Photon counting beyond the rotating-wave approximation

Steven Kim and Fabian Hassler

PDF

Phys. Rev. B 114, 125424 – Published 31 August, 2026

DOI: https://doi.org/10.1103/r2kl-xvd2

Abstract

Open quantum systems are often described by a Lindblad master equation, which relies on a set of approximations, most importantly the rotating-wave approximation, which is only valid for weak damping. In the Lindblad setting, dissipative processes are described through jump operators, distinguishing between absorption and emission of photons. This enables the simple identification of emitted photons, which provides a straightforward way to obtain the radiation statistics. Outside the rotating-wave limit, the Lindblad approach does not work. Open quantum systems can then be described by, e.g., the quantum Langevin equation. However, in this framework the number of emitted photons is not easily accessible. In this work, we point out how to obtain the photon counting statistics from a quantum Langevin equation and provide an expression for the photon current operator, for arbitrary systems coupled to linear environments. As an example, we employ the method to study the radiation statistics of a damped harmonic oscillator at finite temperature beyond the rotating-wave approximation. We show that even outside the rotating-wave limit, the most important contribution to the radiation statistics can be captured by an effective Lindblad equation, thus extending the range of possible applications of the Lindblad framework.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (52)

  1. F. Campaioli, J. H. Cole, and H. Hapuarachchi, Quantum master equations: Tips and tricks for quantum optics, quantum computing, and beyond, PRX Quantum 5, 020202 (2024).
  2. S. Haroche and D. Kleppner, Cavity Quantum Electrodynamics (Springer US, Boston, MA, 1995), pp. 849–855.
  3. M. Westig, B. Kubala, O. Parlavecchio, Y. Mukharsky, C. Altimiras, P. Joyez, D. Vion, P. Roche, D. Esteve, M. Hofheinz, M. Trif, P. Simon, J. Ankerhold, and F. Portier, Emission of nonclassical radiation by inelastic Cooper pair tunneling, Phys. Rev. Lett. 119, 137001 (2017).
  4. A. O. Caldeira and A. J. Leggett, Path integral approach to quantum Brownian motion, Physica A 121, 587 (1983).
  5. G. W. Ford, J. T. Lewis, and R. F. O'Connell, Quantum Langevin equation, Phys. Rev. A 37, 4419 (1988).
  6. M. Srinivas and E. Davies, Photon counting probabilities in quantum optics, Optica Acta: Int. J. Opt. 28, 981 (1981).
  7. S. Kim and F. Hassler, Third quantization for bosons: Symplectic diagonalization, non-Hermitian Hamiltonian, and symmetries, J. Phys. A: Math. Theor. 56, 385303 (2023).
  8. K. S. U. Kansanen, P. Portugal, C. Flindt, and P. Samuelsson, Photon counting statistics in Gaussian bosonic networks, SciPost Phys. 18, 116 (2025).
  9. C. W. Gardiner and M. J. Collett, Input and output in damped quantum systems: Quantum stochastic differential equations and the master equation, Phys. Rev. A 31, 3761 (1985).
  10. C. Ciuti and I. Carusotto, Input-output theory of cavities in the ultrastrong coupling regime: The case of time-independent cavity parameters, Phys. Rev. A 74, 033811 (2006).
  11. A. Roy and M. Devoret, Quantum-limited parametric amplification with Josephson circuits in the regime of pump depletion, Phys. Rev. B 98, 045405 (2018).
