Identification and optimization of accurate spin models for Fermi-Hubbard ladders using matrix product states

Andoni Agirre1,2,*, Thomas Frederiksen1,3, Géza Giedke1,3, and Tobias Graß1,3

  • *Contact author: andoni.agirre@dipc.org
PDF

Phys. Rev. B 113, 245422 – Published 22 June, 2026

DOI: https://doi.org/10.1103/l88j-p4f3

Abstract

Open-shell nanographenes offer a controlled setting to study correlated magnetism emerging from π-electron systems. Here, we study non-bipartite Fermi-Hubbard ladders describing oligo(indenoindene) molecules. These feature a gapped, weakly dispersing manifold of quasizero modes in their single-particle spectra, and we show that their low-energy properties can be effectively mapped onto an interacting set of spin-1/2 degrees of freedom. Using density matrix renormalization group simulations of the full Fermi-Hubbard model, we obtain their excitation spectra, entanglement profiles, and spin-spin correlations. We then construct optimized delocalized fermionic modes that act as emergent spins and demonstrate that their interactions are well described by a frustrated J1–J2 Heisenberg chain. This effective description clarifies how spin degrees of freedom arise and interact in non-bipartite nanographene ladders, providing a compact and accurate representation of their correlated behavior.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (40)

  1. A. Auerbach, Interacting Electrons and Quantum Magnetism (Springer-Verlag, Berlin, 1994).
  2. P. A. McClarty, Topological magnons: A review, Annu. Rev. Condens. Matter Phys. 13, 171 (2022).
  3. O. V. Yazyev, Emergence of magnetism in graphene materials and nanostructures, Rep. Prog. Phys. 73, 056501 (2010).
  4. D. G. de Oteyza and T. Frederiksen, Carbon-based nanostructures as a versatile platform for tunable π-magnetism, J. Phys.: Condens. Matter 34, 443001 (2022).
  5. J. Li, S. Sanz, M. Corso, D. J. Choi, D. Peña, T. Frederiksen, and J. I. Pascual, Single spin localization and manipulation in graphene open-shell nanostructures, Nat. Commun. 10, 200 (2019).
  6. T. Wang, S. Sanz, J. Castro-Esteban, J. Lawrence, A. Berdonces-Layunta, M. S. G. Mohammed, M. Vilas-Varela, M. Corso, D. Peña, T. Frederiksen, and D. G. de Oteyza, Magnetic interactions between radical pairs in chiral graphene nanoribbons, Nano Lett. 22, 164 (2022).
  7. J. Li, S. Sanz, J. Castro-Esteban, M. Vilas-Varela, N. Friedrich, T. Frederiksen, D. Peña, and J. I. Pascual, Uncovering the triplet ground state of triangular graphene nanoflakes engineered with atomic precision on a metal surface, Phys. Rev. Lett. 124, 177201 (2020).
  8. S. Mishra, D. Beyer, K. Eimre, R. Ortiz, J. Fernández-Rossier, R. Berger, O. Gröning, C. A. Pignedoli, R. Fasel, X. Feng, and P. Ruffieux, Collective all-carbon magnetism in triangulene dimers, Angew. Chem. Int. Ed. 59, 12041 (2020).
  9. S. Mishra, G. Catarina, F. Wu, R. Ortiz, D. Jacob, K. Eimre, J. Ma, C. A. Pignedoli, X. Feng, P. Ruffieux, J. Fernández-Rossier, and R. Fasel, Observation of fractional edge excitations in nanographene spin chains, Nature (London) 598, 287 (2021).
  10. J. Hieulle, S. Castro, N. Friedrich, A. Vegliante, F. R. Lara, S. Sanz, D. Rey, M. Corso, T. Frederiksen, J. I. Pascual, and D. Peña, On-surface synthesis and collective spin excitations of a triangulene-based nanostar, Angew. Chem. Int. Ed. 60, 25224 (2021).
  11. Z. Majzik, N. Pavliček, M. Vilas-Varela, D. Pérez, N. Moll, E. Guitián, G. Meyer, D. Peña, and L. Gross, Studying an antiaromatic polycyclic hydrocarbon adsorbed on different surfaces, Nat. Commun. 9, 1198 (2018).
  12. M. Di Giovannantonio, Q. Chen, J. I. Urgel, P. Ruffieux, C. A. Pignedoli, K. Müllen, A. Narita, and R. Fasel, On-surface synthesis of oligo(indenoindene), J. Am. Chem. Soc. 142, 12925 (2020).
  13. S. Mishra, M. Vilas-Varela, L.-A. Lieske, R. Ortiz, S. Fatayer, I. Rončević, F. Albrecht, T. Frederiksen, D. Peña, and L. Gross, Bistability between π-diradical open-shell and closed-shell states in indeno[1,2-a]fluorene, Nat. Chem. 16, 755 (2024).
  14. S. Khandarkhaeva, T. Fedotenko, A. Aslandukova, F. I. Akbar, M. Bykov, D. Laniel, A. Aslandukov, U. Ruschewitz, C. Tobeck, B. Winkler, S. Chariton, V. Prakapenka, K. Glazyrin, C. Giacobbe, E. L. Bright, M. Belov, N. Dubrovinskaia, and L. Dubrovinsky, Extending carbon chemistry at high-pressure by synthesis of CaC2 and Ca3C7 with deprotonated polyacene- and para-poly(indenoindene)-like nanoribbons, Nat. Commun. 15, 2855 (2024).
  15. R. Ortiz, G. Giedke, and T. Frederiksen, Magnetic frustration and fractionalization in oligo(indenoindenes), Phys. Rev. B 107, L100416 (2023).
  16. R. Ortiz, Topological edge states in a double isomeric class-II oligo(indenoindene), Theor. Chem. Acc. 144, 91 (2025).
