Triplet-assisted leakage during singlet-triplet qubit readout with a quantum point contact

Karol Kawa*

  • *Contact author: kawa@fzu.cz
PDF

Phys. Rev. B 114, 055302 – Published 28 July, 2026

DOI: https://doi.org/10.1103/szv1-sjgs

Abstract

Quantum point contact readout theory for singlet-triplet qubits in a lateral double quantum dot is extended by including tunneling of triplet configurations in a higher-energy level of the neighboring dot. This additional channel creates energetically allowed leakage pathways that modify the branch-dependent charge and current-noise signatures, even when the Pauli blockade remains effective within the ground-state manifold. The model contains two single-particle levels in each dot. The resulting singlet and triplet block structure is derived together with a Lindblad master equation. Quantum-jump simulations are then used to resolve the dynamics of individual readout events. A complementary Liouvillian steady-state analysis identifies the regime in which tunneling to the excited level qualitatively changes the readout signatures, with the crossover determined by the level spacing.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (37)

  1. D. Loss and D. P. DiVincenzo, Quantum computation with quantum dots, Phys. Rev. A 57, 120 (1998).
  2. J. Levy, Universal quantum computation with spin-1/2 pairs and Heisenberg exchange, Phys. Rev. Lett. 89, 147902 (2002).
  3. J. R. Petta, A. C. Johnson, J. M. Taylor, E. A. Laird, A. Yacoby, M. D. Lukin, C. M. Marcus, M. P. Hanson, and A. C. Gossard, Coherent manipulation of coupled electron spins in semiconductor quantum dots, Science 309, 2180 (2005).
  4. S. Foletti, H. Bluhm, D. Mahalu, V. Umansky, and A. Yacoby, Universal quantum control of two-electron spin quantum bits using dynamic nuclear polarization, Nat. Phys. 5, 903 (2009).
  5. G. Burkard, T. D. Ladd, A. Pan, J. M. Nichol, and J. R. Petta, Semiconductor spin qubits, Rev. Mod. Phys. 95, 025003 (2023).
  6. S. D. Liles, D. J. Halverson, Z. Wang, A. Shamim, R. S. Eggli, I. K. Jin, J. Hillier, K. Kumar, I. Vorreiter, M. J. Rendell, J. Y. Huang, C. C. Escott, F. E. Hudson, W. H. Lim, and D. Culcer, A singlet-triplet hole-spin qubit in MOS silicon, Nat. Commun. 15, 7690 (2024).
  7. P. Cerfontaine, T. Botzem, J. Ritzmann, S. S. Humpohl, A. Ludwig, D. Schuh, D. Bougeard, A. D. Wieck, and H. Bluhm, Closed-loop control of a GaAs-based singlet-triplet spin qubit with 99.5% gate fidelity and low leakage, Nat. Commun. 11, 4144 (2020).
  8. B. M. Maune, M. G. Borselli, B. Huang, T. D. Ladd, P. W. Deelman, K. S. Holabird, A. A. Kiselev, I. Alvarado-Rodriguez, R. S. Ross, A. E. Schmitz, M. Sokolich, C. A. Watson, M. F. Gyure, and A. T. Hunter, Coherent singlet-triplet oscillations in a silicon-based double quantum dot, Nature (London) 481, 344 (2012).
  9. X. Wu, D. R. Ward, J. R. Prance, D. Kim, J. K. Gamble, R. T. Mohr, Z. Shi, D. E. Savage, M. G. Lagally, M. Friesen, S. N. Coppersmith, and M. A. Eriksson, Two-axis control of a singlet–triplet qubit with an integrated micromagnet, Proc. Natl. Acad. Sci. USA 111, 11938 (2014).
  10. R. M. Jock, N. T. Jacobson, M. Rudolph, D. R. Ward, M. S. Carroll, and D. R. Luhman, A silicon singlet-triplet qubit driven by spin-valley coupling, Nat. Commun. 13, 641 (2022).
  11. M. D. Shulman, O. E. Dial, S. P. Harvey, H. Bluhm, V. Umansky, and A. Yacoby, Demonstration of entanglement of electrostatically coupled singlet-triplet qubits, Science 336, 202 (2012).
  12. X. Zhang, E. Morozova, M. Rimbach-Russ, D. Jirovec, T.-K. Hsiao, P. Cova Fariña, C.-A. Wang, S. D. Oosterhout, A. Sammak, G. Scappucci, M. Veldhorst, and L. M. K. Vandersypen, Universal control of four singlet-triplet qubits, Nat. Nanotechnol. 20, 209 (2025).
  13. K. Ono, D. G. Austing, Y. Tokura, and S. Tarucha, Current rectification by Pauli exclusion in a weakly coupled double quantum dot system, Science 297, 1313 (2002).
