Magnetic contribution of itinerant electrons to neutron diffraction in the topological antiferromagnet CeAlGe

V. Pomjakushin*

A. Podlesnyak

P. Puphal

S. Shin

J. S. White

E. Pomjakushina

  • Laboratory for Neutron Scattering and Imaging LNS, PSI Center for Neutron and Muon Sciences, 5232 Villigen PSI, Switzerland

  • Laboratory for Multiscale Materials Experiments LMX, PSI Center for Neutron and Muon Sciences, 5232 Villigen PSI, Switzerland

  • Laboratory for Neutron Scattering and Imaging LNS, PSI Center for Neutron and Muon Sciences, 5232 Villigen PSI, Switzerland

  • Laboratory for Multiscale Materials Experiments LMX, PSI Center for Neutron and Muon Sciences, 5232 Villigen PSI, Switzerland

  • *Contact author: vladimir.pomjakushin@psi.ch
PDF

Phys. Rev. B 112, 094457 – Published 29 September, 2025

DOI: https://doi.org/10.1103/xrmt-jfl8

Abstract

We report a neutron diffraction study of the magnetic structure of CeAlGe, a candidate topological semimetal that hosts a noncollinear, multi-k magnetic phase. By measuring both low- and high-momentum-transfer magnetic Bragg peaks within a single experimental setup, we refine a magnetic structure model based solely on localized Ce moments. This model, which differs from that obtained using only high-Q data, quantitatively reproduces the observed intensities, including the (000) zeroth-order magnetic satellites that are especially sensitive to subtle components of the modulation. While a contribution from itinerant electrons to the zeroth satellite cannot be definitively excluded, our analysis reveals no unambiguous evidence for such effects within experimental uncertainty. The refined magnetic structures exhibit topologically nontrivial winding patterns, derived from the fitted magnetic parameters, that support localized, particle-like spin textures with half-integer topological charges. These features provide a natural microscopic origin for the observed topological Hall effect, establishing CeAlGe as a model system where magnetism and topology are intimately linked.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (25)