  12. M. H. Devoret, Quantum fluctuations in electrical circuits, in Les Houches Session LXIII, edited by S. Reynaud, E. Giacobino, and J. Zinn-Justin (Elsevier, Amsterdam, 1996).
  13. H. Grabert, U. Weiss, and P. Talkner, Quantum theory of the damped harmonic oscillator, Z. Phys. B 55, 87 (1984).
  14. W.-M. Zhang, P.-Y. Lo, H.-N. Xiong, M. W.-Y. Tu, and F. Nori, General non-Markovian dynamics of open quantum systems, Phys. Rev. Lett. 109, 170402 (2012).
  15. H.-P. Breuer, E.-M. Laine, J. Piilo, and B. Vacchini, Colloquium: Non-Markovian dynamics in open quantum systems, Rev. Mod. Phys. 88, 021002 (2016).
  16. I. de Vega and D. Alonso, Dynamics of non-Markovian open quantum systems, Rev. Mod. Phys. 89, 015001 (2017).
  17. M. Lednev, F. J. García-Vidal, and J. Feist, Lindblad master equation capable of describing hybrid quantum systems in the ultrastrong coupling regime, Phys. Rev. Lett. 132, 106902 (2024).
  18. M. Xu, V. Vadimov, J. T. Stockburger, and J. Ankerhold, Colloquium: Simulating non-Markovian dynamics in open quantum systems, Rev. Mod. Phys. 98, 021002 (2026).
  19. H. J. Carmichael, Statistical Methods in Quantum Optics 1: Master Equations and Fokker–Planck Equations (Springer, Berlin, 1999).
  20. A. Blais, A. L. Grimsmo, S. M. Girvin, and A. Wallraff, Circuit quantum electrodynamics, Rev. Mod. Phys. 93, 025005 (2021).
  21. M. Aspelmeyer, T. J. Kippenberg, and F. Marquardt, Cavity optomechanics, Rev. Mod. Phys. 86, 1391 (2014).
  22. A. Nunnenkamp, K. Børkje, and S. M. Girvin, Single-photon optomechanics, Phys. Rev. Lett. 107, 063602 (2011).
  23. A. A. Clerk, M. H. Devoret, S. M. Girvin, F. Marquardt, and R. J. Schoelkopf, Introduction to quantum noise, measurement, and amplification, Rev. Mod. Phys. 82, 1155 (2010).
  24. K. C. Schwab and M. L. Roukes, Putting mechanics into quantum mechanics, Phys. Today 58(7), 36 (2005).
  25. H. Qiao, É. Dumur, G. Andersson, H. Yan, M.-H. Chou, J. Grebel, C. R. Conner, Y. J. Joshi, J. M. Miller, R. G. Povey, X. Wu, and A. N. Cleland, Splitting phonons: Building a platform for linear mechanical quantum computing, Science 380, 1030 (2023).
  26. P. Portugal, F. Brange, K. S. U. Kansanen, P. Samuelsson, and C. Flindt, Photon emission statistics of a driven microwave cavity, Phys. Rev. Res. 5, 033091 (2023).
  27. E. Zakka-Bajjani, J. Dufouleur, N. Coulombel, P. Roche, D. C. Glattli, and F. Portier, Experimental determination of the statistics of photons emitted by a tunnel junction, Phys. Rev. Lett. 104, 206802 (2010).
  28. G. C. Ménard, A. Peugeot, C. Padurariu, C. Rolland, B. Kubala, Y. Mukharsky, Z. Iftikhar, C. Altimiras, P. Roche, H. le Sueur, P. Joyez, D. Vion, D. Esteve, J. Ankerhold, and F. Portier, Emission of photon multiplets by a dc-biased superconducting circuit, Phys. Rev. X 12, 021006 (2022).
  29. H. Ritsch, P. Domokos, F. Brennecke, and T. Esslinger, Cold atoms in cavity-generated dynamical optical potentials, Rev. Mod. Phys. 85, 553 (2013).
  30. A. Peugeot, G. Ménard, S. Dambach, M. Westig, B. Kubala, Y. Mukharsky, C. Altimiras, P. Joyez, D. Vion, P. Roche, D. Esteve, P. Milman, J. Leppäkangas, G. Johansson, M. Hofheinz, J. Ankerhold, and F. Portier, Generating two continuous entangled microwave beams using a dc-biased Josephson junction, Phys. Rev. X 11, 031008 (2021).
