Graphene lattice recoil in hard x-ray photoemission: Experiment and theory

Simone Ritarossi1,2,*, Alice Apponi1,2, Orlando Castellano1,2, José Lorenzana3, Domenica Convertino4, Camilla Coletti4,5, Tien-Lin Lee6, Francesco Offi1,2, and Alessandro Ruocco1,2

  • *Contact author: simone.ritarossi@uniroma3.it
PDF

Phys. Rev. B 114, 194307 – Published 27 October, 2026

DOI: https://doi.org/10.1103/s8w3-plc1

Abstract

Hard-x-ray C 1s photoemission from monolayer graphene probes a regime in which nuclear recoil and intrinsic electronic asymmetry contribute on comparable energy scales to the observed spectral line shape. Here we combine experiment and modeling over the photon-energy range 0.8–8keV to resolve this interplay quantitatively. A graphene-specific implementation of the Fujikawa-Takata cumulant formalism, based on an anisotropic vibrational density of states constrained by first-principles phonon calculations, captures the expected recoil scaling with photon energy and emission geometry but fails to reproduce the pronounced asymmetric tails of the measured spectra. To overcome this limitation, we introduce an explicit electronic convolution model in which a photon-energy-independent reference response, dominated by the electronic line shape and extracted from the low-recoil 0.8keV data through a recoil-inclusive fit, is convolved with a phonon recoil kernel carrying the full dependence on photon energy and emission angle. This approach reproduces both the measured line-shape evolution and the observed peak shifts across the explored energy range without refitting the spectra at higher photon energies. The results show that recoil in graphene cannot be described by a baseline treatment in which the phonon recoil kernel is combined only with symmetric lifetime broadening, but must be treated together with the intrinsic many-body electronic response of the C 1s line.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (42)