  17. E. H. Lieb, Two theorems on the Hubbard model, Phys. Rev. Lett. 62, 1201 (1989).
  18. S. R. White, Density matrix formulation for quantum renormalization groups, Phys. Rev. Lett. 69, 2863 (1992).
  19. U. Schollwöck, The density-matrix renormalization group in the age of matrix product states, Ann. Phys. (NY) 326, 96 (2011).
  20. C. Zhao, G. Catarina, J.-J. Zhang, J. C. G. Henriques, L. Yang, J. Ma, X. Feng, O. Gröning, P. Ruffieux, J. Fernández-Rossier, and R. Fasel, Tunable topological phases in nanographene-based spin-1/2 alternating-exchange Heisenberg chains, Nat. Nanotechnol. 19, 1789 (2024).
  21. C. Zhao, L. Yang, J. C. G. Henriques, M. Ferri-Cortés, G. Catarina, C. A. Pignedoli, J. Ma, X. Feng, P. Ruffieux, J. Fernández-Rossier, and R. Fasel, Spin excitations in nanographene-based antiferromagnetic spin-1/2 Heisenberg chains, Nat. Mater. 24, 722 (2025).
  22. J. C. G. Henriques, Y. del Castillo, R. Segundo, J. Phillips, and J. Fernández-Rossier, Two topological phases in exchange alternating spin-1 nanographene chains, SciPost Phys. (2026), https://scipost.org/submissions/2510.23555v2/.
  23. Y. del Castillo, A. Ferrón, and J. Fernández-Rossier, Remote spin control in Haldane spin chains, SciPost Phys. Core 9, 024 (2026).
  24. G. Catarina and J. Fernández-Rossier, Hubbard model for spin-1 Haldane chains, Phys. Rev. B 105, L081116 (2022).
  25. G. Catarina, E. Turco, N. Krane, M. Bommert, A. Ortega-Guerrero, O. Gröning, P. Ruffieux, R. Fasel, and C. A. Pignedoli, Conformational tuning of magnetic interactions in coupled nanographenes, Nano Lett. 24, 12536 (2024).
  26. R. Bursill, G. A. Gehring, D. J. J. Farnell, J. B. Parkinson, T. Xiang, and C. Zeng, Numerical and approximate analytical results for the frustrated spin- 1/2 quantum spin chain, J. Phys.: Condens. Matter 7, 8605 (1995).
  27. S. Furukawa, M. Sato, S. Onoda, and A. Furusaki, Ground-state phase diagram of a spin-12 frustrated ferromagnetic XXZ chain: Haldane dimer phase and gapped/gapless chiral phases, Phys. Rev. B 86, 094417 (2012).
  28. C. E. Agrapidis, S.-L. Drechsler, J. van den Brink, and S. Nishimoto, Coexistence of valence-bond formation and topological order in the frustrated ferromagnetic J1−J2 chain, SciPost Phys. 6, 019 (2019).
  29. M. Schüler, M. Rösner, T. O. Wehling, A. I. Lichtenstein, and M. I. Katsnelson, Optimal Hubbard models for materials with nonlocal Coulomb interactions: Graphene, silicene, and benzene, Phys. Rev. Lett. 111, 036601 (2013).
  30. M. Fishman, S. R. White, and E. M. Stoudenmire, The ITensor software library for tensor network calculations, SciPost Phys. Codebases 4 (2022).
  31. This behavior can be understood from the limiting case J2/|J1|→∞: For P a multiple of 4, the chain splits into two spin chains with even numbers of spins (both with singlet ground states), whereas for even nonmultiples of 4, it splits into two chains with odd numbers of spins, each with a doublet ground state. Due to the weak FM coupling, the two doublets split into a lower triplet and a slightly higher-energy singlet.
  32. E. Clar, The Aromatic Sextet (Wiley, London, 1972).
  33. Although in these full optimization cases the sets M(p) will be the same for different spins corresponding to different pentagons p, we still label its operators with M(p) for short, M(p) representing the mode with support around the pth pentagon tip.
  34. S. G. Johnson, The NLopt nonlinear-optimization package, https://github.com/stevengj/nlopt.
  35. M. J. D. Powell, A direct search optimization method that models the objective and constraint functions by linear interpolation, in Advances in Optimization and Numerical Analysis, edited by S. Gomez and J.-P. Hennart, Mathematics and Its Applications Vol. 275 (Springer, 1994), pp. 51–67.
  36. Only optimizing over the green and purple sites means that the single occupation operator only spans a few tensors. With an appropriate gauge transformation of the MPS, the number of bonds to contract over remains constant with P.
  37. A. Agirre, T. Frederiksen, G. Giedke, and T. Graß, Dataset for “Identification and optimization of accurate spin models for Fermi-Hubbard ladders with matrix product states,” Zenodo, 2026, doi:10.5281/zenodo.19725907.
  38. R. Ortiz, R. A. Boto, N. García-Martínez, J. C. Sancho-García, M. Melle-Franco, and J. Fernández-Rossier, Exchange rules for diradical π-conjugated hydrocarbons, Nano Lett. 19, 5991 (2019).
  39. D. Jacob and J. Fernández-Rossier, Theory of intermolecular exchange in coupled spin-1/2 nanographenes, Phys. Rev. B 106, 205405 (2022).
  40. Note that the placement of the spin-chain markers is not precise due to the overlap of different effective spins.
