Environment-dependent tight-binding models from ab initio pseudoatomic orbital Hamiltonians

M. Buongiorno Nardelli

PDF

Phys. Rev. B 114, 045125 – Published 24 July, 2026

DOI: https://doi.org/10.1103/y72v-hhxj

Abstract

Ab initio pseudoatomic orbital (PAO) Hamiltonians express the electronic structure of a solid in a compact, localized basis that spans the same Hilbert space as a conventional Slater-Koster tight-binding model, thereby providing an exact ab initio representation without any loss of accuracy. Building on this correspondence, we develop an environment-dependent tight-binding framework in which Slater-Koster hopping integrals are augmented with bond-screening functions that capture the local coordination environment. All parameters are determined by fitting to the PAO eigenvalue spectrum across multiple atomic configurations simultaneously, which breaks the degeneracy between screening and hopping parameters and yields physically meaningful, transferable models capable of generating Hamiltonians for large systems with ab initio precision. We demonstrate the efficiency and accuracy of the approach on four prototypical systems: bulk platinum, silicon surfaces, Si/Ge [001] superlattices, and twisted bilayer graphene with up to 4324 atoms. The method is implemented in the paoflow code and integrates seamlessly with its full postprocessing suite, enabling the evaluation of a broad range of electronic, optical, and transport properties.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (42)

