Intrinsic nonreciprocity in electron-phonon-interaction-driven thermoelectric diodes

Hao-Kun Ke, Lie-Run Tian, and Jun-Feng Liu*

Pei-Hao Fu

Jun Wang†

Hu Xu‡

  • *Contact author: phjfliu@gzhu.edu.cn
  • †Contact author: jwang@seu.edu.cn
  • ‡Contact author: xuh@sustech.edu.cn
PDF

Phys. Rev. Research 8, L022058 – Published 25 June, 2026

DOI: https://doi.org/10.1103/5gnb-p4m7

Abstract

We study an electron-phonon-interaction-driven thermoelectric diode. The nonreciprocity in this diode arises from the asymmetry between the probabilities of phonon emission and absorption in the electron-phonon interaction, as well as the structural reflection asymmetry. We reveal the intrinsic nature of this nonreciprocity, as the forward and backward electron transport remains asymmetric even when the applied temperature difference is not reversed. This intrinsic nonreciprocity gives rise to two novel transport phenomena. One is a novel thermoelectric effect that is driven by the temperature difference between the leads and the central device region, rather than the conventional temperature difference between the two leads. The second, and more significant, phenomenon is the suppression of electronic backscattering in the load resistor. This suppression decreases the resistance of the load resistor, which leads to the breakdown of Ohm’s addition law. Under suitable conditions, the presence of electron-phonon interaction can yield a larger thermoelectric current compared to the case without it. This intrinsic nonreciprocity opens up a pathway for low-power electronics besides topology and superconductivity, and for nonreciprocal thermoelectric devices.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (50)

