Enhanced slipperiness through rapid drop motion on liquid-infused surfaces

Kun Li1, Xi-Qiao Feng1,2,3, and Cunjing Lv1,2,3,*

  • 1Institute of Biomechanics and Medical Engineering, AML, Department of Engineering Mechanics, Tsinghua University, Beijing 100084, China
  • 2Center for Nano and Micro Mechanics, Tsinghua University, Beijing 100084, China
  • 3State Key Laboratory of Flexible Electronics Technology, Tsinghua University, Beijing 100084, China

  • *Contact author: cunjinglv@tsinghua.edu.cn
PDF

Phys. Rev. Research 8, 013269 – Published 10 March, 2026

DOI: https://doi.org/10.1103/3hw1-82w5

Abstract

Introducing a lubricant layer between a fluid and a solid substrate endows slippery liquid-infused surfaces (SLISs) with excellent interfacial properties, such as a low sliding angle, repellency toward various liquids, icephobicity, and self-healing capability. Previous studies found that the friction force of a sliding drop on SLISs obeys the Landau-Levich-Derjaguin (LLD) theory, i.e., Fη∼Ca2/3, with Ca being the capillary number. In this paper, however, our experiments show that this scaling law holds only at low capillary numbers. We find a distinct decrease in the scaling exponent as the drop accelerates: In the rapid sliding regime, SLISs demonstrate even greater slipperiness than that predicted by the LLD theory. Numerical simulations reveal that this unexpected behavior originates from the incompletely developed state of the back meniscus, while the influence of the front meniscus is insignificant. Compared with the prediction of the Bretherton model, the back meniscus possesses a shorter shear length and a thicker shear layer, therefore reducing friction and enhancing surface slipperiness. An analytical solution is derived to describe the incompletely developed meniscus. This work offers insights into the abnormal frictional behavior when the capillary number of a moving drop exceeds 4×10−3.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (49)

