Edge Reconstruction in a Quantum Spin Hall Insulator

Rahul Soni1,2, Matthias Thamm3, Gonzalo Alvarez4, Bernd Rosenow3, and Adrian Del Maestro1,2,5

PDF

Phys. Rev. Lett. 136, 256504 – Published 24 June, 2026

DOI: https://doi.org/10.1103/98j3-424f

Abstract

We study interaction-driven edge reconstruction in a quantum spin Hall insulator described by the Bernevig-Hughes-Zhang model with Kanamori-Hubbard interactions using the real-space density matrix renormalization group method in both the grand-canonical and canonical ensembles. For a two-dimensional cylinder with a smooth edge, we identify discrete particle-number transitions that lead to a spin-polarized edge state stabilized by an emergent ferromagnetic exchange interaction. The reconstruction is orbital-selective, occurring predominantly in the s-orbital channel. Our results reveal a microscopic mechanism for emergent fluctuating moments at the edge that could compromise the topological protection of helical edge states by time-reversal symmetry.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (87)

  1. C. L. Kane and E. J. Mele, Phys. Rev. Lett. 95, 226801 (2005).
  2. C. L. Kane and E. J. Mele, Phys. Rev. Lett. 95, 146802 (2005).
  3. B. A. Bernevig, T. L. Hughes, and S.-C. Zhang, Science 314, 1757 (2006).
  4. M. König, S. Wiedmann, C. Brüne, A. Roth, H. Buhmann, L. W. Molenkamp, X.-L. Qi, and S.-C. Zhang, Science 318, 766 (2007).
  5. M. König, H. Buhmann, L. W. Molenkamp, T. Hughes, C.-X. Liu, X.-L. Qi, and S.-C. Zhang, J. Phys. Soc. Jpn. 77, 031007 (2008).
  6. C. Brüne, A. Roth, H. Buhmann, E. M. Hankiewicz, L. W. Molenkamp, J. Maciejko, X.-L. Qi, and S.-C. Zhang, Nat. Phys. 8, 485 (2012).
  7. M. König, M. Baenninger, Andrei G. F. Garcia, N. Harjee, B. L. Pruitt, C. Ames, P. Leubner, C. Brüne, H. Buhmann, L. W. Molenkamp, and D. Goldhaber-Gordon, Phys. Rev. X 3, 021003 (2013).
  8. S. Hart, H. Ren, T. Wagner, P. Leubner, M. Mühlbauer, C. Brüne, H. Buhmann, L. W. Molenkamp, and A. Yacoby, Nat. Phys. 10, 638 (2014).
  9. M. C. Dartiailh, S. Hartinger, A. Gourmelon, K. Bendias, H. Bartolomei, H. Kamata, J.-M. Berroir, G. Fève, B. Plaçais, L. Lunczer, R. Schlereth, H. Buhmann, L. W. Molenkamp, and E. Bocquillon, Phys. Rev. Lett. 124, 076802 (2020).
  10. L. Lunczer, P. Leubner, M. Endres, V. L. Müller, C. Brüne, H. Buhmann, and L. W. Molenkamp, Phys. Rev. Lett. 123, 047701 (2019).
  11. J. Strunz, J. Wiedenmann, C. Fleckenstein, L. Lunczer, W. Beugeling, V. L. Müller, P. Shekhar, N. T. Ziani, S. Shamim, J. Kleinlein, H. Buhmann, B. Trauzettel, and L. W. Molenkamp, Nat. Phys. 16, 83 (2019).
  12. I. Knez, R.-R. Du, and G. Sullivan, Phys. Rev. Lett. 107, 136603 (2011).
  13. E. M. Spanton, K. C. Nowack, L. Du, G. Sullivan, R.-R. Du, and K. A. Moler, Phys. Rev. Lett. 113, 026804 (2014).
  14. L. Du, I. Knez, G. Sullivan, and R.-R. Du, Phys. Rev. Lett. 114, 096802 (2015).
  15. F. Nichele, H. J. Suominen, M. Kjaergaard, C. M. Marcus, E. Sajadi, J. A. Folk, F. Qu, A. J. A. Beukman, F. K. de Vries, J. van Veen, S. Nadj-Perge, L. P. Kouwenhoven, B.-M. Nguyen, A. A. Kiselev, W. Yi, M. Sokolich, M. J. Manfra, E. M. Spanton, and K. A. Moler, New J. Phys. 18, 083005 (2016).
