Octahedral tilt relaxation decoupled from lattice parameters in epitaxial perovskite oxide films

Xuhui Xu1,*, Yuta Ishii2, Hidekazu Shimotani3, Yuta Inoue4, Yuto Miyahara4, Kohei Miyazaki4,5, Masao Nakamura1, Daisuke Okuyama6, Hajime Sagayama6,7 et al.

Kakeru Ninomiya8, Maiko Nishibori8, and Yusuke Wakabayashi1,†

  • *Contact author: xu.xuhui.s7@dc.tohoku.ac.jp
  • †Contact author: wakabayashi@tohoku.ac.jp
PDF

Phys. Rev. Materials 10, 103601 – Published 5 October, 2026

DOI: https://doi.org/10.1103/72nx-sczv

Abstract

Epitaxial strain in perovskite oxide thin films is conventionally understood through lattice parameter modulation, characterized by the c/a ratio of the pseudocubic cell. However, internal atomic arrangements such as octahedral tilting can relax independently, a phenomenon that has remained largely unexplored. Here, we demonstrate that electrochemical operation induces internal structural relaxation in epitaxial La0.7Sr0.3CoO3 films while in-plane lattice parameters remain pinned to the substrate. Synchrotron x-ray diffraction reveals that prolonged electrochemical treatment drives the octahedral tilt mode from the as-grown strained configuration toward the bulk structure without conventional lattice parameter changes. This relaxation is enabled by ionic oxygen migration during electrochemical reactions, which reduces energy barriers between structural configurations. Our findings reveal a relaxation pathway in epitaxial oxides that operates independently of conventional lattice parameter relaxation, and demonstrate the importance of monitoring internal atomic arrangements under operating conditions. This establishes electrochemically driven ionic migration as a versatile tool for controlling internal structure in epitaxial oxides, opening opportunities for designing strain-engineered functional materials.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (57)

