Surface Wave Electron Acceleration from Flat Foils at Parallel Laser Incidence

A. McCay1,2,*, A. McIlvenny1,†, A. Macchi3,4, L. Romagnani5, P. Martin1, O. Cavanagh1,6, D. P. Molloy1,7, L. Lancia5, T. Dzelzainis6 et al.

H. Ahmed6, J. Sarma1, S. Kar1, D. Margarone2,1, and M. Borghesi1,‡

  • 1Centre for Light-Matter Interactions, Queens University Belfast, Belfast BT7 1NN, United Kingdom
  • 2ELI Beamlines Facility, The Extreme Light Infrastructure ERIC, Dolní Brežany 252 41, Czech Republic
  • 3National Institute of Optics, National Research Council (CNR/INO), Adriano Gozzini Laboratory, 56124 Pisa, Italy
  • 4Dipartimento di Fisica Enrico Fermi, Universitá di Pisa, Pisa, Italy
  • 5LULI–CNRS, Ecole Polytechnique, CEA, Universite Paris-Saclay, F-91128 Palaiseau cedex, France
  • 6Central Laser Facility, Rutherford Appleton Laboratory, Oxfordshire OX11 0QX, United Kingdom
  • 7HB11 Energy Holdings Pty, Freshwater 2096, Australia

  • *Contact author: amccay06@qub.ac.uk
  • †Present address: Lawrence Berkeley National Laboratory, 1 Cyclotron Road, Berkeley, California, 94720, USA.
  • ‡Contact author: m.borghesi@qub.ac.uk
PDF

Phys. Rev. Lett. 135, 145001 – Published 1 October, 2025

DOI: https://doi.org/10.1103/y29y-f63h

Abstract

The acceleration of electrons by surface plasma waves (SPWs) generated during the interaction of ultrashort, linearly polarized, and contrast-enhanced laser pulses at a peak intensity of ∼6×1020  W cm−2 with flat, noncorrugated foils at parallel incidence (with respect to the target surface) is investigated. We experimentally demonstrate the generation of a collimated electron beam (<0.6  mrad) with a non-Maxwellian spectrum, characterized by peaks at superponderomotive energies (30–36 MeV) and total charge ∼120  pC. Through particle-in-cell (PIC) simulations, we identify the J×B force at the front edge as the primary mechanism for injecting electrons into the SPW, where they are further accelerated. Furthermore, our simulation findings reveal that lateral surface contaminants influence SPW dynamics and give rise to a long-ranging plasmonic mode.

View figure in article

Physics Subject Headings (PhySH)

Corrections

13 November, 2025

Correction: An incorrect value for the laser wavelength was given in the third sentence of the fifth paragraph and has been fixed.

synopsis

A Smooth Plasmon Accelerator

Published 1 October, 2025

Researchers have shown experimentally that ultraintense lasers can drive high-amplitude surface plasma waves without the need for intricate structures.

See more in Physics

Article Text

Supplemental Material

References (37)