  16. Z. Fei, T. Palomaki, S. Wu, W. Zhao, X. Cai, B. Sun, P. Nguyen, J. Finney, X. Xu, and D. H. Cobden, Nat. Phys. 13, 677 (2017).
  17. S. Wu, V. Fatemi, Q. D. Gibson, K. Watanabe, T. Taniguchi, R. J. Cava, and P. Jarillo-Herrero, Science 359, 76 (2018).
  18. W. Zhao, E. Runburg, Z. Fei, J. Mutch, P. Malinowski, B. Sun, X. Huang, D. Pesin, Y.-T. Cui, X. Xu, J.-H. Chu, and D. H. Cobden, Phys. Rev. X 11, 041034 (2021).
  19. M. Papaj, Phys. Rev. B 110, 165422 (2024).
  20. F. Reis, G. Li, L. Dudy, M. Bauernfeind, S. Glass, W. Hanke, R. Thomale, J. Schäfer, and R. Claessen, Science 357, 287 (2017).
  21. R. Stühler, F. Reis, T. Müller, T. Helbig, T. Schwemmer, R. Thomale, J. Schäfer, and R. Claessen, Nat. Phys. 16, 47 (2019).
  22. K. Kang, B. Shen, Y. Qiu, Y. Zeng, Z. Xia, K. Watanabe, T. Taniguchi, J. Shan, and K. F. Mak, Nature (London) 628, 522 (2024).
  23. K. Kang, Y. Qiu, K. Watanabe, T. Taniguchi, J. Shan, and K. F. Mak, Nano Lett. 24, 14901 (2024).
  24. A. M. Lunde and G. Platero, Phys. Rev. B 86, 035112 (2012).
  25. A. Del Maestro, T. Hyart, and B. Rosenow, Phys. Rev. B 87, 165440 (2013).
  26. C.-H. Hsu, P. Stano, J. Klinovaja, and D. Loss, Phys. Rev. B 96, 081405(R) (2017).
  27. A. Russo, E. Barnes, and S. E. Economou, Phys. Rev. B 98, 235412 (2018).
  28. C.-H. Hsu, P. Stano, J. Klinovaja, and D. Loss, Phys. Rev. B 97, 125432 (2018).
  29. J. I. Väyrynen, D. I. Pikulin, and J. Alicea, Phys. Rev. Lett. 121, 106601 (2018).
  30. A. Ström, H. Johannesson, and G. I. Japaridze, Phys. Rev. Lett. 104, 256804 (2010).
  31. F. Geissler, F. Crépin, and B. Trauzettel, Phys. Rev. B 89, 235136 (2014).
  32. H.-Y. Xie, H. Li, Y.-Z. Chou, and M. S. Foster, Phys. Rev. Lett. 116, 086603 (2016).
  33. M. Kharitonov, F. Geissler, and B. Trauzettel, Phys. Rev. B 96, 155134 (2017).
  34. S. Mondal and S. Basu, Phys. Rev. B 105, 235409 (2022).
  35. A. C. Balram, K. Flensberg, J. Paaske, and M. S. Rudner, Phys. Rev. Lett. 123, 246803 (2019).
  36. Y.-Z. Chou, R. M. Nandkishore, and L. Radzihovsky, Phys. Rev. B 98, 054205 (2018).
  37. J. Maciejko, C. Liu, Y. Oreg, X.-L. Qi, C. Wu, and S.-C. Zhang, Phys. Rev. Lett. 102, 256803 (2009).
  38. L. Kimme, B. Rosenow, and A. Brataas, Phys. Rev. B 93, 081301(R) (2016).
  39. V. D. Kurilovich, P. D. Kurilovich, and I. S. Burmistrov, Phys. Rev. B 95, 115430 (2017).
  40. P. D. Kurilovich, V. D. Kurilovich, I. S. Burmistrov, and M. Goldstein, JETP Lett. 106, 593 (2017).
  41. B. L. Altshuler, I. L. Aleiner, and V. I. Yudson, Phys. Rev. Lett. 111, 086401 (2013).
  42. A. Vezvaee, A. Russo, S. E. Economou, and E. Barnes, Phys. Rev. B 98, 035301 (2018).
  43. J.-H. Zheng and M. A. Cazalilla, Phys. Rev. B 97, 235402 (2018).
  44. B. V. Pashinsky, M. Goldstein, and I. S. Burmistrov, Phys. Rev. B 102, 125309 (2020).
  45. L. Vannucci, T. Olsen, and K. S. Thygesen, Phys. Rev. B 101, 155404 (2020).
  46. T. Dietl, Phys. Rev. Lett. 130, 086202 (2023).
  47. N. Lezmy, Y. Oreg, and M. Berkooz, Phys. Rev. B 85, 235304 (2012).
  48. J. I. Väyrynen, M. Goldstein, and L. I. Glazman, Phys. Rev. Lett. 110, 216402 (2013).
  49. J. I. Väyrynen, M. Goldstein, Y. Gefen, and L. I. Glazman, Phys. Rev. B 90, 115309 (2014).
