Ballistic-to-diffusive transition in engineered counterpropagating quantum Hall channels

Aifei Zhang1, Kenji Watanabe2, Takashi Taniguchi3, Patrice Roche1, Carles Altimiras1, François D. Parmentier1,4, and Olivier Maillet1,*

  • *Contact author: olivier.maillet@cea.fr
PDF

Phys. Rev. Research 7, L042037 – Published 19 November, 2025

DOI: https://doi.org/10.1103/3d25-wpth

Abstract

Exotic quantum Hall systems hosting counterpropagating edge states can show seemingly nonuniversal transport regimes, usually depending on the size of the sample. We experimentally probe transport in a quantum Hall sample engineered to host a tunable number of counterpropagating edge states. The latter are coupled by Landauer reservoirs, which force charge equilibration over a tunable effective length. We show that charge transport is determined by the balance of up- and downstream channels, with a ballistic regime emerging for unequal numbers of channels. For equal numbers, we observe a transition to a critical diffusive regime, characterized by a diverging equilibration length. Our approach allows simulating the equilibration of hole-conjugate states and other exotic quantum Hall effects with fully controlled parameters using well-understood quantum Hall states.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (34)

  1. I. Neder, M. Heiblum, Y. Levinson, D. Mahalu, and V. Umansky, Unexpected behavior in a two-path electron interferometer, Phys. Rev. Lett. 96, 016804 (2006).
  2. H. le Sueur, C. Altimiras, U. Gennser, A. Cavanna, D. Mailly, and F. Pierre, Energy relaxation in the integer quantum Hall regime, Phys. Rev. Lett. 105, 056803 (2010).
  3. M. König, S. Wiedmann, C. Brüne, A. Roth, H. Buhmann, L. W. Molenkamp, X.-L. Qi, and S.-C. Zhang, Quantum spin Hall insulator state in HgTe quantum wells, Science 318, 766 (2007).
  4. A. H. MacDonald, Edge states in the fractional-quantum-Hall-effect regime, Phys. Rev. Lett. 64, 220 (1990).
  5. C. L. Kane, M. P. A. Fisher, and J. Polchinski, Randomness at the edge: Theory of quantum Hall transport at filling ν = 2/3, Phys. Rev. Lett. 72, 4129 (1994).
  6. I. Protopopov, Y. Gefen, and A. Mirlin, Transport in a disordered ν = 2/3 fractional quantum Hall junction, Ann. Phys. 385, 287 (2017).
  7. C. Nosiglia, J. Park, B. Rosenow, and Y. Gefen, Incoherent transport on the ν=2/3 quantum Hall edge, Phys. Rev. B 98, 115408 (2018).
  8. J. Park, A. D. Mirlin, B. Rosenow, and Y. Gefen, Noise on complex quantum Hall edges: Chiral anomaly and heat diffusion, Phys. Rev. B 99, 161302 (2019).
  9. C. Spånslätt, J. Park, Y. Gefen, and A. D. Mirlin, Topological classification of shot noise on fractional quantum Hall edges, Phys. Rev. Lett. 123, 137701 (2019).
  10. C. Spånslätt, J. Park, Y. Gefen, and A. D. Mirlin, Conductance plateaus and shot noise in fractional quantum Hall point contacts, Phys. Rev. B 101, 075308 (2020).
  11. T. Fujisawa and C. Lin, Plasmon modes of coupled quantum Hall edge channels in the presence of disorder-induced tunneling, Phys. Rev. B 103, 165302 (2021).
  12. D. C. Glattli, C. Boudet, A. De, and P. Roulleau, Revisiting the physics of hole-conjugate fractional quantum Hall channels, Phys. Rev. Res. 7, 043026 (2025).
  13. A. Bid, N. Ofek, H. Inoue, M. Heiblum, C. L. Kane, V. Umansky, and D. Mahalu, Observation of neutral modes in the fractional quantum Hall regime, Nature (London) 466, 585 (2010).
  14. C. Lin, R. Eguchi, M. Hashisaka, T. Akiho, K. Muraki, and T. Fujisawa, Charge equilibration in integer and fractional quantum Hall edge channels in a generalized Hall-bar device, Phys. Rev. B 99, 195304 (2019).
  15. Y. Cohen, Y. Ronen, W. Yang, D. Banitt, J. Park, M. Heiblum, A. D. Mirlin, Y. Gefen, and V. Umansky, Synthesizing a ν = 2/3 fractional quantum Hall effect edge state from counter-propagating ν = 1 and ν = 1/3 states, Nat. Commun. 10, 1920 (2019).