  1. C. S. Fadley, X-ray photoelectron spectroscopy: Progress and perspectives, J. Electron Spectrosc. Relat. Phenom. 178–179, 2 (2010).
  2. C. S. Fadley, Hard x-ray photoemission: An overview and future perspective, in Hard X-Ray Photoelectron Spectroscopy (HAXPES), edited by J. C. Woicik, Springer Series in Surface Sciences Vol. 59 (Springer, Cham, 2016), pp. 1–34.
  3. T. Fujikawa, R. Suzuki, and L. Kövér, Theory of recoil effects of elastically scattered electrons and of photoelectrons, J. Electron Spectrosc. Relat. Phenom. 151, 170 (2006).
  4. Y. Takata, Y. Kayanuma, M. Yabashi, K. Tamasaku, Y. Nishino, D. Miwa, Y. Harada, K. Horiba, S. Shin, S. Tanaka, E. Ikenaga, K. Kobayashi, Y. Senba, H. Ohashi, and T. Ishikawa, Recoil effects of photoelectrons in a solid, Phys. Rev. B 75, 233404 (2007).
  5. Y. Takata, Y. Kayanuma, S. Oshima, S. Tanaka, M. Yabashi, K. Tamasaku, Y. Nishino, M. Matsunami, R. Eguchi, A. Chainani, M. Oura, T. Takeuchi, Y. Senba, H. Ohashi, S. Shin, and T. Ishikawa, Recoil effect of photoelectrons in the Fermi edge of simple metals, Phys. Rev. Lett. 101, 137601 (2008).
  6. M. Vos, M. R. Went, Y. Kayanuma, S. Tanaka, Y. Takata, and J. Mayers, Comparison of recoil effects in graphite as observed by photoemission, electron scattering, and neutron scattering, Phys. Rev. B 78, 024301 (2008).
  7. E. Kukk, T. D. Thomas, D. Céolin, S. Granroth, O. Travnikova, M. Berholts, T. Marchenko, R. Guillemin, L. Journel, I. Ismail, R. Püttner, M. N. Piancastelli, K. Ueda, and M. Simon, Energy transfer into molecular vibrations and rotations by recoil in inner-shell photoemission, Phys. Rev. Lett. 121, 073002 (2018).
  8. F. Roth, D. Potorochin, A. Gloskovskii, C. Schlueter, L. Wenthaus, S. Molodtsov, W. Drube, and W. Eberhardt, Recoil effects in high energy photoemission of solids – Revisited, J. Electron Spectrosc. Relat. Phenom. 281, 147544 (2025).
  9. T. Fujikawa and K. Niki, Phonon effects in high-energy photoemission spectra, J. Electron Spectrosc. Relat. Phenom. 280, 147525 (2025).
  10. O. Dubay and G. Kresse, Accurate density functional calculations for the phonon dispersion relations of graphite layer and carbon nanotubes, Phys. Rev. B 67, 035401 (2003).
  11. L. Falkovsky, Symmetry constraints on phonon dispersion in graphene, Phys. Lett. A 372, 5189 (2008).
  12. S. V. Kusminskiy, D. K. Campbell, and A. H. C. Neto, Lenosky's energy and the phonon dispersion of graphene, Phys. Rev. B 80, 035401 (2009).
  13. W. L. Z. Zhao, K. S. Tikhonov, and A. M. Finkel'stein, Flexural phonons in supported graphene: From pinning to localization, Sci. Rep. 8, 16256 (2018).
  14. A. A. Taleb and D. Farías, Phonon dynamics of graphene on metals, J. Phys.: Condens. Matter 28, 103005 (2016).
  15. A. Politano, A. R. Marino, and G. Chiarello, Phonon dispersion of quasi-freestanding graphene on Pt(111), J. Phys.: Condens. Matter 24, 104025 (2012).
  16. K. H. Michel and B. Verberck, Theory of the evolution of phonon spectra and elastic constants from graphene to graphite, Phys. Rev. B 78, 085424 (2008).
  17. S. Doniach and M. Sunjic, Many-electron singularity in x-ray photoemission and x-ray line spectra from metals, J. Phys. C 3, 285 (1970).
  18. P. Nozières and C. T. De Dominicis, Singularities in the x-ray absorption and emission of metals. III. One-body theory exact solution, Phys. Rev. 178, 1097 (1969).
  19. F. Sette, G. K. Wertheim, Y. Ma, G. Meigs, S. Modesti, and C. T. Chen, Lifetime and screening of the C 1s photoemission in graphite, Phys. Rev. B 41, 9766 (1990).
  20. A. Apponi, D. Convertino, N. Mishra, C. Coletti, M. Iodice, F. Frasconi, F. Pilo, N. S. Blaj, D. Paoloni, I. Rago, G. De Bellis, G. Cavoto, and A. Ruocco, Transmission through graphene of electrons in the 30–900 eV range, Carbon 216, 118502 (2024).
  21. Y. Kayanuma, Recoil effects in x-ray photoelectron spectroscopy, in Hard X-Ray Photoelectron Spectroscopy (HAXPES), edited by J. C. Woicik, Springer Series in Surface Sciences Vol. 59 (Springer, Cham, 2016), pp. 175–195.