  50. P. Novelli, F. Taddei, A. K. Geim, and M. Polini, Phys. Rev. Lett. 122, 016601 (2019).
  51. J. Dempsey, B. Y. Gelfand, and B. I. Halperin, Phys. Rev. Lett. 70, 3639 (1993).
  52. X. Wan, K. Yang, and E. H. Rezayi, Phys. Rev. Lett. 88, 056802 (2002).
  53. X. Wan, E. H. Rezayi, and K. Yang, Phys. Rev. B 68, 125307 (2003).
  54. K. Yang, Phys. Rev. Lett. 91, 036802 (2003).
  55. U. Khanna, M. Goldstein, and Y. Gefen, Phys. Rev. Lett. 129, 146801 (2022).
  56. T. Lotrič, T. Wang, M. P. Zaletel, S. H. Simon, and S. A. Parameswaran, arXiv:2507.07161.
  57. A. Saha, S. J. De, S. Rao, Y. Gefen, and G. Murthy, Phys. Rev. B 103, L081401 (2021).
  58. U. Khanna, G. Murthy, S. Rao, and Y. Gefen, Phys. Rev. Lett. 119, 186804 (2017).
  59. J. Wang, Y. Meir, and Y. Gefen, Phys. Rev. Lett. 118, 046801 (2017).
  60. N. John, A. D. Maestro, and B. Rosenow, Europhys. Lett. 140, 26002 (2022).
  61. A. Amaricci, L. Privitera, F. Petocchi, M. Capone, G. Sangiovanni, and B. Trauzettel, Phys. Rev. B 95, 205120 (2017).
  62. N. M. Nguyen, G. Cuono, R. Islam, C. Autieri, T. Hyart, and W. Brzezicki, Phys. Rev. B 107, 045138 (2023).
  63. S. R. White, Phys. Rev. Lett. 69, 2863 (1992).
  64. U. Schollwöck, Rev. Mod. Phys. 77, 259 (2005).
  65. R. Soni, H. Radhakrishnan, B. Rosenow, G. Alvarez, and A. Del Maestro, Phys. Rev. B 109, 245115 (2024).
  66. J. Kanamori, Prog. Theor. Phys. 30, 275 (1963).
  67. R. Soni, N. Kaushal, C. Şen, F. A. Reboredo, A. Moreo, and E. Dagotto, New J. Phys. 24, 073014 (2022).
  68. J. C. Budich, B. Trauzettel, and G. Sangiovanni, Phys. Rev. B 87, 235104 (2013).
  69. S. Miyakoshi and Y. Ohta, Phys. Rev. B 87, 195133 (2013).
  70. Z. Chen and T. K. Ng, Phys. Rev. B 99, 235157 (2019).
  71. See Supplemental Material at http://link.aps.org/supplemental/10.1103/98j3-424f for more details, which includes Refs. [72–74].
  72. C. G. Broyden, Math. Comput. 19, 577 (1965).
  73. A. Baran, A. Bulgac, M. M. N. Forbes, G. Hagen, W. Nazarewicz, N. Schunck, and M. V. Stoitsov, Phys. Rev. C 78, 014318 (2008).
  74. J. Motruk, M. P. Zaletel, Roger S. K. Mong, and F. Pollmann, Phys. Rev. B 93, 155139 (2016).
  75. M. Fishman, S. R. White, and E. M. Stoudenmire, SciPost Phys. Codebases 4 (2022).
  76. M. Fishman, S. R. White, and E. M. Stoudenmire, SciPost Phys. Codebases 4 (2022).
  77. G. Alvarez, Comput. Phys. Commun. 180, 1572 (2009).
  78. G. Alvarez, Comput. Phys. Commun. 183, 2226 (2012).
  79. G. Alvarez, Dmrg++ website, https://g1257.github.io/dmrgPlusPlus/ (2025).
  80. X. Qian, J. Liu, L. Fu, and J. Li, Science 346, 1344 (2014).
  81. S. Chadov, X. Qi, J. Kübler, G. H. Fecher, C. Felser, and S.-C. Zhang, Nat. Mater. 9, 541 (2010).
  82. M. Neupane, N. Alidoust, S. Xu, T. Kondo, Y. Ishida, D.-J. Kim, C. Liu, I. Belopolski, Y. Jo, T.-R. Chang, H.-T. Jeng, T. Durakiewicz, L. Balicas, H. Lin, A. Bansil, S. Shin, Z. Fisk, and M. Z. Hasan, Nat. Commun. 4, 2991 (2013).
  83. S.-H. Hung and H.-T. Jeng, Materials 13, 4381 (2020).
  84. K. Yang, Phys. Rev. Lett. 93, 066401 (2004).
  85. E. Lieb and D. Mattis, Phys. Rev. 125, 164 (1962).
  86. H. J. Schulz, Phys. Rev. Lett. 71, 1864 (1993).
  87. A. Del Maestro, Github Repository (2025), 10.5281/zenodo.16875877.
