Charge puddles complicate nonlinear transport in large Berry phase materials

Arya Thenapparambil1,2,3, Kajetan M. Fijalkowski1,3,*, Mohamed AbdelGhany1,3, Hartmut Buhmann1,3, Charles Gould1,3,†, and Laurens W. Molenkamp1,2,3

  • *Contact author: kajetan.fijalkowski@uni-wuerzburg.de
  • †Contact author: gould@uni-wuerzburg.de
PDF

Phys. Rev. B 113, 125108 – Published 3 March, 2026

DOI: https://doi.org/10.1103/mc1p-blhk

Abstract

Nonlinear transport in narrow band-gap materials has recently attracted significant attention, being commonly recognized as a useful tool to study a variety of complex physical effects related to Berry phase. Here we demonstrate that a mundane, commonly overlooked mechanism stemming from tunneling between charge puddles, can drive substantial nonlinearities in these narrow band gap materials. As a test bed, we use an epitaxial topological HgTe layer, underscoring that even good crystalline quality materials suffer from this issue. Indeed, we show that signatures of electrical transport through a network of charge puddles are not limited to the linear planar magnetoresistance, but also dominate nonlinear transport. Our findings highlight the need for utmost caution when interpreting nonlinear electrical transport phenomena, as harmonic distortion of the electrical signal, caused by charge puddles, is unavoidable in any realistic narrow-gap system, complicating the identification of other proposed effects related to the Berry phase.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (37)

