Tunable energy landscape of screw dislocation cores by compositional fluctuations in bcc high-entropy alloys from first-principles calculations

Pedro P. P. O. Borges*, Robert O. Ritchie, and Mark Asta†

  • *Contact author: pedro_borges@berkeley.edu
  • †Contact author: mdasta@berkeley.edu
PDF

Phys. Rev. Materials 9, 093602 – Published 11 September, 2025

DOI: https://doi.org/10.1103/2xb2-7nn7

Abstract

The energy landscape of screw dislocation cores plays a central role in dislocation-mediated deformation mechanisms in body-centered cubic (bcc) metals. In bcc high-entropy alloys (HEAs), this energy landscape is modulated by local compositional fluctuations, which has important implications for deformation processes in these materials. Through first-principles calculations, this study investigates high-symmetry screw dislocation core structures in NbTaMoW and NbTaTiHf bcc HEAs. The results show that alloying group IV transition metals lead to large local lattice distortions at dislocation cores, which is demonstrated to be an important factor governing fluctuations in core configurations along a dislocation line. Importantly, group IV elements near the core induce features in the energy landscape that are exclusive for HEAs, specifically lowering the energy of core configurations that are unstable in elemental bcc metals. A combined influence of these chemical effects with crystallographic details enables the activation of {112} glide planes, a feature that has been linked to ductility improvements in bcc HEAs. These findings provide new insights into the atomic-scale mechanisms underlying dislocation mobility in bcc HEAs, offering a pathway for designing materials with tailored mechanical properties.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (64)

