Loop-gap resonators achieving strong magnon-photon coupling in magnetic insulator thin films

Francesca Zanichelli1,2,*, Davit Petrosyan1,*, Hanchen Wang1, Patrick Helbingk1, Richard Schlitz1,3, Pietro Gambardella1, and William Legrand1,4,†

  • *These authors contributed equally to this work.
  • †Contact author: william.legrand@neel.cnrs.fr
PDF

Phys. Rev. Research 8, 023249 – Published 5 June, 2026

DOI: https://doi.org/10.1103/1mc9-k683
