Electronic temperature driven phase stability and structural evolution of iron at high pressure

S. Azadi1,2,* and S. M. Vinko2,3

  • *Contact author: sam.azadi@physics.ox.ac.uk
PDF

Phys. Rev. B 112, 134103 – Published 23 October, 2025

DOI: https://doi.org/10.1103/tm8g-1ld1

Abstract

We present Gibbs free-energy phase diagrams for compressed iron within a pressure range of 20–300 GPa and electronic temperature up to 3 eV, obtained using finite-temperature density functional and density functional perturbation theories. Our results for bcc, fcc, and hcp phases predict solid-solid phase transitions in iron driven purely by electronic entropy and temperature. We found a phase transition from hcp to bcc at pressures above 200 GPa, which depends on the electronic temperature. An experimental observation of the stability of the bcc phase above 200 GPa has recently been reported (Z. Konopkova et al., arXiv:2505.15397).

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (38)

  1. W. Pepperhoff and M. Acet, Constitution and Magnetism of Iron and its Alloys (Springer, Berlin, 2001).
  2. S. Anzellini, A. Dewaele, M. Mezouar, P. Loubeyre, and G. Morard, Melting of iron at Earth's inner core boundary based on fast x-ray diffraction, Science 340, 464 (2013).
  3. A. B. Belonoshko, R. Ahuja, and B. Johansson, Stability of the body-centred-cubic phase of iron in the Earth's inner core, Nature (London) 424, 1032 (2003).
  4. L. Vočadlo, D. Alfé, M. Gillan, I. Wood, J. Brodholt, and G. D. Price, Possible thermal and chemical stabilization of body-centred-cubic iron in the Earth's core, Nature (London) 424, 536 (2003).
  5. A. Wilson, C. Davies, A. Walker, M. Pozzo, D. Alfé, and A. Deuss, The formation and evolution of the Earth's inner core, Nat. Rev. Earth Environ. 6, 140 (2025).
  6. Y. Ping, F. Coppari, D. G. Hicks, B. Yaakobi, D. E. Fratanduono, S. Hamel, J. H. Eggert, J. R. Rygg, R. F. Smith, D. C. Swift, D. G. Braun, T. R. Boehly, and G. W. Collins, Solid iron compressed up to 560 GPa, Phys. Rev. Lett. 111, 065501 (2013).
  7. L. Dubrovinsky, N. Dubrovinskaia, O. Narygina, I. Kantor, A. Kuznetzov, V. B. Prakapenka, L. Vitos, B. Johansson, A. S. Mikhaylushkin, S. I. Simak, and I. A. Abrikosov, Body-centered cubic iron-nickel alloy in Earth's core, Science 316, 1880 (2007).
  8. H. Hwang, T. Kim, H. Cynn, T. Vogt, R. J. Husband, K. Appel et al., X-ray free electron laser-induced synthesis of ε-iron nitride at high pressures, J. Phys. Chem. Lett. 12, 3246 (2021).
  9. S. Zhang, A. Panjwani, P. Xiao, M. Ghosh, T. Ogitsu, Y. Ping, and S. X. Hu, Thermally induced structural competitiveness and metastability of body-centered-cubic iron under nonequilibrium conditions, Phys. Rev. B 111, 224106 (2025).
  10. A. Dewaele, P. Loubeyre, F. Occelli, M. Mezouar, P. I. Dorogokupets, and M. Torrent, Quasihydrostatic equation of state of iron above 2 Mbar, Phys. Rev. Lett. 97, 215504 (2006).
  11. S. Merkel, A. F. Goncharov, H. k. Mao, P. Gillet, and R. J. Hemley, Raman spectroscopy of iron to 152 gigapascals: Implications for Earth's inner core, Science 288, 1626 (2000).
  12. G. Shen, H. Mao, R. J. Hemley, T. Duffy, and M. L. Rivers, Melting and crystal structure of iron at high pressures and temperatures, Geophys. Res. Lett. 25, 373 (1998).
  13. V. Alexopoulou and A. Markopoulos, A critical assessment regarding two-temperature models: An investigation of the different forms of two-temperature models, the various ultrashort pulsed laser models and computational methods, Arch. Comput. Methods Eng. 31, 93 (2024).
  14. C. Siders, Detection of nonthermal melting by ultrafast x-ray diffraction, Science 286, 1340 (1999).
  15. S. Sundaram and E. Mazur, Inducing and probing non-thermal transitions in semiconductors using femtosecond laser pulses, Nat. Mater. 1, 217 (2002).
  16. V. Recoules, J. Clérouin, G. Zérah, P. M. Anglade, and S. Mazevet, Effect of intense laser irradiation on the lattice stability of semiconductors and metals, Phys. Rev. Lett. 96, 055503 (2006).