  1. J. Joanny and P.-G. De Gennes, A model for contact angle hysteresis, J. Chem. Phys. 81, 552 (1984).
  2. T. S. Wong, S. H. Kang, S. K. Y. Tang, E. J. Smythe, B. D. Hatton, A. Grinthal, and J. Aizenberg, Bioinspired self-repairing slippery surfaces with pressure-stable omniphobicity, Nature (London) 477, 443 (2011).
  3. A. Keiser, L. Keiser, C. Clanet, and D. Quéré, Drop friction on liquid-infused materials, Soft Matter 13, 6981 (2017).
  4. P.-G. Gennes, F. Brochard-Wyart, and D. Quéré, Capillarity and Wetting Phenomena: Drops, Bubbles, Pearls, Waves (Springer, New York, 2004).
  5. D. Quéré, Leidenfrost dynamics, Annu. Rev. Fluid Mech. 45, 197 (2013).
  6. A. Lafuma and D. Quéré, Superhydrophobic states, Nat. Mater. 2, 457 (2003).
  7. C. Ma, Z. Yuan, W. Tong, L. Wang, C. Lv, and Q. Zheng, Modelling ridge enhanced droplet jumping with varying mismatches and scales for vapor chamber performance estimations, Int. J. Heat Mass Transfer 217, 124668 (2023).
  8. A. Lafuma and D. Quéré, Slippery pre-suffused surfaces, Europhys. Lett. 96, 56001 (2011).
  9. A. Tuteja, W. Choi, J. M. Mabry, G. H. McKinley, and R. E. Cohen, Robust omniphobic surfaces, Proc. Natl. Acad. Sci. USA 105, 18200 (2008).
  10. R. Poetes, K. Holtzmann, K. Franze, and U. Steiner, Metastable underwater superhydrophobicity, Phys. Rev. Lett. 105, 166104 (2010).
  11. L. Keiser, A. Keiser, M. L’Estimé, J. Bico, and E. Reyssat, Motion of viscous droplets in rough confinement: Paradoxical lubrication, Phys. Rev. Lett. 122, 074501 (2019).
  12. D. C. Leslie, A. Waterhouse, J. B. Berthet, T. M. Valentin, A. L. Watters, A. Jain, P. Kim, B. D. Hatton, A. Nedder, K. Donovan, et al., A bioinspired omniphobic surface coating on medical devices prevents thrombosis and biofouling, Nat. Biotechnol. 32, 1134 (2014).
  13. J. D. Smith, R. Dhiman, S. Anand, E. Reza-Garduno, R. E. Cohen, G. H. McKinley, and K. K. Varanasi, Droplet mobility on lubricant-impregnated surfaces, Soft Matter 9, 1772 (2013).
  14. S. Hardt and G. McHale, Flow and drop transport along liquid-infused surfaces, Annu. Rev. Fluid Mech. 54, 83 (2022).
  15. M. Villegas, Y. Zhang, N. A. Jarad, L. Soleymani, and T. F. Didar, Liquid-infused surfaces: A review of theory, design, and applications, ACS Nano 13, 8517 (2019).
  16. S. B. Subramanyam, K. Rykaczewski, and K. K. Varanasi, Ice adhesion on lubricant-impregnated textured surfaces, Langmuir 29, 13414 (2013).
  17. K. Golovin, S. P. Kobaku, D. H. Lee, E. T. DiLoreto, J. M. Mabry, and A. Tuteja, Designing durable icephobic surfaces, Sci. Adv. 2, e1501496 (2016).
  18. P. Juuti, J. Haapanen, C. Stenroos, H. Niemelä-Anttonen, J. Harra, H. Koivuluoto, H. Teisala, J. Lahti, M. Tuominen, J. Kuusipalo, et al., Achieving a slippery, liquid-infused porous surface with anti-icing properties by direct deposition of flame synthesized aerosol nanoparticles on a thermally fragile substrate, Appl. Phys. Lett. 110, 161603 (2017).
  19. P. Kim, M. J. Kreder, J. Alvarenga, and J. Aizenberg, Hierarchical or not? Effect of the length scale and hierarchy of the surface roughness on omniphobicity of lubricant-infused substrates, Nano Lett. 13, 1793 (2013).
  20. L. Xiao, J. Li, S. Mieszkin, A. Di Fino, A. S. Clare, M. E. Callow, J. A. Callow, M. Grunze, A. Rosenhahn, and P. A. Levkin, Slippery liquid-infused porous surfaces showing marine antibiofouling properties, ACS Appl. Mater. Interfaces 5, 10074 (2013).
  21. C. Howell, A. Grinthal, S. Sunny, M. Aizenberg, and J. Aizenberg, Designing liquid-infused surfaces for medical applications: A review, Adv. Mater. 30, 1802724 (2018).
  22. A. Keiser, P. Baumli, D. Vollmer, and D. Quéré, Universality of friction laws on liquid-infused materials, Phys. Rev. Fluids 5, 014005 (2020).
  23. D. Daniel, J. V. Timonen, R. Li, S. J. Velling, and J. Aizenberg, Oleoplaning droplets on lubricated surfaces, Nat. Phys. 13, 1020 (2017).
