Sub-10-nm quantification of spin and orbital magnetic moment across the metamagnetic phase transition in FeRh using EMCD

Jan Hajduček1,*, Veronica Leccese2,*, Ján Rusz3, Jon Ander Arregi1, Alexey Sapozhnik2, Jáchym Štindl4, Francesco Barantani2, Paolo Cattaneo2, Antoine Andrieux2 et al.

Vojtěch Uhlíř1,4, Fabrizio Carbone2, and Thomas LaGrange2,†

  • *These authors contributed equally to this work.
  • †Contact author: thomas.lagrange@epfl.ch
PDF

Phys. Rev. Materials 10, 013801 – Published 26 January, 2026

DOI: https://doi.org/10.1103/m3vy-18hn

Abstract

Electron magnetic circular dichroism (EMCD) in transmission electron microscopy (TEM) enables element-specific measurement of spin and orbital magnetic moments, analogous to x-ray magnetic circular dichroism (XMCD). While the EMCD technique offers unmatched spatial resolution, its quantitative accuracy remains under scrutiny, particularly in beam-splitter geometries with convergent probes. Here, we systematically evaluate the limits of quantitative EMCD analysis using the first-order magnetostructural transition in the functional phase-change material FeRh as a tunable magnetic reference. Unlike previous EMCD studies primarily focused on elemental ferromagnets such as Fe, we demonstrate its applicability to a correlated material exhibiting coupled structural and magnetic order. We demonstrate that the extracted orbital-to-spin moment ratio (mL/mS) remains within the same order of magnitude as XMCD benchmarks, despite a systematic reduction in absolute value, for TEM probes down to approximately 6 nm, thereby establishing the validity range for reliable quantification. For nanometer-sized probes with higher convergence angles, we observe an enhanced mL/mS, which we attribute to a combination of instrumental factors and sensitivity to nanoscale heterogeneity within the probed volume. Our results confirm that EMCD provides quantitative agreement with macroscale techniques under suitable conditions, while uniquely enabling spatially confined measurements of local magnetic moments in functional magnetic materials, and allowing the study of interfacial, defect-mediated, or phase-separated magnetism that is inaccessible to photon-based methods.

View figure in article