  1. D. G. Schlom, L.-Q. Chen, X. Pan, A. Schmehl, and M. A. Zurbuchen, A thin film approach to engineering functionality into oxides, J. Am. Ceram. Soc. 91, 2429 (2008).
  2. J. M. Rondinelli, S. J. May, and J. W. Freeland, Control of octahedral connectivity in perovskite oxide heterostructures: An emerging route to multifunctional materials discovery, MRS Bull. 37, 261 (2012).
  3. J. M. Rondinelli and N. A. Spaldin, Structure and properties of functional oxide thin films: Insights from electronic-structure calculations, Adv. Mater. 23, 3363 (2011).
  4. R. Ramesh and N. A. Spaldin, Multiferroics: Progress and prospects in thin films, Nat. Mater. 6, 21 (2007).
  5. J. W. Matthews and A. E. Blakeslee, Defects in epitaxial multilayers: I. Misfit dislocations, J. Cryst. Growth 27, 118 (1974).
  6. A. Herklotz, D. Lee, E.-J. Guo, T. L. Meyer, J. R. Petrie, and H. N. Lee, Strain coupling of oxygen non-stoichiometry in perovskite thin films, J. Phys.: Condens. Matter 29, 493001 (2017).
  7. H. Yamada, Y. Ogawa, Y. Ishii, H. Sato, M. Kawasaki, H. Akoh, and Y. Tokura, Engineered interface of magnetic oxides, Science 305, 646 (2004).
  8. Y. Konishi, Z. Fang, M. Izumi, T. Manako, M. Kasai, H. Kuwahara, M. Kawasaki, K. Terakura, and Y. Tokura, Orbital-state-mediated phase-control of manganites, J. Phys. Soc. Jpn. 68, 3790 (1999).
  9. J. Wang, J. B. Neaton, H. Zheng, V. Nagarajan, S. B. Ogale, B. Liu, D. Viehland, V. Vaithyanathan, D. G. Schlom, U. V. Waghmare, N. A. Spaldin, K. M. Rabe, M. Wuttig, and R. Ramesh, Epitaxial BiFeO3 multiferroic thin film heterostructures, Science 299, 1719 (2003).
  10. S. Li, Y. Wang, M. Yang, S. Xu, M. Liu, Q. Li, J. Miao, E.-J. Guo, K. Jin, L. Gu, Q. Zhang, J. Deng, X. Chen, and X. Xing, Ferroelectricity in low-permittivity SrZrO3 epitaxial films, Chem. Mater. 35, 2967 (2023).
  11. Q. Gan, R. A. Rao, C. B. Eom, J. L. Garrett, and M. Lee, Direct measurement of strain effects on magnetic and electrical properties of epitaxial SrRuO3 thin films, Appl. Phys. Lett. 72, 978 (1998).
  12. Z. Weng, L. Liu, Y. Hu, Y. Wei, P. Da, Z. Wu, Z. Mu, P. Xi, and C.-H. Yan, Significance of engineering the MnO6 octahedral units to promote the oxygen reduction reaction of perovskite oxides, Adv. Mater. 36, 2311102 (2024).
  13. W. Li, B. Zhu, R. Zhu, Q. Wang, P. Lu, Y. Sun, C. Cafolla, Z. Qi, A. Chen, P. Gao, H. Wang, Q. He, K. H. L. Zhang, and J. L. MacManus-Driscoll, Atomic-scale control of electronic structure and ferromagnetic insulating state in perovskite oxide superlattices by long-range tuning of BO6 octahedra, Adv. Funct. Mater. 30, 2001984 (2020).
  14. C. Ma, N. Lin, Z. Wang, S. Zhou, H. Yu, J. Lu, and H. Huang, Origin of spin-state crossover and electronic reconstruction at the surface of a LaCoO3 nanoparticle, Phys. Rev. B 99, 115401 (2019).
  15. S. Li, J. Wang, Q. Zhang, M. A. Roldan, L. Shan, Q. Jin, S. Chen, Z. Wu, C. Wang, C. Ge, M. He, H. Guo, L. Gu, K.-J. Jin, and E.-J. Guo, Maximization of ferromagnetism in LaCoO3 films by competing symmetry, Phys. Rev. Mater. 3, 114409 (2019).
  16. T. T. Fister, H. Zhou, Z. Luo, S. S. A. Seo, S. O. Hruszkewycz, D. L. Proffit, J. A. Eastman, P. H. Fuoss, P. M. Baldo, H. N. Lee, and D. D. Fong, Octahedral rotations in strained LaAlO3/SrTiO3 (001) heterostructures, APL Mater. 2, 021102 (2014).
  17. M. Brahlek, A. K. Choquette, C. R. Smith, R. Engel-Herbert, and S. J. May, Structural refinement of Pbnm-type perovskite films from analysis of half-order diffraction peaks, J. Appl. Phys. 121, 045303 (2017).
  18. S. J. May, J.-W. Kim, J. M. Rondinelli, E. Karapetrova, N. A. Spaldin, A. Bhattacharya, and P. J. Ryan, Quantifying octahedral rotations in strained perovskite oxide films, Phys. Rev. B 82, 014110 (2010).
  19. D. Kan, Y. Wakabayashi, H. Tajiri, and Y. Shimakawa, Interfacially engineered oxygen octahedral rotations and their impact on strain relief in coherently grown SrRuO3 films, Phys. Rev. B 94, 024112 (2016).
  20. D. Kan, M. Anada, Y. Wakabayashi, H. Tajiri, and Y. Shimakawa, Oxygen octahedral distortions in compressively strained SrRuO3 epitaxial thin films, J. Appl. Phys. 123, 235303 (2018).
