Topological edge states in curved zigzag superlattices in nonlinear semiconductor microcavity exciton polaritons

Jing Wang1,*, Tobias Schneider2,*, Wei Hu3, Stefan Schumacher2,4,5, and Xuekai Ma2,†

  • *These authors contributed equally to this work.
  • †Contact author: xuekai.ma@gmail.com
PDF

Phys. Rev. B 113, 115302 – Published 3 March, 2026

DOI: https://doi.org/10.1103/rhs6-7mmk

Abstract

Zigzag chains allow for the formation of topological edge states. Several distinct chain architectures have been developed for this purpose. Here, we report a zigzag superlattice, containing two staggered sublattices, that supports multiple edge states, including higher-order modes. In such lattices, the intra- and intercell coupling is imbalanced by the tunneling effect of the eigenstates or deformation of the higher-order modes. We demonstrate that by arranging the zigzag superlattice into a curved shape, some of the edge states transition into bulk states as the curvature of the lattice increases, while some bulk states become more localized towards edge states. The reason is that a curved superlattice strengthens the intralattice coupling of the inner sublattice because of the separation reduction of the potential wells. We also show that some bulk states at larger curvatures can be transformed into edge states by a repulsive nonlinearity, which also enables the coexistence of different edge states. As a specific and ideal platform for realizing such topological superlattices, we explore exciton-polaritons in semiconductor microcavities with their strong nonlinearity and possibility for optical excitation and control. Our work introduces an additional dimension for the design of complex topological lattices and functional photonic devices.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (40)

