Direct probe of magnetic field effects on phonons by ultrasound propagation in the quasi-two-dimensional honeycomb magnet Na2Co2TeO6

Xiaochen Hong1,2,3,*, Maximilian Schiffer2, Beat Valentin Schwarze4, Marc Uhlarz4, Xianghong Jin5, Weiliang Yao5, Lukas Janssen6, Sergei Zherlitsyn4, Bernd Büchner3,7 et al.

Yuan Li5,8, Young Sun1, and Christian Hess2,3,†

  • *Contact author: hongxc@cqu.edu.cn
  • †Contact author: c.hess@uni-wuppertal.de
PDF

Phys. Rev. B 112, 094403 – Published 2 September, 2025

DOI: https://doi.org/10.1103/kw7z-226c

Abstract

We study the phonon behavior of the Co-based honeycomb frustrated magnet Na2Co2TeO6 under a magnetic field applied perpendicular to the honeycomb plane. The temperature and field dependence of the sound velocity and sound attenuation unveil prominent spin-lattice coupling in this material, promoting ultrasound as a sensitive probe for magnetic properties. An out-of-plane ferrimagnetic order is determined below the Néel temperature TN=27 K. A comprehensive analysis of our data further supports a triple-Q ground state of Na2Co2TeO6. Furthermore, the ultrasound data were systematically compared to the thermal transport results from literature, to unveil the importance of the phononic contribution to the observed transport behaviors.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (43)

