Subangstrom Free-Electron Laser Operation with Undulator Deflection Parameter Reaching the Subunity Regime

Eduard Prat1,*, Christopher Arrell2, Marco Calvi2, Nicole Hiller1, Pavle Juranić1, Christoph Kittel1, Sven Reiche1, Thomas Schietinger1, Didier Voulot1 et al.

Tobias Weilbach1

  • *Contact author: eduard.prat@psi.ch
PDF

Phys. Rev. Lett. 137, 115001 – Published 11 September, 2026

DOI: https://doi.org/10.1103/dv32-v967

Abstract

X-ray free-electron lasers (XFELs) enable the exploration of matter with atomic-scale spatiotemporal resolution. Generating radiation wavelengths below one angstrom is critical for applications such as crystallography and Mössbauer studies. Until now, achieving the subangstrom regime has required electron beam energies ≥8  GeV and undulator K parameters ≥1.5. In this Letter, we demonstrate the generation of high-power subangstrom FEL radiation using a 6.2 GeV electron beam and a K parameter around unity and below. We show that exceptional electron beam brilliance—characterized by high peak current and low slice emittance—compensates for the reduced undulator coupling, enabling robust lasing. The demonstration was carried out at SwissFEL, where the subangstrom regime has already been successfully employed in user experiments. Our Letter paves the way for more compact and cost-effective accelerator designs through the optimization of electron beam quality.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (36)