  16. F. Lafont, A. Rosenblatt, M. Heiblum, and V. Umansky, Counter-propagating charge transport in the quantum Hall effect regime, Science 363, 54 (2019).
  17. S. K. Srivastav, R. Kumar, C. Spånslätt, K. Watanabe, T. Taniguchi, A. D. Mirlin, Y. Gefen, and A. Das, Vanishing thermal equilibration for hole-conjugate fractional quantum Hall states in graphene, Phys. Rev. Lett. 126, 216803 (2021).
  18. R. A. Melcer, B. Dutta, C. Spånslätt, J. Park, A. D. Mirlin, and V. Umansky, Absent thermal equilibration on fractional quantum Hall edges over macroscopic scale, Nat. Commun. 13, 376 (2022).
  19. A. Roth, C. Brüne, H. Buhmann, L. W. Molenkamp, J. Maciejko, X.-L. Qi, and S.-C. Zhang, Nonlocal transport in the quantum spin Hall state, Science 325, 294 (2009).
  20. I. Knez, R.-R. Du, and G. Sullivan, Evidence for helical edge modes in inverted InAs/GaSb quantum wells, Phys. Rev. Lett. 107, 136603 (2011).
  21. S. Wu, V. Fatemi, Q. D. Gibson, K. Watanabe, T. Taniguchi, R. J. Cava, and P. Jarillo-Herrero, Observation of the quantum spin Hall effect up to 100 kelvin in a monolayer crystal, Science 359, 76 (2018).
  22. L. Veyrat, C. Déprez, A. Coissard, X. Li, F. Gay, K. Watanabe, T. Taniguchi, Z. Han, B. A. Piot, H. Sellier, and B. Sacépé, Helical quantum Hall phase in graphene on SrTiO3, Science 367, 781 (2020).
  23. K. Kang, B. Shen, Y. Qiu, Y. Zeng, Z. Xia, K. Watanabe, T. Taniguchi, J. Shan, and K. F. Mak, Evidence of the fractional quantum spin Hall effect in moiré MoTe2, Nature (London) 628, 522 (2024).
  24. B. Yang, B. Bhujel, D. G. Chica, E. J. Telford, X. Roy, F. Ibrahim, M. Chshiev, M. Cosset-Chéneau, and B. J. van Wees, Electrostatically controlled spin polarization in Graphene-CrSBr magnetic proximity heterostructures, Nat. Commun. 15, 4459 (2024).
  25. M. Banerjee, M. Heiblum, A. Rosenblatt, Y. Oreg, D. E. Feldman, A. Stern, and V. Umansky, Observed quantization of anyonic heat flow, Nature (London) 545, 75 (2017).
  26. C. R. Dean, A. F. Young, I. Meric, C. Lee, L. Wang, S. Sorgenfrei, K. Watanabe, T. Taniguchi, P. Kim, K. L. Shepard, and J. Hone, Boron nitride substrates for high-quality graphene electronics, Nat. Nanotechnol. 5, 722 (2010).
  27. See Supplemental Material at http://link.aps.org/supplemental/10.1103/3d25-wpth for details on the sample fabrication, derivation of the voltage profiles, additional data in both integer and fractional QH regimes, and theoretical comparison between our approach and transfer matrix descriptions of the ν−2/3 edge.
  28. C. L. Kane and M. P. A. Fisher, Quantized thermal transport in the fractional quantum Hall effect, Phys. Rev. B 55, 15832 (1997).
  29. M. Hashisaka, T. Ito, T. Akiho, S. Sasaki, N. Kumada, N. Shibata, and K. Muraki, Coherent-incoherent crossover of charge and neutral mode transport as evidence for the disorder-dominated fractional edge phase, Phys. Rev. X 13, 031024 (2023).
  30. G. Krizman, J. Bermejo-Ortiz, T. Zakusylo, M. Hajlaoui, T. Takashiro, M. Rosmus, N. Olszowska, J. J. Kołodziej, G. Bauer, Y. Guldner, G. Springholz, and L.-A. de Vaulchier, Valley-polarized quantum Hall phase in a strain-controlled Dirac system, Phys. Rev. Lett. 132, 166601 (2024).
  31. E. Sivre, A. Anthore, F. D. Parmentier, A. Cavanna, U. Gennser, A. Ouerghi, Y. Jin, and F. Pierre, Heat Coulomb blockade of one ballistic channel, Nat. Phys. 14, 145 (2018).
  32. F. Stäbler and E. Sukhorukov, Mesoscopic heat multiplier and fractionalizer, Phys. Rev. B 108, 235405 (2023).
  33. F. Stäbler, A. Gadiaga, and E. V. Sukhorukov, Giant heat flux effect in non-chiral transmission lines, Phys. Rev. Res. 7, 033228 (2025).
  34. https://doi.org/10.5281/zenodo.15538630.
