Interface density driven metal-to-insulator transition in nickelate based heterostructures

Lucia Varbaro1, Lukas Korosec1, Chih-Ying Hsu1,2, Duncan T. L. Alexander2, Alexandru B. Georgescu3, and Jean-Marc Triscone1

PDF

Phys. Rev. Materials 9, 116202 – Published 10 November, 2025

DOI: https://doi.org/10.1103/syz5-9cbc

Abstract

Heterostructures made of alternating metallic layers of Nd0.7La0.3NiO3 and layers displaying a metal-to-insulator transition (such as SmNiO3) have been grown varying the period of the superlattices on top of LaAlO3 substrates. Exploiting the phase boundary cost found between metallic and insulating phases of nickelates, it is shown that a metallic layer can be turned into an insulating one by means of heterostructuring in an intermediate thickness regime in which the single layers retain their metallic behavior.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (32)

  1. D. I. Khomskii, Transition Metal Compounds (Cambridge University Press, Cambridge, 2014).
  2. P. A. Cox, Transition Metal Oxides: An Introduction to their Electronic Structure and Properties (Oxford University Press, Oxford, 2010).
  3. H. Y. Hwang, Y. Iwasa, M. Kawasaki, B. Keimer, N. Nagaosa, and Y. Tokura, Emergent phenomena at oxide interfaces, Nat. Mater. 11, 103 (2012).
  4. N. F. Mott, The basis of the electron theory of metals, with special reference to the transition metals, Proc. Phys. Soc. A 62, 416 (1949).
  5. N. F. Mott, Metal-insulator transition, Rev. Mod. Phys. 40, 677 (1968).
  6. J. A. Alonso, M. J. Martínez-Lope, M. T. Casais, M. A. G. Aranda, and M. T. Fernández-Díaz, Metal-insulator transitions, structural and microstructural evolution of RNiO3 (R = Sm, Eu, Gd, Dy, Ho, Y) perovskites: Evidence for room-temperature charge disproportionation in monoclinic HoNiO3 and YNiO3, J. Am. Chem. Soc. 121, 4754 (1999).
  7. J. A. Alonso, J. L. García-Muñoz, M. T. Fernández-Díaz, M. A. G. Aranda, M. J. Martínez-Lope, and M. T. Casais, Charge disproportionation in NiO3 perovskites: Simultaneous metal-insulator and structural transition in YNiO3, Phys. Rev. Lett. 82, 3871 (1999).
  8. J. del Valle, R. Rocco, C. Domínguez, J. Fowlie, S. Gariglio, M. J. Rozenberg, and J.-M. Triscone, Dynamics of the electrically induced insulator-to-metal transition in rare-earth nickelates, Phys. Rev. B 104, 165141 (2021).
  9. J. Son, S. Rajan, S. Stemmer, and S. J. Allen, A heterojunction modulation-doped Mott transistor, J. Appl. Phys. 110, 084503 (2011).
  10. A. Parihar, M. Jerry, S. Datta, and A. Raychowdhury, Stochastic IMT (insulator-metal-transition) neurons: An interplay of thermal and threshold noise at bifurcation, Front. Neurosci. 12, 210 (2018).
  11. G. Catalan, Progress in perovskite nickelate research, Ph. Transit. 81, 729 (2008).
  12. M. L. Medarde, Structural, magnetic and electronic properties of perovskites (R = rare earth), J. Phys.: Condens. Matter 9, 1679 (1997).
  13. S. Catalano, M. Gibert, J. Fowlie, J. Íñiguez, J.-M. Triscone, and J. Kreise, Rare-earth nickelates: thin films and heterostructures, Rep. Prog. Phys. 81, 046501 (2018).
  14. J. B. Torrance, P. Lacorre, A. I. Nazzal, E. J. Ansaldo, and Ch. Niedermayer, Systematic study of insulator-metal transitions in perovskites RNiO3 (R = Pr, Nd, Sm, Eu) due to closing of charge-transfer gap, Phys. Rev. B 45, 8209 (1992).
  15. A. Subedi, O. E. Peil, and A. Georges, Low-energy description of the metal-insulator transition in the rare-earth nickelates, Phys. Rev. B 91, 075128 (2015).
  16. O. E. Peil, A. Hampel, C. Ederer, and A. Georges, Mechanism and control parameters of the coupled structural and metal-insulator transition in nickelates, Phys. Rev. B 99, 245127 (2019).