  1. D. B. Miracle and O. N. Senkov, A critical review of high entropy alloys and related concepts, Acta Mater. 122, 448 (2017).
  2. E. P. George, D. Raabe, and R. O. Ritchie, High-entropy alloys, Nat. Rev. Mater. 4, 515 (2019).
  3. O. N. Senkov, D. B. Miracle, K. J. Chaput, and J.-P. Couzinie, Development and exploration of refractory high entropy alloys – A review, J. Mater. Res. 33, 3092 (2018).
  4. O. N. Senkov, G. B. Wilks, D. B. Miracle, C. P. Chuang, and P. K. Liaw, Refractory high-entropy alloys, Intermetallics 18, 1758 (2010).
  5. O. N. Senkov, G. B. Wilks, J. M. Scott, and D. B. Miracle, Mechanical properties of Nb25Mo25Ta25W25 and V20Nb20Mo20Ta20W20 refractory high entropy alloys, Intermetallics 19, 698 (2011).
  6. O. N. Senkov, J. M. Scott, S. V. Senkova, D. B. Miracle, and C. F. Woodward, Microstructure and room temperature properties of a high-entropy TaNbHfZrTi alloy, J. Alloys Compd. 509, 6043 (2011).
  7. S. Wang, M. Wu, D. Shu, G. Zhu, D. Wang, and B. Sun, Mechanical instability and tensile properties of TiZrHfNbTa high entropy alloy at cryogenic temperatures, Acta Mater. 201, 517 (2020).
  8. X. Wen, L. Zhu, M. Naeem, H. Huang, S. Jiang, H. Wang, X. Liu, X. Zhang, X.-L. Wang, Y. Wu, and Z. Lu, Strong work-hardenable body-centered-cubic high-entropy alloys at cryogenic temperature, Scr. Mater. 231, 115434 (2023).
  9. D. H. Cook, P. Kumar, M. I. Payne, C. H. Belcher, P. Borges, W. Wang, F. Walsh, Z. Li, A. Devaraj, M. Zhang, M. Asta, A. M. Minor, E. J. Lavernia, D. Apelian, and R. O. Ritchie, Kink bands promote exceptional fracture resistance in a NbTaTiHf refractory medium-entropy alloy, Science 384, 178 (2024).
  10. F. Wang, G. H. Balbus, S. Xu, Y. Su, J. Shin, P. F. Rottmann, K. E. Knipling, J.-C. Stinville, L. H. Mills, O. N. Senkov, I. J. Beyerlein, T. M. Pollock, and D. S. Gianola, Multiplicity of dislocation pathways in a refractory multiprincipal element alloy, Science 370, 95 (2020).
  11. S. Wang, M. Wu, D. Shu, and B. Sun, Kinking in a refractory TiZrHfNb0.7 medium-entropy alloy, Mater. Lett. 264, 127369 (2020).
  12. P. Kumar, D. H. Cook, W. Wang, M. Payne, P. P. Borges, A. M. Minor, M. Asta, and R. O. Ritchie, Fracture behavior of high-entropy alloys: Resistance to fracture from strain hardening and softening, Matter 8, 102042 (2025).
  13. J.-P. Couzinie, L. Lilensten, Y. Champion, G. Dirras, L. Perriere, and I. Guillot, On the room temperature deformation mechanisms of a TiZrHfNbTa refractory high-entropy alloy, Mater. Sci. Eng. A 645, 255 (2015).
  14. Y. Bu, Y. Wu, Z. Lei, X. Yuan, H. Wu, X. Feng, J. Liu, J. Ding, Y. Lu, H. Wang, Z. Lu, and W. Yang, Local chemical fluctuation mediated ductility in body-centered-cubic high-entropy alloys, Mater. Today 46, 28 (2021).
  15. G. H. Balbus, S. I. Rao, O. N. Senkov, and E. J. Payton, Orientation dependent plasticity of the refractory multi-principal element alloy MoNbTi investigated via micropillar compression, Acta Mater. 262, 119401 (2024).
  16. S. Han, Z. Wang, L. Li, S. Onda, Z. Chen, J.-P. Couzinié, and H. Inui, Effects of HCP elements Ti and Zr on the plastic deformation behavior of Ti-Zr-Nb medium-entropy alloys with the BCC structure, Acta Mater. 297 121367 (2025).
  17. S. Yin, J. Ding, M. Asta, and R. O. Ritchie, Ab initio modeling of the energy landscape for screw dislocations in body-centered cubic high-entropy alloys, npj Comput. Mater. 6, 110 (2020).
  18. T. Tsuru, S. Han, S. Matsuura, Z. Chen, K. Kishida, I. Iobzenko, S. I. Rao, C. Woodward, E. P. George, and H. Inui, Intrinsic factors responsible for brittle versus ductile nature of refractory high-entropy alloys, Nat. Commun. 15, 1706 (2024).
  19. T. Leveau, L. Ventelon, and E. Clouet, Interaction of C, N and O interstitial solute atoms with screw dislocations in HfNbTaTiZr high entropy alloy, Acta Mater. 275, 120062 (2024).
  20. P. P. P. O. Borges, R. O. Ritchie, and M. Asta, Electronic descriptors for dislocation deformation behavior and intrinsic ductility in bcc high-entropy alloys, Sci. Adv. 10, eadp7670 (2024).