  14. T. Ihn, S. Gustavsson, U. Gasser, B. Küng, T. Müller, R. Schleser, M. Sigrist, I. Shorubalko, R. Leturcq, and K. Ensslin, Quantum dots investigated with charge detection techniques, Solid State Commun. 149, 1419 (2009).
  15. S. Gustavsson, R. Leturcq, B. Simovič, R. Schleser, T. Ihn, P. Studerus, K. Ensslin, D. C. Driscoll, and A. C. Gossard, Counting statistics and super-Poissonian noise in a quantum dot, Phys. Rev. B 74, 195305 (2006).
  16. H.-S. Goan, G. J. Milburn, H. M. Wiseman, and H. B. Sun, Continuous quantum measurement of two coupled quantum dots using a point contact: A quantum trajectory approach, Phys. Rev. B 63, 125326 (2001).
  17. T. M. Stace and S. D. Barrett, Continuous quantum measurement: Inelastic tunneling and lack of current oscillations, Phys. Rev. Lett. 92, 136802 (2004).
  18. T. M. Stace and S. D. Barrett, Continuous measurement of a charge qubit with a point contact detector at arbitrary bias: The role of inelastic tunnelling, arXiv:cond-mat/0309610.
  19. S.-H. Ouyang, C.-H. Lam, and J. Q. You, Backaction of a charge detector on a double quantum dot, Phys. Rev. B 81, 075301 (2010).
  20. Z.-Z. Li, C.-H. Lam, T. Yu, and J. Q. You, Detector-induced backaction on the counting statistics of a double quantum dot, Sci. Rep. 3, 3026 (2013).
  21. S. D. Barrett and T. M. Stace, Two-spin measurements in exchange interaction quantum computers, Phys. Rev. B 73, 075324 (2006).
  22. L. Marcinowski, K. Roszak, P. Machnikowski, and M. Krzyzosiak, Phonon influence on the measurement of spin states in double quantum dots using the quantum point contact, Phys. Rev. B 88, 125303 (2013).
  23. K. Roszak, L. Marcinowski, and P. Machnikowski, Decoherence-enhanced quantum measurement of a quantum-dot spin qubit, Phys. Rev. A 91, 032118 (2015).
  24. H. W. Liu, T. Fujisawa, Y. Ono, H. Inokawa, A. Fujiwara, K. Takashina, and Y. Hirayama, Pauli-spin-blockade transport through a silicon double quantum dot, Phys. Rev. B 77, 073310 (2008).
  25. J. Dalibard, Y. Castin, and K. Mølmer, Wave-function approach to dissipative processes in quantum optics, Phys. Rev. Lett. 68, 580 (1992).
  26. H. J. Carmichael, Quantum trajectory theory for cascaded open systems, Phys. Rev. Lett. 70, 2273 (1993).
  27. M. Lax, Formal theory of quantum fluctuations from a driven state, Phys. Rev. 129, 2342 (1963).
  28. H.-P. Breuer and F. Petruccione, The Theory of Open Quantum Systems (Oxford University Press, Oxford, 2002).
  29. C. W. Gardiner and P. Zoller, Quantum Noise: A Handbook of Markovian and Non-Markovian Quantum Stochastic Methods with Applications to Quantum Optics, 2nd ed. (Springer, Berlin, 2000).
  30. H. J. Carmichael, Statistical Methods in Quantum Optics 1: Master Equations and Fokker-Planck Equations (Springer, Berlin, 1999).
  31. G. W. Ford and R. F. O'Connell, There is no quantum regression theorem, Phys. Rev. Lett. 77, 798 (1996).
  32. G. Guarnieri, A. Smirne, and B. Vacchini, Quantum regression theorem and non-Markovianity of quantum dynamics, Phys. Rev. A 90, 022110 (2014).
  33. S. Khan, B. K. Agarwalla, and S. Jain, Quantum regression theorem for multi-time correlators: A detailed analysis in the Heisenberg picture, Phys. Rev. A 106, 022214 (2022).
  34. G. T. Landi, M. J. Kewming, M. T. Mitchison, and P. P. Potts, Current fluctuations in open quantum systems: Bridging the gap between quantum continuous measurements and full counting statistics, PRX Quantum 5, 020201 (2024).
  35. Y. M. Blanter and M. Büttiker, Shot noise in mesoscopic conductors, Phys. Rep. 336, 1 (2000).
  36. A. A. Clerk, M. H. Devoret, S. M. Girvin, F. Marquardt, and R. J. Schoelkopf, Introduction to quantum noise, measurement, and amplification, Rev. Mod. Phys. 82, 1155 (2010).
  37. K. Kawa, Triplet-assisted leakage during singlet-triplet qubit readout with a quantum point contact: Reproduction package, Zenodo, 2026, doi: 10.5281/zenodo.20050550.