  1. M. V. Berry, Quantal phase factors accompanying adiabatic changes, Proc. R. Soc. A 392, 45 (1984).
  2. D. Xiao, M.-C. Chang, and Q. Niu, Berry phase effects on electronic properties, Rev. Mod. Phys. 82, 1959 (2010).
  3. D. J. Thouless, M. Kohmoto, M. P. Nightingale, and M. den Nijs, Quantized Hall conductance in a two-dimensional periodic potential, Phys. Rev. Lett. 49, 405 (1982).
  4. N. Nagaosa, J. Sinova, S. Onoda, A. H. MacDonald, and N. P. Ong, Anomalous Hall effect, Rev. Mod. Phys. 82, 1539 (2010).
  5. J. Sinova, S. O. Valenzuela, J. Wunderlich, C. H. Back, and T. Jungwi rth, Spin Hall effects, Rev. Mod. Phys. 87, 1213 (2015).
  6. C.-Z. Chang, C.-X. Liu, and A. H. MacDonald, Colloquium: Quantum anomalous Hall effect, Rev. Mod. Phys. 95, 011002 (2023).
  7. M. Z. Hasan and C. L. Kane, Colloquium: Topological insulators, Rev. Mod. Phys. 82, 3045 (2010).
  8. I. Sodemann and L. Fu, Quantum nonlinear Hall effect induced by Berry curvature dipole in time-reversal invariant materials, Phys. Rev. Lett. 115, 216806 (2015).
  9. K. Yasuda, A. Tsukazaki, R. Yoshimi, K. Kondou, K. S. Takahashi, Y. Otani, M. Kawasaki, and Y. Tokura, Current-nonlinear Hall effect and spin-orbit torque magnetization switching in a magnetic topological insulator, Phys. Rev. Lett. 119, 137204 (2017).
  10. T. Ideue, K. Hamamoto, S. Koshikawa, M. Ezawa, S. Shimizu, Y. Kaneko, Y. Tokura, N. Nagaosa, and Y. Iwasa, Bulk rectification effect in a polar semiconductor, Nat. Phys. 13, 578 (2017).
  11. Y. Tokura and N. Nagaosa, Nonreciprocal responses from non-centrosymmetric quantum materials, Nat. Commun. 9, 3740 (2018).
  12. P. He, S. S.-L. Zhang, D. Zhu, Y. Liu, Y. Wang, J. Yu, G. Vignale, and H. Yang, Bilinear magnetoelectric resistance as a probe of three-dimensional spin texture in topological surface states, Nat. Phys. 14, 495 (2018).
  13. Q. Ma, S.-Y. Xu, H. Shen, D. MacNeill, V. Fatemi, T.-R. Chang, A. M. Mier Valdivia, S. Wu, Z. Du, C.-H. Hsu, et al., Observation of the nonlinear Hall effect under time-reversal-symmetric conditions, Nature (London) 565, 337 (2019).
  14. K. Kang, T. Li, E. Sohn, J. Shan, and K. F. Mak, Nonlinear anomalous Hall effect in few-layer WTe2, Nat. Mater. 18, 324 (2019).
  15. P. He, S. S.-L. Zhang, D. Zhu, S. Shi, O. G. Heinonen, G. Vignale, and H. Yang, Nonlinear planar Hall effect, Phys. Rev. Lett. 123, 016801 (2019).
  16. Z. Z. Du, H.-Z. Lu, and X. C. Xie, Nonlinear Hall effects, Nat. Rev. Phys. 3, 744 (2021).
  17. W. Rao, Y.-L. Zhou, Y.-j. Wu, H.-J. Duan, M.-X. Deng, and R.-Q. Wang, Theory for linear and nonlinear planar Hall effect in topological insulator thin films, Phys. Rev. B 103, 155415 (2021).
  18. P. He, G. K. W. Koon, H. Isobe, J. Y. Tan, J. Hu, A. H. Castro Neto, L. Fu, and H. Yang, Graphene moiré superlattices with giant quantum nonlinearity of chiral Bloch electrons, Nat. Nanotechnol. 17, 378 (2022).
  19. H. F. Legg, M. Rößler, F. Münning, D. Fan, O. Breunig, A. Bliesener, G. Lippertz, A. Uday, A. A. Taskin, D. Loss, J. Klinovaja, and Y. Ando, Giant magnetochiral anisotropy from quantum-confined surface states of topological insulator nanowires, Nat. Nanotechnol. 17, 696 (2022).
  20. M. Suárez-Rodríguez, F. de Juan, I. Souza, M. Gobbi, F. Casanova, and L. E. Hueso, Nonlinear transport in non-centrosymmetric systems, Nat. Mater. 24, 1005 (2025).
  21. H. Beidenkopf, P. Roushan, J. Seo, L. Gorman, I. Drozdov, Y. S. Hor, R. J. Cava, and A. Yazdani, Spatial fluctuations of helical Dirac fermions on the surface of topological insulators, Nat. Phys. 7, 939 (2011).
  22. B. Skinner, T. Chen, and B. I. Shklovskii, Why is the bulk resistivity of topological insulators so small? Phys. Rev. Lett. 109, 176801 (2012).
  23. M. König, M. Baenninger, Andrei G. F. Garcia, N. Harjee, B. L. Pruitt, C. Ames, P. Leubner, C. Brüne, H. Buhmann, L. W. Molenkamp, and Gordon D. Goldhaber, Spatially resolved study of backscattering in the quantum spin Hall state, Phys. Rev. X 3, 021003 (2013).
  24. D. Nandi, B. Skinner, G. H. Lee, K.-F. Huang, K. Shain, C.-Z. Chang, Y. Ou, S.-P. Lee, J. Ward, J. S. Moodera, P. Kim, B. I. Halperin, and A. Yacoby, Signatures of long-range-correlated disorder in the magnetotransport of ultrathin topological insulators, Phys. Rev. B 98, 214203 (2018).
  25. A. Thenapparambil, G. E. Dos Santos, C.-A. Li, M. Abdelghany, W. Beugeling, H. Buhmann, C. Gould, S.-B. Zhang, B. Trauzettel, and L. W. Molenkamp, Fluctuations in planar magnetotransport due to tilted Dirac cones in topological materials, Nano Lett. 23, 6914 (2023).
  26. S.-H. Zheng, H.-J. Duan, J.-K. Wang, J.-Y. Li, M.-X. Deng, and R.-Q. Wang, Origin of planar Hall effect on the surface of topological insulators: Tilt of Dirac cone by an in-plane magnetic field, Phys. Rev. B 101, 041408(R) (2020).
  27. P. Leubner, L. Lunczer, C. Brüne, H. Buhmann, and L. W. Molenkamp, Strain engineering of the band gap of HgTe quantum wells using superlattice virtual substrates, Phys. Rev. Lett. 117, 086403 (2016).
  28. J. Ruan, S.-K. Jian, H. Yao, H. Zhang, S.-C. Zhang, and D. Xing, Symmetry-protected ideal Weyl semimetal in HgTe-class materials, Nat. Commun. 7, 11136 (2016).
  29. D. M. Mahler, J.-B. Mayer, P. Leubner, L. Lunczer, D. Di Sante, G. Sangiovanni, R. Thomale, E. M. Hankiewicz, H. Buhmann, C. Gould, and L. W. Molenkamp, Interplay of Dirac Nodes and Volkov-Pankratov Surface States in Compressively Strained HgTe, Phys. Rev. X 9, 031034 (2019).
  30. K. Bendias, S. Shamim, O. Herrmann, A. Budewitz, P. Shekhar, P. Leubner, J. Kleinlein, E. Bocquillon, H. Buhmann, and L. W. Molenkamp, High mobility HgTe microstructures for quantum spin Hall studies, Nano Lett. 18, 4831 (2018).
  31. P. Shekhar, S. Shamim, S. Hartinger, R. Schlereth, V. Hock, H. Buhmann, J. Kleinlein, and L. W. Molenkamp, Low-temperature atomic layer deposition of hafnium oxide for gating applications, ACS Appl. Mater. Interfaces 14, 33960 (2022).
  32. See Supplemental Material at http://link.aps.org/supplemental/10.1103/mc1p-blhk for a detailed overview of the second harmonic measurement setup and additional experimental data, which also includes Refs. [33, 34].
  33. NF Corporation, 3625 dual channel programmable filter: Instruction manual, revision 1.0 ed. (NF Corporation, 2012), https://www.nfcorp.co.jp/english/sup/download/manual/mi/pdf/e_3625.pdf.
  34. Stanford Research Systems, DS360 ultra low distortion function generator: Operating manual and programming reference, revision 2.9 ed. (Stanford Research Systems, 2021), https://www.thinksrs.com/downloads/pdfs/manuals/DS360m.pdf.
  35. S.-B. Zhang, C.-A. Li, F. Pena-Benitez, P. Surowka, R. Moessner, L. W. Molenkamp, and B. Trauzettel, Super-resonant transport of topological surface states subjected to in-plane magnetic fields, Phys. Rev. Lett. 127, 076601 (2021).
  36. J. Arrillaga and N. R. Watson, Subject definition and objectives, in Power System Harmonics, 2nd ed. (Wiley, Chichester, UK, 2004), Chap. 1, pp. 1–18.
  37. A. Thenapparambil, K. M. Fijalkowski, M. AbdelGhany, H. Buhmann, C. Gould, and L. W. Molenkamp, Data for Thenapparambil A. et al. “Charge puddles complicate nonlinear transport in large Berry phase materials”, Zenodo (2026), 10.5281/zenodo.18554519.
