Low-energy model for doped graphene nanoribbons

J. Ferrer1,2,3, A. García-Fuente1,2, Y. Yang3, S. Volosheniuk3, and H. S. J. van der Zant3

PDF

Phys. Rev. B 114, 115115 – Published 17 August, 2026

DOI: https://doi.org/10.1103/wlvl-gxxf

Abstract

In this article we analyze the many-body behavior of freestanding doped graphene nanoribbons where the chemical potential lies inside the bulk single-particle bands. We perform an exact mapping from both an extended and an on-site Hubbard model of the ribbons to a Kanamori model, which includes ferromagnetic exchange and pair-hopping interactions. We determine the resulting Coulomb matrix elements analytically, and identify their scaling behavior as a function of ribbon width and length. We propose a low-energy version of the Kanamori Hamiltonian to address the response of the ribbons to external fields, with a view to their use as transport channels in nanoelectronics. We find that the model and the proposed ribbon parameters can produce open-shell, high-spin, many-body states that can lead to shell- and spin-blockade responses.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (27)

  1. A. K. Geim, Graphene: Status and prospects, Science 324, 1530 (2009).
  2. R. M. Westervelt, Graphene nanoelectronics, Science 320, 324 (2008).
  3. J. Cai, P. Ruffieux, R. Jaafar, M. Bieri, T. Braun, S. Blankenburg, M. Muoth, A. P. Seitsonen, M. Saleh, X. Feng, K. Mullen, and R. Fasel, Atomically precise bottom-up fabrication of graphene nanoribbons, Nature (London) 466, 470 (2010).
  4. J. Lawrence, A. Berdonces-Layunta, S. Edalatmanesh, J. Castro-Esteban, T. Wang, A. Jimenez-Martin, B. de la Torre, R. Castrillo-Bodero, P. Angulo-Portugal, M. Mohammed, A. Matej, M. Vilas-Varela, F. Schiller, M. Corso, P. Jelinek, D. Peña, and D. G. de Oteyza, Circumventing the stability problems of graphene nanoribbon zigzag edges, Nat. Chem. 14, 1451 (2022).
  5. J. Zhang, L. Qian, G. B. Barin, A. Daaoub, P. Chen, K. Mullen, S. Sangtarash, P. Ruffieux, R. Fasel, H. Sadeghi, J. Zhang, M. Calame, and M. L. Perrin, Contacting individual graphene nanoribbons using carbon nanotube electrodes, Nat. Electron. 6, 572 (2023).
  6. J. Zhang, G. B. Barin, R. Furrer, C.-Z. Du, X.-Y. Wang, K. Mullen, P. Ruffieux, R. Fasel, M. Calame, and M. L. Perrin, Determining the number of graphene nanoribbons in dual-gate field-effect transistors, Nano Lett. 23, 8474 (2023).
  7. W. Niu, S. Sopp, A. Lodi, A. Gee, F. Kong, T. Pei, P. Gehring, J. Nagele, C.-S. Lau, J. Ma, J. Liu, A. Narita, J. Mol, M. Burghard, K. Mullen, Y. Mai, X. Feng, and L. Bogani, Exceptionally clean single-electron transistors from solutions of molecular graphene nanoribbons, Nat. Mater. 22, 180 (2023).
  8. E. A. Laird, F. Kuemmeth, G. A. Steele, K. Grove-Rasmussen, J. Nygård, K. Flensberg, and L. P. Kouwenhoven, Quantum transport in carbon nanotubes, Rev. Mod. Phys. 87, 703 (2015).
  9. S. Konschuh, M. Gmitra, and J. Fabian, Tight-binding theory of the spin-orbit coupling in graphene, Phys. Rev. B 82, 245412 (2010).
  10. K. Zollner, M. Kurpas, M. Gmitra, and J. Fabian, First-principles determination of spin–orbit coupling parameters in two-dimensional materials, Nat. Rev. Phys. 7, 255 (2025).
  11. A. García-Fuente, D. Carrascal, G. Ross, and J. Ferrer, Full analytical solution of finite-length armchair/zigzag nanoribbons, Phys. Rev. B 107, 115403 (2023).
  12. A. Talkachov and E. Babaev, Wave functions and edge states in rectangular honeycomb lattices revisited: Nanoflakes, armchair and zigzag nanoribbons, and nanotubes, Phys. Rev. B 107, 045419 (2023).
  13. J. Ferrer and A. Garcia-Fuente, Solution of the mean-field Hubbard model of graphene rectangulenes, Phys. Rev. B 112, 165101 (2025).
  14. J. Fernandez-Rossier, Prediction of hidden multiferroic order in graphene zigzag ribbons, Phys. Rev. B 77, 075430 (2008).
  15. J. Jung and A. H. MacDonald, Carrier density and magnetism in graphene zigzag nanoribbons, Phys. Rev. B 79, 235433 (2009).
  16. T. O. Wehling, E. Şaşioğlu, C. Friedrich, A. I. Lichtenstein, M. I. Katsnelson, and S. Blügel, Strength of effective Coulomb interactions in graphene and graphite, Phys. Rev. Lett. 106, 236805 (2011).
  17. M. Schüler, M. Rösner, T. O. Wehling, A. I. Lichtenstein, and M. I. Katsnelson, Optimal Hubbard models for materials with nonlocal Coulomb interactions: Graphene, silicene, and benzene, Phys. Rev. Lett. 111, 036601 (2013).
  18. M. Rösner, E. Şaşioğlu, C. Friedrich, S. Blügel, and T. O. Wehling, Wannier function approach to realistic Coulomb interactions in layered materials and heterostructures, Phys. Rev. B 92, 085102 (2015).
  19. J. Kanamori, Electron correlation and ferromagnetism of transition metals, Prog. Theor. Phys. 30, 275 (1963).
  20. J. Zhang, B. Ghawri, D. Dutta, R. Fasel, M. Calame, G. B. Barin, and M. L. Perrin, Bottom–up-synthesized graphene nanoribbons for nanoelectronics, Nat. Rev. Mater. 11, 194 (2026).
  21. E. Lieb and D. Mattis, Theory of ferromagnetism and the ordering of electronic energy levels, Phys. Rev. 125, 164 (1962).
  22. H. Tasaki, The Hubbard model - an introduction and selected rigorous results, J. Phys.: Condens. Matter 10, 4353 (1998).
  23. P. Pieri, S. Daul, D. Baeriswyl, M. Dzierzawa, and P. Fazekas, Low-density ferromagnetism in the Hubbard model, Phys. Rev. B 54, 9250 (1996).
  24. I. S. Burmistrov, Y. Gefen, D. S. Shapiro, and A. Shnirman, Mesoscopic Stoner instability in open quantum dots: Suppression of Coleman-Weinberg mechanism by electron tunneling, Phys. Rev. Lett. 124, 196801 (2020).
  25. D. J. Carrascal and J. Ferrer, Exact Kohn-Sham eigenstates versus quasiparticles in simple models of strongly correlated electrons, Phys. Rev. B 85, 045110 (2012).
  26. D. J. Carrascal, J. Ferrer, J. C. Smith, and K. Burke, The Hubbard dimer: A density functional case study of a many-body problem, J. Phys.: Condens. Matter 27, 393001 (2015).
  27. I. L. Kurland, I. L. Aleiner, and B. L. Altshuler, Mesoscopic magnetization fluctuations for metallic grains close to the Stoner instability, Phys. Rev. B 62, 14886 (2000).
