Triangular J1−J2 Heisenberg antiferromagnet in a magnetic field

T. Bader1,2, S. Feng1,2, S. Budaraju1,2, F. Becca3, J. Knolle1,2,4, and F. Pollmann1,2

PDF

Phys. Rev. B 113, L241114 – Published 18 June, 2026

DOI: https://doi.org/10.1103/rwhz-jf5b

Abstract

The behavior of the paradigmatic J1−J2 triangular lattice Heisenberg antiferromagnet in a magnetic field remains unsettled despite decades of study. We map out the phase diagram using three complementary approaches, including self-consistent nonlinear spin-wave theory, density-matrix renormalization group, and variational Monte Carlo. This combined analysis resolves the competition among different field-induced magnetic orders and magnetization plateaus across the classically frustrated parameter range. In particular, there is a finite range in the parameter regime around J2/J1=18 in which (i) upon the application of the external field, the gapless quantum spin liquid acquires a finite density of monopoles, and (ii) by further increasing the field, two plateaus are clearly obtained at m=13 and m=12. We discuss the experimental importance of the consecutive magnetization plateau transitions as a signature of an underlying quantum spin-liquid phase.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (59)

  1. Introduction to Frustrated Magnetism: Materials, Experiments, Theory, edited by C. Lacroix, P. Mendels, and F. Mila, Springer Series in Solid-State Sciences, Vol. 164 (Springer, Berlin, 2011).
  2. G. Wannier, Antiferromagnetism. The triangular Ising net, Phys. Rev. 79, 357 (1950).
  3. B. Metcalf, Phase diagram of a nearest neighbor triangular antiferromagnet in an external field, Phys. Lett. A 45, 1 (1973).
  4. B. Metcalf, Ground state spin orderings of the triangular Ising model with the nearest and next nearest neighbor interaction, Phys. Lett. A 46, 325 (1974).
  5. O. Bradley, C. Feng, R. T. Scalettar, and R. R. Singh, Robustness of entropy plateaus: A case study of triangular Ising antiferromagnets, Phys. Rev. B 100, 064414 (2019).
  6. H. Nishimori and S. Miyashita, Magnetization process of the spin-1/2 antiferromagnetic Ising-like Heisenberg model on the triangular lattice, J. Phys. Soc. Jpn. 55, 4448 (1986).
  7. A. Chubukov and D. Golosov, Quantum theory of an antiferromagnet on a triangular lattice in a magnetic field, J. Phys.: Condens. Matter 3, 69 (1991).
  8. H. Kawamura and S. Miyashita, Phase transition of the Heisenberg antiferromagnet on the triangular lattice in a magnetic field, J. Phys. Soc. Jpn. 54, 4530 (1985).
  9. M. Gvozdikova, P. Melchy, and M. Zhitomirsky, Magnetic phase diagrams of classical triangular and kagome antiferromagnets, J. Phys.: Condens. Matter 23, 164209 (2011).
  10. L. Seabra, T. Momoi, P. Sindzingre, and N. Shannon, Phase diagram of the classical Heisenberg antiferromagnet on a triangular lattice in an applied magnetic field, Phys. Rev. B 84, 214418 (2011).
  11. M. Takigawa and F. Mila, Magnetization plateaus, in Introduction to Frustrated Magnetism: Materials, Experiments, Theory (Springer, 2011), Vol. 164, pp. 241–267.
  12. O. A. Starykh, Unusual ordered phases of highly frustrated magnets: A review, Rep. Prog. Phys. 78, 052502 (2015).
  13. A. Honecker, J. Schulenburg, and J. Richter, Magnetization plateaus in frustrated antiferromagnetic quantum spin models, J. Phys.: Condens. Matter 16, S749 (2004).
  14. T. Ono, H. Tanaka, H. Aruga Katori, F. Ishikawa, H. Mitamura, and T. Goto, Magnetization plateau in the frustrated quantum spin system Cs2CuBr4, Phys. Rev. B 67, 104431 (2003).
  15. Y. Shirata, H. Tanaka, A. Matsuo, and K. Kindo, Experimental realization of a spin-1/2 triangular-lattice Heisenberg antiferromagnet, Phys. Rev. Lett. 108, 057205 (2012).
  16. L. Savary and L. Balents, Quantum spin liquids: A review, Rep. Prog. Phys. 80, 016502 (2017).
  17. J. Knolle and R. Moessner, A field guide to spin liquids, Annu. Rev. Condens. Matter Phys. 10, 451 (2019).
  18. C. Broholm, R. J. Cava, S. Kivelson, D. Nocera, M. Norman, and T. Senthil, Quantum spin liquids, Science 367, eaay0668 (2020).
