Coupling quantum spin ice to matter on the centered pyrochlore lattice

Rajah P. Nutakki1,2,3,4,5,6, Sylvain Capponi7, Ludovic D. C. Jaubert8, and Lode Pollet5,6

PDF

Phys. Rev. B 112, 144437 – Published 23 October, 2025

DOI: https://doi.org/10.1103/xrmm-vr6m

Abstract

The low-energy physics of quantum spin ice is known to support an emergent form of quantum electrodynamics (QED), where magnetic monopoles exist and the fine-structure constant is material dependent. In this article, we show how this QED is modified via a coupling to dynamical matter on the centered pyrochlore lattice, a structure that has recently been synthesized using metal-organic frameworks. Specifically, we study the low-energy properties of the S=1/2 quantum XXZ model on the centered pyrochlore lattice, with a focus on the sign-problem-free region. At fourth order in degenerate perturbation theory, this model hosts a quantum spin liquid distinct from the well-known U(1) quantum spin ice on the pyrochlore because of the presence of dynamical matter in the ground state. Exact diagonalization results are consistent with this quantum spin liquid over an extended region of the ground-state phase diagram, although potential quantum critical points within this region could indicate a richer phase structure. Our work thus expands the physics of quantum spin ice in an experimentally motivated geometry, showing how the emergent QED can be coupled to dynamical matter at zero temperature.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (42)