  1. H. J. Zhao, L. Tao, Y. Fu, L. Bellaiche, and Y. Ma, General theory for longitudinal nonreciprocal charge transport, Phys. Rev. Lett. 133, 096802 (2024).
  2. B. Cheng, Y. Gao, Z. Zheng, S. Chen, Z. Liu, L. Zhang, Q. Zhu, H. Li, L. Li, and C. Zeng, Giant nonlinear Hall and wireless rectification effects at room temperature in the elemental semiconductor tellurium, Nat. Commun. 15, 5513 (2024).
  3. M. Nadeem, M. S. Fuhrer, and X. Wang, The superconducting diode effect, Nat. Rev. Phys. 5, 558 (2023).
  4. L. Min, Y. Zhang, Z. Xie, S. V. G. Ayyagar, L. Miao, Y. Onishi, S. H. Lee, Y. Wang, N. Alem, L. Fu, and Z. Mao, Colossal room-temperature non-reciprocal Hall effect, Nat. Mater. 23, 1671 (2024).
  5. Y. Onishi and L. Fu, High-efficiency energy harvesting based on a nonlinear Hall rectifier, Phys. Rev. B 110, 075122 (2024).
  6. L. Chotorlishvili, X.-g. Wang, A. Dyrdał, G.-h Guo, V. K. Dugaev, J. Barnaś, and J. Berakdar, Rectification of the spin Seebeck current in noncollinear antiferromagnets, Phys. Rev. B 106, 014417 (2022).
  7. Y. Fu, Y. Huang, and Q. L. He, Non-reciprocal Coulomb drag between Chern insulators, Nat. Commun. 16, 3058 (2025).
  8. J. Ferreira, T. Jin, J. Mannhart, T. Giamarchi, and M. Filippone, Transport and nonreciprocity in monitored quantum devices: An exact study, Phys. Rev. Lett. 132, 136301 (2024).
  9. N. Nagaosa and Y. Yanase, Nonreciprocal transport and optical phenomena in quantum materials, Annu. Rev. Condens. Matter Phys. 15, 63 (2024).
  10. Y. Tokura and N. Nagaosa, Nonreciprocal responses from noncentrosymmetric quantum materials, Nat. Commun. 9, 3740 (2018).
  11. J. Balduqué and R. Sánchez, Scattering theory of thermal and bipolar thermoelectric diodes, Phys. Rev. Lett. 134, 186301 (2025).
  12. G. T. Craven, D. He, and A. Nitzan, Electron-transfer-induced thermal and thermoelectric rectification, Phys. Rev. Lett. 121, 247704 (2018).
  13. W. Kobayashi, Thermal-rectification coefficients in solid-state thermal rectifiers, Phys. Rev. E 102, 032142 (2020).
  14. M. Kasprzak, M. Sledzinska, K. Zaleski, I. Iatsunskyi, F. Alzina, S. Volz, C. M. S. Torres, and B. Graczykowski, High-temperature silicon thermal diode and switch, Nano Energy 78, 105261 (2020).
  15. J. Senior, A. Gubaydullin, B. Karimi, J. T. Peltonen, J. Ankerhold, and J. P. Pekola, Heat rectification via a superconducting artificial atom, Commun. Phys. 3, 40 (2020).
  16. R. Shrestha, Y. Luan, X. Luo, S. Shin, T. Zhang, P. Smith, W. Gong, M. Bockstaller, T. Luo, R. Chen, K. Hippalgaonkar, and S. Shen, Dual-mode solid-state thermal rectification, Nat. Commun. 11, 4346 (2020).
  17. Y. Zhang, Q. Lv, H. Wang, S. Zhao, Q. Xiong, R. Lv, and X. Zhang, Simultaneous electrical and thermal rectification in a monolayer lateral heterojunction, Science 378, 169 (2022).
  18. P. Ben-Abdallah, Inverse spin thermal Hall effect in nonreciprocal photonic systems, Phys. Rev. Lett. 134, 113804 (2025).
  19. A. R. Karmakar, S. Nandy, A. Taraphder, and G. P. Das, Giant anomalous thermal Hall effect in tilted type-I magnetic Weyl semimetal Co3Sn2S2, Phys. Rev. B 106, 245133 (2022).
  20. T. Yamaguchi, K. Nakazawa, and A. Yamakage, Microscopic theory of nonlinear Hall effect induced by electric field and temperature gradient, Phys. Rev. B 109, 205117 (2024).
  21. H. Varshney, K. Das, P. Bhalla, and A. Agarwal, Quantum kinetic theory of nonlinear thermal current, Phys. Rev. B 107, 235419 (2023).
  22. D.-K. Zhou, Z.-F. Zhang, X.-Q. Yu, Z.-G. Zhu, and G. Su, Fundamental distinction between intrinsic and extrinsic nonlinear thermal Hall effects, Phys. Rev. B 105, L201103 (2022).
  23. C. Zeng, S. Nandy, and S. Tewari, Chiral anomaly induced nonlinear Nernst and thermal Hall effects in Weyl semimetals, Phys. Rev. B 105, 125131 (2022).
  24. G. B. Lesovik and I. A. Sadovskyy, Scattering matrix approach to the description of quantum electron transport, Phys.-Usp. 54, 1007 (2011).
