High-pressure formation and characterization of a boron carbide polymorph featuring bent C–B–C chains

Akun Liang1,2,*, Umbertoluca Ranieri1, James Spender1, Charles Lamb1, Sarah Bolton1, Bernhard Massani1, Ryan Stewart McWilliams1, Timofey Fedotenko3, Konstantin Glazyrin3 et al.

Nico Giordano3, Jonathan Wright4, Florian Trybel5, and Dominique Laniel1,†

  • *Contact author: akliang@eitech.edu.cn
  • †Contact author: Dominique.Laniel@ed.ac.uk
PDF

Phys. Rev. B 113, 104108 – Published 20 March, 2026

DOI: https://doi.org/10.1103/v5kf-svcz

Abstract

Boron carbide is a material of choice for multiple industries, e.g., aerospace, as a lightweight structural ceramic due to its high hardness, high melting temperature, and low density. However, its mechanical properties have been observed to radically degrade under shockwave compression, presumably as a consequence of stress-induced phase transitions resulting in its partial amorphization. So far, the physical mechanism underpinning this behavior remains unclear. Here, we report a pressure-induced phase transition in boron carbide occurring between 78 and 90 GPa during static compression in diamond anvil cells, both at room temperature and after quenching from high temperatures. The crystal structure of the new phase was solved and refined via synchrotron single-crystal x-ray diffraction measurements and further investigated by Raman spectroscopy as well as density functional theory calculations. The discovered high-pressure polymorph, mC60−B13C2, has strong resemblance with the known ambient conditions phase, hR45−B13C2, with the important distinction that the linear C–B–C chain linking B12 icosahedra in hR45−B13C2 is bent in mC60−B13C2. Such bending of the C–B–C chain has been hypothesized as key to explain boron carbide's drop in strength, phase transitions, and amorphization. The observed reversibility of the phase transition, as well as the formation of covalent bonds between B12 icosahedra and the bent C–B–C chains, are assessed to decipher the C–B–C chain's bending importance on the amorphization and mechanical properties of boron carbide.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (61)