  1. C. Pellegrini, A. Marinelli, and S. Reiche, The physics of x-ray free-electron lasers, Rev. Mod. Phys. 88, 015006 (2016).
  2. E. A. Seddon, J. A. Clarke, D. J. Dunning, C. Masciovecchio, C. J. Milne, F. Parmigiani, D. Rugg, J. C. H. Spence, N. R. Thompson, K. Ueda, S. M. Vinko, J. S. Wark, and W. Wurth, Short-wavelength free-electron laser sources and science: A review, Rep. Prog. Phys. 80, 115901 (2017).
  3. R. Bonifacio, C. Pellegrini, and L. M. Narducci, Collective instabilities and high-gain regime in a free electron laser, Opt. Commun. 50, 373 (1984).
  4. E. Saldin, E. Schneidmiller, and M. Yurkov, Coherence properties of the radiation from x-ray free electron laser, Opt. Commun. 281, 1179 (2008).
  5. M. Xie, Exact and variational solutions of 3d eigenmodes in high gain FELs, Nucl. Instrum. Methods Phys. Res., Sect. A 445, 59 (2000).
  6. P. Emma et al., First lasing and operation of an ångstrom-wavelength free-electron laser, Nat. Photonics 4, 641 (2010).
  7. Y. Ding, LCLS-II commissioning and operation with high-repetition-rate CW FELs, in Proceedings of the 16th International Particle Accelerator Conference, Taipei, Taiwan (JACoW, Geneva, Switzerland, 2025), pp. 1710–1713.
  8. T. Ishikawa et al., A compact x-ray free-electron laser emitting in the sub-ångström region, Nat. Photonics 6, 540 (2012).
  9. H.-S. Kang et al., Hard x-ray free-electron laser with femtosecond-scale timing jitter, Nat. Photonics 11, 708 (2017).
  10. W. Decking et al., A MHz-repetition-rate hard x-ray free-electron laser driven by a superconducting linear accelerator, Nat. Photonics 14, 391 (2020).
  11. E. Prat et al., A compact and cost-effective hard x-ray free-electron laser driven by a high-brightness and low-energy electron beam, Nat. Photonics 14, 748 (2020).
  12. Z. Zhao, D. Wang, Z.-H. Yang, and L. Yin, SCLF: An 8-GeV CW SCRF linac-based X-ray FEL facility in Shanghai, in Proceedings of the 38th International Free Electron Laser Conference, Santa Fe, New Mexico, USA (JACoW, Geneva, Switzerland, 2018).
  13. K. Takaba, S. Maki-Yonekura, I. Inoue, K. Tono, T. Hamaguchi, K. Kawakami, H. Naitow, T. Ishikawa, M. Yabashi, and K. Yonekura, Structural resolution of a small organic molecule by serial x-ray free-electron laser and electron crystallography, Nat. Chem. 15, 491 (2023).
  14. K. H. Kim et al., Direct observation of bond formation in solution with femtosecond x-ray scattering, Nature (London) 518, 385 (2015).
  15. A. I. Chumakov, A. Q. R. Baron, I. Sergueev, C. Strohm, O. Leupold, Y. Shvyd’ko, G. V. Smirnov, R. Rüffer, Y. Inubushi, M. Yabashi, K. Tono, T. Kudo, and T. Ishikawa, Superradiance of an ensemble of nuclei excited by a free electron laser, Nat. Phys. 14, 261 (2017).
  16. M. Gerharz et al., Single-shot sorting of Mössbauer time-domain data at x-ray free electron lasers, arXiv:2509.15833.
  17. J. Griffiths, A. F. Suzana, L. Wu, S. D. Marks, V. Esposito, S. Boutet, P. G. Evans, J. F. Mitchell, M. P. M. Dean, D. A. Keen, I. Robinson, S. J. L. Billinge, and E. S. Bozin, Resolving length-scale-dependent transient disorder through an ultrafast phase transition, Nat. Mater. 23, 1041 (2024).
  18. A. F. Sapnik et al., High-quality ultra-fast total scattering and pair distribution function data using an x-ray free-electron laser, IUCrJ 12, 531 (2025).
  19. H. P. Liermann et al., Novel experimental setup for megahertz x-ray diffraction in a diamond anvil cell at the High Energy Density (HED) instrument of the European X-ray Free-Electron Laser (EuXFEL), J. Synchrotron Radiat. 28, 688 (2021).
  20. C. Kittel, M. Aiba, C. Arrell, A. Cassar, E. Ferrari, N. Hiller, E. Prat, S. Reiche, N. Sammut, T. Schietinger, D. Voulot, T. Weilbach, and M. Calvi, Enhancing hard x-ray beamline performance at SwissFEL through spontaneous radiation measurements, J. Synchrotron Radiat. 33, 32 (2026).
  21. E. Prat, P. Dijkstal, E. Ferrari, and S. Reiche, Demonstration of large bandwidth hard x-ray free-electron laser pulses at SwissFEL, Phys. Rev. Lett. 124, 074801 (2020).
  22. E. Prat, A. Malyzhenkov, and P. Craievich, Sub-femtosecond time-resolved measurements of electron bunches with a C-band radio-frequency deflector in x-ray free-electron lasers, Rev. Sci. Instrum. 94, 043103 (2023).
  23. R. Ischebeck, E. Prat, V. Thominet, and C. Ozkan Loch, Transverse profile imager for ultrabright electron beams, Phys. Rev. ST Accel. Beams 18, 082802 (2015).
  24. P. Juranić and E. Prat, Testing high-resolution transverse profile monitors by measuring the dependence of the electron beam size on the beam energy at SwissFEL, Rev. Sci. Instrum. 94, 073301 (2023).
  25. C. David, G. Seniutinas, M. Makita, B. Rösner, J. Rehanek, P. Karvinen, F. Löhl, R. Abela, L. Patthey, and P. Juranić, Spectral monitoring at SwissFEL using a high-resolution on-line hard X-ray single-shot spectrometer, J. Synchrotron Radiat. 28, 1978 (2021).
  26. R. Follath, U. Flechsig, C. J. Milne, J. Szlachetko, G. Ingold, B. Patterson, L. Patthey, and R. Abela, Optical design of the ARAMIS-beamlines at SwissFEL, AIP Conf. Proc. 1741, 020009 (2016).
  27. G. Ingold et al., Experimental station Bernina at SwissFEL: Condensed matter physics on femtosecond time scales investigated by x-ray diffraction and spectroscopic methods, J. Synchrotron Radiat. 26, 874 (2019).
  28. A. A. Sorokin, Y. Bican, S. Bonfigt, M. Brachmanski, M. Braune, U. F. Jastrow, A. Gottwald, H. Kaser, M. Richter, and K. Tiedtke, An x-ray gas monitor for free-electron lasers, J. Synchrotron Radiat. 26, 1092 (2019).
  29. P. Juranić et al., SwissFEL Aramis beamline photon diagnostics, J. Synchrotron Radiat. 25, 1238 (2018).
  30. E. Prat, P. Dijkstal, M. Aiba, S. Bettoni, P. Craievich, E. Ferrari, R. Ischebeck, F. Löhl, A. Malyzhenkov, G. L. Orlandi, S. Reiche, and T. Schietinger, Generation and characterization of intense ultralow-emittance electron beams for compact x-ray free-electron lasers, Phys. Rev. Lett. 123, 234801 (2019).
  31. E. Prat, C. Kittel, M. Calvi, P. Craievich, P. Dijkstal, S. Reiche, T. Schietinger, and G. Wang, Experimental characterization of the optical klystron effect to measure the intrinsic energy spread of high-brightness electron beams, Phys. Rev. Accel. Beams 27, 030701 (2024).
  32. E. Prat, P. Craievich, P. Dijkstal, S. Di Mitri, E. Ferrari, T. G. Lucas, A. Malyzhenkov, G. Perosa, S. Reiche, and T. Schietinger, Energy spread blowup by intrabeam scattering and microbunching at the SwissFEL injector, Phys. Rev. Accel. Beams 25, 104401 (2022).
  33. S. Reiche, genesis 1.3: A fully 3D time-dependent FEL simulation code, Nucl. Instrum. Methods Phys. Res., Sect. A 429, 243 (1999).
  34. N. Kroll, P. Morton, and M. Rosenbluth, Free-electron lasers with variable parameter wigglers, IEEE J. Quantum Electron. 17, 1436 (1981).
  35. C. Bostedt et al., SwissFEL+ conceptual design report, PSI Report No. 26-01 2026.
  36. X. Wang, L. Zeng, J. Shao, Y. Liang, H. Yi, Y. Yu, J. Sun, X. Li, C. Feng, Z. Wang, S. Zhao, H. Jia, S. Huang, W. Zhang, and X. Yang, Physical design for Shenzhen superconducting soft x-ray free-electron laser (S3FEL), in Proceedings of the 14th International Particle Accelerator Conference, Venice, Italy (JACoW, Geneva, Switzerland, 2023), pp. 1852–1855.