  17. R. Ernstorfer et al., The formation of warm dense matter: experimental evidence for electronic bond hardening in gold, Science 323, 1033 (2009).
  18. A. Rousse, C. Rischel, S. Fourmaux, I. Uschmann, S. Sebban, G. Grillon, P. Balcou, E. Foerster, J. Geindre, P. Audebert, J. Gauthier, and D. Hulin, Non-thermal melting in semiconductors measured at femtosecond resolution, Nature (London) 410, 65 (2001).
  19. K. Widmann, T. Ao, M. E. Foord, D. F. Price, A. D. Ellis, P. T. Springer, and A. Ng, Single-state measurement of electrical conductivity of warm dense gold, Phys. Rev. Lett. 92, 125002 (2004).
  20. G. Sciaini and R. J. D. Miller, Femtosecond electron diffraction: heralding the era of atomically resolved dynamics, Rep. Prog. Phys. 74, 096101 (2011).
  21. E. Collet et al., Laser-induced ferroelectric structural order in an organic charge-transfer crystal, Science 300, 612 (2003).
  22. A. Amouretti, C. Crepisson, S. Azadi, F. Brisset, D. Cabaret, T. Campbell, D. A. Chin, G. W. Collins, L. Hansen, G. Fiquet, A. Forte, T. Gawne, F. Guyot, P. Heighway, E. Heripre, E. Cunningham, H. J. Lee, D. McGonegle, B. Nagler, J. Pintor et al., Isostructural phase transition of Fe2O3 under laser shock compression, Phys. Rev. Lett. 134, 176102 (2025).
  23. C. Crepisson, A. Amouretti, M. Harmand, C. Sanloup, P. Heighway, S. Azadi, D. McGonegle, T. Campbell, J. Pintor, D. A. Chin et al., Shock-driven amorphization and melting in Fe2O3, Phys. Rev. B 111, 024209 (2025).
  24. Z. Konopkova, E. Edmund, O. B. Ball, A. Dewaele, H. Ginestet, R. J. Husband, N. Jaisle, C. Strohm, M. S. Anae, D. Antonangeli, K. Appel, M. Baron et al., Observation of body-centered cubic iron above 200 gigapascals, arXiv:2505.15397.
  25. L. Stixrude and R. Cohen, High-pressure elasticity of iron and anisotropy of Earth's inner core, Science 267, 1972 (1995).
  26. G. Steinle-Neumann, L. Stixrude, R. Cohen, and O. Gülseren, Elasticity of iron at the temperature of the Earth's inner core, Nature (London) 413, 57 (2001).
  27. L. Vočadlo, D. P. Dobso, and I. G. Wood, Ab initio calculations of the elasticity of hcp-Fe as a function of temperature at inner-core pressure, Earth Planet. Sci. Lett. 288, 534 (2009).
  28. A. B. Belonoshko, R. Ahuja, and B. Johansson, Quasi–ab initio molecular dynamic study of Fe melting, Phys. Rev. Lett. 84, 3638 (2000).
  29. N. D. Mermin, Thermal properties of the inhomogenous electron gas, Phys. Rev. 137, A1441 (1965).
  30. S. Azadi, J. S. Wark, and S. M. Vinko, Nonthermal solid-solid phase transition in ferromagnetic iron, Phys. Rev. B 110, 214434 (2024).
  31. S. Azadi, J. S. Wark, and S. M. Vinko, Lattice stability of ultrafast-heated gold, Sci. Rep. 15, 5350 (2025).
  32. P. Giannozzi et al., quantum espresso: A modular and open-source software project for quantum simulations of materials, J. Phys.: Condens. Matter 21, 395502 (2009).
  33. J. P. Perdew, K. Burke, and M. Ernzerhof, Generalized gradient approximation made simple, Phys. Rev. Lett. 77, 3865 (1996).
  34. S. Baroni, S. de Gironcoli, A. Dal Corso, and P. Giannozzi, Phonons and related crystal properties from density-functional perturbation theory, Rev. Mod. Phys. 73, 515 (2001).
  35. P. Giannozzi, O. Andreussi, T. Brumme, O. Bunau, M. B. Nardelli, M. Calandra, R. Car, C. Cavazzoni, D. Ceresoli, M. Cococcioni et al., Advanced capabilities for materials modelling with quantum espresso, J. Phys.: Condens. Matter 29, 465901 (2017).
  36. H. K. Mao, Y. Wu, L. C. Chen, J. F. Shu, and A. P. Jephcoat, Static compression of iron to 300 GPa and Fe0.8Ni0.2 alloy to 260 GPa: Implications for composition of the core, J. Geophys. Res. 95, 21737 (1990).
  37. G. Kang, G. Lee, S. Azadi, R. Carley, L. L. Guyader, L. P. Hoang, H. B. Kim, M. Kim, C. Lee, L. Mercadier, G. Mercurio, S. Parchenko, A. Seong, D. Shin, M. Teichmann, B. E. V. Kuiken, Z. Yin, S. M. Vinko, A. Scherz, and B. I. Cho, Nonequilibrium electron-phonon and electron-ion couplings in warm dense copper, Appl. Surf. Sci. 713, 164304 (2025).
  38. S. Azadi, Electronic temperature driven phase stability and structural evolution of iron at high pressure, GitHub, https://github.com/arshamsam.