  31. S. Kim and F. Hassler, Superbunched radiation of a tunnel junction due to charge quantization, Phys. Rev. Lett. 133, 116301 (2024).
  32. D. Bozyigit, C. Lang, L. Steffen, J. M. Fink, C. Eichler, M. Baur, R. Bianchetti, P. J. Leek, S. Filipp, M. P. da Silva, A. Blais, and A. Wallraff, Antibunching of microwave-frequency photons observed in correlation measurements using linear detectors, Nat. Phys. 7, 154 (2011).
  33. R. Loudon, The Quantum Theory of Light (Oxford University Press, Oxford, UK, 2000).
  34. H. P. Breuer and F. Petruccione, The Theory of Open Quantum Systems (Oxford University Press, Oxford, UK, 2007).
  35. C. W. Gardiner and P. Zoller, Quantum Noise: A Handbook of Markovian and non-Markovian Quantum Stochastic Methods with Applications to Quantum Optics, 3rd ed. (Springer, Berlin, (2004).
  36. We include the infinitesimal time delay by 0+ for causality.
  37. R. J. Glauber, The quantum theory of optical coherence, Phys. Rev. 130, 2529 (1963).
  38. G. B. Lesovik and R. Loosen, On the detection of finite-frequency current fluctuations, JETP Lett. 65, 295 (1997).
  39. F. Hassler and D. Otten, Second-order coherence of microwave photons emitted by a quantum point contact, Phys. Rev. B 92, 195417 (2015).
  40. Y. Nazarov and M. Kindermann, Full counting statistics of a general quantum mechanical variable, Eur. Phys. J. B 35, 413 (2003).
  41. C. Emary, C. Pöltl, A. Carmele, J. Kabuss, A. Knorr, and T. Brandes, Bunching and antibunching in electronic transport, Phys. Rev. B 85, 165417 (2012).
  42. M. P. da Silva, D. Bozyigit, A. Wallraff, and A. Blais, Schemes for the observation of photon correlation functions in circuit QED with linear detectors, Phys. Rev. A 82, 043804 (2010).
  43. J. Ankerhold, Phase space dynamics of overdamped quantum systems, Europhys. Lett. 61, 301 (2003).
  44. F. Brange, P. Menczel, and C. Flindt, Photon counting statistics of a microwave cavity, Phys. Rev. B 99, 085418 (2019).
  45. F. Hassler, S. Kim, and L. Arndt, Radiation statistics of a degenerate parametric oscillator at threshold, SciPost Phys. 14, 156 (2023).
  46. F. Hassler, J. Stubenrauch, and A. Ciani, Equation of motion approach to black-box quantization: Taming the multimode Jaynes-Cummings model, Phys. Rev. B 99, 014515 (2019).
  47. J. W. Negele and H. Orland, Quantum Many-Particle Systems (Westview Press, Boulder, Colorado, 1998).
  48. In contrast to the many-body setting, r is complex, which is due to the non-Hermitian nature of the problem.
  49. I. Khomchenko, P. Navez, and H. Ouerdane, SQUID-based interferometric accelerometer, Appl. Phys. Lett. 121, 152601 (2022).
  50. A. J. Leggett, S. Chakravarty, A. T. Dorsey, M. P. A. Fisher, A. Garg, and W. Zwerger, Dynamics of the dissipative two-state system, Rev. Mod. Phys. 59, 1 (1987).
  51. M. Schrauwen, A. Daniel, M. Janovitch, and P. P. Potts, Thermodynamic framework for coherently driven systems, Phys. Rev. Lett. 135, 220201 (2025).
  52. S. Kim and F. Hassler, Photon counting beyond the rotating-wave approximation [Data set], Zenodo, 2026, https://doi.org/10.5281/zenodo.21793686.

Outline

Information

Phys. Rev. B 114, 125424– Published 31 August, 2026
  • Received 24 February 2026
  • Revised 28 July 2026
  • Accepted 3 August 2026
