Elastic Turbulence Hides in the Small Scales of Inertial Polymeric Turbulence

Piyush Garg* and Marco Edoardo Rosti†

  • *Contact author: piyush.garg@oist.jp
  • †Contact author: marco.rosti@oist.jp
PDF

Phys. Rev. Lett. 135, 074001 – Published 13 August, 2025

DOI: https://doi.org/10.1103/pbtf-rn7d

Abstract

Gaining a fundamental understanding of turbulent flows of dilute polymer solutions has been a challenging and outstanding problem for a long time. In this Letter, we examine homogeneous, isotropic polymeric turbulence at large Reynolds and Deborah numbers through direct numerical simulations. While at the largest scales at which the flow inertial turbulence exists, we find that the flow is fundamentally altered from Newtonian turbulence below the Kolmogorov scale. We demonstrate that “elastic turbulence” exists at the smallest scales of polymeric turbulence by quantifying multiple statistical properties of the flow—energy spectrum and flux in Fourier space as well as the spatial statistics of the velocity field—the structure functions and kurtosis, and energy dissipation. Our results show the coexistence of two fundamentally distinct types of turbulence in polymeric fluids and point to the ubiquity of elastic turbulence, which was hitherto only known to exist for negligible inertia.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (76)

  1. B. A. Toms, Some observations on the flow of linear polymersolutions through straight tubes at large Reynolds numbers, in Proceedings of the 1st Intl Congr. Rheol. (1949), Vol. 2, pp. 135–141.
  2. R. B. Bird, R. C. Armstrong, and O. Hassager, Dynamics of Polymeric Liquids. Vol. 1: Fluid Mechanics (John Wiley and Sons Inc., New York, 1987).
  3. R. G. Larson, Constitutive Equations for Polymer Melts and Solutions: Butterworths Series in Chemical Engineering (Butterworth-Heinemann, Washington, DC, 2013).
  4. P. Virk, Drag reduction fundamentals, AIChE J. 21, 625 (1975).
  5. C. White and M. Mungal, Mechanics and prediction of turbulent drag reduction with polymer additives, Annu. Rev. Fluid Mech. 40, 235 (2008).
  6. M. D. Graham, Drag reduction and the dynamics of turbulence in simple and complex fluids, Phys. Fluids 26, 101301 (2014).
  7. R. Benzi and E. S. Ching, Polymers in fluid flows, Annu. Rev. Condens. Matter Phys. 9, 163 (2018).
  8. D. Samanta, Y. Dubief, M. Holzner, C. Schäfer, A. N. Morozov, C. Wagner, and B. Hof, Elasto-inertial turbulence, Proc. Natl. Acad. Sci. U.S.A. 110, 10557 (2013).
  9. P. Garg, I. Chaudhary, M. Khalid, V. Shankar, and G. Subramanian, Viscoelastic pipe flow is linearly unstable, Phys. Rev. Lett. 121, 024502 (2018).
  10. Y. Dubief, V. E. Terrapon, and B. Hof, Elasto-inertial turbulence, Annu. Rev. Fluid Mech. 55, 675 (2023).
  11. B. Barnard and R. Sellin, Grid turbulence in dilute polymer solutions, Nature (London) 222, 1160 (1969).
  12. W. McComb, J. Allan, and C. Greated, Effect of polymer additives on the small-scale structure of grid-generated turbulence, Phys. Fluids 20, 873 (1977).
  13. E. van Doorn, C. M. White, and K. Sreenivasan, The decay of grid turbulence in polymer and surfactant solutions, Phys. Fluids 11, 2387 (1999).
  14. A. Liberzon, M. Guala, W. Kinzelbach, and A. Tsinober, On turbulent kinetic energy production and dissipation in dilute polymer solutions, Phys. Fluids 18, 125101 (2006).
  15. P. Perlekar, D. Mitra, and R. Pandit, Manifestations of drag reduction by polymer additives in decaying, homogeneous, isotropic turbulence, Phys. Rev. Lett. 97, 264501 (2006).
  16. R. Vonlanthen and P. A. Monkewitz, Grid turbulence in dilute polymer solutions: Peo in water, J. Fluid Mech. 730, 76 (2013).
  17. N. T. Ouellette, H. Xu, and E. Bodenschatz, Bulk turbulence in dilute polymer solutions, J. Fluid Mech. 629, 375 (2009).
  18. H.-D. Xi, E. Bodenschatz, and H. Xu, Elastic energy flux by flexible polymers in fluid turbulence, Phys. Rev. Lett. 111, 024501 (2013).
  19. S. Berti, A. Bistagnino, G. Boffetta, A. Celani, and S. Musacchio, Small-scale statistics of viscoelastic turbulence, Europhys. Lett. 76, 63 (2006).
  20. P. Perlekar, D. Mitra, and R. Pandit, Direct numerical simulations of statistically steady, homogeneous, isotropic fluid turbulence with polymer additives, Phys. Rev. E 82, 066313 (2010).
  21. W.-H. Cai, F.-C. Li, and H.-N. Zhang, DNS study of decaying homogeneous isotropic turbulence with polymer additives, J. Fluid Mech. 665, 334 (2010).
  22. T. Watanabe and T. Gotoh, Hybrid Eulerian–Lagrangian simulations for polymer–turbulence interactions, J. Fluid Mech. 717, 535 (2013).
