Effect of calcium deposition on the surfaces of WSe2 and WS2

N. Ghasemi1, L. Karbivska1,2, T. Klaproth1, M. Knupfer1, B. Büchner1,3, and A. Koitzsch1

Phys. Rev. Materials 10, 084004 – Published 24 August, 2026

DOI: https://doi.org/10.1103/s91z-v9m2

Abstract

Functionalization of 2D materials and of transition metal dichalcogenides (TMDs) in particular is central for next generation devices and other applications. Here we study the effect of calcium dosing on the surfaces of clean WSe2 and WS2 in ultrahigh vacuum by x-ray photoelectron spectroscopy, low energy electron diffraction, and scanning electron microscopy. We find that Ca reacts with the chalcogens to CaSex or CaSx and reduces the remaining tungsten. Ca forms an overlayer on top and causes an outdiffusion of the chalcogen. The overlayer oxidizes easily. We obtained detailed understanding of the interactions of archetypal TMD with an abundant alkali-earth element, which expands our knowledge of metal-surface interactions and of surface manipulation of 2D materials.