  25. K. Kawabata and M. Ueda, Nonlinear Landauer formula: Nonlinear response theory of disordered and topological materials, Phys. Rev. B 106, 205104 (2022).
  26. S. Datta, Quantum Transport: Atom to Transistor (Cambridge University Press, Cambridge, 2005).
  27. D. Shin, Y. Lee, M. Sasaki, Y. H. Jeong, F. Weickert, J. B. Betts, H.-J. Kim, K.-S. Kim, and J. Kim, Violation of Ohm’s law in a Weyl metal, Nat. Mater. 16, 1096 (2017).
  28. B. Weber, S. Mahapatra, H. Ryu, S. Lee, A. Fuhrer, T. C. G. Reusch, D. L. Thompson, W. C. T. Lee, G. Klimeck, L. C. L. Hollenberg, and M. Y. Simmons, Ohm’s law survives to the atomic scale, Science 335, 64 (2012).
  29. J. Homoth, M. Wenderoth, T. Druga, L. Winking, R. G. Ulbrich, C. A. Bobisch, B. Weyers, A. Bannani, E. Zubkov, A. M. Bernhart, M. R. Kaspers, and R. Möller, Electronic transport on the nanoscale: Ballistic transmission and Ohm’s law, Nano Lett. 9, 1588 (2009).
  30. See Supplemental Material at http://link.aps.org/supplemental/10.1103/5gnb-p4m7 for the intrinsic nonreciprocity breakout Ohm’s addition law in Chap. S1.
  31. M. Büttiker, Coherent and sequential tunneling in series barriers, IBM J. Res. Dev. 32, 63 (1988).
  32. Z.-q Bao, J.-w Ding, and J. Qi, Complex Landau levels and related transport properties in the strained zigzag graphene nanoribbons, Phys. Rev. B 107, 125411 (2023).
  33. T. Palm and P. Nalbach, Suppressing relaxation through dephasing, Phys. Rev. A 103, 022206 (2021).
  34. Y. Xing, Q.-f. Sun, and J. Wang, Influence of dephasing on the quantum Hall effect and the spin Hall effect, Phys. Rev. B 77, 115346 (2008).
  35. H. Jiang, S. Cheng, Q.-f. Sun, and X. C. Xie, Topological insulator: A new quantized spin Hall resistance robust to dephasing, Phys. Rev. Lett. 103, 036803 (2009).
  36. L. P. Pryadko and A. Auerbach, Hall resistivity and dephasing in the quantum Hall insulator, Phys. Rev. Lett. 82, 1253 (1999).
  37. E. V. Bezuglyi, E. N. Bratus’, and V. S. Shumeiko, Dissipative charge transport in diffusive superconducting double-barrier junctions, Phys. Rev. B 83, 184517 (2011).
  38. J. Lu, Z. Wang, J. Ren, C. Wang, and J.-H. Jiang, Coherence-enhanced thermodynamic performance in a periodically driven inelastic heat engine, Phys. Rev. B 109, 125407 (2024).
  39. J. Lu, R. Wang, J. Ren, M. Kulkarni, and J.-H. Jiang, Quantum-dot circuit-QED thermoelectric diodes and transistors, Phys. Rev. B 99, 035129 (2019).
  40. J.-H. Jiang, M. Kulkarni, D. Segal, and Y. Imry, Phonon thermoelectric transistors and rectifiers, Phys. Rev. B 92, 045309 (2015).
  41. M. Pourfath, The Non-Equilibrium Green’s Function Method for Nanoscale Device Simulation (Springer, Wien, 2014).
  42. M. P. Anantram, M. S. Lundstrom, and D. E. Nikonov, Modeling of nanoscale devices, Proc. IEEE 96, 1511 (2008).
  43. L. Arrachea, N. Bode, and F. von Oppen, Vibrational cooling and thermoelectric response of nanoelectromechanical systems, Phys. Rev. B 90, 125450 (2014).
  44. O. Entin-Wohlman, Y. Imry, and A. Aharony, Three-terminal thermoelectric transport through a molecular junction, Phys. Rev. B 82, 115314 (2010).
  45. F. Giazotto, T. T. Heikkilä, A. Luukanen, A. M. Savin, and J. P. Pekola, Opportunities for mesoscopics in thermometry and refrigeration: Physics and applications, Rev. Mod. Phys. 78, 217 (2006).
  46. J. T. Muhonen, M. Meschke, and J. P. Pekola, Micrometre-scale refrigerators, Rep. Prog. Phys. 75, 046501 (2012).
  47. R. Golizadeh-Mojarad and S. Datta, Nonequilibrium Green’s function based models for dephasing in quantum transport, Phys. Rev. B 75, 081301(R) (2007).
  48. See Supplemental Material at http://link.aps.org/supplemental/10.1103/5gnb-p4m7 for the method of nonequilibrium Green’s function to calculate the charge current in Sec. S2.
  49. See Supplemental Material at http://link.aps.org/supplemental/10.1103/5gnb-p4m7 for Fig. S2 in Sec. S3.
  50. See Supplemental Material at http://link.aps.org/supplemental/10.1103/5gnb-p4m7 for the definitions of thermoelectric voltage and device resistance in Chap. S4.