  21. M. S. Duesbery and V. Vitek, Plastic anisotropy in b.c.c. transition metals, Acta Mater. 46, 1481 (1998).
  22. P. Hohenberg and W. Kohn, Inhomogeneous electron gas, Phys. Rev. 136, B864 (1964).
  23. W. Kohn and L. J. Sham, Self-consistent equations including exchange and correlation effects, Phys. Rev. 140, A1133 (1965).
  24. G. Kresse and J. Furthmüller, Efficient iterative schemes for ab initio total-energy calculations using a plane-wave basis set, Phys. Rev. B 54, 11169 (1996).
  25. P. E. Blöchl, Projector augmented-wave method, Phys. Rev. B 50, 17953 (1994).
  26. G. Kresse and D. Joubert, From ultrasoft pseudopotentials to the projector augmented-wave method, Phys. Rev. B 59, 1758 (1999).
  27. J. P. Perdew, K. Burke, and M. Ernzerhof, Generalized gradient approximation made simple, Phys. Rev. Lett. 77, 3865 (1996).
  28. M. Methfessel and A. T. Paxton, High-precision sampling for Brillouin-zone integration in metals, Phys. Rev. B 40, 3616 (1989).
  29. A. P. Thompson, H. M. Aktulga, R. Berger, D. S. Bolintineanu, W. M. Brown, P. S. Crozier, P. J. in 't Veld, A. Kohlmeyer, S. G. Moore, T. D. Nguyen, R. Shan, M. J. Stevens, J. Tranchida, C. Trott, and S. J. Plimpton, LAMMPS - a flexible simulation tool for particle-based materials modeling at the atomic, meso, and continuum scales, Comput. Phys. Commun. 271, 108171 (2022).
  30. X.-G. Li, C. Chen, H. Zheng, Y. Zuo, and S. P. Ong, Complex strengthening mechanisms in the NbMoTaW multi-principal element alloy, npj Comput. Mater. 6, 70 (2020).
  31. W. Wang, P. Kumar, D. H. Cook, F. Walsh, B. Zhang, P. P. P. O. Borges, D. Farkas, R. O. Ritchie, and M. Asta, Ductility mechanisms in complex concentrated refractory alloys from atomistic fracture simulations, arXiv:2502.17750.
  32. A. Zunger, S.-H. Wei, L. G. Ferreira, and J. E. Bernard, Special quasirandom structures, Phys. Rev. Lett. 65, 353 (1990).
  33. A. van de Walle, P. Tiwary, M. de Jong, D. Olmsted, M. Asta, A. Dick, D. Shin, Y. Wang, L.-Q. Chen, and Z.-K. Liu, Efficient stochastic generation of special quasirandom structures, Calphad 42, 13 (2013).
  34. D. Rodney, L. Ventelon, E. Clouet, L. Pizzagalli, and F. Willaime, Ab initio modeling of dislocation core properties in metals and semiconductors, Acta Mater. 124, 633 (2017).
  35. E. Clouet, Ab initio models of dislocations, in Handbook of Materials Modeling: Methods Theory and Modeling, edited by W. Andreoni and S. Yip (Springer International Publishing, Cham, 2018), pp. 1–22.
  36. E. Clouet, Babel package, Version 11.2 (2025), http://emmanuel.clouet.free.fr/Programs/Babel/index.html.
  37. L. Dezerald, L. Ventelon, E. Clouet, C. Denoual, D. Rodney, and F. Willaime, Ab initio modeling of the two-dimensional energy landscape of screw dislocations in bcc transition metals, Phys. Rev. B 89, 024104 (2014).
  38. E. Clouet, B. Bienvenu, L. Dezerald, and D. Rodney, Screw dislocations in BCC transition metals: from ab initio modeling to yield criterion, C. R. Phys. 22, 83 (2021).
  39. L. Ventelon, F. Willaime, E. Clouet, and D. Rodney, Ab initio investigation of the Peierls potential of screw dislocations in bcc Fe and W, Acta Mater. 61, 3973 (2013).
  40. V. Vitek, Theory of the core structures of dislocations in body-centred-cubic metals, Cryst. Latt. Def. 5, 1 (1974).
  41. C. Hartley and Y. Mishin, Characterization and visualization of the lattice misfit associated with dislocation cores, Acta Mater. 53, 1313 (2005).
  42. E. Clouet, L. Ventelon, and F. Willaime, Dislocation core energies and core fields from first principles, Phys. Rev. Lett. 102, 055502 (2009).
  43. P. P. P. O. Borges, R. O. Ritchie, and M. Asta, Local lattice distortions and the structural instabilities in bcc Nb-Ta-Ti-Hf high-entropy alloys: An ab initio computational study, Acta Mater. 262, 119415 (2024).
