Middle-range-energy structures in Ti L2,3−edge x-ray absorption spectra of titanium oxides

Saki Imada1,*, Yves Joly2, and Frank M. F. de Groot3

  • *Contact author: saki_imada@kit.ac.jp
PDF

Phys. Rev. Research 8, 033377 – Published 29 September, 2026

DOI: https://doi.org/10.1103/36kd-rnvd

Abstract

The Ti L2,3−edge x-ray absorption spectra of various titanium oxides, including perovskite SrTiO3, rutile and anatase TiO2, and ilmenite CoTiO3, are analyzed with particular attention to the energy range beyond the near-edge/charge-transfer region and up to the oxygen K edge. We found that the spectral structure varies among materials and can be described using density functional theory without including the multielectron effects indispensable for describing near-edge and charge-transfer structures. We term the structures in this energy range the middle-range-energy structure and show that the distinct features are determined by the local atomic geometry around the target Ti atoms and, essentially, by the partial density of states of those atoms. Here, we demonstrate how to extract information from middle-range-energy structures by comparing them with ab initio calculations, and we propose this energy-range analysis as a new method for studying local atomic geometry, free of parameters describing multielectron effects.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (33)

  1. C. R. Natoli, M. Benfatto, S. D. Longa, and K. Hatada, X-ray absorption spectroscopy: State-of-the-art analysis, J. Synchrotron Radiat. 10, 26 (2003).
  2. G. Beni and P. M. Platzman, Temperature and polarization dependence of extended x-ray absorption fine-structure spectra, Phys. Rev. B 14, 1514 (1976).
  3. O. Bunău, A. Y. Ramos, and Y. Joly, The fdmnes code, in International Tables for Crystallography (International Union of Crystallography, 2024), Chap. 6.6, pp. 752–757.
  4. P. Blaha, WIEN2k: An augmented plane wave plus local orbital package for the electronic structure of solids, in International Tables for Crystallography (International Union of Crystallography, 2021), Chap. 6.22, pp. 836–842.
  5. J. J. Rehr, J. J. Kas, M. P. Prange, A. P. Sorini, Y. Takimoto, and F. Vila, Ab initio theory and calculations of X-ray spectra, C. R. Phys. 10, 548 (2008).
  6. F. De Groot, Multiplet effects in X-ray spectroscopy, Coord. Chem. Rev. 249, 31 (2005).
  7. F. de Groot, Multiplet approaches in X-ray absorption spectroscopy, in International Tables for Crystallography (International Union of Crystallography, 2024), Vol. I, Chap. 2.4, pp. 55–59.
  8. J. Schwitalla and H. Ebert, Electron core-hole interaction in the X-ray absorption spectroscopy of 3d transition metals, Phys. Rev. Lett. 80, 4586 (1998).
  9. O. Bunãu and Y. Joly, Time-dependent density functional theory applied to x-ray absorption spectroscopy, Phys. Rev. B 85, 155121 (2012).
  10. E. L. Shirley, Bethe-Salpeter treatment of x-ray absorption including core-hole multiplet effects, J. Electron Spectrosc. Relat. Phenom. 144–147, 1187 (2005).
  11. M. Roemelt, D. Maganas, S. DeBeer, and F. Neese, A combined DFT and restricted open-shell configuration interaction method including spin-orbit coupling: Application to transition metal L-edge X-ray absorption spectroscopy, J. Chem. Phys. 138, 204101 (2013).
  12. F. M. F. De Groot, J. C. Fuggle, B. T. Thole, and G. A. Sawatzky, L2,3 X-ray-absorption edges of d0 compounds: K+, Ca2+, Sc3+, and Ti4+ in Oh (octahedral) symmetry, Phys. Rev. B 41, 928 (1990).
  13. G. van der Laan, Polaronic satellites in x-ray-absorption spectra, Phys. Rev. B 41, 12366 (1990).
  14. K. Okada and A. Kotani, Theory of core level X-ray photoemission and photoabsorption in Ti compounds, J. Electron Spectros. Relat. Phenomena 62, 131 (1993).