  1. F. Igoa Saldaña, T. Gaudisson, S. Le Floch, B. Baptiste, L. Delbes, V. Malarewicz, O. Beyssac, K. Béneut, C. Coelho Diogo, C. Gervais, et al., Transforming nanocrystals into superhard boron carbide nanostructures, ACS Nano 18, 30473 (2024).
  2. A. Jay, O. Hardouin Duparc, J. Sjakste, and N. Vast, Theoretical Raman spectrum of boron carbide B4.3C under pressure, Acta Mater. 255, 119085 (2023).
  3. A. Jay, O. Hardouin Duparc, J. Sjakste, and N. Vast, Theoretical phase diagram of boron carbide from ambient to high pressure and temperature, J. Appl. Phys. 125, 185902 (2019).
  4. K. Rasim, R. Ramlau, A. Leithe-Jasper, T. Mori, U. Burkhardt, H. Borrmann, W. Schnelle, C. Carbogno, M. Scheffler, and Y. Grin, Local atomic arrangements and band structure of boron carbide, Angew. Chem. 130, 6238 (2018).
  5. H. K. Clark and J. L. Hoard, The crystal structure of boron carbide, J. Am. Chem. Soc. 65, 2115 (1943).
  6. A. Courac, V. Turkevich, and Y. Le Godec, Thermodynamics and crystallography of hard light-element boron-rich compounds by in situ x-ray diffraction under high-pressure, high-temperature conditions, Solid State Sci. 163, 107909 (2025).
  7. A. Courac, Y. Le Godec, J. Sjakste, N. Vast, O. Rapaud, and V. Turkevich, High-pressure, high-temperature phase equilibria with superhard boron-rich compounds of B–C–N–O and B–C–Si systems by in situ x-ray diffraction and CALPHAD methodology, ACS Appl. Mater. Interfaces 17, 53013 (2025).
  8. J. D. Coe, C.-F. Chen, C. W. Greeff, D. M. Dattelbaum, J. T. Gammel, B. L. Musicó, C. A. McCoy, P. Kalita, and B. A. Branch, Equation of state of boron carbide B4C, Phys. Rev. B 112, 094106 (2025).
  9. V. Domnich, Y. Gogotsi, M. Trenary, and T. Tanaka, Nanoindentation and Raman spectroscopy studies of boron carbide single crystals, Appl. Phys. Lett. 81, 3783 (2002).
  10. T. Francois, Boron carbide—a comprehensive review, J. Eur. Ceram. Soc. 6, 205 (1990).
  11. D. E. Grady, Hugoniot equation of state and dynamic strength of boron carbide, J. Appl. Phys. 117, 165904 (2015).
  12. Y. Zhang, T. Mashimi, T. Uemura, M. Uchino, M. Kodama, K. Shibata, K. Fukuoka, M. Kikuchi, T. Kobayashi, and T. Sekine, Shock compression behaviors of boron carbide (B4C), J. Appl. Phys. 100, 113536 (2006).
  13. S. Song, W. Xu, R. Cao, L. Luo, M. H. Engelhard, M. E. Bowden, B. Liu, L. Estevez, C.-M. Wang, and J.-G. Zhang, B4C as a stable non-carbon-based oxygen electrode material for lithium-oxygen batteries, Nano Energy 33, 195 (2017).
  14. T. J. Vogler, W. D. Reinhart, and L. C. Chhabildas, Dynamic behavior of boron carbide, J. Appl. Phys. 95, 4173 (2004).
  15. D.E. Grady, Shock-wave strength properties of boron carbide and silicon carbide, J. Phys. IV France 04, C8-385 (1994).
  16. W. H. Gust and E. B. Royce, Dynamic yield strengths of B4C, BeO, and Al2O3 ceramics, J. Appl. Phys. 42, 276 (1971).
  17. A. Chakraborti, A. Jay, O. Hardouin Duparc, J. Sjakste, K. Béneut, N. Vast, and Y. Le Godec, Boron carbide under torsional deformation: Evidence of the formation of chain vacancies in the plastic regime, Acta Mater. 226, 117553 (2022).
  18. R. Raucoules, N. Vast, E. Betranhandy, and J. Sjakste, Mechanical properties of icosahedral boron carbide explained from first principles, Phys. Rev. B 84, 014112 (2011).
  19. S. Aryal, P. Rulis, and W. Y. Ching, Mechanism for amorphization of boron carbide B4C under uniaxial compression, Phys. Rev. B 84, 184112 (2011).
  20. X. Q. Yan, Z. Tang, L. Zhang, J. J. Guo, C. Q. Jin, Y. Zhang, T. Goto, J. W. McCauley, and M. W. Chen, Depressurization amorphization of single-crystal boron carbide, Phys. Rev. Lett. 102, 075505 (2009).