  1. W. P. Su, J. R. Schrieffer, and A. J. Heeger, Solitons in polyacetylene, Phys. Rev. Lett. 42, 1698 (1979).
  2. D. J. J. Marchand, G. De Filippis, V. Cataudella, M. Berciu, N. Nagaosa, N. V. Prokof'ev, A. S. Mishchenko, and P. C. E. Stamp, Sharp transition for single polarons in the one-dimensional Su-Schrieffer-Heeger model, Phys. Rev. Lett. 105, 266605 (2010).
  3. E. J. Meier, F. A. An, and B. Gadway, Observation of the topological soliton state in the Su–Schrieffer–Heeger model, Nat. Commun. 7, 13986 (2016).
  4. F. Mei, G. Chen, L. Tian, S.-L. Zhu, and S. Jia, Robust quantum state transfer via topological edge states in superconducting qubit chains, Phys. Rev. A 98, 012331 (2018).
  5. F. Klauck, M. Heinrich, and A. Szameit, Photonic two-particle quantum walks in Su–Schrieffer–Heeger lattices, Photon. Res. 9, A1 (2021).
  6. M. Pan, H. Zhao, P. Miao, S. Longhi, and L. Feng, Photonic zero mode in a non-Hermitian photonic lattice, Nat. Commun. 9, 1308 (2018).
  7. S. Longhi, Probing non-Hermitian skin effect and non-Bloch phase transitions, Phys. Rev. Res. 1, 023013 (2019).
  8. P. St-Jean, V. Goblot, E. Galopin, A. Lemaître, T. Ozawa, L. Le Gratiet, I. Sagnes, J. Bloch, and A. Amo, Lasing in topological edge states of a one-dimensional lattice, Nat. Photon. 11, 651 (2017).
  9. T. Byrnes, N. Y. Kim, and Y. Yamamoto, Exciton–polariton condensates, Nat. Phys. 10, 803 (2014).
  10. R. Su, S. Ghosh, J. Wang, S. Liu, C. Diederichs, T. C. Liew, and Q. Xiong, Observation of exciton polariton condensation in a perovskite lattice at room temperature, Nat. Phys. 16, 301 (2020).
  11. J. D. Plumhof, T. Stöferle, L. Mai, U. Scherf, and R. F. Mahrt, Room-temperature Bose–Einstein condensation of cavity exciton–polaritons in a polymer, Nat. Mater. 13, 247 (2014).
  12. K. Daskalakis, S. Maier, R. Murray, and S. Kéna-Cohen, Nonlinear interactions in an organic polariton condensate, Nat. Mater. 13, 271 (2014).
  13. S. Klembt, T. Harder, O. Egorov, K. Winkler, R. Ge, M. Bandres, M. Emmerling, L. Worschech, T. Liew, M. Segev, C. Schneider, and S. Höfling, Exciton-polariton topological insulator, Nature (London) 562, 552 (2018).
  14. M. Milićević, T. Ozawa, P. Andreakou, I. Carusotto, T. Jacqmin, E. Galopin, A. Lemaitre, L. Le Gratiet, I. Sagnes, J. Bloch, and A. Amo, Edge states in polariton honeycomb lattices, 2D Mater. 2, 034012 (2015).
  15. C. E. Whittaker, E. Cancellieri, P. M. Walker, D. R. Gulevich, H. Schomerus, D. Vaitiekus, B. Royall, D. M. Whittaker, E. Clarke, I. V. Iorsh, I. A. Shelykh, M. S. Skolnick, and D. N. Krizhanovskii, Exciton polaritons in a two-dimensional Lieb lattice with spin-orbit coupling, Phys. Rev. Lett. 120, 097401 (2018).
  16. C. Li, F. Ye, X. Chen, Y. V. Kartashov, A. Ferrando, L. Torner, and D. V. Skryabin, Lieb polariton topological insulators, Phys. Rev. B 97, 081103(R) (2018).
  17. D. R. Gulevich, D. Yudin, D. V. Skryabin, I. V. Iorsh, and I. A. Shelykh, Exploring nonlinear topological states of matter with exciton-polaritons: Edge solitons in kagome lattice, Sci. Rep. 7, 1780 (2017).
  18. D. R. Gulevich, D. Yudin, I. V. Iorsh, and I. A. Shelykh, Kagome lattice from an exciton-polariton perspective, Phys. Rev. B 94, 115437 (2016).
  19. F. Jin, S. Mandal, X. Wang, B. Zhang, and R. Su, Perovskite topological exciton-polariton disclination laser at room temperature, Nat. Commun. 16, 6002 (2025).
  20. K. Sabour and Y. V. Kartashov, Polariton topological insulators with disclinations, Chaos, Solit. & Fract. 199, 116785 (2025).
  21. D. D. Solnyshkov, A. V. Nalitov, and G. Malpuech, Kibble-Zurek mechanism in topologically nontrivial zigzag chains of polariton micropillars, Phys. Rev. Lett. 116, 046402 (2016).
  22. R. Su, S. Ghosh, T. C. H. Liew, and Q. Xiong, Optical switching of topological phase in a perovskite polariton lattice, Sci. Adv. 7, eabf8049 (2021).
  23. M. Pieczarka, E. Estrecho, S. Ghosh, M. Wurdack, M. Steger, D. W. Snoke, K. West, L. N. Pfeiffer, T. C. Liew, A. G. Truscott, and E. A. Ostrovskaya, Topological phase transition in an all-optical exciton-polariton lattice, Optica 8, 1084 (2021).
  24. T. H. Harder, M. Sun, O. A. Egorov, I. Vakulchyk, J. Beierlein, P. Gagel, M. Emmerling, C. Schneider, U. Peschel, I. G. Savenko, S. Klembt, and S. Höfling, Coherent topological polariton laser, ACS Photon. 8, 1377 (2021).
  25. I. Georgakilas, R. Mirek, D. Urbonas, M. Forster, U. Scherf, R. F. Mahrt, and T. Stöferle, In situ tunable, room-temperature polariton condensation in individual states of a 1D topological lattice, Sci. Adv. 11, eadt8645 (2025).
  26. D. Zhao, Z. Wang, L. Yang, Y. Zhong, X. Xi, Z. Zhu, X. Jiao, Q.-a. Tu, Y. Meng, B. Yan, C. Shang, and Z. Gao, Observation of cavity-tunable topological phases of polaritons, Nat. Commun. 16, 5914 (2025).
  27. Y. V. Kartashov and D. V. Skryabin, Bistable topological insulator with exciton-polaritons, Phys. Rev. Lett. 119, 253904 (2017).
  28. X. Ma, Y. V. Kartashov, A. Ferrando, and S. Schumacher, Topological edge states of nonequilibrium polaritons in hollow honeycomb arrays, Opt. Lett. 45, 5311 (2020).
  29. Y. V. Kartashov and D. V. Skryabin, Modulational instability and solitary waves in polariton topological insulators, Optica 3, 1228 (2016).
  30. Y. Zhang, Y. V. Kartashov, and A. Ferrando, Interface states in polariton topological insulators, Phys. Rev. A 99, 053836 (2019).
  31. N. Pernet, P. St-Jean, D. D. Solnyshkov, G. Malpuech, N. Carlon Zambon, Q. Fontaine, B. Real, O. Jamadi, A. Lemaître, M. Morassi, et al., Gap solitons in a one-dimensional driven-dissipative topological lattice, Nat. Phys. 18, 678 (2022).
  32. T. Schneider, W. Gao, T. Zentgraf, S. Schumacher, and X. Ma, Topological edge and corner states in coupled wave lattices in nonlinear polariton condensates, Nanophotonics 13, 509 (2024).
  33. B. Midya and L. Feng, Topological multiband photonic superlattices, Phys. Rev. A 98, 043838 (2018).
  34. Y. Zhang, B. Ren, Y. Li, and F. Ye, Topological states in the super-SSH model, Opt. Express 29, 42827 (2021).
  35. B.-Y. Xie, H.-F. Wang, H.-X. Wang, X.-Y. Zhu, J.-H. Jiang, M.-H. Lu, and Y.-F. Chen, Second-order photonic topological insulator with corner states, Phys. Rev. B 98, 205147 (2018).
  36. B.-Y. Xie, G.-X. Su, H.-F. Wang, H. Su, X.-P. Shen, P. Zhan, M.-H. Lu, Z.-L. Wang, and Y.-F. Chen, Visualization of higher-order topological insulating phases in two-dimensional dielectric photonic crystals, Phys. Rev. Lett. 122, 233903 (2019).
  37. J. Wu, S. Ghosh, Y. Gan, Y. Shi, S. Mandal, H. Sun, B. Zhang, T. C. Liew, R. Su, and Q. Xiong, Higher-order topological polariton corner state lasing, Sci. Adv. 9, eadg4322 (2023).
  38. C. Bennenhei, H. Shan, M. Struve, N. Kunte, F. Eilenberger, J. Ohmer, U. Fischer, S. Schumacher, X. Ma, C. Schneider, and M. Esmann, Organic room-temperature polariton condensate in a higher-order topological lattice, ACS Photon. 11, 3046 (2024).
  39. J. Wingenbach, D. Bauch, X. Ma, R. Schade, C. Plessl, and S. Schumacher, Phoenix–Paderborn highly optimized and energy efficient solver for two-dimensional nonlinear Schrödinger equations with integrated extensions, Comput. Phys. Commun. 315, 109689 (2025).
  40. G. C. Righini, J. Krzak, A. Lukowiak, G. Macrelli, S. Varas, and M. Ferrari, From flexible electronics to flexible photonics: A brief overview, Opt. Mater. (Amsterdam) 115, 111011 (2021).