  24. E. Jambon-Puillet, P. G. Ledda, F. Gallaire, and P.-T. Brun, Drops on the underside of a slightly inclined wet substrate move too fast to grow, Phys. Rev. Lett. 127, 044503 (2021).
  25. M. J. Kreder, D. Daniel, A. Tetreault, Z. Cao, B. Lemaire, J. V. I. Timonen, and J. Aizenberg, Film dynamics and lubricant depletion by droplets moving on lubricated surfaces, Phys. Rev. X 8, 031053 (2018).
  26. F. P. Bretherton, The motion of long bubbles in tubes, J. Fluid Mech. 10, 166 (1961).
  27. See Supplemental Material at http://link.aps.org/supplemental/10.1103/3hw1-82w5 for our measurement of the thickness of thin films behind drops, experimental investigation of dependence of drop sliding velocity v on volume V0, numerical discussion of influence of computational domain height H, self-similarity analysis of the back meniscus, numerical setup for the front meniscus, and supplemental movie captions, which includes Refs. [44, 45, 46, 47, 48, 49].
  28. A. Huerre, O. Theodoly, A. M. Leshansky, M.-P. Valignat, I. Cantat, and M.-C. Jullien, Droplets in microchannels: Dynamical properties of the lubrication film, Phys. Rev. Lett. 115, 064501 (2015).
  29. M. Taroni, C. Breward, P. Howell, and J. Oliver, Boundary conditions for free surface inlet and outlet problems, J. Fluid Mech. 708, 100 (2012).
  30. G. Taylor, Cavitation of a viscous fluid in narrow passages, J. Fluid Mech. 16, 595 (1963).
  31. L. Landau and B. Levich, Dragging of a liquid by a moving plate, Acta Physicochim. URSS 17, 42 (1942).
  32. B. Derjaguin, On the thickness of the liquid film adhering to the walls of a vessel after emptying, C. R. Acad. Sci. URSS 39, 11 (1943).
  33. D. Quéré, Fluid coating on a fiber, Annu. Rev. Fluid Mech. 31, 347 (1999).
  34. C. Clanet and D. Quéré, Onset of menisci, J. Fluid Mech. 460, 131 (2002).
  35. A. Ponomarenko, D. Quéré, and C. Clanet, A universal law for capillary rise in corners, J. Fluid Mech. 666, 146 (2011).
  36. L. Tanner, The spreading of silicone oil drops on horizontal surfaces, J. Phys. D 12, 1473 (1979).
  37. S. L. Cormier, J. D. McGraw, T. Salez, E. Raphaël, and K. Dalnoki-Veress, Beyond Tanner's law: Crossover between spreading regimes of a viscous droplet on an identical film, Phys. Rev. Lett. 109, 154501 (2012).
  38. I. Cantat, Liquid meniscus friction on a wet plate: Bubbles, lamellae, and foams, Phys. Fluids 25, 031303 (2013).
  39. K. Ruschak, Boundary conditions at a liquid/air interface in lubrication flows, J. Fluid Mech. 119, 107 (1982).
  40. R. W. Hewson, Free surface model derived from the analytical solution of Stokes flow in a wedge, J. Fluids Eng. 131, 041205 (2009).
  41. B. Zhao, A. A. Pahlavan, L. Cueto-Felgueroso, and R. Juanes, Forced wetting transition and bubble pinch-off in a capillary tube, Phys. Rev. Lett. 120, 084501 (2018).
  42. M. Muradoglu and H. A. Stone, Motion of large bubbles in curved channels, J. Fluid Mech. 570, 455 (2007).
  43. E. Klaseboer, R. Gupta, and R. Manica, An extended Bretherton model for long Taylor bubbles at moderate capillary numbers, Phys. Fluids 26, 032107 (2014).
  44. J. B. Luo, M. W. Shen, and S. Z. Wen, Tribological properties of nanoliquid film under an external electric field, J. Appl. Phys. 96, 6733 (2004).
  45. H. Chen, Q. Meng, and J. Li, Thin lubrication film around moving bubbles measured in square microchannels, Appl. Phys. Lett. 107, 141608 (2015).
  46. E. Hecht, Optics, 5th ed. (Pearson, Harlow, Essex, 2014).
  47. G. I. Barenblatt, Scaling, Self-Similarity, and Intermediate Asymptotics (Cambridge University Press, New York, 1996).
  48. M. Jalaal, C. Seyfert, and J. H. Snoeijer, Capillary ripples in thin viscous films, J. Fluid Mech. 880, 430 (2019).
  49. M. D. Giavedoni and F. A. Saita, The rear meniscus of a long bubble steadily displacing a Newtonian liquid in a capillary tube, Phys. Fluids 11, 786 (1999).