  19. K. Kanoda and R. Kato, Mott physics in organic conductors with triangular lattices, Annu. Rev. Condens. Matter Phys. 2, 167 (2011).
  20. Z. Zhu and S. R. White, Spin liquid phase of the S=12J1−J2 Heisenberg model on the triangular lattice, Phys. Rev. B 92, 041105(R) (2015).
  21. S.-S. Gong, W. Zheng, M. Lee, Y.-M. Lu, and D. N. Sheng, Chiral spin liquid with spinon Fermi surfaces in the spin-12 triangular Heisenberg model, Phys. Rev. B 100, 241111(R) (2019).
  22. Z. Zhu, P. A. Maksimov, S. R. White, and A. L. Chernyshev, Topography of spin liquids on a triangular lattice, Phys. Rev. Lett. 120, 207203 (2018).
  23. M. Drescher, L. Vanderstraeten, R. Moessner, and F. Pollmann, Dynamical signatures of symmetry-broken and liquid phases in an S=12 Heisenberg antiferromagnet on the triangular lattice, Phys. Rev. B 108, L220401 (2023).
  24. A. O. Scheie, Y. Kamiya, H. Zhang, S. Lee, A. J. Woods, M. O. Ajeesh, M. G. Gonzalez, B. Bernu, J. W. Villanova, J. Xing, Q. Huang, Q. Zhang, J. Ma, E. S. Choi, D. M. Pajerowski, H. Zhou, A. S. Sefat, S. Okamoto, T. Berlijn, L. Messio, et al., Nonlinear magnons and exchange Hamiltonians of the delafossite proximate quantum spin liquid candidates KYbSe2 and NaYbSe2, Phys. Rev. B 109, 014425 (2024).
  25. Y. Shen, Y.-D. Li, H. Wo, Y. Li, S. Shen, B. Pan, Q. Wang, H. C. Walker, P. Steffens, M. Boehm, Y. Hao, D. L. Quintero-Castro, L. W. Harriger, M. D. Frontzek, L. Hao, S. Meng, Q. Zhang, G. Chen, and J. Zhao, Evidence for a spinon Fermi surface in a triangular-lattice quantum-spin-liquid candidate, Nature (London) 540, 559 (2016).
  26. P. Anderson, Resonating valence bonds: A new kind of insulator? Mater. Res. Bull. 8, 153 (1973).
  27. W.-J. Hu, S.-S. Gong, W. Zhu, and D. N. Sheng, Competing spin-liquid states in the spin-12 Heisenberg model on the triangular lattice, Phys. Rev. B 92, 140403(R) (2015).
  28. Y. Iqbal, W.-J. Hu, R. Thomale, D. Poilblanc, and F. Becca, Spin liquid nature in the Heisenberg J1−J2 triangular antiferromagnet, Phys. Rev. B 93, 144411 (2016).
  29. F. Ferrari and F. Becca, Dynamical structure factor of the J1−J2 Heisenberg model on the triangular lattice: Magnons, spinons, and gauge fields, Phys. Rev. X 9, 031026 (2019).
  30. T. Tang, B. Moritz, and T. P. Devereaux, Spectra of a gapped quantum spin liquid with a strong chiral excitation on the triangular lattice, Phys. Rev. B 106, 064428 (2022).
  31. A. O. Scheie, E. A. Ghioldi, J. Xing, J. A. M. Paddison, N. E. Sherman, M. Dupont, L. D. Sanjeewa, S. Lee, A. J. Woods, D. Abernathy, D. M. Pajerowski, T. J. Williams, S.-S. Zhang, L. O. Manuel, A. E. Trumper, C. D. Pemmaraju, A. S. Sefat, D. S. Parker, T. P. Devereaux, R. Movshovich, et al., Proximate spin liquid and fractionalization in the triangular antiferromagnet KYbSe2, Nat. Phys. 20, 74 (2024).
  32. T. Xie, A. A. Eberharter, J. Xing, S. Nishimoto, M. Brando, P. Khanenko, J. Sichelschmidt, A. A. Turrini, D. G. Mazzone, P. G. Naumov, L. D. Sanjeewa, N. Harrison, A. S. Sefat, B. Normand, A. M. Läuchli, A. Podlesnyak, and S. E. Nikitin, Complete field-induced spectral response of the spin-1/2 triangular-lattice antiferromagnet CsYbSe2, npj Quantum Mater. 8, 48 (2023).
  33. A. Scheie, M. Lee, K. Wang, P. Laurell, E. Choi, D. Pajerowski, Q. Zhang, J. Ma, H. Zhou, S. Lee, et al., Spectrum and low-energy gap in triangular quantum spin liquid NaYbSe2, arXiv:2406.17773.
  34. See Supplemental Material at http://link.aps.org/supplemental/10.1103/rwhz-jf5b for details of the linear and nonlinear spin wave theories, and the determination of phase boundaries.
  35. T. Jolicoeur, E. Dagotto, E. Gagliano, and S. Bacci, Ground-state properties of the s = 1/2 Heisenberg antiferromagnet on a triangular lattice, Phys. Rev. B 42, 4800 (1990).
  36. A. V. Chubukov and T. Jolicoeur, Order-from-disorder phenomena in Heisenberg antiferromagnets on a triangular lattice, Phys. Rev. B 46, 11137 (1992).
  37. D. A. Huse and V. Elser, Simple variational wave functions for two-dimensional Heisenberg spin-½ antiferromagnets, Phys. Rev. Lett. 60, 2531 (1988).
