System-size and event-shape dependence of particle-identified balance functions in proton-proton collisions at s=13 TeV using PYTHIA 8 and EPOS models

Subash Chandra Behera1,* and Arvind Khuntia2,†

  • *Contact author: subash.chandra.behera@cern.ch
  • †Contact author: arvind.khuntia@cern.ch
PDF

Phys. Rev. C 113, 035201 – Published 2 March, 2026

DOI: https://doi.org/10.1103/34vh-wjv2

Abstract

We investigate charge-balance functions for pion, kaon, and proton pairs in proton-proton (pp) collisions at s=13 TeV using Monte Carlo models, pythia8, and epos-lhc, with transverse spherocity to classify event topology and charged-particle multiplicity to select system size. Simulations with pythia8 and epos-lhc reveal that balance-function widths in rapidity and azimuthal angle depend on multiplicity and event shape. In pythia8, widths decrease monotonically with multiplicity, consistent with local charge conservation in a fragmentation-dominated scenario. In contrast, the epos-lhc model, especially when using the core corona implementation, exhibits a more intricate response, where the combined effects of hydrodynamic radial flow and longitudinal diffusion result in narrower azimuthal correlations and broader rapidity correlations. These features are characteristic signatures of collective dynamics, similar to those observed in heavy-ion collisions. Events with low spherocity, which are jetlike in nature, exhibit significantly narrower balance-function widths compared to isotropic events with high spherocity, illustrating that event-shape selection provides clear sensitivity to the underlying dynamics of particle production in pp collisions. The species dependence and event-shape sensitivity of the balance-function widths provide information about the hadronization dynamics and collectivity in small systems. These results demonstrate that multidimensional, particle-species-dependent balance-function measurements can disentangle the underlying mechanisms of charge correlations and mediumlike behavior in high-multiplicity pp collisions.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (54)