  1. P. Puphal, V. Pomjakushin, N. Kanazawa, V. Ukleev, D. J. Gawryluk, J. Ma, M. Naamneh, N. C. Plumb, L. Keller, R. Cubitt, E. Pomjakushina, and J. S. White, Topological magnetic phase in the candidate Weyl semimetal CeAlGe, Phys. Rev. Lett. 124, 017202 (2020).
  2. M. M. Piva, J. C. Souza, G. A. Lombardi, K. R. Pakuszewski, C. Adriano, P. G. Pagliuso, and M. Nicklas, Topological Hall effect in CeAlGe, Phys. Rev. Mater. 7, 074204 (2023).
  3. S. W. Lovesey, Theory of Neutron Scattering from Condensed Matter. Polarization Effects and Magnetic Scattering, Vol. 2 (Oxford University Press, New York, 1984).
  4. C. G. Windsor, Neutron scattering experiments on itinerant electron magnets, Physica B+C 91, 119 (1977).
  5. T. Moriya and Y. Takahashi, Itinerant electron magnetism, Annu. Rev. Mater. Sci. 14, 1 (1984).
  6. P. Puphal, C. Mielke, N. Kumar, Y. Soh, T. Shang, M. Medarde, J. S. White, and E. Pomjakushina, Bulk single-crystal growth of the theoretically predicted magnetic Weyl semimetals R AlGe (R = Pr, Ce), Phys. Rev. Mater. 3, 024204 (2019).
  7. G. Ehlers, A. A. Podlesnyak, J. L. Niedziela, E. B. Iverson, and P. E. Sokol, The new cold neutron chopper spectrometer at the spallation neutron source: Design and performance, Rev. Sci. Instrum. 82, 085108 (2011).
  8. G. Ehlers, A. A. Podlesnyak, and A. I. Kolesnikov, The cold neutron chopper spectrometer at the spallation neutron source review of the first 8 years of operation, Rev. Sci. Instrum. 87, 093902 (2016).
  9. P. Fischer, G. Frey, M. Koch, M. Könnecke, V. Pomjakushin, J. Schefer, R. Thut, N. Schlumpf, R. Bürge, U. Greuter, S. Bondt, and E. Berruyer, High-resolution powder diffractometer HRPT for thermal neutrons at SINQ, Physica B 146, 276 (2000).
  10. J. Rodríguez-Carvajal, Recent advances in magnetic-structure determination by neutron powder diffraction, Phys. B: Condens. Matter 192, 55 (1993).
  11. B. J. Campbell, H. T. Stokes, D. E. Tanner, and D. M. Hatch, ISODISPLACE: A web-based tool for exploring structural distortions, J. Appl. Cryst. 39, 607 (2006).
  12. H. T. Stokes, D. M. Hatch, and B. J. Campbell, ISOTROPY Software Suite, iso.byu.edu (2021).
  13. M. I. Aroyo, J. M. Perez-Mato, D. Orobengoa, E. Tasci, G. De La Flor, and A. Kirov, Crystallography online: Bilbao crystallographic server, Bulg. Chem. Commun. 43, 183 (2011).
  14. J. M. Perez-Mato, S. V. Gallego, E. S. Tasci, L. Elcoro, G. de la Flor, and M. I. Aroyo, Symmetry-based computational tools for magnetic crystallography, Annu. Rev. Mater. Res. 45, 217 (2015).
  15. See Supplemental Material at http://link.aps.org/supplemental/10.1103/xrmt-jfl8 for the mcif-files with crystallographic information about crystal and magnetic structures and additional figures.
  16. S. V. Gallego, J. M. Perez-Mato, L. Elcoro, E. S. Tasci, R. M. Hanson, K. Momma, M. I. Aroyo, and G. Madariaga, MAGNDATA: Towards a database of magnetic structures. I. The commensurate case, J. Appl. Crystallogr. 49, 1750 (2016).
  17. I. Belopolski, K. Manna, D. S. Sanchez, G. Chang, B. Ernst, J. Yin, S. S. Zhang, T. Cochran, N. Shumiya, H. Zheng, B. Singh, G. Bian, D. Multer, M. Litskevich, X. Zhou, S.-M. Huang, B. Wang, T.-R. Chang, S.-Y. Xu, A. Bansil et al., Discovery of topological Weyl fermion lines and drumhead surface states in a room temperature magnet, Science 365, 1278 (2019).
  18. G. Chang, B. Singh, S.-Y. Xu, G. Bian, S.-M. Huang, C.-H. Hsu, I. Belopolski, N. Alidoust, D. S. Sanchez, H. Zheng, H. Lu, X. Zhang, Y. Bian, T.-R. Chang, H.-T. Jeng, A. Bansil, H. Hsu, S. Jia, T. Neupert, H. Lin et al., Magnetic and noncentrosymmetric Weyl fermion semimetals in the RAlGe family of compounds (R=rareearth), Phys. Rev. B 97, 041104 (2018).
  19. H. Hodovanets, C. J. Eckberg, P. Y. Zavalij, H. Kim, W.-C. Lin, M. Zic, D. J. Campbell, J. S. Higgins, and J. Paglione, Single-crystal investigation of the proposed type-II Weyl semimetal CeAlGe, Phys. Rev. B 98, 245132 (2018).
  20. E. Cheng, L. Yan, X. Shi et al., Tunable positions of Weyl nodes via magnetism and pressure in the ferromagnetic Weyl semimetal CeAlSi, Nat. Commun. 15, 1467 (2024).
  21. O. K. Forslund, X. Liu, S. Shin, C. Lin, M. Horio, Q. Wang, K. Kramer, S. Mukherjee, T. Kim, C. Cacho, C. Wang, T. Shang, V. Ukleev, J. S. White, P. Puphal, Y. Sassa, E. Pomjakushina, T. Neupert, and J. Chang, Anomalous Hall effect due to magnetic fluctuations in a ferromagnetic Weyl semimetal, Phys. Rev. Lett. 134, 126602 (2025).
  22. D. Destraz, L. Das, S. S. Tsirkin, Y. Xu, T. Neupert, J. Chang, A. Schilling, A. G. Grushin, J. Kohlbrecher, L. Keller, P. Puphal, E. Pomjakushina, and J. S. White, Magnetism and anomalous transport in the Weyl semimetal PrAlGe possible route to axial gauge fields, npj Quantum Mater. 5, 5 (2020).
  23. V. Pomjakushin, I. Plokhikh, J. S. White, Y. Fujishiro, N. Kanazawa, Y. Tokura, and E. Pomjakushina, Topological magnetic structures in MnGe: Neutron diffraction and symmetry analysis, Phys. Rev. B 107, 024410 (2023).
  24. A. van Oosterom and J. Strackee, The solid angle of a plane triangle, IEEE Trans. Biomed. Eng. 30, 125 (1983).
  25. A. Podlesnyak, V. Pomjakushin, E. Pomjakushina, and J. White, https://doi.org/10.14461/oncat.data/2568841