  17. C. Domínguez, A. B. Georgescu, B. Mundet, Y. Zhang, J. Fowlie, A. Mercy, A. Waelchli, S. Catalano, D. T. L. Alexander, P. Ghosez, A. Georges, A. J. Millis, M. Gibert, and J.-M. Triscone, Length scales of interfacial coupling between metal and insulator phases in oxides, Nat. Mater. 19, 1182 (2020).
  18. B. Mundet, C. Domínguez, J. Fowlie, M. Gibert, J.-M. Triscone, and D. T. L. Alexander, Near-atomic-scale mapping of electronic phases in rare earth nickelate superlattices, Nano Lett. 21, 2436 (2021).
  19. See Supplemental Material at http://link.aps.org/supplemental/10.1103/syz5-9cbc for details of the growth and characterization of single-layer and superlattice nickelate films; high-resolution STEM, EDXS, and EELS analyses of layer structure, composition, and interdiffusion; strain and domain mapping using geometric phase analysis; quantification of interface intermixing; resistivity versus temperature curves for all superlattices; DFT calculations of crystal symmetry and Ni–O–Ni bond angles; and a full description of experimental methods, which includes Refs. [25, 26, 27, 28, 29, 30, 31].
  20. J. Fowlie, B. Mundet, C. Toulouse, A. Schober, M. Guennou, C. Domínguez, M. Gibert, D. T. L. Alexander, J. Kreisel, and J.-M. Triscone, Crossover between distinct symmetries in solid solutions of rare earth nickelates, APL Mater. 9, 081119 (2021).
  21. J. Fowlie, Electronic and structural properties of LaNiO3-based heterostructures, PhD. thesis, Université de Genève, 2018.
  22. C. B. Eom, J. Z. Sun, B. M. Lairson, S. K. Streiffer, A. F. Marshall, K. Yamamoto, S. M. Anlage, J. C. Bravman, T. H. Geballe, S. S. Laderman, R. C. Taber, and R. D. Jacowitz, Synthesis and properties of YBa2Cu3O7 thin films grown in situ by 90∘ off-axis single magnetron sputtering, Physica C: Supercond. 171, 354 (1990).
  23. L. Varbaro, B. Mundet, C. Domínguez, J. Fowlie, A. B. Georgescu, L. Korosec, D. T. L. Alexander, and J.-M. Triscone, Electronic coupling of metal-to-insulator transitions in nickelate-based heterostructures, Adv. Electron. Mater. 9, 2201291 (2023).
  24. L. Varbaro, B. Mundet, S. Bandyopadhyay, C. Domínguez, J. Fowlie, L. Korosec, C.-Y. Hsu, D. T. L. Alexander, P. Ghosez, and J.-M. Triscone, Structural study of nickelate based heterostructures, APL Mater. 12, 031104 (2024).
  25. G. Lucas, P. Burdet, M. Cantoni, and C. Hébert, Multivariate statistical analysis as a tool for the segmentation of 3D spectral data, Micron 52–53, 49 (2013).
  26. Y. Zhu and C. Dwyer, Quantitative position-averaged K-, L-, and M-shell core-loss scattering in STEM, Microsc. Microanal. 20, 1070 (2014).
  27. M. J. Hÿtch, E. Snoeck, and R. Kilaas, Quantitative measurement of displacement and strain fields from HREM micrographs, Ultramicroscopy 74, 131 (1998).
  28. P. Giannozzi, O. Andreussi, T. Brumme, O. Bunau, M. B. Nardelli, M. Calandra, R. Car, C. Cavazzoni, D. Ceresoli, M. Cococcioni, N. Colonna, I. Carnimeo, A. Dal Corso, S. de Gironcoli, P. Delugas, R. A. DiStasio, A. Ferretti, A. Floris, G. Fratesi, G. Fugallo, R. Gebauer et al., Advanced capabilities for materials modelling with Quantum ESPRESSO, J. Phys.: Condens. Matter 29, 465901 (2017).
  29. D. Vanderbilt, Soft self-consistent pseudopotentials in a generalized eigenvalue formalism, Phys. Rev. B 41, 7892 (1990).
  30. J. P. Perdew, K. Burke, and M. Ernzerhof, Generalized gradient approximation made simple, Phys. Rev. Lett. 77, 3865 (1996).
  31. B. Mundet, M. Hadjimichael, J. Fowlie, L. Korosec, L. Varbaro, C. Domínguez, J.-M. Triscone, and D. T. L. Alexander, Mapping orthorhombic domains with geometrical phase analysis in rare-earth nickelate heterostructures, APL Mater. 12, 031124 (2024).
  32. https://doi.org/10.26037/yareta:mzfaokbfr5e6hoxnowsgjt62fe