  38. T. Coletta, T. A. Tóth, K. Penc, and F. Mila, Semiclassical theory of the magnetization process of the triangular lattice Heisenberg model, Phys. Rev. B 94, 075136 (2016).
  39. M. Ye and A. V. Chubukov, Quantum phase transitions in the Heisenberg J1−J2 triangular antiferromagnet in a magnetic field, Phys. Rev. B 95, 014425 (2017).
  40. M. Ye and A. V. Chubukov, Half-magnetization plateau in a Heisenberg antiferromagnet on a triangular lattice, Phys. Rev. B 96, 140406(R) (2017).
  41. S. R. White, Density matrix formulation for quantum renormalization groups, Phys. Rev. Lett. 69, 2863 (1992).
  42. J. Hauschild, J. Unfried, S. Anand, B. Andrews, M. Bintz, U. Borla, S. Divic, M. Drescher, J. Geiger, M. Hefel, K. Hémery, W. Kadow, J. Kemp, N. Kirchner, V. S. Liu, G. Möller, D. Parker, M. Rader, A. Romen, S. Scalet, et al., Tensor network Python (TeNPy) version 1, SciPost Phys. Codebases 41 (2024).
  43. F. Becca and S. Sorella, Quantum Monte Carlo Approaches for Correlated Systems (Cambridge University Press, Cambridge, UK, 2017).
  44. R. Yadav, S. Rachel, L. Hozoi, J. van den Brink, and G. Jackeli, Strain- and pressure-tuned magnetic interactions in honeycomb Kitaev materials, Phys. Rev. B 98, 121107(R) (2018).
  45. P. Sakrikar, B. Shen, E. H. T. Poldi, F. Bahrami, X. Hu, E. M. Kenney, Q. Wang, K. W. Fruhling, C. Wang, R. Gupta, R. Khasanov, H. Luetkens, S. A. Calder, A. A. Aczel, G. Fabbris, R. J. Hemley, K. W. Plumb, Y. Ran, P. Gegenwart, A. A. Tsirlin, et al., Pressure tuning of competing interactions on a honeycomb lattice, Nat. Commun. 16, 4712 (2025).
  46. B. P. Belbase, A. Unnikrishnan, S. Feng, E. S. Choi, J. Knolle, and A. Banerjee, Finite spinon density-of-states in triangular-lattice delafossite TlYbSe2, arXiv:2504.05436.
  47. D. Sellmann, X.-F. Zhang, and S. Eggert, Phase diagram of the antiferromagnetic XXZ model on the triangular lattice, Phys. Rev. B 91, 081104(R) (2015).
  48. D. Yamamoto, G. Marmorini, and I. Danshita, Quantum phase diagram of the triangular-lattice XXZ model in a magnetic field, Phys. Rev. Lett. 112, 127203 (2014).
  49. L. Seabra and N. Shannon, Competition between supersolid phases and magnetization plateaus in the frustrated easy-axis antiferromagnet on a triangular lattice, Phys. Rev. B 83, 134412 (2011).
  50. S. Hu, W. Zhu, S. Eggert, and Y.-C. He, Dirac spin liquid on the spin-1/2 triangular Heisenberg antiferromagnet, Phys. Rev. Lett. 123, 207203 (2019).
  51. Y.-C. He, M. P. Zaletel, M. Oshikawa, and F. Pollmann, Signatures of Dirac cones in a DMRG study of the kagome Heisenberg model, Phys. Rev. X 7, 031020 (2017).
  52. S. Budaraju et al., Field induced monopole condensate in the triangular J1−J2 Heisenberg model in a magnetic field (unpublished).
  53. X.-Y. Song, C. Wang, A. Vishwanath, and Y.-C. He, Unifying description of competing orders in two-dimensional quantum magnets, Nat. Commun. 10, 4254 (2019).
  54. S. Budaraju, A. Parola, Y. Iqbal, F. Becca, and D. Poilblanc, Monopole excitations in the U(1) Dirac spin liquid on the triangular lattice, Phys. Rev. B 111, 125150 (2025).
  55. X.-Y. Song, Y.-C. He, A. Vishwanath, and C. Wang, From spinon band topology to the symmetry quantum numbers of monopoles in Dirac spin liquids, Phys. Rev. X 10, 011033 (2020).
  56. Y. Ran, W.-H. Ko, P. A. Lee, and X.-G. Wen, Spontaneous spin ordering of a Dirac spin liquid in a magnetic field, Phys. Rev. Lett. 102, 047205 (2009).
  57. A. Keselman, X. Xu, H. Zhang, C. D. Batista, and O. A. Starykh, J1−J2 triangular lattice antiferromagnet in a magnetic field, arXiv:2512.02150.
  58. W. O. Wang, U. F. P. Seifert, O. A. Starykh, and L. Balents, Chirality and quasi-long-range order in finite-flux Gutzwiller states for magnetized frustrated magnets, arXiv:2601.14458.
  59. T. Bader, S. Feng, S. Budaraju, B. Federico, J. Knolle, and F. Pollmann, Triangular J1−J2 Heisenberg antiferromagnet in a magnetic field [Dataset], Zenodo, 2026, https://doi.org/10.5281/zenodo.20510149.