  22. T.-L. Lee and D. A. Duncan, A two-color beamline for electron spectroscopies at Diamond Light Source, Synchrotron Radiat. News 31, 16 (2018).
  23. V. Miseikis, D. Convertino, N. Mishra, M. Gemmi, T. Mashoff, S. Heun, N. Haghighian, F. Bisio, M. Canepa, V. Piazza, and C. Coletti, Rapid CVD growth of millimetre-sized single crystal graphene using a cold-wall reactor, 2D Mater. 2, 014006 (2015).
  24. D. Convertino, F. Fabbri, N. Mishra, M. Mainardi, V. Cappello, G. Testa, S. Capsoni, L. Albertazzi, S. Luin, L. Marchetti, and C. Coletti, Graphene promotes axon elongation through local stall of nerve growth factor signaling endosomes, Nano Lett. 20, 3633 (2020).
  25. X. Li, W. Cai, J. An, S. Kim, J. Nah, D. Yang, R. Piner, A. Velamakanni, I. Jung, E. Tutuc, S. K. Banerjee, L. Colombo, and R. S. Ruoff, Large-area synthesis of high-quality and uniform graphene films on copper foils, Science 324, 1312 (2009).
  26. A. J. Marsden, M. Skilbeck, M. Healey, H. R. Thomas, M. Walker, R. S. Edwards, N. A. Garcia, F. Vuković, H. Jabraoui, T. R. Walsh, J. P. Rourke, and N. R. Wilson, From graphene to graphene oxide: The importance of extended topological defects, Phys. Chem. Chem. Phys. 24, 2318 (2022).
  27. D. A. Shirley, High-resolution x-ray photoemission spectrum of the valence bands of gold, Phys. Rev. B 5, 4709 (1972).
  28. S. M. Story, J. J. Kas, F. D. Vila, M. J. Verstraete, and J. J. Rehr, Cumulant expansion for phonon contributions to the electron spectral function, Phys. Rev. B 90, 195135 (2014).
  29. T. Fujikawa, H. Arai, R. Suzuki, H. Shinotsuka, L. Kövér, and N. Ueno, Recoil effects in high-energy photoemission beyond single-site approximation, J. Electron Spectrosc. Relat. Phenom. 162, 146 (2008).
  30. L. Van Hove, Correlations in space and time and Born approximation scattering in systems of interacting particles, Phys. Rev. 95, 249 (1954).
  31. See Supplemental Material at http://link.aps.org/supplemental/10.1103/s8w3-plc1 for details of the low-recoil reference analysis, model-sensitivity and background tests, energy calibration, photon-momentum correction, and temperature dependence.
  32. E. Mariani and F. von Oppen, Flexural phonons in free-standing graphene, Phys. Rev. Lett. 100, 076801 (2008).
  33. J.-A. Yan, W. Y. Ruan, and M. Y. Chou, Phonon dispersions and vibrational properties of monolayer, bilayer, and trilayer graphene: Density-functional perturbation theory, Phys. Rev. B 77, 125401 (2008).
  34. N. Mounet and N. Marzari, First-principles determination of the structural, vibrational and thermodynamic properties of diamond, graphite, and derivatives, Phys. Rev. B 71, 205214 (2005).
  35. D. L. Nika and A. A. Balandin, Two-dimensional phonon transport in graphene, J. Phys.: Condens. Matter 24, 233203 (2012).
  36. E. N. Koukaras, G. Kalosakas, C. Galiotis, and K. Papagelis, Phonon properties of graphene derived from molecular dynamics simulations, Sci. Rep. 5, 12923 (2015).
  37. L. Hedin, Effects of recoil on shake-up spectra in metals, Phys. Scr. 21, 477 (1980).
  38. A. Politano, G. Chiarello, and C. Spinella, Plasmon spectroscopy of graphene and other two-dimensional materials with transmission electron microscopy, Mater. Sci. Semicond. Process. 65, 88 (2017).
  39. S. Yuan, R. Roldán, and M. I. Katsnelson, Excitation spectrum and high-energy plasmons in single-layer and multilayer graphene, Phys. Rev. B 84, 035439 (2011).
  40. M. Guzzo, J. J. Kas, L. Sponza, C. Giorgetti, F. Sottile, D. Pierucci, M. G. Silly, F. Sirotti, J. J. Rehr, and L. Reining, Multiple satellites in materials with complex plasmon spectra: From graphite to graphene, Phys. Rev. B 89, 085425 (2014).
  41. J. A. Leiro, M. H. Heinonen, T. Laiho, and I. G. Batirev, Core-level XPS spectra of fullerene, highly oriented pyrolytic graphite, and glassy carbon, J. Electron Spectrosc. Relat. Phenom. 128, 205 (2003).
  42. Y. Kayanuma, I. Fukahori, S. Tanaka, and Y. Takata, Site-specific recoil effect in hard x-ray photoelectron spectroscopy of the valence band of compound crystals, J. Electron Spectrosc. Relat. Phenom. 184, 468 (2011).
