Helicon plasma mode transitions at low magnetic fields

Landon D. Bevier* and Justin M. Little

  • *Contact author: ldbevier@gmail.com
PDF

Phys. Rev. Research 8, 023177 – Published 18 May, 2026

DOI: https://doi.org/10.1103/13gy-rz2v

Abstract

The nature of a low-field helicon plasma mode transition is examined using experiment and theory. Tests in a radio frequency plasma source reveal an abrupt transition between helicon and capacitive discharge modes that occurs at a critical magnetic field strength. To characterize the mode transition, a global model for low-field m=0 helicon plasmas is developed based on power absorption via Landau damping. A general scaling law for the critical field strength is derived from the model and experimentally validated using measurements of electron density and temperature. The assumption of power absorption via Landau damping in the model leads to a critical condition for the ratio of wave phase velocity and electron thermal velocity. Measurements of wave phase velocity and electron temperature while operating on mixtures of argon and N2O support the theoretical prediction and show that the mode transition depends on electron properties rather than on the ion and neutral composition. Agreement between theory and experiment shows that Landau damping is the primary power absorption mechanism in low-field, conducting boundary helicon plasmas.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (48)

  1. M. A. Lieberman and A. J. Lichtenberg, Principles of Plasma Discharges and Materials Processing (John Wiley & Sons, Inc., Hoboken, NJ, 2005).
  2. S. Shinohara, Helicon high-density plasma sources: Physics and applications, Adv. Phys.: X 3, 1420424 (2018).
  3. A. J. Perry, The application of the helicon source to plasma processing, J. Vac. Sci. Technol. B 9, 310 (1991).
  4. C. Charles, R. W. Boswell, R. Laine, and P. MacLellan, An experimental investigation of alternative propellants for the helicon double layer thruster, J. Phys. D: Appl. Phys. 41, 175213 (2008).
  5. J. L. Rovey, C. T. Lyne, A. J. Mundahl, N. Rasmont, M. S. Glascock, M. J. Wainwright, and S. P. Berg, Review of multimode space propulsion, Prog. Aerosp. Sci. 118, 100627 (2020).
  6. K. Takahashi, Helicon-type radiofrequency plasma thrusters and magnetic plasma nozzles, Rev. Mod. Plasma Phys. 3, 3 (2019).
  7. R. Winglee, T. Ziemba, L. Giersch, J. Prager, J. Carscadden, and B. R. Roberson, Simulation and laboratory validation of magnetic nozzle effects for the high power helicon thruster, Phys. Plasmas 14, 063501 (2007).
  8. A. C. Hossack, T. Firman, T. R. Jarboe, J. R. Prager, B. S. Victor, J. S. Wrobel, and T. Ziemba, Reduction of plasma density in the helicity injected Torus with steady inductance experiment by using a helicon pre-ionization source, Rev. Sci. Instrum. 84, 103506 (2013).
  9. S. C. Thakur, C. Brandt, L. Cui, J. J. Gosselin, A. D. Light, and G. R. Tynan, Multi-instability plasma dynamics during the route to fully developed turbulence in a helicon plasma, Plasma Sources Sci. Technol. 23, 044006 (2014).
  10. P. Chabert and N. Braithwaite, Physics of Radio-Frequency Plasmas, 1st ed. (Cambridge University Press, Cambridge, UK, 2011).
  11. F. F. Chen, Plasma ionization by helicon waves, Plasma Phys. Control. Fusion 33, 339 (1991).
  12. R. W. Boswell, Very efficient plasma generation by whistler waves near the lower hybrid frequency, Plasma Phys. Control. Fusion 26, 1147 (1984).
  13. J. E. Stevens, M. J. Sowa, and J. L. Cecchi, Helicon plasma source excited by a flat spiral coil, J. Vac. Sci. Technol. A 13, 2476 (1995).
  14. F. F. Chen, X. Jiang, J. D. Evans, G. Tynan, and D. Arnush, Low-field helicon discharges, Plasma Phys. Control. Fusion 39, A411 (1997).
  15. T. Lafleur, C. Charles, and R. W. Boswell, Ion beam formation in a very low magnetic field expanding helicon discharge, Phys. Plasmas 17, 043505 (2010).
  16. F. F. Chen, Helicon discharges and sources: A review, Plasma Sources Sci. Technol. 24, 014001 (2015).
  17. S. Shinohara and T. Tanikawa, Characteristics of a large volume, helicon plasma source, Phys. Plasmas 12, 044502 (2005).
  18. T. Motomura, K. Tanaka, S. Shinohara, T. Tanikawa, and K. P. Shamrai, Characteristics of large diameter, high-density helicon plasma with short axial length using a flat spiral antenna, J. Plasma Fusion Res. 8, 6 (2009).
  19. G. Sato, W. Oohara, and R. Hatakeyama, Experimental characterization of a density peak at low magnetic fields in a helicon plasma source, Plasma Sources Sci. Technol. 16, 734 (2007).