  23. T. Watanabe and T. Gotoh, Power-law spectra formed by stretching polymers in decaying isotropic turbulence, Phys. Fluids 26, 035110 (2014).
  24. P. Valente, C. Da Silva, and F. Pinho, The effect of viscoelasticity on the turbulent kinetic energy cascade, J. Fluid Mech. 760, 39 (2014).
  25. M. Q. Nguyen, A. Delache, S. Simoëns, W. J. T. Bos, and M. El Hajem, Small scale dynamics of isotropic viscoelastic turbulence, Phys. Rev. Fluids 1, 083301 (2016).
  26. Y.-B. Zhang, E. Bodenschatz, H. Xu, and H.-D. Xi, Experimental observation of the elastic range scaling in turbulent flow with polymer additives, Sci. Adv. 7, eabd3525 (2021).
  27. M. E. Rosti, P. Perlekar, and D. Mitra, Large is different: Nonmonotonic behavior of elastic range scaling in polymeric turbulence at large Reynolds and Deborah numbers, Sci. Adv. 9, eadd3831 (2023).
  28. A. Chiarini, R. K. Singh, and M. E. Rosti, Extending kolmogorov theory to polymeric turbulence, Phys. Rev. Res. 7, L022043 (2025).
  29. A. Groisman and V. Steinberg, Elastic turbulence in a polymer solution flow, Nature (London) 405, 53 (2000).
  30. R. G. Larson, Turbulence without inertia, Nature (London) 405, 27 (2000).
  31. G. Boffetta, A. Celani, and S. Musacchio, Two-dimensional turbulence of dilute polymer solutions, Phys. Rev. Lett. 91, 034501 (2003).
  32. A. Groisman and V. Steinberg, Elastic turbulence in curvilinear flows of polymer solutions, New J. Phys. 6, 29 (2004).
  33. T. Burghelea, E. Segre, and V. Steinberg, Elastic turbulence in von Karman swirling flow between two disks, Phys. Fluids 19, 053104 (2007).
  34. V. Steinberg, Scaling relations in elastic turbulence, Phys. Rev. Lett. 123, 234501 (2019).
  35. V. Steinberg, Elastic turbulence: An experimental view on inertialess random flow, Annu. Rev. Fluid Mech. 53, 27 (2021).
  36. M. Lellep, M. Linkmann, and A. Morozov, Purely elastic turbulence in pressure-driven channel flows, Proc. Natl. Acad. Sci. U.S.A. 121, e2318851121 (2024).
  37. R. K. Singh, P. Perlekar, D. Mitra, and M. E. Rosti, Intermittency in the not-so-smooth elastic turbulence, Nat. Commun. 15, 4070 (2024).
  38. G. Foggi Rota, C. Amor, S. Le Clainche, and M. E. Rosti, Unified view of elastic and elasto-inertial turbulence in channel flows at low and moderate Reynolds numbers, Phys. Rev. Fluids 9, L122602 (2024).
  39. R. K. Singh and M. E. Rosti, The interplay of inertia and elasticity in polymeric flows, arXiv:2309.14752.
  40. See Supplemental Material at http://link.aps.org/supplemental/10.1103/pbtf-rn7d for additional details, which includes Refs. [25,27,37,41–47].
  41. A. Fouxon and V. Lebedev, Spectra of turbulence in dilute polymer solutions, Phys. Fluids 15, 2060 (2003).
  42. R. Fattal and R. Kupferman, Constitutive laws for the matrix-logarithm of the conformation tensor, J. Non-Newtonian Fluid Mech. 123, 281 (2004).
  43. S. R. Yerasi, J. R. Picardo, A. Gupta, and D. Vincenzi, Preserving large-scale features in simulations of elastic turbulence, J. Fluid Mech. 1000, A37 (2024).
  44. M. S. Abdelgawad, I. Cannon, and M. E. Rosti, Scaling and intermittency in turbulent flows of elastoviscoplastic fluids, Nat. Phys. 19, 1059 (2023).
  45. M. Aswathy and M. E. Rosti, The dynamics of fibres dispersed in viscoelastic turbulent flows, J. Fluid Mech. 984, A72 (2024).
  46. C. M. Casciola and E. De Angelis, Energy transfer in turbulent polymer solutions, J. Fluid Mech. 581, 419 (2007).
  47. M. E. Rosti, The effect of shear-thinning on the scalings and small-scale structures of turbulence, J. Fluid Mech. 1012, R5 (2025).
  48. U. Frisch, Turbulence: The Legacy of AN Kolmogorov (Cambridge University Press, Cambridge, England, 1995).
  49. P. Davidson, Turbulence: An Introduction for Scientists and Engineers (Oxford University Press, New York, 2015).
  50. S. Chen, G. Doolen, J. R. Herring, R. H. Kraichnan, S. A. Orszag, and Z. S. She, Far-dissipation range of turbulence, Phys. Rev. Lett. 70, 3051 (1993).
  51. J. Schumacher, Sub-Kolmogorov-scale fluctuations in fluid turbulence, Europhys. Lett. 80, 54001 (2007).
  52. S. Khurshid, D. A. Donzis, and K. Sreenivasan, Energy spectrum in the dissipation range, Phys. Rev. Fluids 3, 082601(R) (2018).
  53. A. Gorbunova, G. Balarac, M. Bourgoin, L. Canet, N. Mordant, and V. Rossetto, Analysis of the dissipative range of the energy spectrum in grid turbulence and in direct numerical simulations, Phys. Rev. Fluids 5, 044604 (2020).
  54. K. P. Iyer, K. R. Sreenivasan, and P. K. Yeung, Scaling exponents saturate in three-dimensional isotropic turbulence, Phys. Rev. Fluids 5, 054605 (2020).