  21. H. Meley, Karandeep, L. Oberson, J. de Bruijckere, D. T. L. Alexander, J.-M. Triscone, Ph. Ghosez, and S. Gariglio, Structural analysis of LaVO3 thin films under epitaxial strain, APL Mater. 6, 046102 (2018).
  22. Y. Heo, D. Kan, M. Anada, Y. Wakabayashi, H. Tajiri, and Y. Shimakawa, Correlations between oxygen octahedral distortions and magnetic and transport properties in strained La0.5Sr0.5CoO3 thin films, Phys. Rev. B 99, 174420 (2019).
  23. J. Fowlie, C. Lichtensteiger, M. Gibert, H. Meley, P. Willmott, and J.-M. Triscone, Thickness-dependent perovskite octahedral distortions at heterointerfaces, Nano Lett. 19, 4188 (2019).
  24. L. Qiao, J. H. Jang, D. J. Singh, Z. Gai, H. Xiao, A. Mehta, R. K. Vasudevan, A. Tselev, Z. Feng, H. Zhou, S. Li, W. Prellier, X. Zu, Z. Liu, A. Borisevich, A. P. Baddorf, and M. D. Biegalski, Dimensionality controlled octahedral symmetry-mismatch and functionalities in epitaxial LaCoO3/SrTiO3 heterostructures, Nano Lett. 15, 4677 (2015).
  25. F. Izumisawa, Y. Ishii, M. Kimura, T. Katase, T. Kamiya, J.-i. Yamaura, and Y. Wakabayashi, Symmetry change in LaNiO3 films caused by epitaxial strain from LaAlO3, SrTiO3, and DyScO3 pseudocubic (001) surfaces, J. Appl. Phys. 136, 075303 (2024).
  26. L. Yan, H. Niu, C. A. Bridges, P. A. Marshall, J. Hadermann, G. van Tendeloo, P. R. Chalker, and M. J. Rosseinsky, Unit-cell-level assembly of metastable transition-metal oxides by pulsed-laser deposition, Angew. Chem. Int. Ed. 46, 4539 (2007).
  27. X. Chen, J. Yu, and S. B. Adler, Thermal and chemical expansion of Sr-doped lanthanum cobalt oxide (La1−xSrxCoO3−δ), Chem. Mater. 17, 4537 (2005).
  28. H. Fujii, Y. Wakabayashi, and T. Doi, Early stages of iron anodic oxidation: Defective growth and density increase of oxide layer, Phys. Rev. Mater. 4, 033401 (2020).
  29. J. K. Wenderott, T. Billo, and D. D. Fong, Epitaxial oxide ionotronics: Interfaces and oxygen vacancies, APL Mater. 12, 050901 (2024).
  30. R. Caciuffo, D. Rinaldi, G. Barucca, J. Mira, J. Rivas, M. A. Señarís-Rodríguez, P. G. Radaelli, D. Fiorani, and J. B. Goodenough, Structural details and magnetic order of La1−xSrxCoO3(x ≤ 0. 3), Phys. Rev. B 59, 1068 (1999).
  31. X. Cheng, E. Fabbri, M. Nachtegaal, I. E. Castelli, M. El Kazzi, R. Haumont, N. Marzari, and T. J. Schmidt, Oxygen evolution reaction on La1−xSrxCoO3 perovskites: A combined experimental and theoretical study of their structural, electronic, and electrochemical properties, Chem. Mater. 27, 7662 (2015).
  32. P. M. Raccah and J. B. Goodenough, A localized-electron to collective-electron transition in the system (La, Sr)CoO3, J. Appl. Phys. 39, 1209 (1968).
  33. M. Itoh, I. Natori, S. Kubota, and K. Motoya, Spin-glass behavior and magnetic phase diagram of La1−xSrxCoO3(0≤x ≤0.5) studied by magnetization measurements, J. Phys. Soc. Jpn. 63, 1486 (1994).
  34. K. Asai, O. Yokokura, N. Nishimori, H. Chou, J. M. Tranquada, G. Shirane, S. Higuchi, Y. Okajima, and K. Kohn, Neutron-scattering study of the spin-state transition and magnetic correlations in La1−xSrxCoO3(x=0 and 0.08), Phys. Rev. B 50, 3025 (1994).
  35. A. Grimaud, O. Diaz-Morales, B. Han, W. T. Hong, Y.-L. Lee, L. Giordano, K. A. Stoerzinger, M. T. M. Koper, and Y. Shao-Horn, Activating lattice oxygen redox reactions in metal oxides to catalyse oxygen evolution, Nat. Chem. 9, 457 (2017).
  36. M. L. Weber, G. Lole, A. Kormanyos, A. Schwiers, L. Heymann, F. D. Speck, T. Meyer, R. Dittmann, S. Cherevko, C. Jooss, C. Baeumer, and F. Gunkel, Atomistic insights into activation and degradation of La0.6Sr0.4CoO3−δ electrocatalysts under oxygen evolution conditions, J. Am. Chem. Soc. 144, 17966 (2022).
  37. J. T. Mefford, X. Rong, A. M. Abakumov, W. G. Hardin, S. Dai, A. M. Kolpak, K. P. Johnston, and K. J. Stevenson, Water electrolysis on La1−xSrxCoO3−δ perovskite electrocatalysts, Nat. Commun. 7, 11053 (2016).
  38. X. Liu, L. Zhang, Y. Zheng, Z. Guo, Y. Zhu, H. Chen, F. Li, P. Liu, B. Yu, X. Wang, J. Liu, Y. Chen, and M. Liu, Uncovering the effect of lattice strain and oxygen deficiency on electrocatalytic activity of perovskite cobaltite thin films, Adv. Sci. 6, 1801898 (2019).