  21. M. Chen, J. W. Mccauley, and K. J. Hemker, Shock-induced localized amorphization in boron carbide, Science 299, 1563 (2003).
  22. P. Korotaev, P. Pokatashkin, and A. Yanilkin, Structural phase transitions in boron carbide under stress, Model. Simul. Mat. Sci. Eng. 24, 015004 (2016).
  23. P. Korotaev, P. Pokatashkin, and A. Yanilkin, The role of non-hydrostatic stresses in phase transitions in boron carbide, Comput. Mater. Sci. 121, 106 (2016).
  24. D. E. Taylor, Shock compression of boron carbide: A quantum mechanical analysis, J. Am. Ceram. Soc. 98, 3308 (2015).
  25. Q. An, W. A. Goddard, III, and T. Cheng, Atomistic explanation of shear-induced amorphous band formation in boron carbide, Phys. Rev. Lett. 113, 095501 (2014).
  26. I. Chuvashova, B. Gasharova, Y. L. Mathis, L. Dubrovinsky, and N. Dubrovinskaia, Structural stability of boron carbide under pressure proven by spectroscopic studies up to 73 GPa, Z. Anorg. Allg. Chem. 643, 1357 (2017).
  27. I. Chuvashova, E. Bykova, M. Bykov, V. Svitlyk, L. Dubrovinsky, and N. Dubrovinskaia, Structural stability and mechanism of compression of stoichiometric B13C2 up to 68 GPa, Sci. Rep. 7, 8969 (2017).
  28. A. Hushur, M. H. Manghnani, H. Werheit, P. Dera, and Q. Williams, High-pressure phase transition makes B4.3C boron carbide a wide-gap semiconductor, J. Phys. Condens. Matter 28, 045403 (2016).
  29. T. Fujii, Y. Mori, H. Hyodo, and K. Kimura, X-ray diffraction study of B4C under high pressure, J. Phys. Conf. Ser. 215, 012011 (2010).
  30. H. Werheit, M. H. Manghnani, U. Kuhlmann, A. Hushur, and S. Shalamberidze, Mode Grüneisen parameters of boron carbide, Solid State Sci. 72, 80 (2017).
  31. P. Dera, M. H. Manghnani, A. Hushur, Y. Hu, and S. Tkachev, New insights into the enigma of boron carbide inverse molecular behavior, J. Solid State Chem. 215, 85 (2014).
  32. R. Sereika, S. Iwan, P. A. Baker, and Y. K. Vohra, High pressure Raman spectroscopy of boron-rich boron carbides up to 50 GPa, High. Press. Res. 45, 79 (2025).
  33. See Supplemental Material at http://link.aps.org/supplemental/10.1103/v5kf-svcz for detailed experimental and computational methods, discussion of the structure and stoichiometry determination, Raman spectra analysis, partial disorder of the C–B–C chain in the mC60-B13C2 phase, and the complete set of supplementary tables and figures.
  34. The phonon band structures to be visualized on the website, https://henriquemiranda.github.io/phononwebsite/phonon.html (2025).
  35. D. Laniel, F. Trybel, A. Aslandukov, J. Spender, U. Ranieri, T. Fedotenko, K. Glazyrin, E. L. Bright, S. Chariton, V. B. Prakapenka, et al., Structure determination of zeta-N2 from single-crystal x-ray diffraction and theoretical suggestion for the formation of amorphous nitrogen, Nat. Commun. 14, 6207 (2023).
  36. P. Giannozzi, O. Baseggio, P. Bonfa, D. Brunato, R. Car, I. Carnimeo, C. Cavazzoni, S. de Gironcoli, P. Delugas, F. Ferrari Ruffino, et al., Quantum ESPRESSO toward the exascale, J. Chem. Phys. 152, 154105 (2020).
  37. Single crystal diffraction software CrysAlisPro, Rigaku Journal, 32, 31 (2016).
  38. X. Yang, W. A. Goddard, and Q. An, Structure and properties of boron-very-rich boron carbides: B12 icosahedra linked through bent CBB chains, J. Phys. Chem. C 122, 2448 (2018).
  39. P. Giannozzi, O. Andreussi, T. Brumme, O. Bunau, M. Buongiorno Nardelli, M. Calandra, R. Car, C. Cavazzoni, D. Ceresoli, M. Cococcioni, et al., Advanced capabilities for materials modelling with Quantum ESPRESSO, J. Phys. Condens. Matter 29, 465901 (2017).