  1. M. J. Harris, S. T. Bramwell, D. F. McMorrow, T. Zeiske, and K. W. Godfrey, Geometrical frustration in the ferromagnetic pyrochlore Ho2Ti2O7, Phys. Rev. Lett. 79, 2554 (1997).
  2. Spin Ice, edited by M. Udagawa and L. Jaubert, Springer Series in Solid-State Sciences Vol. 197 (Springer International Publishing, Cham, 2021).
  3. C. Castelnovo, R. Moessner, and S. L. Sondhi, Magnetic monopoles in spin ice, Nature (London) 451, 42 (2008).
  4. M. Hermele, M. P. A. Fisher, and L. Balents, Pyrochlore photons: The U(1) spin liquid in a S = 1/2 three-dimensional frustrated magnet, Phys. Rev. B 69, 064404 (2004).
  5. A. Banerjee, S. V. Isakov, K. Damle, and Y. B. Kim, Unusual liquid state of hard-core bosons on the pyrochlore lattice, Phys. Rev. Lett. 100, 047208 (2008).
  6. O. Benton, O. Sikora, and N. Shannon, Seeing the light: Experimental signatures of emergent electromagnetism in a quantum spin ice, Phys. Rev. B 86, 075154 (2012).
  7. S. D. Pace, S. C. Morampudi, R. Moessner, and C. R. Laumann, Emergent fine structure constant of quantum spin ice is large, Phys. Rev. Lett. 127, 117205 (2021).
  8. R. Sibille, N. Gauthier, H. Yan, M. Ciomaga Hatnean, J. Ollivier, B. Winn, U. Filges, G. Balakrishnan, M. Kenzelmann, N. Shannon, and T. Fennell, Experimental signatures of emergent quantum electrodynamics in Pr2Hf2O7, Nat. Phys. 14, 711 (2018).
  9. R. Sibille, N. Gauthier, E. Lhotel, V. Porée, V. Pomjakushin, R. A. Ewings, T. G. Perring, J. Ollivier, A. Wildes, C. Ritter et al., A quantum liquid of magnetic octupoles on the pyrochlore lattice, Nat. Phys. 16, 546 (2020).
  10. V. Porée, H. Yan, F. Desrochers, S. Petit, E. Lhotel, M. Appel, J. Ollivier, Y. B. Kim, A. H. Nevidomskyy, and R. Sibille, Evidence for fractional matter coupled to an emergent gauge field in a quantum spin ice, Nat. Phys. 21, 83 (2025).
  11. E. M. Smith, O. Benton, D. R. Yahne, B. Placke, R. Schäfer, J. Gaudet, J. Dudemaine, A. Fitterman, J. Beare, A. R. Wildes, S. Bhattacharya, T. DeLazzer, C. R. C. Buhariwalla, N. P. Butch, R. Movshovich, J. D. Garrett, C. A. Marjerrison, J. P. Clancy, E. Kermarrec, G. M. Luke et al., Case for a U(1)π quantum spin liquid ground state in the dipole-octupole pyrochlore Ce2Zr2O7, Phys. Rev. X 12, 021015 (2022).
  12. Where (ta) stands for the 1,2,3-triazolate ligand.
  13. F. Gándara, F. J. Uribe-Romo, D. K. Britt, H. Furukawa, L. Lei, R. Cheng, X. Duan, M. O'Keeffe, and O. M. Yaghi, Porous, conductive metal-triazolates and their structural elucidation by the charge-flipping method, Chem. Eur. J. 18, 10595 (2012).
  14. R. P. Nutakki, R. Röß-Ohlenroth, D. Volkmer, A. Jesche, H.-A. K. von Nidda, A. A. Tsirlin, P. Gegenwart, L. Pollet, and L. D. C. Jaubert, Frustration on a centered pyrochlore lattice in metal-organic frameworks, Phys. Rev. Res. 5, L022018 (2023).
  15. R. P. Nutakki, L. D. C. Jaubert, and L. Pollet, The classical Heisenberg model on the centered pyrochlore lattice, SciPost Phys. 15, 040 (2023).
  16. N. Shannon, O. Sikora, F. Pollmann, K. Penc, and P. Fulde, Quantum ice: A quantum Monte Carlo study, Phys. Rev. Lett. 108, 067204 (2012).
  17. C.-J. Huang, Y. Deng, Y. Wan, and Z. Y. Meng, Dynamics of topological excitations in a model quantum spin ice, Phys. Rev. Lett. 120, 167202 (2018).
  18. M. J. P. Gingras and P. A. McClarty, Quantum spin ice: A search for gapless quantum spin liquids in pyrochlore magnets, Rep. Prog. Phys. 77, 056501 (2014).
  19. Y.-P. Huang, G. Chen, and M. Hermele, Quantum spin ices and topological phases from dipolar-octupolar doublets on the pyrochlore lattice, Phys. Rev. Lett. 112, 167203 (2014).
  20. S. H. Curnoe, Quantum spin configurations in Tb2Ti2O7, Phys. Rev. B 75, 212404 (2007).
  21. S. H. Curnoe, Structural distortion and the spin liquid state in Tb2Ti2O7, Phys. Rev. B 78, 094418 (2008).
  22. N. Davier, L. Pollet, and L. D. C. Jaubert (unpublished).
  23.  A J1 anisotropy could, however, appear spontaneously below a transition temperature selecting a preferred axis for the center spins.
  24. D. Slobinsky, G. Baglietto, and R. A. Borzi, Charge and spin correlations in the monopole liquid, Phys. Rev. B 97, 174422 (2018).
  25. A. Szabó, S. A. Grigera, P. C. W. Holdsworth, L. D. C. Jaubert, R. Moessner, D. G. Slobinsky, M. Sturla, and, R. A. Borzi, Hidden order and Z 2 confinement transition in a fully packed monopole liquid, Phys. Rev. B 112, 014452 (2025).
  26. D. L. Bergman, R. Shindou, G. A. Fiete, and L. Balents, Quantum effects in a half-polarized pyrochlore antiferromagnet, Phys. Rev. Lett. 96, 097207 (2006).
  27. D. L. Bergman, G. A. Fiete, and L. Balents, Ordering in a frustrated pyrochlore antiferromagnet proximate to a spin liquid, Phys. Rev. B 73, 134402 (2006).
  28. O. Sikora, F. Pollmann, N. Shannon, K. Penc, and P. Fulde, Quantum liquid with deconfined fractional excitations in three dimensions, Phys. Rev. Lett. 103, 247001 (2009).
  29. O. Sikora, N. Shannon, F. Pollmann, K. Penc, and P. Fulde, Extended quantum U(1)-liquid phase in a three-dimensional quantum dimer model, Phys. Rev. B 84, 115129 (2011).
  30. J. R. Schrieffer and P. A. Wolff, Relation between the anderson and Kondo Hamiltonians, Phys. Rev. 149, 491 (1966).
  31. S. Bravyi, D. P. DiVincenzo, and D. Loss, Schrieffer–Wolff transformation for quantum many-body systems, Ann. Phys. 326, 2793 (2011).
  32. K. Slagle and Y. B. Kim, Fracton topological order from nearest-neighbor two-spin interactions and dualities, Phys. Rev. B 96, 165106 (2017).
  33. A. Sanders and C. Castelnovo, Vison crystal in quantum spin ice on the breathing pyrochlore lattice, Phys. Rev. B 109, 094426 (2024).
  34. L. Savary and L. Balents, Quantum spin liquids, Rep. Prog. Phys. 80, 016502 (2017).
  35. J. Kogut and L. Susskind, Hamiltonian formulation of Wilson's lattice gauge theories, Phys. Rev. D 11, 395 (1975).
  36. X. Y. Xu, Y. Qi, L. Zhang, F. F. Assaad, C. Xu, and Z. Y. Meng, Monte Carlo study of lattice compact quantum electrodynamics with fermionic matter: The parent state of quantum phases, Phys. Rev. X 9, 021022 (2019).
  37. C. Hickey, C. Berke, P. P. Stavropoulos, H.-Y. Kee, and S. Trebst, Field-driven gapless spin liquid in the spin-1 Kitaev honeycomb model, Phys. Rev. Res. 2, 023361 (2020).
  38. S. Sachdev, Quantum Phase Transitions, 2nd ed. (Cambridge University Press, Cambridge, 2011).
  39. R. Pohle and L. D. C. Jaubert, Curie-law crossover in spin liquids, Phys. Rev. B 108, 024411 (2023).
  40. M. E. Brooks-Bartlett, S. T. Banks, L. D. C. Jaubert, A. Harman-Clarke, and P. C. W. Holdsworth, Magnetic-moment fragmentation and monopole crystallization, Phys. Rev. X 4, 011007 (2014).
  41. D. S. Rokhsar and S. A. Kivelson, Superconductivity and the quantum hard-core dimer gas, Phys. Rev. Lett. 61, 2376 (1988).
  42. R. P. Nutakki, S. Capponi, L. Jaubert, and L. Pollet, Data for “Coupling quantum spin ice to matter on the centered pyrochlore lattice”, 10.5281/zenodo.17244452 (2025).