  15. J. P. Crocombette and F. Jollet, Ti 2p X-ray absorption in titanium dioxides (TiO2): The influence of the cation site environment, J. Phys. Condens. Matter 6, 10811 (1994).
  16. J. C. Woicik, C. Weiland, C. Jaye, D. A. Fischer, A. K. Rumaiz, E. L. Shirley, J. J. Kas, and J. J. Rehr, Charge-transfer satellites and chemical bonding in photoemission and x-ray absorption of SrTiO3 and rutile TiO2: Experiment and first-principal, Phys. Rev. B 101, 245119 (2020).
  17. S. Stemmer, T. Höche, R. Keding, C. Rüssel, R. Schneider, N. D. Browning, S. K. Streiffer, and H. J. Kleebe, Oxidation states of titanium in bulk barium titanates and in (100) fiber-textured (BaxSr1−x)Ti1+yO3+z thin films, Appl. Phys. Lett. 79, 3149 (2001).
  18. H. Gu, Chemical structure of grain-boundary layer in SrTiO3 and its segregation-induced transition: A continuum interface approach, Chin. Phys. B 27, 060503 (2018).
  19. F. M. F. De Groot, M. O. Figueiredo, M. J. Basto, M. Abbate, H. Petersen, and J. C. Fuggle, 2p X-ray absorption of titanium in minerals, Phys. Chem. Miner. 19, 140 (1992).
  20. Y. Harada, T. Kinugasa, R. Eguchi, M. Matsubara, A. Kotani, M. Watanabe, A. Yagishita, and S. Shin, Polarization dependence of soft-x-ray Raman scattering at the L edge of TiO2, Phys. Rev. B 61, 12854 (2000).
  21. A. Agui, M. Mizumaki, Y. Saitoh, T. Matsushita, T. Nakatani, A. Fukaya, and E. Torikai, Soft X-ray absorption spectra of ilmenite family, J. Synchrotron Radiat. 8, 907 (2001).
  22. K. Yoshimatsu, H. Mashiko, N. Umezawa, K. Horiba, H. Kumigashira, and A. Ohtomo, Electronic structures and photoanodic properties of ilmenite-type MTiO3 epitaxial films (M=Mn, Fe, Co, Ni), J. Phys. Chem. C 121, 18717 (2017).
  23. Y. Joly, A. Y. Ramos, and O. Bunău, Finite-difference method for the calculation of x-ray spectroscopies, Int. Tables Crystallogr. I, 114 (2024).
  24. H. Ohashi, E. Ishiguro, Y. Tamenori, H. Kishimoto, M. Tanaka, M. Irie, T. Tanaka, and T. Ishikawa, Outline of soft X-ray photochemistry beamline BL27SU of SPring-8, Methods Phys. Res. A: Accel. Spectrom. Detect. Assoc. 467–468, 529 (2001).
  25. T. Gejo, Y. Takata, T. Hatsui, M. Nagasono, H. Oji, N. Kosugi, and E. Shigemasa, Angle-resolved photoion spectroscopy of NO2 and SO2, Chem. Phys. 289, 15 (2003).
  26. See Supplemental Material at http://link.aps.org/supplemental/10.1103/36kd-rnvd for fdmnes calculations and figures of spectra calculated using MT-MST and MT.
  27. A. Jain et al., Commentary: The Materials Project: A materials genome approach to accelerating materials innovation, APL Mater. 1, 011002 (2013).
  28. M. K. Horton et al., Accelerated data-driven materials science with the Materials Project, Nat. Mater. 24, 1522 (2025).
  29. A. Scherz, E. K. U. Gross, H. Appel, C. Sorg, K. Baberschke, H. Wende, and K. Burke, Measuring the kernel of time-dependent density functional theory with X-ray absorption spectroscopy of 3d transition metals, Phys. Rev. Lett. 95, 253006 (2005).
  30. N. C. Wilson, J. Muscat, D. Mkhonto, P. E. Ngoepe, and N. M. Harrison, Structure and properties of ilmenite from first principles, Phys. Rev. B 71, 075202 (2005).
  31. F. M. F. de Groot, J. Faber, J. J. M. Michiels, M. T. Czyżyk, M. Abbate, and J. C. Fuggle, Oxygen 1s x-ray absorption of tetravalent titanium oxides: A comparison with single-particle calculations, Phys. Rev. B 48, 2074 (1993).
  32. A. Hariki, K. Higashi, T. Yamaguchi, J. Li, C. Kalha, M. Mascheck, S. K. Eriksson, T. Wiell, F. M. F. de Groot, and A. Regoutz, Satellites in the Ti 1s core level spectra of SrTiO3 and TiO2, Phys. Rev. B 106, 205138 (2022).
  33. K. Okada, T. Uozumi, and A. Kotani, Charge-transfer satellites in Ti 2p XAS and XPS of Ti compounds, Jpn. J. Appl. Phys. 32, 113 (1993).
