monolayers during chemisorption and catalytic reaction, Acta Cryst. B 51, 502 (1995).
  2. L. Tan, L. Huang, Y. Liu, and Q. Wang, Augmented pairwise additive interaction model for lateral adsorbate interactions: The NO–CO reaction system on Rh(100) and Rh(111), Langmuir 34, 5174 (2018).
  3. M. Shelef and G. W. Graham, Why rhodium in automotive three-way catalysts? Catal. Rev. 36, 433 (1994).
  4. R. R. Davda, J. W. Shabaker, G. W. Huber, R. D. Cortright, and J. A. Dumesic, A review of catalytic issues and process conditions for renewable hydrogen and alkanes by aqueous-phase reforming of oxygenated hydrocarbons over supported metal catalysts, Appl. Catal. B 56, 171 (2005).
  5. J. Gustafson, S. Blomberg, N. M. Martin, V. Fernandes, A. Borg, Z. Liu, R. Chang, and E. Lundgren, A high pressure x-ray photoelectron spectroscopy study of CO oxidation over Rh(100), J. Phys.: Condens. Matter 26, 055003 (2014).
  6. J. Gustafson, O. Balmes, C. Zhang, M. Shipilin, A. Schaefer, B. Hagman, L. R. Merte, N. M. Martin, P.-A. Carlsson, M. Jankowski, E. J. Crumlin, and E. Lundgren, The role of oxides in catalytic CO oxidation over rhodium and palladium, ACS Catal. 8, 4438 (2018).
  7. W. Oed, B. Dötsch, L. Hammer, K. Heinz, and K. Müller, A LEED investigation of clean and oxygen covered Rh(100), Surf. Sci. 207, 55 (1988).
  8. J. R. Mercer, P. Finetti, F. M. Leibsle, R. McGrath, V. R. Dhanak, A. Baraldi, K. C. Prince, and R. Rosei, STM and SPA-LEED studies of O-induced structures on Rh(100) surfaces, Surf. Sci. 352-354, 173 (1996).
  9. A. Baraldi, V. R. Dhanak, G. Comelli, K. C. Prince, and R. Rosei, Order-disorder phase transitions of oxygen on Rh(100), Phys. Rev. B 56, 10511 (1997).
  10. Y. G. Shen, A. Qayyum, D. J. O’Connor, and B. V. King, Oxygen-induced surface (2×2)p4g reconstruction of Rh(001), Phys. Rev. B 58, 10025 (1998).
  11. D. Alfe, S. de Gironcoli, and S. Baroni, The reconstruction of Rh(001) upon oxygen adsorption, Surf. Sci. 410, 151 (1998).
  12. A. Baraldi, J. Cerdá, J. A. Martín-Gago, G. Comelli, S. Lizzit, G. Paolucci, and R. Rosei, Oxygen induced reconstruction of the Rh(100) surface: General tendency towards threefold oxygen adsorption site on Rh surfaces, Phys. Rev. Lett. 82, 4874 (1999).
  13. D. Alfè, S. de Gironcoli, and S. Baroni, The reconstruction of nickel and rhodium (001) surfaces upon carbon, nitrogen or oxygen adsorptions, Surf. Sci. 437, 18 (1999).
  14. A. G. Norris, F. Schedin, G. Thornton, V. R. Dhanak, T. S. Turner, and R. McGrath, Surface x-ray diffraction study of the Rh(100)(2×2)-O reconstruction, Phys. Rev. B 62, 2113 (2000).
  15. J. E. Kirsch and S. Harris, Electronic structure studies of adsorbate-induced surface reconstructions: Oxygen on Rh(100), Surf. Sci. 553, 82 (2004).
  16. L. Bianchettin, A. Baraldi, S. de Gironcoli, E. Vesselli, S. Lizzit, G. Comelli, and R. Rosei, Surface core level shift: High sensitive probe to oxygen-induced reconstruction of Rh(100), J. Phys. Chem. C 113, 13192 (2009).
  17. L. Tan, L. Huang, Q. Wang, and Y. Liu, First-principles study on O2 adsorption and dissociation processes over Rh(100) and Rh(111) surfaces, Langmuir 33, 11156 (2017).
  18. L. Hammer, T. Kißlinger, M. Wagner, R. B. Neder, M. Schmid, U. Diebold, and M. A. Schneider, Oxygen on Rh(100) revisited with ultra-high precision (unpublished).
  19. T Kißlinger, P. Ferstl, M. A. Schneider, and L. Hammer, Crystallographic structure and energetics of the Rh(100)−(3×1)−2O phase, J. Phys.: Condens. Matter 29, 365001 (2017).
  20. F. Kraushofer, A. M. Imre, G. Franceschi, T. Kißlinger, E. Rheinfrank, M. Schmid, U. Diebold, L. Hammer, and M. Riva, ViPErLEED package I: Calculation of I(V) curves and structural optimization, Phys. Rev. Res. 7, 013005 (2025).
  21. J. Rundgren, Optimized surface-slab excited-state muffin-tin potential and surface core level shifts, Phys. Rev. B 68, 125405 (2003).
  22. V. Blum and K. Heinz, Fast LEED intensity calculations for surface crystallography using tensor LEED, Comput. Phys. Commun. 134, 392 (2001).
  23. J. B. Pendry, Reliability factors for LEED calculations, J. Phys. C 13, 937 (1980).
  24. G. Kresse and J. Furthmüller, Efficient iterative schemes for ab initio total-energy calculations using a plane-wave basis set, Phys. Rev. B 54, 11169 (1996).
  25. J. P. Perdew, K. Burke, and M. Ernzerhof, Generalized gradient approximation made simple, Phys. Rev. Lett. 77, 3865 (1996).
  26. J. P. Perdew, A. Ruzsinszky, Gábor I. Csonka, O. A. Vydrov, G. E. Scuseria, L. A. Constantin, X. Zhou, and K. Burke, Restoring the density-gradient expansion for exchange in solids and surfaces, Phys. Rev. Lett. 100, 136406 (2008).
  27. J. Klimeš, D. R. Bowler, and A. Michaelides, Van der Waals density functionals applied to solids, Phys. Rev. B 83, 195131 (2011).
  28. G. Henkelman, B. P. Uberuaga, H. Jónsson, A climbing image nudged elastic band method for finding saddle points and minimum energy paths, J. Chem. Phys. 113, 9901 (2000).
  29. H. Group, Transition state tools for VASP, 2020, http://henkelmanlab.org/vtsttools/.
  30. M. V. Ganduglia-Pirovano and M. Scheffler, Structural and electronic properties of chemisorbed oxygen on Rh(111), Phys. Rev. B 59, 15533 (1999).
  31. J. Tersoff and D. R. Hamann, Theory of the scanning tunneling microscope, Phys. Rev. B 31, 805 (1985).
  32. See Supplemental Material at http://link.aps.org/supplemental/10.1103/5wmb-kmjb for the LEED best-fit atomic coordinates in POSCAR format.
  33. A. Baraldi, L. Gregoratti, G. Comelli, V. R. Dhanak, M. Kiskinova, and R. Rosei, CO adsorption and CO oxidation on Rh(100), Appl. Surf. Sci. 99, 1 (1996).
