Geometry-dependent localization of surface plasmons on random gold nanoparticle assemblies

Mohammed Fayis Kalady1,2,*, Johannes Schultz1, Kristina Weinel1,3, Daniel Wolf1, and Axel Lubk1,4,†

  • *Contact author: m.f.kalady@ifw-dresden.de
  • †Contact author: a.lubk@ifw-dresden.de
PDF

Phys. Rev. Research 7, 043053 – Published 15 October, 2025

DOI: https://doi.org/10.1103/44nk-6bp2

Abstract

Assemblies of plasmonic nanoparticles (NPs) support hybridized modes of localized surface plasmons (LSPs), which delocalize in geometrically well-ordered arrangements. Here, the hybridization behavior of LSPs in geometrically completely disordered two-dimensional arrangements of Au NPs fabricated by an e-beam synthesis method is studied. Employing electron energy loss spectroscopy in a scanning transmission electron microscope and numerical simulations, the disorder-driven spatial and spectral localization of the coupled LSP modes that depends on the NP thickness is revealed. Below a NP thickness of 0.4 nm, localization increases toward higher hybridized LSP mode energies. In comparison, above 10 nm thickness, a decrease of localization toward higher mode energies is observed. In the intermediate thickness regime, a transition of the energy dependence of the localization between the two limiting cases, exhibiting a mode energy with minimal localization, is observed. It is shown that this behavior is mainly driven by the energy and thickness dependence of the polarizability of the individual NPs.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (22)

  1. H. Schlicke, M. Behrens, C. J. Schröter, G. T. Dahl, H. Hartmann, and T. Vossmeyer, Cross-linked gold-nanoparticle membrane resonators as microelectromechanical vapor sensors, ACS Sensors 2, 540 (2017).
  2. K. Kim, Y.-G. Park, B. G. Hyun, M. Choi, and J.-U. Park, Recent advances in transparent electronics with stretchable forms, Adv. Mater. 31, 1804690 (2019).
  3. I. R. Minev, P. Musienko, A. Hirsch, Q. Barraud, N. Wenger, E. M. Moraud, J. Gandar, M. Capogrosso, T. Milekovic, L. Asboth et al., Electronic dura mater for long-term multimodal neural interfaces, Science 347, 159 (2015).
  4. Y. Liu, M. Pharr, and G. A. Salvatore, Lab-on-skin: A review of flexible and stretchable electronics for wearable health monitoring, ACS Nano 11, 9614 (2017).
  5. M. Mayer, P. L. Potapov, D. Pohl, A. M. Steiner, J. Schultz, B. Rellinghaus, A. Lubk, T. A. F. König, and A. Fery, Direct observation of plasmon band formation and delocalization in quasi-infinite nanoparticle chains, Nano Lett. 19, 3854 (2019).
  6. V. G. Kravets, A. V. Kabashin, W. L. Barnes, and A. N. Grigorenko, Plasmonic surface lattice resonances: A review of properties and applications, Chem. Rev. 118, 5912 (2018).
  7. S. Zou and G. C. Schatz, Theoretical studies of plasmon resonances in one-dimensional nanoparticle chains: Narrow lineshapes with tunable widths, Nanotechnology 17, 2813 (2006).
  8. V. A. Markel and A. K. Sarychev, Propagation of surface plasmons in ordered and disordered chains of metal nanospheres, Phys. Rev. B 75, 085426 (2007).
  9. J. Schultz, K. Hiekel, P. Potapov, R. A. Römer, P. Khavlyuk, A. Eychmüller, and A. Lubk, Maximal Anderson localization and suppression of surface plasmons in two-dimensional random Au networks, Phys. Rev. Res. 6, 033221 (2024).
  10. A. Xomalis, X. Zheng, A. Demetriadou, A. Martínez, R. Chikkaraddy, and J. J. Baumberg, Interfering plasmons in coupled nanoresonators to boost light localization and sers, Nano Lett. 21, 2512 (2021).
  11. R. K. M. Raguindin and C. C. Mercado, Localized surface plasmon resonance shift of biosynthesized and functionalized quasi-spherical gold nanoparticle systems, RSC Adv. 13, 24211 (2023).
  12. J. Fregoni, T. S. Haugland, S. Pipolo, T. Giovannini, H. Koch, and S. Corni, Strong coupling between localized surface plasmons and molecules by coupled cluster theory, Nano Lett. 21, 6664 (2021).
  13. M. Horák, V. Křápek, M. Hrtoň, A. Konečná, F. Ligmajer, M. Stöger-Pollach, T. Šamořil, A. Paták, Z. Édes, O. Metelka et al., Limits of Babinet’s principle for solid and hollow plasmonic antennas, Sci. Rep. 9, 4004 (2019).
  14. T. Zentgraf, T. Meyrath, A. Seidel, S. Kaiser, H. Giessen, C. Rockstuhl, and F. Lederer, Babinet’s principle for optical frequency metamaterials and nanoantennas, Phys. Rev. B 76, 033407 (2007).
  15. F. Falcone, T. Lopetegi, M. Laso, J. Baena, J. Bonache, M. Beruete, R. Marqués, F. Martín, and M. Sorolla, Babinet principle applied to the design of metasurfaces and metamaterials, Phys. Rev. Lett. 93, 197401 (2004).
  16. K. Weinel, M. B. Hahn, A. Lubk, W. Feng, I. G. Gonzalez Martinez, B. Büchner, and L. Agudo Jácome, Nanoparticle synthesis by precursor irradiation with low-energy electrons, ACS Appl. Nano Mater. 8, 4980 (2025).
  17. J. Nelayah, M. Kociak, O. Stéphan, F. J. García de Abajo, M. Tencé, L. Henrard, D. Taverna, I. Pastoriza-Santos, L. M. Liz-Marzán, and C. Colliex, Mapping surface plasmons on a single metallic nanoparticle, Nat. Phys. 3, 348 (2007).
  18. See Supplemental Material at http://link.aps.org/supplemental/10.1103/44nk-6bp2 for additional details on the self-consistent dipole model, the role of diagonal and off-diagonal disorder, the impact of nanoparticle shape, and electron holography measurements of nanoparticle thickness.
  19. H. Lichte, F. Börrnert, A. Lenk, A. Lubk, F. Röder, J. Sickmann, S. Sturm, K. Vogel, and D. Wolf, Electron holography for fields in solids: Problems and progress, Ultramicroscopy 134, 126 (2013).
  20. V. A. Markel, Anderson localization of polar eigenmodes in random planar composites, J. Phys.: Condens. Matter 18, 11149 (2006).
  21. B. Kramer and A. MacKinnon, Localization: Theory and experiment, Rep. Prog. Phys. 56, 1469 (1993).
  22. A. Lubk and M. F. Kalady, Supplementary Material to “Geometry dependent localization of surface plasmons on random gold nanoparticle assemblies” (Technische Universität Dresden, 2025), doi:10.25532/opara-715.