  44. P. P. Borges, R. O. Ritchie, and M. Asta, Chemical trends favoring interstitial cluster formation in bcc high-entropy alloys from first-principles calculations, Acta Mater. 294, 121091 (2025).
  45. S. I. Rao, B. Akdim, E. Antillon, C. Woodward, T. A. Parthasarathy, and O. N. Senkov, Modeling solution hardening in BCC refractory complex concentrated alloys: NbTiZr, Nb1.5TiZr0.5 and Nb0.5TiZr1.5, Acta Mater. 168, 222 (2019).
  46. B. Chen, S. Li, J. Ding, X. Ding, J. Sun, and E. Ma, Correlating dislocation mobility with local lattice distortion in refractory multi-principal element alloys, Scr. Mater. 222, 115048 (2023).
  47. M. S. Nitol, M. J. Echeverria, K. Dang, M. I. Baskes, and S. J. Fensin, New modified embedded-atom method interatomic potential to understand deformation behavior in VNbTaTiZr refractory high entropy alloy, Comput. Mater. Sci. 237, 112886 (2024).
  48. L. Dezerald, D. Rodney, E. Clouet, L. Ventelon, and F. Willaime, Plastic anisotropy and dislocation trajectory in BCC metals, Nat. Commun. 7, 11695 (2016).
  49. K. Persson, M. Ekman, and V. Ozolins, Phonon instabilities in bcc Sc, Ti, La, and Hf, Phys. Rev. B 61, 11221 (2000).
  50. W. Wang, F. Walsh, R. O. Ritchie, and M. Asta, Elucidating the roles of chemistry, compositional complexity, and short-range order in the dislocation energetics of body-centered-cubic concentrated solid solutions, Phys. Rev. Mater. 8, 013608 (2024).
  51. J. Wang, Z. Zeng, M. Wen, Q. Wang, D. Chen, Y. Zhang, P. Wang, H. Wang, Z. Zhang, S. X. Mao, and T. Zhu, Anti-twinning in nanoscale tungsten, Sci. Adv. 6, aay2792 (2020).
  52. B. Joos and M. S. Duesbery, The Peierls stress of dislocations: An analytic formula, Phys. Rev. Lett. 78, 266 (1997).
  53. A. H. W. Ngan, A generalized Peierls-Nabarro model for nonplanar screw dislocation cores, J. Mech. Phys. Solids 45, 903 (1997).
  54. H. Li, S. Wurster, C. Motz, L. Romaner, C. Ambrosch-Draxl, and R. Pippan, Dislocation-core symmetry and slip planes in tungsten alloys: Ab initio calculations and microcantilever bending experiments, Acta Mater. 60, 748 (2012).
  55. X. Zhou, X. Wang, L. Fey, S. He, I. Beyerlein, P. Cao, and J. Marian, Models of dislocation glide and strengthening mechanisms in bcc complex concentrated alloys, MRS Bull. 48, 777 (2023).
  56. X. Wang, F. Maresca, and P. Cao, The hierarchical energy landscape of screw dislocation motion in refractory high-entropy alloys, Acta Mater. 234, 118022 (2022).
  57. F. Maresca and W. A. Curtin, Theory of screw dislocation strengthening in random BCC alloys from dilute to “High-Entropy” alloys, Acta Mater. 182, 144 (2020).
  58. M. R. Jones, L. T. W. Fey, and I. J. Beyerlein, High temperature dislocation glide in the MoNbTi refractory multiprincipal element alloy, Phys. Rev. Mater. 8, 013604 (2024).
  59. N. Zotov and B. Grabowski, Molecular dynamics simulations of screw dislocation mobility in bcc Nb, Model. Simul. Mater. Sci. Eng. 29, 085007 (2021).
  60. M. Pozuelo and J. Marian, In-situ observation of ‘chemical’ strengthening induced by compositional fluctuations in Nb-Mo-Ta-W, Scr. Mater. 238, 115750 (2024).
  61. F. Maresca and W. A. Curtin, Mechanistic origin of high strength in refractory BCC high entropy alloys up to 1900K, Acta Mater. 182, 235 (2020).
  62. C. Baruffi, F. Maresca, and W. A. Curtin, Screw vs. edge dislocation strengthening in body-centered-cubic high entropy alloys and implications for guided alloy design, MRS Commun. 12, 1111 (2022).
  63. P. Kumar, X. Gou, D. H. Cook, M. I. Payne, N. J. Morrison, W. Wang, M. Zhang, M. Asta, A. M. Minor, R. Cao, Y. Li, and R. O. Ritchie, Degradation of the mechanical properties of NbMoTaW refractory high-entropy alloy in tension, Acta Mater. 279, 120297 (2024).
  64. S. Rao, C. Woodward, B. Akdim, O. Senkov, and D. Miracle, Theory of solid solution strengthening of bcc chemically complex alloys, Acta Mater. 209, 116758 (2021).

Outline

Information

Phys. Rev. Materials 9, 093602– Published 11 September, 2025
  • Received 14 May 2025
  • Accepted 27 August 2025