  1. L. Savary and L. Balents, Quantum spin liquids: A review, Rep. Prog. Phys. 80, 016502 (2017).
  2. M. Ye, R. M. Fernandes, and N. B. Perkins, Phonon dynamics in the Kitaev spin liquid, Phys. Rev. Res. 2, 033180 (2020).
  3. T. Oh and N. Nagaosa, Phonon thermal Hall effect in Mott insulators via skew scattering by the scalar spin chirality, Phys. Rev. X 15, 011036 (2025).
  4. I. A. Leahy, C. A. Pocs, P. E. Siegfried, D. Graf, S.-H. Do, K.-Y. Choi, B. Normand, and M. Lee, Anomalous thermal conductivity and magnetic torque response in the honeycomb magnet α−RuCl3, Phys. Rev. Lett. 118, 187203 (2017).
  5. Y. Kasahara, K. Sugii, T. Ohnishi, M. Shimozawa, M. Yamashita, N. Kurita, H. Tanaka, J. Nasu, Y. Motome, T. Shibauchi, and Y. Matsuda, Unusual thermal Hall effect in a Kitaev spin liquid candidate α−RuCl3, Phys. Rev. Lett. 120, 217205 (2018).
  6. P. Czajka, T. Gao, M. Hirschberger, P. Lampen-Kelley, A. Banerjee, J. Yan, D. G. Mandrus, S. E. Nagler, and N. P. Ong, Oscillations of the thermal conductivity in the spin-liquid state of α−RuCl3, Nat. Phys. 17, 915 (2021).
  7. R. Hentrich, A. U. B. Wolter, X. Zotos, W. Brenig, D. Nowak, A. Isaeva, Th Doert, A. Banerjee, P. Lampen-Kelley, D. G. Mandrus, S. E. Nagler, J. Sears, Y.-J. Kim, B. Büchner, and C. Hess, Unusual phonon heat transport in α−RuCl3: Strong spin-phonon scattering and field-induced spin gap, Phys. Rev. Lett. 120, 117204 (2018).
  8. E. Lefrançois, G. Grissonnanche, J. Baglo, P. Lampen-Kelley, J. Yan, C. Balz, D. Mandrus, S. E. Nagler, S. Kim, Y.-J. Kim, N. Doiron-Leyraud, and L. Taillefer, Evidence of a phonon Hall effect in the Kitaev spin liquid candidate α−RuCl3, Phys. Rev. X 12, 021025 (2022).
  9. J. A. N. Bruin, R. R. Claus, Y. Matsumoto, J. Nuss, S. Laha, B. V. Lotsch, N. Kurita, H. Tanaka, and H. Takagi, Origin of oscillatory structures in the magnetothermal conductivity of the putative Kitaev magnet α−RuCl3, APL Mater. 10, 090703 (2022).
  10. W. Yaoand Y. Li, Ferrimagnetism and anisotropic phase tunability by magnetic fields in Na2Co2TeO6, Phys. Rev. B 101, 085120 (2020).
  11. G. Lin, J. Jeong, C. Kim, Y. Wang, Q. Huang, T. Masuda, S. Asai, S. Itoh, G. Günther, M. Russina, Z. Lu, J. Sheng, L. Wang, J. Wang, G. Wang, Q. Ren, C. Xi, W. Tong, L. Ling, Z. Liu et al., Field-induced quantum spin disordered state in spin-1/2 honeycomb magnet Na2Co2TeO6, Nat. Commun. 12, 5559 (2021).
  12. X. Hong, M. Gillig, R. Hentrich, W. Yao, V. Kocsis, A. R. Witte, T. Schreiner, D. Baumann, N. Pèrez, A. U. B. Wolter, Y. Li, B. Büchner, and C. Hess, Strongly scattered phonon heat transport of the candidate Kitaev material Na2Co2TeO6, Phys. Rev. B 104, 144426 (2021).
  13. A. L. Sanders, R. A. Mole, J. Liu, A. J. Brown, D. Yu, C. D. Ling, and S. Rachel, Dominant Kitaev interactions in the honeycomb materials Na3Co2SbO6 and Na2Co2TeO6, Phys. Rev. B 106, 014413 (2022).
  14. H. Yang, C. Kim, Y. Choi, J. H. Lee, G. Lin, J. Ma, M. Kratochvilova, P. Proschek, E.-G. Moon, K. H. Lee, Y. S. Oh, and J.-G. Park, Significant thermal Hall effect in the cobalt Kitaev system, Phys. Rev. B 106, L081116 (2022).
  15. M. Gillig, X. Hong, C. Wellm, V. Kataev, W. Yao, Y. Li, B. Büchner, and C. Hess, Phononic-magnetic dichotomy of the thermal Hall effect in the Kitaev material Na2Co2TeO6, Phys. Rev. Res. 5, 043110 (2023).
  16. L. Chen, E. Lefrancois, A. Vallipuram, Q. Barthelemy, A. Ataei, W. Yao, Y. Li, and L. Taillefer, Planar thermal Hall effect from phonons in a Kitaev candidate material, Nat. Commun. 15, 3513 (2024).
  17. X.-G. Zhou, H. Li, C. Kim, A. Matsuo, K. Mehlawat, K. Matsui, Z. Yang, A. Miyata, G. Su, K. Kindo, J.-G. Park, Y. Kohama, W. Li, and Y. H. Matsuda, Emergent quantum disordered phase in Na2Co2TeO6 under intermediate magnetic field along c axis, arXiv:2408.01957.
  18. H. Liuand G. Khaliullin, Pseudospin exchange interactions in d7 cobalt compounds: Possible realization of the Kitaev model, Phys. Rev. B 97, 014407 (2018).
  19. R. Sano, Y. Kato, and Y. Motome, Kitaev-Heisenberg Hamiltonian for high-spin d7 Mott insulators, Phys. Rev. B 97, 014408 (2018).
  20. H. Liu, J. Chaloupka, and G. Khaliullin, Kitaev spin liquid in 3d transition metal compounds, Phys. Rev. Lett. 125, 047201 (2020).
  21. S. M. Winter, Magnetic couplings in edge-sharing high-spin d7 compounds, J. Phys. Mater. 5, 045003 (2022).