  1. S. Maier, Plasmonics: Fundamentals and applications, 10.1007/0-387-37825-1 (2007).
  2. J. Pitarke, V. Silkin, E. Chulkov, and P. Echenique, Theory of surface plasmons and surface-plasmon polaritons, Rep. Prog. Phys. 70, 1 (2006).
  3. R. E. Rottmayer, S. Batra, D. Buechel, W. A. Challener, J. Hohlfeld, Y. Kubota, L. Li, B. Lu, C. Mihalcea, K. Mountfield et al., Heat-assisted magnetic recording, IEEE Trans. Magn. 42, 2417 (2006).
  4. A. G. Brolo, Plasmonics for future biosensors, Nat. Photonics 6, 709 (2012).
  5. A. Macchi, M. Borghesi, and M. Passoni, Ion acceleration by superintense laser-plasma interaction, Rev. Mod. Phys. 85, 751 (2013).
  6. L. Fedeli, A. Sgattoni, G. Cantono, D. Garzella, F. Réau, I. Prencipe, M. Passoni, M. Raynaud, M. Květoň, J. Proska et al., Electron acceleration by relativistic surface plasmons in laser-grating interaction, Phys. Rev. Lett. 116, 015001 (2016).
  7. G.-y. Hu, A.-l. Lei, W.-t. Wang, X. Wang, L.-g. Huang, J.-w. Wang, Y. Xu, J.-s. Liu, W. Yu, B.-f. Shen et al., Collimated hot electron jets generated from subwavelength grating targets irradiated by intense short-pulse laser, Phys. Plasmas 17, 033109 (2010).
  8. X. F. Shen, A. Pukhov, and B. Qiao, Monoenergetic high-energy ion source via femtosecond laser interacting with a microtape, Phys. Rev. X 11, 041002 (2021).
  9. J. Sarma, A. McIlvenny, N. Das, M. Borghesi, and A. Macchi, Surface plasmon-driven electron and proton acceleration without grating coupling, New J. Phys. 24, 073023 (2022).
  10. S. Bagchi, P. Prem Kiran, W.-M. Wang, Z. Sheng, M. Bhuyan, M. Krishnamurthy, and G. Ravindra Kumar, Surface-plasmon-enhanced MeV ions from femtosecond laser irradiated, periodically modulated surfaces, Phys. Plasmas 19, 030703 (2012).
  11. X. Shen, A. Pukhov, and B. Qiao, High-flux bright x-ray source from femtosecond laser-irradiated microtapes, Commun. Phys. 7, 84 (2024).
  12. A. Macchi, G. Cantono, L. Fedeli, F. Pisani, and T. Ceccotti, Extreme high field plasmonics: Electron acceleration and XUV harmonic generation from ultrashort surface plasmons, Phys. Plasmas 26, 042114 (2019).
  13. L. Fedeli, A. Sgattoni, G. Cantono, and A. Macchi, Relativistic surface plasmon enhanced harmonic generation from gratings, Appl. Phys. Lett. 110, 051103 (2017).
  14. T. Tajima and J. M. Dawson, Laser electron accelerator, Phys. Rev. Lett. 43, 267 (1979).
  15. S. P. Mangles, C. Murphy, Z. Najmudin, A. G. R. Thomas, J. Collier, A. E. Dangor, E. Divall, P. Foster, J. Gallacher, C. Hooker et al., Monoenergetic beams of relativistic electrons from intense laser–plasma interactions, Nature (London) 431, 535 (2004).
  16. J. Faure, Y. Glinec, A. Pukhov, S. Kiselev, S. Gordienko, E. Lefebvre, J.-P. Rousseau, F. Burgy, and V. Malka, A laser–plasma accelerator producing monoenergetic electron beams, Nature (London) 431, 541 (2004).
  17. E. Esarey, C. B. Schroeder, and W. P. Leemans, Physics of laser-driven plasma-based electron accelerators, Rev. Mod. Phys. 81, 1229 (2009).
  18. M. Raynaud, J. Kupersztych, C. Riconda, J. Adam, and A. Heron, Strongly enhanced laser absorption and electron acceleration via resonant excitation of surface plasma waves, Phys. Plasmas 14, 092702 (2007).
  19. G. Cantono, L. Fedeli, A. Sgattoni, A. Denoeud, L. Chopineau, F. Réau, T. Ceccotti, and A. Macchi, Extreme ultraviolet beam enhancement by relativistic surface plasmons, Phys. Rev. Lett. 120, 264803 (2018).