  39. C. Yang, C. Laberty-Robert, D. Batuk, G. Cibin, A. V. Chadwick, V. Pimenta, W. Yin, L. Zhang, J.-M. Tarascon, and A. Grimaud, Phosphate ion functionalization of perovskite surfaces for enhanced oxygen evolution reaction, J. Phys. Chem. Lett. 8, 3466 (2017).
  40. Y. Lu, A. Ma, Y. Yu, R. Tan, C. Liu, P. Zhang, D. Liu, and J. Gui, Engineering oxygen vacancies into LaCoO3 perovskite for efficient electrocatalytic oxygen evolution, ACS Sustain. Chem. Eng. 7, 2906 (2019).
  41. Y. Matsumoto, H. Manabe, and E. Sato, Oxygen evolution on La1−xSrxCoO3 electrodes in alkaline solutions, J. Electrochem. Soc. 127, 811 (1980).
  42. Z. Shen, M. Qu, J. Shi, F. E. Oropeza, V. A. de la Peña O'Shea, G. Gorni, C. M. Tian, J. P. Hofmann, J. Cheng, J. Li, and K. H. L. Zhang, Correlating the electronic structure of perovskite La1−xSrxCoO3 with activity for the oxygen evolution reaction: The critical role of Co 3d hole state, J. Energy Chem. 65, 637 (2022).
  43. A. Fujisawa, X. Xu, Y. Ishii, H. Shimotani, Y. Inoue, Y. Miyahara, K. Miyazaki, and Y. Wakabayashi, Surface structure modulation of La0.6Sr0.4CoO3 films on SrTiO3 (001) substrate under electrochemical conditions, ACS Appl. Mater. Interfaces 17, 57603 (2025).
  44. M. Anada, Y. Nakanishi-Ohno, M. Okada, T. Kimura, and Y. Wakabayashi, Bayesian inference of metal oxide ultrathin film structure based on crystal truncation rod measurements, J. Appl. Crystallogr. 50, 1611 (2017).
  45. K. Nagai, M. Anada, Y. Nakanishi-Ohno, M. Okada, and Y. Wakabayashi, Robust surface structure analysis with reliable uncertainty estimation using the exchange Monte Carlo method, J. Appl. Crystallogr. 53, 387 (2020).
  46. A. M. Glazer, The classification of tilted octahedra in perovskites, Acta Crystallogr. Sect. B 28, 3384 (1972).
  47. A. M. Glazer, Simple ways of determining perovskite structures, Acta Crystallogr. A 31, 756 (1975).
  48. J. Walter, G. Yu, B. Yu, A. Grutter, B. Kirby, J. Borchers, Z. Zhang, H. Zhou, T. Birol, M. Greven, and C. Leighton, Ion-gel-gating-induced oxygen vacancy formation in epitaxial La0.5Sr0.5CoO3−δ films from in operando x-ray and neutron scattering, Phys. Rev. Mater. 1, 071403 (2017).
  49. S. Zhang and G. Galli, Understanding the metal-to-insulator transition in La1−xSrxCoO3−δ and its applications for neuromorphic computing, npj Comput. Mater. 6, 170 (2020).
  50. See Supplemental Material at http://link.aps.org/supplemental/10.1103/72nx-sczv for the results of the position dependent XAS measurements.
  51. M. Kopecký, J. Fábry, and J. Kub, X-ray diffuse scattering in SrTiO3 and model of atomic displacements, J. Appl. Crystallogr. 45, 393 (2012).
  52. A. Mineshige, M. Inaba, T. Yao, Z. Ogumi, K. Kikuchi, and M. Kawase, Crystal structure and metal–insulator transition of La1−xSrxCoO3, J. Solid State Chem. 121, 423 (1996).
  53. A. Mineshige, M. Kobune, S. Fujii, Z. Ogumi, M. Inaba, T. Yao, and K. Kikuchi, Metal–insulator transition and crystal structure of La1−xSrxCoO3 as functions of Sr-content, temperature, and oxygen partial pressure, J. Solid State Chem. 142, 374 (1999).
  54. P. Radaelli and S.-W. Cheong, Structural phenomena associated with the spin-state transition in LaCoO3, Phys. Rev. B 66, 094408 (2002).
  55. T. Deguchi, T. Hara, Y. Ishii, H.-B. Li, A. N. Hattori, H. Tanaka, H. Sagayama, and Y. Wakabayashi, Long-period ordering induced by hydrogen doping in NdNiO3 films on SrTiO3 (001) substrates, Phys. Rev. B 113, 174113 (2026).
  56. M. Abbate, F. M. F. de Groot, J. C. Fuggle, A. Fujimori, O. Strebel, F. Lopez, M. Domke, G. Kaindl, G. A. Sawatzky, M. Takano, Y. Takeda, H. Eisaki, and S. Uchida, Controlled-valence properties of La1−xSrxFeO3 and La1−xSrxMnO3 studied by soft-x-ray absorption spectroscopy, Phys. Rev. B 46, 4511 (1992).
  57. M. C.Weber, M. Guennou, N. Dix, D. Pesquera, F. Sánchez, G. Herranz, J. Fontcuberta, L. López-Conesa, S. Estradé, F. Peiró, J. Iñiguez, and J. Kreisel, Multiple strain-induced phase transitions in LaNiO3 thin films, Phys. Rev. B 94, 014118 (2016).