  22. B. Lüthi, Physical Acoustics in the Solid State (Springer, Berlin, 2005).
  23. S. Zherlitsyn, S. Yasin, J. Wosnitza, A. A. Zvyagin, A. V. Andreev, and V. Tsurkan, Spin-lattice effects in selected antiferromagnetic materials, Low Temp. Phys. 40, 123 (2014).
  24. J. Wosnitza, S. A. Zvyagin, and S. Zherlitsyn, Frustrated magnets in high magnetic fields—selected examples, Rep. Prog. Phys. 79, 074504 (2016).
  25. V. Tsurkan, H.-A. K. von Nidda, J. Deisenhofer, P. Lunkenheimer, and A. Loidl, On the complexity of spinels: Magnetic, electronic, and polar ground states, Phys. Rep. 926, 1 (2021).
  26. A. Hauspurg, S. Zherlitsyn, T. Helm, V. Felea, J. Wosnitza, V. Tsurkan, K.-Y. Choi, S.-H. Do, M. Ye, W. Brenig, and N. B. Perkins, Fractionalized excitations probed by ultrasound, Phys. Rev. B 109, 144415 (2024).
  27. A. Hauspurg, S. Singh, T. Yanagisawa, V. Tsurkan, J. Wosnitza, W. Brenig, N. B. Perkins, and S. Zherlitsyn, Spin-strain interactions under hydrostatic pressure in α−RuCl3, arXiv:2503.04656.
  28. W. G. F. Krüger, W. Chen, X. Jin, Y. Li, and L. Janssen, Triple-q order in Na2Co2TeO6 from proximity to hidden-SU(2) symmetric point, Phys. Rev. Lett. 131, 146702 (2023).
  29. W. Chen, X. Li, Z. Hu, Z. Hu, L. Yue, R. Sutarto, F. He, K. Iida, K. Kamazawa, W. Yu, X. Lin, and Y. Li, Spin-orbit phase behavior of Na2Co2TeO6 at low temperatures, Phys. Rev. B 103, L180404 (2021).
  30. X. Hong, M. Gillig, W. Yao, L. Janssen, V. Kocsis, S. Gass, Y. Li, A. U. B. Wolter, B. Büchner, and C. Hess, Phonon thermal transport shaped by strong spin-phonon scattering in a Kitaev material Na2Co2TeO6, npj Quantum Mater. 9, 18 (2024).
  31. N. Li, R. R. Neumann, S. K. Guang, Q. Huang, J. Liu, K. Xia, X. Y. Yue, Y. Sun, Y. Y. Wang, Q. J. Li, Y. Jiang, J. Fang, Z. Jiang, X. Zhao, A. Mook, J. Henk, I. Mertig, H. D. Zhou, and X. F. Sun, Magnon-polaron driven thermal Hall effect in a Heisenberg-Kitaev antiferromagnet, Phys. Rev. B 108, L140402 (2023).
  32. S. Zhang, S. Lee, A. J. Woods, W. K. Peria, S. M. Thomas, R. Movshovich, E. Brosha, Q. Huang, H. Zhou, V. S. Zapf, and M. Lee, Electronic and magnetic phase diagrams of the Kitaev quantum spin liquid candidate, Phys. Rev. B 108, 064421 (2023).
  33. E. Lefrançois, M. Songvilay, J. Robert, G. Nataf, E. Jordan, L. Chaix, C. V. Colin, P. Lejay, A. Hadj-Azzem, R. Ballou, and V. Simonet, Magnetic properties of the honeycomb oxide Na2Co2TeO6, Phys. Rev. B 94, 214416 (2016).
  34. A. K. Bera, S. M. Yusuf, A. Kumar, and C. Ritter, Zigzag antiferromagnetic ground state with anisotropic correlation lengths in the quasi-two-dimensional honeycomb lattice compound, Phys. Rev. B 95, 094424 (2017).
  35. S. Zhang, S. Lee, E. Brosha, Q. Huang, H. Zhou, V. S. Zapf, and M. Lee, Out-of-plane magnetic phase diagram of the Kitaev quantum magnet Na2Co2TeO6, Phys. Rev. B 110, 144431 (2024).
  36. A. K. Bera, S. M. Yusuf, F. Orlandi, P. Manuel, L. Bhaskaran, and S. A. Zvyagin, Field-induced phase transitions and anisotropic magnetic properties of the Kitaev-Heisenberg compound Na2Co2TeO6, Phys. Rev. B 108, 214419 (2023).
  37. W. Yao, Y. Zhao, Y. Qiu, C. Balz, J. R. Stewart, J. W. Lynn, and Y. Li, Magnetic ground state of the Kitaev Na2Co2TeO6 spin liquid candidate, Phys. Rev. Res. 5, L022045 (2023).
  38. X. Jin, M. Geng, F. Orlandi, D. Khalyavin, P. Manuel, Y. Liu, and Yuan Li, Robust triple-q magnetic order with trainable spin vorticity in Na2Co2TeO6, arXiv:2501.07843.
  39. C. Dhanasekhar, M. Jawale, R. Kumar, D. C. Kakarla, S. Mahapatra, M. M. C. Chou, A. Sundaresan, H. D. Yang, and A. V. Mahajan, Susceptibility anisotropy and absence of ferroelectric order in the Kitaev spin liquid candidate Na2Co2TeO6, arXiv:2502.01580.
  40. N. Franciniand L. Janssen, Ferrimagnetism from triple-q order in Na2Co2TeO6, Phys. Rev. B 110, 235118 (2024).
  41. See Supplemental Material at http://link.aps.org/supplemental/10.1103/kw7z-226c for more data of measurements done with different acoustic wave polarization and frequencies.
  42. E. Lefrancois Lefrançois, J. Baglo, Q. Barthelemy, S. Kim, Y.-J. Kim, and L. Taillefer, Oscillations in the magnetothermal conductivity of α−RuCl3: Evidence of transition anomalies, Phys. Rev. B 107, 064408 (2023).
  43. X. C. Hong, NCTO-Ultrasound-Data-HZDR, Figshare, 2025, https://doi.org/10.6084/m9.figshare.29880203.v1