  20. T. Lafleur, C. Charles, and R. W. Boswell, Characterization of the ion beam formed in a low magnetic field helicon mode, J. Phys. D: Appl. Phys. 44, 145204 (2011).
  21. S. J. Wang, J. G. Kwak, C. B. Kim, and S. K. Kim, Observation of enhanced negative hydrogen ion production in weakly magnetized RF plasma, Phys. Lett. A 313, 278 (2003).
  22. K. P. Shamrai and V. B. Taranov, Volume and surface rf power absorption in a helicon plasma source, Plasma Sources Sci. Technol. 5, 474 (1996).
  23. D. D. Blackwell, T. G. Madziwa, D. Arnush, and F. F. Chen, Evidence for Trivelpiece-Gould modes in a helicon discharge, Phys. Rev. Lett. 88, 145002 (2002).
  24. F. F. Chen and D. D. Blackwell, Upper limit to Landau damping in helicon discharges, Phys. Rev. Lett. 82, 2677 (1999).
  25. T. Lafleur, C. Charles, and R. W. Boswell, Plasma control by modification of helicon wave propagation in low magnetic fields, Phys. Plasmas 17, 073508 (2010).
  26. X. M. Guo, J. Scharer, Y. Mouzouris, and L. Louis, Helicon experiments and simulations in nonuniform magnetic field configurations, Phys. Plasmas 6, 3400 (1999).
  27. B. N. Breizman and A. V. Arefiev, Radially localized helicon modes in nonuniform plasma, Phys. Rev. Lett. 84, 3863 (2000).
  28. A. W. Degeling, C. O. Jung, R. W. Boswell, and A. R. Ellingboe, Plasma production from helicon waves, Phys. Plasmas 3, 2788 (1996).
  29. M. A. Lieberman and R. W. Boswell, Modeling the transitions from capacitive to inductive to wave-sustained rf discharges, J. Phys. IV France 08, Pr7-145 (1998).
  30. E. Ahedo and M. Merino, On plasma detachment in propulsive magnetic nozzles, Phys. Plasmas 18, 053504 (2011).
  31. J. M. Little and E. Y. Choueiri, Electron demagnetization in a magnetically expanding plasma, Phys. Rev. Lett. 123, 145001 (2019).
  32. J. M. Little and E. Y. Choueiri, Thrust and efficiency model for electron-driven magnetic nozzles, Phys. Plasmas 20, 103501 (2013).
  33. T. Lafleur, Helicon plasma thruster discharge model, Phys. Plasmas 21, 043507, (2014).
  34. R. B. Lobbia and B. E. Beal, Recommended practice for use of Langmuir probes in electric propulsion testing, J. Propul. Power 33, 566 (2017).
  35. F. F. Chen, J. D. Evans, and D. Arnush, A floating potential method for measuring ion density, Phys. Plasmas 9, 1449 (2002).
  36. J. Hopwood, Review of inductively coupled plasmas for plasma processing, Plasma Sources Sci. Technol. 1, 109 (1992).
  37. A. R. Ellingboe and R. W. Boswell, Capacitive, inductive and helicon-wave modes of operation of a helicon plasma source, Phys. Plasmas 3, 2797 (1996).
  38. J. M. Little and E. Y. Choueiri, Critical condition for plasma confinement in the source of a magnetic nozzle flow, IEEE Trans. Plasma Sci. 43, 277 (2015).
  39. F. F. Chen, The low-field density peak in helicon discharges, Phys. Plasmas 10, 2586 (2003).
  40. S. Cho, The resistance peak of helicon plasmas at low magnetic fields, Phys. Plasmas 13, 033504 (2006).
  41. J. Meichsner, M. Schmidt, R. Schneider, and H.-E. Wagner, Nonthermal Plasma Chemistry and Physics, 1st ed. (CRC Press, Boca Raton, FL, 2013).
  42. A. J. Sheppard and J. M. Little, Scaling laws for electrodeless plasma propulsion with water vapor propellant, Plasma Sources Sci. Technol. 29, 045007 (2020).
  43. K. Shamrai and V. Taranov, Resonances and anti-resonances of a plasma column in a helicon plasma source, Phys. Lett. A 204, 139 (1995).
  44. K. P. Shamrai, V. P. Pavlenko, and V. B. Taranov, Plasma physics and controlled fusion excitation, conversion and damping of waves in a helicon plasma source driven by an m = 0 antenna excitation, conversion and damping of waves in a helicon plasma source driven by an m = 0 antenna, Plasma Phys. Control. Fusion 39, 505 (1997).
  45. K. A. Polzin, C. S. Hill, P. J. Turchi, R. L. Burton, S. Messer, R. H. Lovberg, and A. K. Hallock, Recommended practice for use of inductive magnetic field probes in electric propulsion testing, J. Propul. Power 33, 659 (2017).
  46. R. J. Goldston and P. H. Rutherford, Introduction to Plasma Physics (Taylor & Francis Group, New York, 1995).
  47. A. W. Molvik, A. R. Ellingboe, and T. D. Rognlien, Hot-electron production and wave structure in a helicon plasma source, Phys. Rev. Lett. 79, 233 (1997).
  48. R. T. S. Chen and N. Hershkowitz, Multiple electron beams generated by a helicon plasma discharge, Phys. Rev. Lett. 80, 4677 (1998).