  20. X. M. Zhu, R. Prasad, M. Swantusch, B. Aurand, A. A. Andreev, O. Willi, and M. Cerchez, Relativistic electron acceleration by surface plasma waves excited with high intensity laser pulses, High Power Laser Sci. Eng. 8, e15 (2020).
  21. S. Marini, M. Grech, P. S. Kleij, M. Raynaud, and C. Riconda, Electron acceleration by laser plasma wedge interaction, Phys. Rev. Res. 5, 013115 (2023).
  22. S. C. Wilks, W. L. Kruer, M. Tabak, and A. B. Langdon, Absorption of ultra-intense laser pulses, Phys. Rev. Lett. 69, 1383 (1992).
  23. L. D. Landau, E. M. Lifshitz, L. P. Pitaevskii, J. S. Bell, M. J. Kearsley, and J. B. Sykes, Electrodynamics of Continuous Media, 2nd ed., Course of Theoretical Physics Vol. 8 (Elsevier, Amsterdam, Netherlands, 1984), Chap. X, Sec. 88.
  24. T. Arber, K. Bennett, C. Brady, A. Lawrence-Douglas, M. Ramsay, N. J. Sircombe, P. Gillies, R. Evans, H. Schmitz, A. Bell et al., Contemporary particle-in-cell approach to laser-plasma modelling, Plasma Phys. Controlled Fusion 57, 113001 (2015).
  25. W. L. Kruer and K. Estabrook, J× b heating by very intense laser light, Phys. Fluids 28, 430 (1985).
  26. B. Dromey, S. Kar, M. Zepf, and P. Foster, The plasma mirror—A subpicosecond optical switch for ultrahigh power lasers, Rev. Sci. Instrum. 75, 645 (2004).
  27. A. Lévy, T. Ceccotti, P. d’Oliveira, F. Réau, M. Perdrix, F. Quéré, P. Monot, M. Bougeard, H. Lagadec, P. Martin et al., Double plasma mirror for ultrahigh temporal contrast ultraintense laser pulses, Opt. Lett. 32, 310 (2007).
  28. C. Thaury, F. Quere, J.-P. Geindre, A. Levy, T. Ceccotti, P. Monot, M. Bougeard, F. Réau, P. d’Oliveira, P. Audebert et al., Plasma mirrors for ultrahigh-intensity optics, Nat. Phys. 3, 424 (2007).
  29. N. Rabhi, K. Bohacek, D. Batani, G. Boutoux, J.-E. Ducret, E. Guillaume, K. Jakubowska, C. Thaury, and I. Thfoin, Calibration of imaging plates to electrons between 40 and 180 MeV, Rev. Sci. Instrum. 87, 053306 (2016).
  30. A. Sgattoni, L. Fedeli, G. Cantono, T. Ceccotti, and A. Macchi, High field plasmonics and laser-plasma acceleration in solid targets, Plasma Phys. Controlled Fusion 58, 014004 (2015).
  31. A. McIlvenny, D. Doria, L. Romagnani, H. Ahmed, N. Booth, E. J. Ditter, O. C. Ettlinger, G. S. Hicks, P. Martin, G. G. Scott, S. D. R. Williamson, A. Macchi, P. McKenna, Z. Najmudin, D. Neely, S. Kar, and M. Borghesi, Selective ion acceleration by intense radiation pressure, Phys. Rev. Lett. 127, 194801 (2021).
  32. See Supplemental Material at http://link.aps.org/supplemental/10.1103/y29y-f63h for additional information on the experimental and simulation data.
  33. C. Riconda, M. Raynaud, T. Vialis, and M. Grech, Simple scalings for various regimes of electron acceleration in surface plasma waves, Phys. Plasmas 22, 073103 (2015).
  34. D. Sarid, Long-range surface-plasma waves on very thin metal films, Phys. Rev. Lett. 47, 1927 (1981).
  35. B. Prade, J. Y. Vinet, and A. Mysyrowicz, Guided optical waves in planar heterostructures with negative dielectric constant, Phys. Rev. B 44, 13556 (1991).
  36. P. Berini, Long-range surface plasmon polaritons, Adv. Opt. Photonics 1, 484 (2009).
  37. A. McCay et al., Data for “Surface Wave Electron Acceleration from Flat Foils at Parallel Laser Incidence”, Queen’s University Belfast. PRL_McCay_data(.zip), README(.txt) (2025), 10.17034/ba65ff12-d460-4408-8038-38e9f482244a.