  55. Following [27], we expect that the contribution of the polymeric flux in the inertial range would decrease for larger De and Reλ.

  56. S. Berti, A. Bistagnino, G. Boffetta, A. Celani, and S. Musacchio, Two-dimensional elastic turbulence, Phys. Rev. E 77, 055306(R) (2008).
  57. K. R. Sreenivasan and R. A. Antonia, The phenomenology of small-scale turbulence, Annu. Rev. Fluid Mech. 29, 435 (1997).
  58. T. Ishihara, T. Gotoh, and Y. Kaneda, Study of high-Rreynolds number isotropic turbulence by direct numerical simulation, Annu. Rev. Fluid Mech. 41, 165 (2009).
  59. P. A. Davidson, Y. Kaneda, and K. R. Sreenivasan, Ten Chapters in Turbulence (Cambridge University Press, Cambridge, England, 2012).
  60. J. Schumacher, K. R. Sreenivasan, and V. Yakhot, Asymptotic exponents from low-Reynolds-number flows, New J. Phys. 9, 89 (2007).
  61. M. Nelkin, Do the dissipation fluctuations in high Reynolds number turbulence define a universal exponent?, Phys. Fluids 24, 556 (1981).
  62. M. E. Cates and J. M. Deutsch, Spatial correlations in multifractals, Phys. Rev. A 35, 4907 (1987).
  63. K. Sreenivasan and P. Kailasnath, An update on the intermittency exponent in turbulence, Phys. Fluids A 5, 512 (1993).
  64. C. Meneveau and K. Sreenivasan, The multifractal nature of turbulent energy dissipation, J. Fluid Mech. 224, 429 (1991).
  65. D. Buaria and K. R. Sreenivasan, Intermittency of turbulent velocity and scalar fields using three-dimensional local averaging, Phys. Rev. Fluids 7, L072601 (2022).
  66. J. Schumacher, J. D. Scheel, D. Krasnov, D. A. Donzis, V. Yakhot, and K. R. Sreenivasan, Small-scale universality in fluid turbulence, Proc. Natl. Acad. Sci. U.S.A. 111, 10961 (2014).
  67. M. Tabor and P. De Gennes, A cascade theory of drag reduction, Europhys. Lett. 2, 519 (1986).
  68. P. De Gennes, Towards a scaling theory of drag reduction, Physica (Amsterdam) 140A, 9 (1986).
  69. K. R. Sreenivasan and C. M. White, The onset of drag reduction by dilute polymer additives, and the maximum drag reduction asymptote, J. Fluid Mech. 409, 149 (2000).
  70. J. L. Lumley, Drag reduction by additives, Annu. Rev. Fluid Mech. 1, 367 (1969).
  71. J. L. Lumley, Drag reduction in turbulent flow by polymer additives, J. Polym. Sci. 7, 263 (1973).
  72. I. Procaccia, V. S. L’vov, and R. Benzi, Colloquium: Theory of drag reduction by polymers in wall-bounded turbulence, Rev. Mod. Phys. 80, 225 (2008).
  73. E. Balkovsky, A. Fouxon, and V. Lebedev, Turbulence of polymer solutions, Phys. Rev. E 64, 056301 (2001).
  74. S. S. Datta, A. M. Ardekani, P. E. Arratia, A. N. Beris, I. Bischofberger, G. H. McKinley, J. G. Eggers, J. E. López-Aguilar, S. M. Fielding, A. Frishman et al., Perspectives on viscoelastic flow instabilities and elastic turbulence, Phys. Rev. Fluids 7, 080701 (2022).
  75. S. J. Haward, C. C. Hopkins, and A. Q. Shen, Stagnation points control chaotic fluctuations in viscoelastic porous media flow, Proc. Natl. Acad. Sci. U.S.A. 118, e2111651118 (2021).
  76. C. A. Browne and S. S. Datta, Harnessing elastic instabilities for enhanced mixing and reaction kinetics in porous media, Proc. Natl. Acad. Sci. U.S.A. 121, e2320962121 (2024).