  40. J. M. Skelton, L. A. Burton, S. C. Parker, A. Walsh, C.-E. Kim, A. Soon, J. Buckeridge, A. A. Sokol, C. R. A. Catlow, A. Togo, et al., Anharmonicity in the high-temperature Cmcm phase of SnSe: Soft modes and three-phonon interactions, Phys. Rev. Lett. 117, 075502 (2016).
  41. A. Togo and I. Tanaka, First principles phonon calculations in materials science, Acta Mater. 108, 1 (2015).
  42. G. M. Sheldrick, SHELXT-Integrated space-group and crystal-structure determination, Acta Crystallogr. 71, 3 (2015).
  43. K. Shirai, K. Sakuma, and N. Uemura, Theoretical study of the structure of boron carbide B13C2, Phys. Rev. B 90, 064109 (2014).
  44. H. Werheit and U. Kuhlmann, Superconductivity in boron carbide? Clarification by low-temperature MIR/FIR spectra, J. Phys. Condens. Matter 23, 435501 (2011).
  45. K. Momma and F. Izumi, VESTA 3 for three-dimensional visualization of crystal, volumetric and morphology data, J. Appl. Crystallogr. 44, 1272 (2011).
  46. V. Domnich, S. Reynaud, R. A. Haber, and M. Chhowalla, Boron carbide: Structure, properties, and stability under stress, J. Am. Ceram. Soc. 94, 3605 (2011).
  47. J. Guo, L. Zhang, T. Fujita, T. Goto, and M. Chen, Pressure-induced depolarization and resonance in Raman scattering of single-crystalline boron carbide, Phys. Rev. B 81, 060102(R) (2010).
  48. S. Grimme, J. Antony, S. Ehrlich, and H. Krieg, A consistent and accurate ab initio parametrization of density functional dispersion correction (DFT-D) for the 94 elements H-Pu, J. Chem. Phys. 132, 154104 (2010).
  49. P. Giannozzi, S. Baroni, N. Bonini, M. Calandra, R. Car, C. Cavazzoni, D. Ceresoli, G. L. Chiarotti, M. Cococcioni, I. Dabo, et al., QUANTUM ESPRESSO: A modular and open-source software project for quantum simulations of materials, J. Phys. Condens. Matter 21, 395502 (2009).
  50. O. V. Dolomanov, L. J. Bourhis, R. J. Gildea, J. A. K. Howard, and H. Puschmann, OLEX2: A complete structure solution, refinement and analysis program, J. Appl. Crystallogr. 42, 339 (2009).
  51. A. Dewaele, P. Loubeyre, and M. Mezouar, Equations of state of six metals above 94 GPa, Phys. Rev. B 70, 094112 (2004).
  52. M. Calandra, N. Vast, and F. Mauri, Superconductivity from doping boron icosahedra, Phys. Rev. B 69, 224505 (2004).
  53. J. P. Perdew, K. Burke, and M. Ernzerhof, Generalized gradient approximation made simple, Phys. Rev. Lett. 77, 3865 (1996).
  54. P. E. Blöchl, Projector augmented-wave method, Phys. Rev. B 50, 17953 (1994).
  55. T. L. Aselage and R. G. Tissot, Lattice constants of boron carbides, J. Am. Chem. Soc. 75, 2207 (1992).
  56. S. Mondal, E. Bykova, S. Dey, S. I. Ali, N. Dubrovinskaia, L. Dubrovinsky, G. Parakhonskiy, and S. van Smaalen, Disorder and defects are not intrinsic to boron carbide, Sci. Rep. 6, 19330 (2016).
  57. I. Chuvashova, E. Bykova, M. Bykov, V. Svitlyk, B. Gasharova, Y.-L. Mathis, R. Caracas, L. Dubrovinsky, and N. Dubrovinskaia, High-pressure behavior of α-boron studied on single crystals by x-ray diffraction, Raman and IR spectroscopy, J. Solid State Chem. 245, 50 (2017).
  58. A. Savin, R. Nesper, S. Wengert, and T. F. Fässler, ELF: The electron localization function, Angew. Chem. Int. Ed. 36, 1808 (1997).
  59. F. D. Murnaghan, The compressibility of media under extreme pressures, Proc. Natl. Acad. Sci. USA 30, 244 (1944).
  60. F. Birch, Finite elastic strain of cubic crystals, Phys. Rev. 71, 809 (1947).
  61. The phonon dispersion files can be found at https://doi.org/10.6084/m9.figshare.30207958; https://doi.org/10.6084/m9.figshare.30208117.
