Exact Coherent Structures as Building Blocks of Turbulence on Spatially Extended Domains

Dmitriy Zhigunov* and Jacob Page†

  • *Contact author: dmitriy.zhigunov@ed.ac.uk
  • †Contact author: jacob.page@ed.ac.uk
PDF

Phys. Rev. Lett. 137, 164001 – Published 14 October, 2026

DOI: https://doi.org/10.1103/lh7v-r983

Abstract

Exact unstable solutions of the Navier-Stokes equations are thought to underpin the dynamics of turbulence but are usually computed in minimal computational domains. Here, we extend this dynamical systems approach to spatially extended turbulent flows featuring multiple interacting “substructures” and show how new simple invariant solutions can be constructed by spatial tiling of exact solutions from small-box calculations. Candidate solutions are found via gradient-based optimization of a scalar loss function which targets autorecurrence in spatially localized regions of the flow. We first identify 25 relative periodic orbits (RPOs) which are combinations of high-dissipation, small-box solutions with laminar patches. We then show that vertically stacked combinations of pairs of distinct small-box RPOs can form robust guesses for dynamically relevant two-tori in the larger domain. Finally, we show how our optimization procedure can identify “turbulent” trajectories which locally shadow a small-box RPO for multiple periods in a subdomain. These small-box combinations are possible as the flow spends prolonged periods in a regime where it can be effectively considered to be a pair of weakly coupled small-box systems. The new large-scale states are the first examples of solutions featuring multiple interacting substructures and support the long-standing hypothesis that turbulence can be built up as a spatiotemporal tapestry of smaller domain solutions.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (30)

  1. G. Kawahara, M. Uhlmann, and L. Van Veen, The significance of simple invariant solutions in turbulent flows, Annu. Rev. Fluid Mech. 44, 203 (2012).
  2. B. Suri, J. Tithof, R. O. Grigoriev, and M. F. Schatz, Forecasting fluid flows using the geometry of turbulence, Phys. Rev. Lett. 118, 114501 (2017).
  3. C. J. Crowley, J. L. Pughe-Sanford, W. Toler, M. C. Krygier, R. O. Grigoriev, and M. F. Schatz, Turbulence tracks recurrent solutions, Proc. Natl. Acad. Sci. U.S.A. 119, e2120665119 (2022).
  4. H. Faisst and B. Eckhardt, Traveling waves in pipe flow, Phys. Rev. Lett. 91, 224502 (2003).
  5. H. Wedin and R. R. Kerswell, Exact coherent structures in pipe flow: Travelling wave solutions, J. Fluid Mech. 508, 333 (2004).
  6. G. Kawahara and S. Kida, Periodic motion embedded in plane Couette turbulence: Regeneration cycle and burst, J. Fluid Mech. 449, 291 (2001).
  7. J. F. Gibson, J. Halcrow, and P. Cvitanović, Equilibrium and travelling-wave solutions of plane Couette flow, J. Fluid Mech. 638, 243 (2009).
  8. G. J. Chandler and R. R. Kerswell, Invariant recurrent solutions embedded in a turbulent two-dimensional Kolmogorov flow, J. Fluid Mech. 722, 554 (2013).
  9. A. P. Willis, P. Cvitanović, and M. Avila, Revealing the state space of turbulent pipe flow by symmetry reduction, J. Fluid Mech. 721, 514 (2013).
  10. M. D. Graham and D. Floryan, Exact coherent states and the nonlinear dynamics of wall-bounded turbulent flows, Annu. Rev. Fluid Mech. 53, 227 (2021).
  11. J. Page, P. Norgaard, M. P. Brenner, and R. R. Kerswell, Recurrent flow patterns as a basis for two-dimensional turbulence: Predicting statistics from structures, Proc. Natl. Acad. Sci. U.S.A. 121, e2320007121 (2024).
  12. T. M. Schneider, J. F. Gibson, and J. Burke, Snakes and ladders: Localized solutions of plane Couette flow, Phys. Rev. Lett. 104, 104501 (2010).
  13. M. Avila, F. Mellibovsky, N. Roland, and B. Hof, Streamwise-localized solutions at the onset of turbulence in pipe flow, Phys. Rev. Lett. 110, 224502 (2013).
  14. K. Deguchi, Self-sustained states at Kolmogorov microscale, J. Fluid Mech. 781, R6 (2015).
  15. B. Eckhardt and S. Zammert, Small scale exact coherent structures at large Reynolds numbers in plane Couette flow, Nonlinearity 31, R66 (2018).
  16. C. Beaume, E. Knobloch, G. P. Chini, and K. Julien, Modulated patterns in a reduced model of a transitional shear flow, Phys. Scr. 91, 024003 (2016).
  17. R. Song, K. Deguchi, G. Kawahara, and Y. Hwang, Multiscale quasi-time-periodic coherent structures in shear flows, J. Fluid Mech. 1034, R2 (2026).
  18. Z. Zheng, L. S. Tuckerman, and T. M. Schneider, Natural convection in a vertical channel. part 3. bifurcations of many (additional) unstable periodic orbits and their dynamical relevance, J. Fluid Mech. 1022, A42 (2025).
  19. H. Liang and P. Cvitanović, A chaotic lattice field theory in one dimension, J. Phys. A 55, 304002 (2022).
  20. P. Cvitanović and H. Liang, A chaotic lattice field theory in two dimensions, Chaos 36, 023130 (2026).
  21. M. Gudorf, Spatiotemporal tiling of the Kuramoto-Sivashinsky equation, Ph.D thesis, Georgia Institute of Technology, Atlanta, GA, 2020.
  22. S. D. V. Williams, M. N. Gudorf, and D. M. Orlov, Understanding plasma turbulence through exact coherent structures, Phys. Plasmas 32, 092302 (2025).
  23. A. Cleary and J. Page, Dynamical relevance of periodic orbits under increasing Reynolds number and connections to inviscid dynamics, J. Fluid Mech. 1020, A52 (2025).
  24. See Supplemental Material at http://link.aps.org/supplemental/10.1103/lh7v-r983 for details on the numerical methods, which includes Refs. [25–27].
  25. R. Kerswell, Nonlinear nonmodal stability theory, Annu. Rev. Fluid Mech. 50, 319 (2018).
  26. P. J. Schmid, Nonmodal stability theory, Annu. Rev. Fluid Mech. 39, 129 (2007).
  27. D. Viswanath, Recurrent motions within plane Couette turbulence, J. Fluid Mech. 580, 339 (2007).
  28. K. J. Burns, G. M. Vasil, J. S. Oishi, D. Lecoanet, and B. P. Brown, Dedalus: A flexible framework for numerical simulations with spectral methods, Phys. Rev. Res. 2, 023068 (2020).
  29. J. Duchi, E. Hazan, and Y. Singer, Adaptive subgradient methods for online learning and stochastic optimization, J. Mach. Learn. Res. 12, 2121 (2011).
  30. The datasets discussed in this letter and the code used to generate them are available at, 10.7488/ds/8187.