  1. I. Arsene, et al. (BRAHMS Collaboration), Quark gluon plasma and color glass condensate at RHIC? The Perspective from the BRAHMS experiment”, Nucl. Phys. A 757, 1 (2005).
  2. J. Adams, et al. (STAR Collaboration), Experimental and theoretical challenges in the search for the quark gluon plasma: The STAR Collaboration's critical assessment of the evidence from RHIC collisions, Nucl. Phys. A 757, 102 (2005).
  3. B. B. Back, et al. (PHOBOS Collaboration), The PHOBOS perspective on discoveries at RHIC, Nucl. Phys. A 757, 28 (2005).
  4. A. Hayrapetyan, et al. (CMS Collaboration), Overview of high-density QCD studies with the CMS experiment at the LHC, Phys. Rep. 1115, 219 (2025).
  5. V. Khachatryan, et al. (CMS Collaboration), Observation of long-range, near-side angular correlations in proton-proton collisions at the LHC, J. High Energy Phys. 09 (2010) 091.
  6. V. Khachatryan, et al. (CMS Collaboration), Measurement of long-range near-side two-particle angular correlations in pp collisions at s=13 TeV, Phys. Rev. Lett. 116, 172302 (2016).
  7. A. Baty, P. Gardner, and W. Li, Novel observables for exploring QCD collective evolution and quantum entanglement within individual jets, Phys. Rev. C 107, 064908 (2023).
  8. V. Khachatryan, et al. (CMS Collaboration), Evidence for collectivity in pp collisions at the LHC, Phys. Lett. B 765, 193 (2017).
  9. G. Aad, et al. (ATLAS Collaboration), Measurement of the Sensitivity of Two-Particle Correlations in pp Collisions to the Presence of Hard Scatterings, Phys. Rev. Lett. 131, 162301 (2023).
  10. M. Aaboud, et al. (ATLAS Collaboration), Measurement of long-range two-particle azimuthal correlations in Z-boson tagged pp collisions at s=8 and 13TeV, Eur. Phys. J. C 80, 64 (2020).
  11. M. Aaboud, et al. (ATLAS Collaboration), Measurements of long-range azimuthal anisotropies and associated Fourier coefficients for pp collisions at s=5.02 and 13 TeV and p Pb collisions at sNN=5.02 TeV with the ATLAS detector, Phys. Rev. C 96, 024908 (2017).
  12. G. Aad, et al. (ATLAS Collaboration), Observation of Long-Range Elliptic Azimuthal Anisotropies in s=13 and 2.76 TeV pp Collisions with the ATLAS Detector, Phys. Rev. Lett. 116, 172301 (2016).
  13. G. Aad, et al. (ATLAS Collaboration), Measurement of long-range pseudorapidity correlations and azimuthal harmonics in sNN=5.02 TeV proton-lead collisions with the ATLAS detector, Phys. Rev. C 90, 044906 (2014).
  14. G. Aad, et al. (ATLAS Collaboration), Observation of associated near-side and away-side long-range correlations in sNN=5.02 TeV proton-lead collisions with the ATLAS Detector, Phys. Rev. Lett. 110, 182302 (2013).
  15. B. Abelev, et al. (ALICE Collaboration), Long-range angular correlations on the near and away side in p-Pb collisions at sNN=5.02 TeV, Phys. Lett. B 719, 29 (2013).
  16. M. I. Abdulhamid, et al. (STAR Collaboration), Measurement of flow coefficients in high-multiplicity p+Au, d+Au, and He3+Au collisions at sNN=200GeV, Phys. Rev. C 110, 064902 (2024).
  17. M. I. Abdulhamid, et al., Measurements of the elliptic and triangular azimuthal anisotropies in central He3+Au, d+Au and p+Au Collisions at sNN=200GeV, Phys. Rev. Lett. 130, 242301 (2023).
  18. U. A. Acharya, et al. (PHENIX Collaboration), Kinematic dependence of azimuthal anisotropies in p+Au,d+Au, and H3e+Au at sNN=200 GeV, Phys. Rev. C 105, 024901 (2022).
  19. M. Mace, V. V. Skokov, P. Tribedy, and R. Venugopalan, Hierarchy of azimuthal anisotropy harmonics in collisions of small systems from the color glass condensate, Phys. Rev. Lett. 121, 052301 (2018); 123, 039901 (2019).
  20. S. Basu, V. Gonzalez, J. Pan, A. Knospe, A. Marin, C. Markert, and C. Pruneau, Differential two-particle number and momentum correlations with the AMPT, UrQMD, and EPOS models in Pb-Pb collisions at sNN=2.76 TeV, Phys. Rev. C 104, 064902 (2021).
  21. S. Pratt, General charge balance functions: A tool for studying the chemical evolution of the quark-gluon plasma, Phys. Rev. C 85, 014904 (2012).
  22. W.-H. Zhou, H. Liu, F. Li, Y.-F. Sun, J. Xu, and C. M. Ko, Elliptic flow splittings in the Polyakov-Nambu-Jona-Lasinio transport model, Phys. Rev. C 104, 044901 (2021).
  23. C. A. Pruneau, Role of baryon number conservation in measurements of fluctuations, Phys. Rev. C 100, 034905 (2019).
  24. S. Acharya, et al. (ALICE Collaboration), General balance functions of identified charged hadron pairs of (π,K,p) in Pb-Pb collisions at sNN=2.76 TeV, Phys. Lett. B 833, 137338 (2022).
  25. A. Manea, C. Pruneau, D. C. Brandibur, A. Danu, A. F. Dobrin, V. Gonzalez, and S. Basu, Investigating late-stage particle production in pp collisions with balance functions, Eur. Phys. J. C 85, 323 (2025).
  26. S. Acharya, et al. (ALICE Collaboration), Two-particle differential transverse momentum and number density correlations in p-Pb and Pb-Pb at the LHC, Phys. Rev. C 100, 044903 (2019).
  27. S. Acharya, et al. (ALICE Collaboration), Measurements of differential two-particle number and transverse momentum correlation functions in pp collisions at s=13 TeV, Eur. Phys. J. C, 85, 866 (2025).