  1. J. C. Slater and G. F. Koster, Simplified LCAO method for the periodic potential problem, Phys. Rev. 94, 1498 (1954).
  2. W. A. Harrison, Electronic Structure and the Properties of Solids (Freeman, San Francisco, 1980).
  3. D. A. Papaconstantopoulos and M. J. Mehl, The Slater–Koster tight-binding method: A computationally efficient and accurate approach, J. Phys.: Condens. Matter 15, R413 (2003).
  4. M. Buongiorno Nardelli, F. T. Cerasoli, M. Costa, S. Curtarolo, R. De Gennaro, M. Fornari, L. Liyanage, A. R. Supka, and H. Wang, Paoflow: A utility to construct and operate on ab initio Hamiltonians from the projections of electronic wavefunctions on atomic orbital bases, including characterization of topological materials, Comput. Mater. Sci. 143, 462 (2018).
  5. F. T. Cerasoli, A. R. Supka, A. Jayaraj, M. Costa, I. Siloi, J. Sławińska, S. Curtarolo, M. Fornari, D. Ceresoli, and M. Buongiorno Nardelli, Advanced modeling of materials with PAOFLOW 2.0: New features and software design, Comput. Mater. Sci. 200, 110828 (2021).
  6. L. Goodwin, A. J. Skinner, and D. G. Pettifor, Generating transferable tight-binding parameters: Application to silicon, Europhys. Lett. 9, 701 (1989).
  7. R. E. Cohen, M. J. Mehl, and D. A. Papaconstantopoulos, Tight-binding total-energy method for transition and noble metals, Phys. Rev. B 50, 14694 (1994).
  8. M. J. Mehl and D. A. Papaconstantopoulos, Applications of a tight-binding total-energy method for transition and noble metals, Phys. Rev. B 54, 4519 (1996).
  9. N. Bernstein, M. J. Mehl, D. A. Papaconstantopoulos, N. C. Papanicolaou, M. Z. Bazant, and E. Kaxiras, Energetic, vibrational, and electronic properties of silicon using a nonorthogonal tight-binding model, Phys. Rev. B 62, 4477 (2000).
  10. M. S. Tang, C. Z. Wang, C. T. Chan, and K. M. Ho, Environment-dependent tight-binding potential model, Phys. Rev. B 53, 979 (1996).
  11. A. Urban, M. Reese, M. Mrovec, C. Elsässer, and B. Meyer, Parameterization of tight-binding models from density functional theory calculations, Phys. Rev. B 84, 155119 (2011).
  12. L. A. Agapito, S. Ismail-Beigi, S. Curtarolo, M. Fornari, and M. Buongiorno Nardelli, Accurate tight-binding Hamiltonian matrices from ab initio calculations: Minimal basis sets, Phys. Rev. B 93, 035104 (2016).
  13. L. A. Agapito, M. Fornari, D. Ceresoli, A. Ferretti, S. Curtarolo, and M. Buongiorno Nardelli, Accurate tight-binding Hamiltonians for two-dimensional and layered materials, Phys. Rev. B 93, 125137 (2016).
  14. P. D'Amico, L. Agapito, A. Catellani, A. Ruini, S. Curtarolo, M. Fornari, M. Buongiorno Nardelli, and A. Calzolari, Accurate ab initio tight-binding Hamiltonians: Effective tools for electronic transport and optical spectroscopy from first principles, Phys. Rev. B 94, 165166 (2016).
  15. P. Giannozzi et al., QUANTUM ESPRESSO: A modular and open-source software project for quantum simulations of materials, J. Phys.: Condens. Matter 21, 395502 (2009).
  16. P. Giannozzi et al., Advanced capabilities for materials modelling with QUANTUM ESPRESSO, J. Phys.: Condens. Matter 29, 465901 (2017).
  17. H.-J. Kim, TBFIT: Tight-binding parameter fitting package (2018).
  18. M. Nakhaee, S. A. Ketabi, and F. M. Peeters, TB Studio: A technical tool for evaluating the electronic properties of solids, Comput. Phys. Commun. 254, 107379 (2020).
  19. G. Hegde, M. Povolotskyi, T. Kubis, T. B. Boykin, and G. Klimeck, An environment-dependent semi-empirical tight binding model suitable for electron transport in bulk metals, metal alloys, metallic interfaces, and metallic nanostructures. I. Model and validation, J. Appl. Phys. 115, 123703 (2014).
  20. K. Levenberg, A method for the solution of certain non-linear problems in least squares, Q. Appl. Math. 2, 164 (1944).
  21. D. W. Marquardt, An algorithm for least-squares estimation of nonlinear parameters, J. Soc. Ind. Appl. Math. 11, 431 (1963).
  22. G. Hegde, Generation and optimization of tight binding (TB) parameters using genetic algorithms and their validation using NEMO3D, Ph.D. thesis, Purdue University, 2010.
  23. A.-L. Phan, D. Soccodato, A. Pecchia, A. Di Vito, and M. Auf der Maur, Obtaining highly transferable parameters for empirical tight-binding simulations: From pure materials to polytypic heterostructures and dilute alloys, Phys. Rev. B 112, 165202 (2025).
  24. A. G. Frøseth, R. Holmestad, P. M. Derlet, and K. Marthinsen, Improved tight-binding parametrization for the simulation of stacking faults in aluminum, Phys. Rev. B 68, 012105 (2003).
  25. K. F. Garrity and K. Choudhary, Fast and accurate prediction of material properties with three-body tight-binding model for the periodic table, Phys. Rev. Mater. 7, 044603 (2023).
  26. Z. Wang, S. Ye, H. Wang, J. He, Q. Huang, and S. Chang, Machine learning method for tight-binding Hamiltonian parameterization from ab initio band structure, npj Comput. Mater. 7, 11 (2021).
  27. S. Kim, Construction of optimized tight-binding models using ab initio Hamiltonian: Application to monolayer 2H-transition metal dichalcogenides, J. Phys.: Condens. Matter 35, 415501 (2023).
  28. PAOFLOW development team (unpublished).
  29. G. Y. Guo, Y. Yao, and Q. Niu, Ab initio calculation of the intrinsic spin Hall effect in semiconductors, Phys. Rev. Lett. 94, 226601 (2005).
  30. G. Y. Guo, S. Murakami, T.-W. Chen, and N. Nagaosa, Intrinsic spin Hall effect in platinum: First-principles calculations, Phys. Rev. Lett. 100, 096401 (2008).
  31. J. Qiao, J. Zhou, Z. Yuan, and W. Zhao, Calculation of intrinsic spin Hall conductivity by Wannier interpolation, Phys. Rev. B 98, 214402 (2018).
  32. C. G. Van de Walle and R. M. Martin, Theoretical calculations of heterojunction discontinuities in the Si/Ge system, Phys. Rev. B 34, 5621 (1986).
  33. T. B. Boykin, G. Klimeck, M. Friesen, S. N. Coppersmith, P. von Allmen, F. Oyafuso, and S. Lee, Valley splitting in strained silicon quantum wells, Phys. Rev. B 70, 165325 (2004).
  34. M. Friesen, S. Chutia, C. Tahan, and S. N. Coppersmith, Valley splitting theory of SiGe/Si/SiGe quantum wells, Phys. Rev. B 75, 115318 (2007).
  35. C. Lanczos, An iteration method for the solution of the eigenvalue problem of linear differential and integral operators, J. Res. Natl. Bur. Stan. 45, 255 (1950).
  36. D. C. Sorensen, Implicit application of polynomial filters in a k-step Arnoldi method, SIAM J. Matrix Anal. Appl. 13, 357 (1992).
  37. R. Bistritzer and A. H. MacDonald, Moiré bands in twisted double-layer graphene, Proc. Natl. Acad. Sci. USA 108, 12233 (2011).
  38. P. Moon and M. Koshino, Energy spectrum and quantum Hall effect in twisted bilayer graphene, Phys. Rev. B 85, 195458 (2012).
  39. S. Pathak, T. Rakib, R. Hou, A. Nevidomskyy, E. Ertekin, H. T. Johnson, and L. K. Wagner, Accurate tight-binding model for twisted bilayer graphene describes topological flat bands without geometric relaxation, Phys. Rev. B 105, 115141 (2022).
  40. Anthropic, Introducing Claude 4 (2025).
  41. https://github.com/marcobn/PAOFLOW.
  42. https://github.com/marcobn/EDTB_code.

Outline

Information

Phys. Rev. B 114, 045125– Published 24 July, 2026
  • Received 15 April 2026
  • Revised 12 June 2026
  • Accepted 8 July 2026