  28. J. Adam, et al. (ALICE Collaboration), Multiplicity and transverse momentum evolution of charge-dependent correlations in pp, p-Pb, and Pb-Pb collisions at the LHC, Eur. Phys. J. C 76, 86 (2016).
  29. S. A. Bass, P. Danielewicz, and S. Pratt, Clocking hadronization in relativistic heavy ion collisions with balance functions, Phys. Rev. Lett. 85, 2689 (2000).
  30. A. Tumasyan, et al. (CMS Collaboration), Multiplicity and transverse momentum dependence of charge-balance functions in pPb and PbPb collisions at LHC energies, J. High Energy Phys. 08 (2024) 148.
  31. K. Werner, Core-corona procedure and microcanonical hadronization to understand strangeness enhancement in proton-proton and heavy ion collisions in the EPOS4 framework, Phys. Rev. C 109, 014910 (2024).
  32. T. Pierog, I. Karpenko, J. M. Katzy, E. Yatsenko, and K. Werner, EPOS LHC: Test of collective hadronization with data measured at the CERN Large Hadron Collider, Phys. Rev. C 92, 034906 (2015).
  33. M. Cacciari, G. P. Salam, and G. Soyez, FastJet user manual, Eur. Phys. J. C 72, 1896 (2012).
  34. C. Bierlich, et al., A comprehensive guide to the physics and usage of PYTHIA 8.3, SciPost Phys. Codeb, 2022, 8 (2022).
  35. A. Chernyshov, G. K. Eyyubova, V. L. Korotkikh, I. P. Lokhtin, L. V. Malinina, S. V. Petrushanko, A. M. Snigirev, and E. E. Zabrodin, The charge balance function with HYDJET model in heavy ion collisions at LHC, Int. J. Mod. Phys. A 39, 2443021 (2024).
  36. S. N. Alam (ALICE Collaboration), Charge correlations using balance functions of identified particles in Pb-Pb collisions at sNN=2.76 TeV with ALICE, PoS EPS-HEP 723, 267 (2017).
  37. B. I. Abelev, et al. (STAR Collaboration), Longitudinal scaling property of the charge balance function in Au + Au collisions at 200 GeV, Phys. Lett. B 690, 239 (2010).
  38. M. R. Atayan, et al. (EHS NA22 Collaboration), Boost invariance and multiplicity dependence of the charge balance functionin π+p and K+p collisions at s=22GeV/c, Phys. Lett. B 637, 39 (2006).
  39. S. Pratt and C. Plumberg, Charge balance functions for heavy-ion collisions at energies available at the CERN Large Hadron Collider, Phys. Rev. C 104, 014906 (2021).
  40. S. Pratt, Identifying the charge carriers of the quark-gluon plasma, Phys. Rev. Lett. 108, 212301 (2012).
  41. S. A. Voloshin, Heavy ion collisions: Correlations and fluctuations in particle production, J. Phys.: Conf. Ser. 50, 111 (2006).
  42. S. Acharya, et al. (ALICE Collaboration), Charged-particle production as a function of multiplicity and transverse spherocity in pp collisions at s=5.02 and 13 TeV, Eur. Phys. J. C 79, 857 (2019).
  43. A. Khuntia, S. Tripathy, A. Bisht, and R. Sahoo, Event shape engineering and multiplicity dependent study of identified particle production in proton proton collisions at s=13 TeV using PYTHIA8, J. Phys. G: Nucl. Part. Phys. 48, 035102 (2021).
  44. CMS Collaboration, A. Tumasyan, “Correlations between azimuthal anisotropy and mean transverse momentum in pp, pPb, and peripheral PbPb collisions”, arXiv:2410.04578.
  45. A. Hayrapetyan, et al. (CMS Collaboration), Observation of enhanced long-range elliptic anisotropies inside high-multiplicity jets in pp collisions at s=13 TeV, Phys. Rev. Lett. 133, 142301 (2024).
  46. S. Chatrchyan, et al. (CMS Collaboration), Long-range and short-range dihadron angular correlations in central PbPb collisions at a nucleon-nucleon center of mass energy of 2.76 TeV, J. High Energy Phys. 07 (2011) 076.
  47. A. Tumasyan, et al. (CMS Collaboration), Two-particle azimuthal correlations in γp interactions using pPb collisions at sNN=8.16 TeV, Phys. Lett. B 844, 137905 (2023).
  48. A. M. Sirunyan, et al. (CMS Collaboration), Elliptic flow of charm and strange hadrons in high-multiplicity p + Pb collisions at sNN=8.16TeV, Phys. Rev. Lett. 121, 082301 (2018).
  49. S. Pratt and J. Vredevoogd, Femtoscopy in relativistic heavy ion collisions and its relation to bulk properties of QCD matter, Phys. Rev. C 78, 054906 (2008); 79, 069901(E) (2009).
  50. R. H. Brown and R. Q. Twiss, Correlation between Photons in two Coherent Beams of Light, Nature (London) 177, 27 (1956).
  51. S. Acharya, et al. (ALICE Collaboration), Light-flavor particle production in high-multiplicity pp collisions at s=13 TeV as a function of transverse spherocity, J. High Energy Phys. 05 (2024) 184.
  52. A. Tumasyan, et al. (CMS Collaboration), CMS pythia 8 reconnection tunes based on underlying-event data, Eur. Phys. J. C 83, 587 (2023).
  53. A. Ortiz Velasquez, P. Christiansen, E. Cuautle Flores, I. Maldonado Cervantes, and G. Paić, Color reconnection and flowlike patterns in pp collisions, Phys. Rev. Lett. 111, 042001 (2013).
  54. L. Lönnblad and H. Shah, Baryon correlations in Pythia, Eur. Phys. J. C 83, 1105 (2023).

Outline

Information

Phys. Rev. C 113, 035201– Published 2 March, 2026
  • Received 28 August 2025
  • Revised 23 November 2025
  • Accepted 2 February 2026
